LEXUS LX570 2018 Owners Manual

91
LX570_OM_OM60Q78U_(U) 2. Instrument cluster
2
Instrument cluster
Multi-information display The following information will be dis-
played when a menu icon is selected.
( → P. 93)
Some of the information may be dis-
played automatically depending on the
situation.
Drive information Select to display various drive data. ( → P. 94)
Vehicle information display (if equipped) Select to display the vehicle information. ( → P. 95)
Navigation system-linked display Select to display the following na vigation system-linked information.
•Route guidance
• Compass display (north-up display/heading-up display)
Audio system-linked display Select to enable selection of an audio source or track on the display using the
meter control switches.Display contents

92
LX570_OM_OM60Q78U_(U) 2. Instrument cluster
Driving assist system information (if equipped) Select to display the operational status of the following systems:
• Dynamic radar cruise control with full-speed range ( → P. 269)
When the vehicle is in constant speed control mode ( → P. 277), the menu
icon will change to .
• LDA (Lane Departure Alert) ( → P. 261)
Warning message display Select to display warning messages and me asures to be taken if a malfunction is
detected. ( → P. 528)
Settings display Select to change the meter display settings and the operation settings of some
vehicle functions. ( → P. 96)

LX570_OM_OM60Q78U_(U) 932. Instrument cluster
2
Instrument cluster The multi-information display is operated using the meter control switches.
:Switch menu
: Change displayed con-
tent, scroll up/down the
screen and move the
cursor up/down
Press: Enter/Set
Press and hold: Reset
Return to the previous screen
Press: Displays the screen registered to When no screen has been registered, th e drive information screen will be dis-
played.
Press and hold: Registers the currently displayed screen to When the confirmation screen is displayed, select yes to register the screen. If the
selected screen cannot be registered, a registration failure me ssage will be shown.Operating the meter control switches 1
2
3
4

94
LX570_OM_OM60Q78U_(U) 2. Instrument cluster
■
Drive information
4 of the following items can be register ed and displayed as the drive informa-
tion 1 and the drive information 2 (2 items on each screen).
Refer to P. 96 for the registration me thod of the drive information 1 and the
drive information 2. ●
Current fuel consumption (bar type/value type)
Displays the current rate of fuel consumption. ●
Average fuel consumption (after reset
* 2
/after start/after refuel)
* 1
Displays the average fuel consumption since the function was reset, the
engine was started, and the vehicle was refueled, respectively. ●
Average vehicle speed (after reset
* 2
/after start)
Displays the average vehicle speed si nce the function was reset and the
engine was started, respectively. ●
Elapsed time (after reset
* 2
/after start)
Displays the elapsed time since the function was reset and the engine was
started, respectively. ●
Distance (driving range/after start)
Displays the estimated maximum distance that can be driven with the
quantity of fuel remaining.
• This distance is computed based on your average fuel consumption.
As a result, the actual distance that can be driven may differ from that
displayed.
• When only a small amount of fuel is added to the tank, the display may
not be updated.
When refueling, turn the engine switch off. If the vehicle is refueled with-
out turning the engine switch off, the display may not be updated.
* 1
: Use the displayed average fuel consumption as a reference.
* 2
: The function can be reset by pressing for longer than 1 second when the item to
reset is displayed. If there is more than on e item that can be rese t, the item selection
screen will appear.Drive information

LX570_OM_OM60Q78U_(U) 952. Instrument cluster
2
Instrument cluster ■
Eco Indicator (Eco Driving Indicator Zone Display)
→ P. 98■
Speed
Displays the vehicle speed. ■
Outside temperature
Displays the outside temperature within the range of -40 ° F (-40 ° C) to 122 ° F
(50 ° C).■
Sway warning (if equipped)
Detects the sway of the vehicle within a lane, which is often associated with a
decrease in the driver’s at tention level, and displays the decrease in attention
using a bar display.
The shorter the bar length, the more the driver may need to rest. This display is a part of the LDA (Lan e Departure Alert) system. The display is
enabled when the operating conditions of the vehicle sway warning are met.
( → P. 261)■
Blank screen (display off)
Drive information is not displayed. ■
Front tire angle (if equipped)
Displays the direction of the front tires. The tire direction is displaye d in 3 stages for both left and right, in accordance with
the angle of the tire.
If a battery terminal is disconnected an d reconnected, the display may be disabled
temporarily. After driving the vehicle fo r a while, the display will be enabled.■
Tire inflation pressure
Displays inflation pressure of each tire. The inflation pressure of the spare tire will be displayed.■
Oil maintenance (if equipped)
Displays the remaining distance before the next maintenance is required.Vehicle information

96
LX570_OM_OM60Q78U_(U) 2. Instrument cluster
The settings of some features can be changed by using the meter control
switches. ■
Setting procedure
For functions that can be enabled or disabled, the function switches between
on and off each time is pressed. ■
Setting items ●
LDA (Lane Departure Alert)
*Select to set up LDA. ( → P. 580)
• Alert method
• Alert sensitivity
• Sway warning
• Sway sensitivity ●
BSM (Blind Spot Monitor)
Select to set up BSM. ( → P. 580)
•BSM on/off
• RCTA (Rear Cross Traffic Alert) on/off ●
Head-up display
*Select to set up Head-up display. ( → P. 580)
• Display brightness/location
• Display content ●
Scheduled maintenance
Select to reset the message indi cating maintenance is required.●
Oil maintenance
*Select to reset the engine oil maintenance informationSettings display

LX570_OM_OM60Q78U_(U) 972. Instrument cluster
2
Instrument cluster ●
Meter settings
Select to set the following items.
• Language
Select to change the language on the display.
•Units
Select to change the unit for measure.
• Eco Driving Indicator Light
Select to activate/deactivate the Eco Driving Indicator Light. ( →
P. 87)
• switch settings
You can register 1 screen as the to p screen. To register, press and hold
while the desired screen is displayed.
• Drive information 1 and 2
Select to select up to 2 items that will be displayed on a drive informa-
tion screen, up to 2 drive in formation screens can be set.
•Pop-up display
Select to set the pop-up displays, which may appear in some situations,
on/off. ( → P. 98)
• Accent color
Select to change the accent colors on the screen, such as the cursor
color.
• Initialization
Registered or changed meter settin gs will be deleted or returned to
their default setting.
* :If equipped

98
LX570_OM_OM60Q78U_(U) 2. Instrument cluster■
Eco Driving Indicator
■
When disconnecting and reco nnecting battery terminals
The drive information will be reset (only items that can be reset manually). ■
Pop-Up display
The pop-up display is displayed on the multi- information display according to the operat-
ing conditions of the following functions: ●
Route guidance display of the navigation system-linked system●
Incoming call display of the hands-free phone system (if equipped)
The pop-up display function can be disabled. ( → P. 96)■
Tire inflation pressure ●
It may take a few minutes to display the tire inflation pressure after the engine switch is
turned to IGNITION ON mode. It may also take a few minutes to display the tire infla-
tion pressure after inflation pressure has been adjusted.●
“---” may be displayed if the tire information cannot be determined due to unfavorable
radio wave conditions. ●
Tire inflation pressure changes with temperat ure. The displayed values may also be dif-
ferent from the values measured using a tire pressure gauge. ■
When setting up the display
Stop the vehicle in a safe place, apply the pa rking brake, and shift the shift lever to P. ■
Suspension of the settings display
In the following situations, the settings disp lay using the meter control switches will be
suspended. ●
When a warning message appears on the multi-information display●
When the vehicle begins to move ■
Liquid crystal display
Small spots or light spots may appear on the display. This phenomenon is characteristic
of liquid crystal displays, and there is no problem continuing to use the display.Eco Driving Indicator Light ( → P. 87)
Eco Driving Indicator Zone Display
Suggests the Zone of Eco driving with current
Eco driving ratio based on acceleration.
Eco driving ratio based on acceleration
If the acceleration exceeds Zone of Eco driv-
ing, the right side of Eco Driving Indicator
Zone Display will illuminate.
Zone of Eco driving 1
2
3
4

LX570_OM_OM60Q78U_(U) 992. Instrument cluster
2
Instrument cluster WARNING ■
Caution for use while driving
For safety, avoid operating the meter control switch while driving as much as possible,
and do not look continuously at the multi- information display while driving. Stop the
vehicle and operate the meter control switch . Failure to do so may cause a steering
wheel operation error, resultin g in an unexpected accident.■
Cautions while setting up the display
As the engine needs to be running during sett ing up the display, en sure that the vehicle
is parked in a place with adequate ventilation. In a closed area such as a garage,
exhaust gases including harmful carbon mo noxide (CO) may collect and enter the
vehicle. This may lead to death or a serious health hazard.
NOTICE ■
While setting up the display
To prevent battery discharge, ensure that the engine is running while setting up the dis-
play features.

100
LX570_OM_OM60Q78U_(U) 2. Instrument cluster
Head-up display ∗The head-up display is linked to the meters and navigation system and projects a
variety of information in front of the driv er, such as the current vehicle speed and
route guidance to a set destination.
Navigation system-linked display area ( → P. 102)Displays the following items, which are linked to the navigation system:
• Route guidance to destination
•Compass
Message display area ( → P. 102)Displays the following items:
• Warning/Message (if equipped)
• Audio system operation status
• Outside temperature
Warning and information icons ( → P. 102)
Vehicle speed display area Displays the following items:
• Vehicle speed
• Speed limit
∗ : If equippedSummary of functions
1
2
3
4
