service indicator LEXUS LX570 2016 Owners Manual

451
LX570_OM_OM60N01U_(U) 5-6. Using the other interior features
5
Interior features
LEXUS Enform Safety Connect 
Microphone
LED light indicators
“SOS” button
 : If equippedSafety Connect is a subscription-based telematics service that uses Global
Positioning System (GPS) data and embe dded cellular techno logy to provide
safety and security features to subscribers. Safety Connect is supported by
Lexus’ designated response center, wh ich operates 24 hours per day, 7 days
per week.
Safety Connect service is available by su bscription on select, telematics hard-
ware-equipped vehicles.
By using the Safety Connect service, yo u are agreeing to be bound by the
Telematics Subscription Service Agreement and its Terms and Conditions, as
in effect and amended from time to time, a current copy of which is available
at Lexus.com. All use of the Safety Connect service is subject to such then-
applicable Terms and Conditions.
System components 1
2
3

LX570_OM_OM60N01U_(U) 4535-6. Using the other interior features
5
Interior features ■
When contacting the response center
You may be unable to contact the resp onse center if the network is busy.■
Safety Connect backup battery depletion
An exclusive backup battery is built in to assist the Automatic Collision Notification,
which is activated when impact above a certain level is applied to the vehicle, or when the
airbags operate. This battery is a primary battery, and cannot be recharged. The red LED
indicator will flash to indicate that the battery should be replaced.
The backup battery will need to be replaced if the Automatic Collision Notification oper-
ates for 60 seconds or more. For replacement, consult your Lexus dealer.
When the engine switch is turned to IGNITION ON mode, the red indicator
light comes on for 2 seconds then turns off. Afterward, the green indicator light
comes on, indicating that the service is active.
The following indicator light patterns indicate specific system usage conditions: ●
Green indicator light on = Active service ●
Green indicator light flashing = Safety Connect call in process ●
Red indicator light (except at vehicle start-up) = System malfunction (contact
your Lexus dealer) ●
No indicator light (off) = Safety Connect service not active ■
Automatic Collis ion Notification
In case of either airbag deployment or severe rear-end collision, the system is
designed to automatically call the response center. The responding agent
receives the vehicle’s location and attempts to speak with the vehicle occu-
pants to assess the level of emergency. If the occupants are unable to commu-
nicate, the agent automatically treats the call as an emergency, contacts the
nearest emergency services provider to describe the situation, and requests
that assistance be se nt to the location.■
Stolen Vehicle Location
If your vehicle is stolen, Safety Connect can work with local authorities to
assist them in locating and recovering the vehicle. After filing a police report,
call the Safety Connect response center at 1-800-25-LEXUS (1-800-255-
3987) and follow the prompts for Safety Connect to initiate this service.
In addition to assisting law enforcement with recovery of a stolen vehicle,
Safety-Connect-equipped vehicle location data may, under certain circum-
stances, be shared with third parties to locate your vehicle. Further informa-
tion is available at Lexus.com.Safety Connect LED light Indicators
Safety Connect services

469
LX570_OM_OM60N01U_(U) 6-2. Maintenance
6
Maintenance and care
Emission inspection and maintenance (I/M) programsThe OBD system determines that a problem exists somewhere in the emission
control system. Your vehicle may not pa ss the I/M test and may need to be
repaired. Contact your Lexus dealer to service the vehicle. ●
When the battery is disconnected or discharged
Readiness codes that are set during ordinary driving are erased.
Also, depending on your driving habits, the readiness codes may not be com-
pletely set. ●
When the fuel tank cap is loose
The malfunction indicator lamp comes on indicating a temporary malfunction
and your vehicle may not pass the I/M test.
The error code in the OBD system will not be cleared unless the vehicle is driven
40 or more times.
Contact your Lexus dealer to prepare the vehicle for re-testing.Some states have vehicle emission inspection programs which include OBD
(On Board Diagnostics) checks. The OBD system monitors the operation of
the emission control system.
If the malfunction indicator lamp comes on
Your vehicle may not pass the I/M test in the following situations:
When the malfunction indicator lamp s till remains on af ter several driv-
ing trips
If your vehicle does not pass the I/M test

572
LX570_OM_OM60N01U_(U) 8-1. Specifications■
Non-recommendation of the use of blended gasoline
●
If you use gasohol in your vehicle, be sure th at it has an octane rating no lower than 87.●
Lexus does not recommend the use of gasoline containing methanol.■
Non-recommendation of the use of gasoline containing MMT
Some gasoline contains on octane enhancing additive called MMT (Methylcy clopenta-
dienyl Manganese Tricarbonyl).
Lexus does not recommend the use of gasolin e that contains MMT. If fuel containing
MMT is used, your emission control system may be adversely affected.
The malfunction indicator lamp on the instru ment cluster may come on. If this happens,
contact your Lexus dealer for service. ■
If your engine knocks ●
Consult your Lexus dealer. ●
You may occasionally notice light knocking fo r a short time while accelerating or driv-
ing uphill. This is normal and there is no need for concern. ●
Use only gasoline containing up to 15% etha-
nol.
DO NOT use any flex-fuel or gasoline that
could contain more than 15% ethanol, includ-
ing from any pump labeled E30, E50, E85
(which are only some examples of fuel con-
taining more than 15% ethanol). DO NOT use gasoline con-
taining more than 15% ethanol.
(30% ethanol)
(50% ethanol)
(85% ethanol)

627Alphabetical index
LX570_OM_OM60N01U_(U) Seat heaters .............................................. 417
Seat position memory............................ 151
Seat ventilators ........................................ 417
Seating capacity..................................... 186
Seats...................................................140, 142
Adjustment ................................... 140, 142
Adjustment precautions ......... 141, 150
Armrest ...................................................443
Child seats/child restraint
system installation.............................. 63
Cleaning .................................................. 461
Driving position memory .................. 151
Folding up the third seats................ 145
Front seats .............................................. 140
Head restraint ....................................... 155
Heaters......................................................417
Power easy access system .............. 151
Properly sitting in the seat ................ 28
Rear seats ................................................142
Seat heaters ............................................417
Seat position memory......................... 151
Seat ventilators ......................................417
Second seats ..........................................142
Third seats ...............................................142
Tumbling the second seats ............ 143
Ventilators ...............................................417 Sensor
Automatic headlight system .........222
Automatic High Beam
system .................................................. 224
Inside rear view mirror..................... 160
Intuitive parking assist...................... 289
LDA (Lane Departure Alert)....... 263
Radar sensor........................................ 244
Rain-sensing windshield
wipers................................................... 233
Service reminder indicators ............... 82
Shift lever
Automatic transmission ....................210
If the shift lever cannot be
shifted from P ................................... 549
Shift lock system ................................... 549
Side airbags ............................................... 38
Side doors .................................................. 115
Side marker lights ................................ 220
Light switch........................................... 220
Replacing light bulbs ........................ 510
Side mirrors .............................................. 162
Adjusting and folding ........................ 162
Blind Spot Monitor ........................... 365
Heaters ................................................... 407
Side turn signal lights
Replacing light bulbs ........................ 510
Turn signal lever ................................... 216
Smart access system with
push-button start................................. 132
Antenna location.................................. 132
Entry functions ............................. 115, 122
Starting the engine ............................205
* : Refer to
the “NAVIGATION SYSTEM OWNER’S MANUAL”.
