LEXUS NX300h 2018 Owners Manual

2815-4. Using the storage features
LEXUS NX300h Owners Manu-
al_USA_OM78212U 5
Interior features 5-4.Using the storage features
Glove box ( → P.282)
Bottle holders ( → P.282)
Console box ( → P.282)
Cup holders ( → P.282)
Sunglass holder ( → P.283)List of storage features
Location of the storage features
A
B
C
D
E
WARNING
■
Items that should not be left in the
vehicle
Do not leave glasses, lighters or spray
cans in the storage spaces, as this may
cause the following when cabin tempera-
ture becomes high:
●
Glasses may be deformed by heat or
cracked if they come into contact with
other stored items. ●
Lighters or spray ca ns may explode. If
they come into contact with other
stored items, the lighter may catch fire
or the spray can may release gas,
causing a fire hazard.
■
When storage compartments are not
in use
When driving or when the glove box and
the console box are not in use, keep it
closed.
In the event of sudden braking or sudden
swerving, an accident may occur due to
an occupant being struck by an open lid
or the items stored inside.

282 5-4. Using the storage features
LEXUS NX300h Owners Manu-
al_USA_OM78212U 1 Open (press the button)
2 Unlock with the mechanical key
3 Lock with the mechanical key ■
Glove box light
The glove box light turns on when the tail
lights are on.
1 Lift the lid while pushing the button
to release the lock. 2 Vehicles with wireless charger: Lift
the wireless charger.
■
Console box tray (vehicles without wire-
less charger) ●
The tray slides forward/backward and
can be removed.
■
Console box light
The console box light turns on when the tail
lights are on.
■
Cup holders 
FrontGlove box
Console box
Cup holders/bottle holders

2835-4. Using the storage features
LEXUS NX300h Owners Manu-
al_USA_OM78212U 5
Interior features 
Rear
Pull down the armrest and push the
release button.
■
Bottle holders 
Front 
Rear
■
Cup holders/bottle holders
●
When storing a bottle, close the cap.
●
The bottle may not be stored depending
on its size or shape. Remove the lid using the strap .
■
Sunglass holder lid
●
The removed sunglass holder lid can be
stored on the tray in the console box. WARNING■
Items unsuitable for the cup holders/
bottle holders
Do not place anything other than cups or
aluminum cans in the cup holders. Other
items may be thrown out of the holders in
the event of an accident or sudden brak-
ing, causing injury. If possible, cover hot
drinks to prevent burns.
NOTICE■
To prevent damage to the rear cup
holder
Stow the cup holder before stowing the
armrest. ■
Bottle holders
Do not place open bottles or glass and
paper cups containing liquid in the bottle
holders. The contents may spill and
glasses may break.
Sunglass holder A

284 5-4. Using the storage features
LEXUS NX300h Owners Manu-
al_USA_OM78212U ●
The back side of the sunglass holder lid
can be used as a vanity mirror.
Raise the hook to use. The cargo hooks are provided for securing
loose items.
Raise the hook to use. The cargo net can be hanged, using the
hook.Luggage compartment fea-
tures
Cargo hooks
WARNING■
When cargo hooks are not in use
To avoid injury, always return the hooks
to their stowed positions when not in use.
Cargo net hooks

2855-4. Using the storage features
LEXUS NX300h Owners Manu-
al_USA_OM78212U 5
Interior features
Lift the deck board and attach the
hook. ( → P.285) The following item
can be stowed. First-aid kit and other items
Accessories
Warning reflector **
: The warning reflec tor itself is not
included as an original equipment.
1 Open the back door.
2 Pull the lever upwards and open the
deck board.WARNING■
When cargo net hooks are not in use
To avoid injury, always return the hooks
to their stowed positions when not in use.
Grocery bag hooks
NOTICE■
To prevent damage to the grocery
bag hooks
Do not hang any object heavier than 11 lb.
(5 kg) on the grocery bag hooks.
Deck under tray Deck board A
B
C

286 5-4. Using the storage features
LEXUS NX300h Owners Manu-
al_USA_OM78212U 3 Lift the deck board and remove the
hook on the backside of the deck
board.
4 Use the hook to secure the deck
board as shown in the illustration.
■
When attaching the side deck board
When attaching the side deck board, attach
it so that the “ FRONT” mark points to
the front side of the vehicle. 1 Unhook the cords.
2 Fold up the luggage cover. WARNING■
If the deck boards are opened or
removed
Return them to their original positions
before driving. In the event of sudden
braking, an accident may occur due to an
occupant being struck by the deck
boards or the items stored in the deck
under tray.
Stowing the luggage cover

2875-4. Using the storage features
LEXUS NX300h Owners Manu-
al_USA_OM78212U 5
Interior features 3 Pull the lever upwards and open the
deck board.
4 Remove the luggage cover.When the seatback for the rear seat is col-
lapsed to the rear, remove the cover after
the cover most upright position.
( → P.129)
5 Stow the luggage cover in the deck
under tray while lifting the deck
board. WARNING■
Luggage cover ●
Do not place anything on the luggage
cover. In the event of sudden braking
or turning, the item may go flying and
strike an occupant. This could lead to
an unexpected accident, resulting in
death or serious injury. ●
Do not allow children to climb on the
luggage cover. Climbing on the lug-
gage cover could result in damage to
the luggage cover, possibly causing
death or serious injury to the child.

288 5-5. Using the other interior features
LEXUS NX300h Owners Manu-
al_USA_OM78212U 5-5.Using the other interior features
1 To set the visor in the forward posi-
tion, flip it down.
2 To set the visor in the side position,
flip down, unhook, and swing it to
the side.
3 To use the side extender, place the
visor in the side position, then slide
it backward. ■
Sun visors
Slide the cover to open. The light turns on when the cover is
opened.
■
Sunglass holder
Remove the lid of sunglasses holder using the strap . ( → P.283)There is a vanity mirror on the back side of
the lid.
■
Automatic lights off to prevent 12-volt
battery discharge
If the vanity lights remain on when the
power switch is turned off, the lights will go
off automatically after 20 minutes.
The GPS clock’s time is automatically
adjusted by utilizing GPS time infor-
mation.
For details, refer to the “NAVIGA-
TION AND MULTIMEDIA SYSTEM
OWNER’S MANUAL”.Other interior features
Sun visors
Vanity mirrors NOTICE■
To prevent damage to the vanity mir-
ror
When the lid of sunglass holder is
removed, do not subject it to strong
impacts or set heavy objects on top of it. ■
To prevent 12-volt battery discharge
Do not leave the lights on longer than
necessary when the hy brid system is off.
Clock A

2895-5. Using the other interior features
LEXUS NX300h Owners Manu-
al_USA_OM78212U 5
Interior features Please use a power supply for elec-
tronic goods that use less than 12
VDC/10 A (power consumption of
120 W).
When using electronic goods, make
sure that the power consumption of all
the connected power outlets is less
than 120 W. ■
Console box
Open the lid.
■
Luggage compartment
Open the lid. ■
The power outlet can be used when
The power switch is in ACCESSORY or
ON mode. ■
Using power outlet
The notch in console box allows power
cables to be passed through even when the
console box is closed.
Please use a power supply for elec-
tronic goods that use less than 120
VAC (power consumption of 100 W).
Open the lid.Power outlet (12 VDC)
NOTICE■
When power outlet is not in use
To avoid damaging the power outlet,
close the power outlet lid when the
power outlet is not in use.
Foreign objects or li quids that enter the
power outlet may cause a short circuit.
■
To prevent 12-volt battery discharge
Do not use the power outlet longer than
necessary when the hy brid system is off.
Power outlet (120 VAC) (if
equipped)

290 5-5. Using the other interior features
LEXUS NX300h Owners Manu-
al_USA_OM78212U ■
The power outlet can be used when
The power switch is in ON mode. A portable device can be charged by
just placing Qi standard wireless
charge compatible portable devices
according to the Wireless Power Con-
sortium, such as smart phones and
mobile batteries, etc., on the charge
area.
This function cannot be used with por-
table devices that are larger than the
charging area. Also, depending on the
portable device, it may not operate as
normal. Please read the operation
manual for portable devices to be
used. ■
The “Qi” symbol
The “Qi” symbol is a trademark of the
Wireless Power Consortium.NOTICE■
When power outlet (120 VAC) is not
in use
To avoid damaging the power outlet,
close the power outlet lid when the
power outlet is not in use.
Foreign objects or liquids that enter the
power outlet may cause a short circuit. ■
To prevent blown fuse
Do not use a 120 VAC appliance that
requires more than 100W.
If a 120 VAC appliance that consumes
more than 100 W is used, the protection
circuit will cut the power supply.
■
To prevent battery discharge
Do not use the power outlet longer than
necessary when the hy brid system is off.
■
Appliances that may not operate
properly
The following 120 VAC appliances may
not operate properly even if their power
consumption is under 100W:
●
Appliances with high initial peak watt-
age
●
Measuring devices that process pre-
cise data
●
Other appliances that require an
extremely stable power supply Wireless charger (if equipped)
