LX570_OM_OM60N01U_(U) 4175-3. Using the air conditio ning system and defogger
5
Interior features
Seat heater switches The indicator light (yellow) on the switch co mes on when the seat heater is operating.
Seat ventilator switches (if equipped) The indicator light (green) on the switch comes on when the seat ventilator is operat-
ing.
Level indicator lights The seat heater temperature level or the seat ventilator fan speed level (if equipped) is
displayed.
“AUTO” indicator lightsSeat heaters and ventilators (if equipped) 
Front seats 
Second outboard seats
1
2
3
4

442
LX570_OM_OM60N01U_(U) 5-6. Using the other interior features
WA R N I N G ■
Conditions in which the function may not operate correctly
In the following conditions, it may not operate correctly ●
The portable device is fully charged ●
There is foreign matter between the charge area and portable device ●
The temperature of the portable device gets higher from charging ●
The charging surface of the portable device is facing up ●
The placement of the portable device is out of alignment with the charge area●
Near a TV tower, electric power plant, gas st ation, radio station, large display, airport
or other facility that generates strong radio waves or electrical noise ●
When the electronic key is in contact with , or is covered by the following metallic
objects
• Cards to which aluminum foil is attached
• Cigarette boxes that have aluminum foil inside
• Metallic wallets or bags
•Coins
•Hand warmers made of metal
• Media such as CDs and DVDs ●
When other wireless keys (that emit radio waves) are being used nearby
In addition, excluding the above-mentioned, when the charger does not perform nor-
mally or the operation indicator light is flashi ng continuously, it is considered that the
wireless charger is malfunctioning. Contact your Lexus dealer. ■
To prevent failure or damage to data ●
Do not bring magnetic cards, such as credit cards, or magnetic recording media, etc.,
close to the charger while charging, otherw ise, data may disapp ear under the influ-
ence of magnetism. Also, do not bring pr ecision instruments such as wrist watches,
etc., close to the charger, as such objects may break. ●
Do not leave portable devices in the cab in. The temperature inside the cabin may
become high, when under the sun, and cause damage to the device.■
To prevent battery discharge
When the engine is stopped, do not use the wireless charger for a long time.

LX570_OM_OM60N01U_(U) 4596-1. Maintenance and care
6
Maintenance and care ■
Notes for a smart access system with push-button start ●
If the door handle becomes wet while the el ectronic key is within the effective range,
the door may lock and unlock repeatedly. Place the key in a position 6 ft. (2 m) or more
separate from the vehicle while the vehicle is being washed. (Take care to ensure that
the key is not stolen.) ●
If the electronic key is insi de the vehicle and a door handle becomes wet during a car
wash, a message may be shown on the mult i-information display and a buzzer will
sound outside the vehicle. To turn off the alarm, lock all the doors.
WA R N I N G ■
When washing the vehicle
Do not apply water to the inside of the en gine compartment. Doing so may cause the
electrical components etc. to catch fire. ■
When cleaning the windshield
●
When the upper part of the windshield where the raindrop sensor is located is
touched by hand ●
When a wet rag or similar is held close to the raindrop sensor ●
If something bumps against the windshield ●
If you directly touch the raindrop sensor body or if something bumps into the raindrop
sensor ■
Precautions regarding the exhaust pipe
Exhaust gasses cause the exhaust pipe to become quite hot.
When washing the vehicle, be careful not to touch the pipe until it has cooled suffi-
ciently, as touching a hot exhaust pipe can cause burns. ■
Precautions regarding the Blin d Spot Monitor (if equipped)
If the paint of the rear bumper is chipped or scratched, the system may malfunction.
If this occurs, consult your Lexus dealer.Set the wiper switch to off.
If the wiper switch is in “A U T O ” , t h e w i p e r s m a y
operate unexpectedly in the following situa-
tions, and may result in hands being caught or
other serious injuries and cause damage to the
wiper blades. OFF
AUTO

LX570_OM_OM60N01U_(U) 4656-2. Maintenance
6
Maintenance and care ■
Repair and replacement
It is recommended that genuine Lexus parts be used for repairs to ensure performance
of each system. If non-Lexus parts are used in replacement or if a repair shop other than
a Lexus dealer performs repairs, confirm the warranty coverage. ■
Resetting the message indicating main tenance is required (U.S.A. only)
After the required maintenance is performed according to the maintenance schedule,
please reset the message.
To reset the message, follow the procedures described below:
Press or of the meter control switches, select .
Press or of the meter control switches, select “Scheduled Maintenance” and
then press .
Select the “Yes” and press .
A message is displayed on the multi-information display. ■
Allow inspection and repairs to be performed by a Lexus dealer ●
Lexus technicians are well-trained specialists an d are kept up to date with the latest ser-
vice information. They are well informed about the operation of all systems on your
vehicle. ●
Keep a copy of the repair order. It proves that the maintenance that has been per-
formed is under warranty coverage. If any problem should arise while your vehicle is
under warranty, your Lexus dealer will promptly take care of it.
WA R N I N G ■
If your vehicle is not properly maintained
Improper maintenance could result in seriou s damage to the vehicle and possible seri-
ous injury or death. ■
Handling of the battery ●
Engine exhaust, some of its constituents , and a wide variety of automobile compo-
nents contain or emit chemicals known to th e State of California to cause cancer and
birth defects and other reproductive harm. Work in a well ventilated area. ●
Oils, fuels and fluids contained in vehicles as well as waste produced by component
wear contain or emit chemicals known to the State of California to cause cancer and
birth defects or other reproductive harm. Avoid exposure and wash any affected area
immediately. ●
Battery posts, terminals and related accessories contain lead and lead compounds
which are known to cause brain damage. Wash your hands after handling. (  P. 4 8 2 )1
2
3
4

476
LX570_OM_OM60N01U_(U) 6-3. Do-it-yourself maintenance■
Adding engine oil
If the oil level is below or near the
low level mark, add engine oil of the
same type as already in the engine.
Make sure to check the oil type and prepare the items needed before adding
oil.
Remove the oil filler cap by turning it coun terclockwise.
Add engine oil slowly, checking the dipstick.
Install the oil filler cap by turning it clockwise. ■
Engine oil consumption
A certain amount of engine oil will be consum ed while driving. In th e following situations,
oil consumption may increase, and engine o il may need to be refilled in between oil
maintenance intervals. ●
When the engine is new, for example directly after purchasing the vehicle or after
replacing the engine ●
If low quality oil or oil of an inappropriate viscosity is used ●
When driving at high engine speeds or with a heavy load, when towing, or when driving
while accelerating or de celerating frequently●
When leaving the engi ne idling for a long time, or when driving frequently through
heavy traffic ■
After changing the engine oil
The engine oil maintenance da ta should be reset. Perform the following procedures:
Press or of the meter control switches, select .
Press or of the meter control switch es, select “Oil Maintenance” and then
press .
Select the “Yes” and press .
A message is displayed on the multi-information display.Engine oil selection  P. 5 6 4
Oil quantity (Low  Full) 1.6 qt. (1.5 L, 1.3 Imp.qt.)
Items Clean funnel1
2
3
1
2
3
4

LX570_OM_OM60N01U_(U) 4856-3. Do-it-yourself maintenance
6
Maintenance and care If any washer does not work or the
warning message appears on the multi-
information display, the washer tank
may be empty. Add washer fluid.Washer fluid
WA R N I N G ■
When adding washer fluid
Do not add washer fluid when the engine is hot or running as washer fluid contains
alcohol and may catch fire if spilled on the engine etc.
NOTICE ■
Do not use any fluid other than washer fluid
Do not use soapy water or engine antifreeze instead of washer fluid.
Doing so may cause streaking on the vehicle’s painted surfaces.■
Diluting washer fluid
Dilute washer fluid with water as necessary.
Refer to the freezing temperatures listed on the label of the washer fluid bottle.

LX570_OM_OM60N01U_(U) 4876-3. Do-it-yourself maintenance
6
Maintenance and care Your Lexus is equipped with a tire pressure warning system that uses tire pres-
sure warning valves and transmitters to detect low tire inflation pressure before
serious problems arise. ●
If the tire pressure drops below a predet ermined level, the driver is warned by
a screen display and a warning light. (  P. 5 2 6 )●
The tire pressure detected by the
tire pressure warning system can be
displayed on the multi-information
display. (  P. 9 1 )
◆ Installing tire pressure warning valves and transmitters
When replacing tires or wheels, tire pressure warning valves and transmitters
must also be installed.
When new tire pressure warning valves and transmitters are installed, new ID
codes must be registered in the tire pressure warning computer and the tire
pressure warning system must be initialized. Have tire pressure warning valve
and transmitter ID codes registered by your Lexus dealer. (  P. 4 8 8 )
◆ Initializing the tire pressure warning system ■
The tire pressure warning system must be initialized in the following circum-
stances: ●
When rotating the tires in above situation. ●
When the set tire pressure has been changed before towing. (  P. 5 6 9 )
When the tire pressure warning system is initialized, the current tire inflation
pressure is set as the benchmark pressure.The tire pressure warning system

488
LX570_OM_OM60N01U_(U) 6-3. Do-it-yourself maintenance■
How to initialize the tire pressure warning system
Park the vehicle in safe place and turn the engine switch to OFF. Initialization cannot be performe d while the vehicle is moved.
Adjust the tire inflation pressure to the specified cold tire inflation pressure
level. (  P. 5 6 9 )Make sure to adjust the tire pressure to the specified cold tire inflation pressure
level. The tire pressure warning system w ill operate based on this pressure level.
Turn the engine switch to IGNITION ON mode.
Push and hold the tire pressure
warning reset switch until the tire
pressure warning light blinks
slowly 3 times. “--” will be displayed for inflation
pressure of each tire on the multi-
information display while the tire
pressure warning system determines
the position on the multi-information
display.
When position of each tire is determined, the inflation pressure of each tire will be
displayed on the multi-information display.
Drive the vehicle at approximately 25 mph (40 km/h) or more for approx-
imately 10 minutes. When initialization is complete , the inflation pressure of each tire will be displayed
on the multi-information display.
Initialization will take long er than approximately 10 minutes if the vehicle is
stopped for a long time, su ch as at traffic signals.
◆ Registering ID codes
The tire pressure warning valve and transmitter is equipped with a unique ID
code. When replacing a tire pressure warning valve and transmitter, it is nec-
essary to register the ID code of tire pressure warning valve and transmitter.
Have the ID code registered by your Lexus dealer. 1
2
3
4
5

LX570_OM_OM60N01U_(U) 4916-3. Do-it-yourself maintenance
6
Maintenance and care ●
Performance may be affected in the following situations.
• Near a TV tower, electric power plant, gas station, radio station, large display, air-
port or other facility th at generates strong radio waves or electrical noise
• When carrying a portable radio, cellular phone, cordless ph one or other wireless
communication device
If tire position information is not correctl y displayed due to the radio wave conditions,
the display may be corrected by driving and changing the radio wave conditions. ●
When the vehicle is parked, the time taken for the warning to start or go off could be
extended. ●
When tire inflation pressure declines rapidly for example when a tire has burst, the
warning may not function. ■
The initialization operation ●
Make sure to carry out initialization after adjusting the tire inflation pressure.
Also, make sure the tires are cold before carry ing out initialization or tire inflation pres-
sure adjustment. ●
If you have accidentally turned the engine swit ch off during initialization, it is not neces-
sary to press the reset switch again as init ialization will restart automatically when the
engine switch has been turned to IG NITION ON mode for the next time.●
If you accidentally press the reset switch when initialization is not necessary, adjust the
tire inflation pressure to the specified leve l when the tires are co ld, and conduct initial-
ization again. ●
While the position of each tire is being de termined and the inflation pressures are not
being displayed on the mu lti-information display, if the in flation pressure of a tire drops,
the tire pressure warning light will come on.

492
LX570_OM_OM60N01U_(U) 6-3. Do-it-yourself maintenance■
When the initialization of the tire pressure warning system has failed
Initialization can be completed in a few minutes. However, in the following cases, the set-
tings have not been recorded and the system will not operate properly. If repeated
attempts to record tire inflation pressure settings are unsuccessful, have the vehicle
inspected by your Lexus dealer. ●
When operating the tire pressure warning reset switch, the tire pressure warning light
does not blink 3 times and the setting mess age does not appear on the multi-informa-
tion display. ●
After carrying out the initializat ion procedure, the tire pressure warning light blinks for 1
minute then stays on after driving for about 20 minutes.
If the inflation of each tire is not displaye d after driving for approximately 1 hour, perform
the following procedure. ●
Park the vehicle in a safe place for approxim ately 20 minutes. Then drive straight (with
occasional left and right turns) at approximately 25 mph (40 km/h) or more for
approximately 10 to 20 minutes.
However, in the following situations, the tire inflation pressure will not be recorder and
the system will not operate properly. Perform initialization. ●
When operating the tire pressure warning reset switch, the tire pressure warning light
does not blink 3 times. ●
After performing initialization, the tire pres sure warning light blinks for 1 minute then
stays on after driving for about 20 minutes.
If the inflation pressure of each tire is st ill not displayed, have the vehicle inspected by
your Lexus dealer. ■
Tire pressure warning system certification 
For vehicles sold in the U.S.A., Hawaii, Guam and Puerto Rico
