fuel cap LEXUS NX300h 2018 Owners Manual

3TABLE OF CONTENTS
LEXUS NX300h Owners Manu-
al_USA_OM78212U 1
2
3
4
5
6
7
8
94-1. Before driving
Driving the vehicle ........................ 150
Cargo and luggage ...................... 155
Vehicle load limits ......................... 158
Trailer towing (vehicles with towing
package) ........................................ 159
Trailer towing (vehicles without
towing package) ......................... 167
Dinghy towing ................................ 167
4-2. Driving procedures
Power (ignition) switch ............... 168
EV drive mode ................................ 171
Hybrid transmission ..................... 173
Turn signal lever............................. 176
Parking brake ................................. 177
Brake Hold....................................... 180
ASC (Active Sound Control) ... 181
4-3. Operating the lights and wipers
Headlight switch ............................ 183
Automatic High Beam ................ 186
Fog light switch .............................. 189
Windshield wipers and washer 189
Rear window wiper and washer
............................................................ 194
4-4. Refueling
Opening the fuel tank cap......... 196 4-5. Using the driving support systems
Lexus Safety System+ ................. 198
PCS (Pre-Collision System) ... 203
LDA (Lane Departure Alert with
steering control) ......................... 210
Dynamic radar cruise control with
full-speed range........................... 217
Intuitive parking assist ................. 227
Parking Support Brake function (for
static objects)............................... 232
BSM (Blind Spot Monitor) ......... 241
Driving mode select switch ..... 249
Driving assist systems ................ 250
4-6. Driving tips
Hybrid vehicle driving tips ....... 255
Winter driving tips ....................... 257
Utility vehicle precautions........ 259
5-1. Remote Touch
Remote Touch............................... 264
5-2. Using the air conditioning system
and defogger
Automatic air conditioning system
.......................................................... 268
Heated steering wheel/seat heat-
ers/seat ventilators................... 275
5-3. Using the interior lights
Interior lights list ........................... 278
5-4. Using the storage features
List of storage features ............... 281
Luggage compartment features
.......................................................... 2844
Driving
5
Interior features

13Pictorial index
LEXUS NX300h Owners Manu-
al_USA_OM78212U Precautions against winter season ............................................................................ P.257
To prevent freezing (windshield wiper de-icer) .................................................. P.273
Precautions against car wash ....................................................................................... P.315
Fuel filler door .......................................................................................................... P.196
Refueling method .............................................................................................................. P .196
Fuel type/fuel tank capacity ...... .................................................................................... P.401
Tires.......................................................................................................................... ..P.336
Tire size/inflation pressure ...........................................................................................P.406
Winter tires/tire chain .................................................................................................... P.25 7
Checking/rotation/tire pressure warning system.............................................. P.336
Coping with flat tires........................................................................................................ P .377
Hood ......................................................................................................................... P. 325
Opening ........................................................................................................................ ....... P.325
Engine compartment cover .........................................................................................P.328
Engine oil ..................................................................................................................... ......... P.402
Coping with overheat ..................................................................................................... P.394
Warning messages .......................................................................................................... P.374
Headlights .................................................................................................................P.18 3
Parking lights/daytime running lights...............................................................P.183
Fog lights....................................................................................................................P .189
Turn signal lights ...................................................................................................... P.176
Tail lights .................................................................................................................... P.183
License plate lights .................................................................................................P.183
Back-up light
Shifting the shift lever to R ...............................................................................................P.1 73
Side marker lights ...................................................................................................P.183 *
:If equipped Light bulbs of the exterior lights for driving
(Replacing method: P.353, Watts: P.407) E
F
G
H
I
J
K
L
M
N
O

149
LEXUS NX300h Owners Manu-
al_USA_OM78212U 4 4
Driving Driving4-1. Before driving
Driving the vehicle ..................... 150
Cargo and luggage ................... 155
Vehicle load limits ...................... 158
Trailer towing (vehicles with tow-
ing package).............................. 159
Trailer towing (vehicles without
towing package) ...................... 167
Dinghy towing ............................. 167
4-2. Driving procedures
Power (ignition) switch ............ 168
EV drive mode ............................. 171
Hybrid transmission .................. 173
Turn signal lever.......................... 176
Parking brake .............................. 177
Brake Hold.................................... 180
ASC (Active Sound Control) 181
4-3. Operating the lights and wipers
Headlight switch ......................... 183
Automatic High Beam ............. 186
Fog light switch ........................... 189
Windshield wipers and washer
......................................................... 189
Rear window wiper and washer
......................................................... 194
4-4. Refueling
Opening the fuel tank cap...... 196 4-5. Using the driving support sys-
tems
Lexus Safety System+ .............. 198
PCS (Pre-Collision System) 203
LDA (Lane Departure Alert with
steering control) ...................... 210
Dynamic radar cruise control with
full-speed range........................ 217
Intuitive parking assist .............. 227
Parking Support Brake function
(for static objects) .................. 232
BSM (Blind Spot Monitor) ...... 241
Driving mode select switch .. 249
Driving assist systems.............. 250
4-6. Driving tips
Hybrid vehicle driving tips .... 255
Winter driving tips .................... 257
Utility vehicle precautions..... 259

1514-1. Before driving
LEXUS NX300h Owners Manu-
al_USA_OM78212U 4
Driving multi-information display while the sys-
tem is operating.■
Restraining sudden start (Drive-Start
Control)●
When the following unusual operation is
performed, the hybrid system output may
be restrained.
• When the shift lever is shifted from R to D,
D to R, N to R, P to D, or P to R (D
includes S) with the accelerator pedal
depressed, a warning message appears
on the multi-information display. If a
warning message is shown on the multi-
information display, read the message
and follow the instructions.
• When the accelerator pedal is depressed
too while the vehicl e is in reverse.●
While Drive-Start Control is being acti-
vated, your vehicle may have trouble
escaping from the mud or fresh snow. In
such case, deactivate TRAC ( → P.251) to
cancel Drive- Start Control so that the
vehicle may become able to escape from
the mud or fresh snow.■
Breaking in your new Lexus
To extend the life of the vehicle, observing
the following precautions is recommended: ●
For the first 200 miles (300 km):
Avoid sudden stops.●
For the first 1000 miles (1600 km):
• Do not drive at extremely high speeds.
• Avoid sudden acceleration.
• Do not drive continuously in low gears.
• Do not drive at a constant speed for
extended periods. 
Vehicles with towing package●
For the first 500miles (800 km):
Do not tow a trailer.
■
Operating your vehicle in a foreign
country
Comply with the relevant vehicle registra-
tion laws and confirm the availability of the
correct fuel. ( → P.408)
■
Eco-friendly driving
→ P.82 WARNING
Observe the following precautions.
Failure to do so may result in death or
serious injury. ■
When starting the vehicle
Always keep your foot on the brake
pedal while stopped with the “READY”
indicator is illuminated. This prevents the
vehicle from creeping. ■
When driving the vehicle ●
Do not drive if you are unfamiliar with
the location of the brake and accelera-
tor pedals to avoid depressing the
wrong pedal.
• Accidentally depressing the accelera-
tor pedal instead of the brake pedal
will result in sudden acceleration that
may lead to an accident.
• When backing up, you may twist your
body around, leading to difficulty in
operating the pedals. Make sure to
operate the pedals properly.
• Make sure to keep a correct driving
posture even when moving the vehicle
only slightly. This allows you to depress
the brake and accelerator pedals
properly.
• Depress the brake pedal using your
right foot. Depressing the brake pedal
using your left foot may delay
response in an emer gency, resulting in
an accident.
●
The driver should pay extra attention
to pedestrians when the vehicle is
powered only by the electric motor
(traction motor). As there is no engine
noise, the pedestrians may misjudge
the vehicle’s movement.
●
Do not drive the vehicle over or stop
the vehicle near flammable materials.
The exhaust system and exhaust gases
can be extremely hot. These hot parts
may cause a fire if there is any flamma-
ble material nearby.

196 4-4. Refueling
LEXUS NX300h Owners Manu-
al_USA_OM78212U 4-4.Refueling
 Turn the power switch off and
ensure that all the doors and win-
dows are closed.
 Confirm the type of fuel. ■
Fuel types
→ P.408■
Fuel tank opening for unleaded gasoline
To help prevent incorrect fueling, your vehi-
cle has a fuel tank opening that only accom-
modates the special nozzle on unleaded
fuel pumps.
1 With the doors unlocked, press the
center of the rear edge of the fuel
filler door. Push inward and take your hand away to
slightly open the fuel filler door. Then open Opening the fuel tank cap
Before refueling the vehicle
WARNING■
When refueling the vehicle
Observe the following precautions while
refueling the vehicle. Failure to do so may
result in death or serious injury. ●
After exiting the ve hicle and before
opening the fuel door, touch an
unpainted metal surface to discharge
any static electricity. It is important to
discharge static electricity before refu-
eling because sparks resulting from
static electricity can cause fuel vapors
to ignite while refueling.
●
Always hold the grips on the fuel tank
cap and turn it slowly to remove it.
A whooshing sound may be heard
when the fuel tank cap is loosened.
Wait until the sound cannot be heard
before fully removing the cap. In hot
weather, pressurized fuel may spray
out of the filler neck and cause injury.
●
Do not allow anyone that has not dis-
charged static electricity from their
body to come close to an open fuel
tank. ●
Do not inhale vaporized fuel.
Fuel contains substances that are
harmful if inhaled. ●
Do not smoke while refueling the vehi-
cle.
Doing so may cause the fuel to ignite
and cause a fire. ●
Do not return to the vehicle or touch
any person or object that is statically
charged. This may cause static elec-
tricity to build up, re sulting in a possible
ignition hazard. ■
When refueling
Observe the following precautions to
prevent fuel overflowing from the fuel
tank: ●
Securely insert the fuel nozzle into the
fuel filler neck. ●
Stop filling the tank after the fuel noz-
zle automatically clicks off. ●
Do not top off the fuel tank.
NOTICE■
Refueling
Do not spill fuel during refueling.
Doing so may damage the vehicle, such
as causing the emission control system to
operate abnormally, damaging fuel sys-
tem components or the vehicle’s painted
surface.
Opening the fuel tank cap

1974-4. Refueling
LEXUS NX300h Owners Manu-
al_USA_OM78212U 4
Driving the door fully by hand.
2 Turn the fuel tank cap slowly to
open and put it into the holder on
the fuel filler door.
■
When the fuel filler door cannot be
opened
→ P.387
1 After refueling, turn the fuel tank
cap until you hear a click. Once the
cap is released, it will turn slightly in
the opposite direction. 2 Close the fuel filler door, and press
the center of the rear edge of the
fuel filler door. When you lock the doors, the fuel filler
door will lock also.
■
Fuel filler door lock condition
The fuel filler door may not be locked even
when the vehicle’s doors are locked in the
following conditions: ●
When operating the door lock button
inside the vehicle ●
When the automatic door locking system
is operated ●
When the fuel filler door is closed after
the vehicle’s doors are locked
Closing the fuel tank cap WARNING■
When replacing the fuel tank cap
Do not use anything but a genuine Lexus
fuel tank cap designed for your vehicle.
Doing so may cause a fire or other inci-
dent which may result in death or serious
injury.

270 5-2. Using the air conditio ning system and defogger
LEXUS NX300h Owners Manu-
al_USA_OM78212U mode automatically.
This may also reduce fuel consumption.●
Recirculated air mode is selected as a
default mode when the power switch is
turned to ON mode.●
It is possible to switch to outside air mode
at any time by pressing the outside/recir-
culated air mode switch.■
Fogging up of the windows●
The windows will easily fog up when the
humidity in the vehicle is high. Pressing
“A/C” button or selecting “A/C” will
dehumidify the air from the outlets and
defog the windshield effectively.●
If you turn “A/C” off, the windows may
fog up more easily.●
The windows may fog up if the recircu-
lated air mode is used.■
Outside/recirculated air mode●
When driving on dusty roads such as tun-
nels or in heavy traffic, set the outside/
recirculated air mode switch to the recir-
culated air mode. This is effective in pre-
venting outside air from entering the
vehicle interior. During cooling opera-
tion, setting the recirculated air mode will
also cool the vehicle interior effectively.●
Outside/recirculated air mode may auto-
matically switch de pending on the tem-
perature setting or the inside
temperature.■
Registering air condit ioning settings to
electronic keys (vehicles with driving
position memory)●
Unlocking the vehicle using an electronic
key and turning the power switch to ON
mode will recall that key’s registered air
conditioning settings.
●
When the power switch is turned off, the
current air conditioning settings will auto-
matically be registered to the electronic
key that was used to unlock the vehicle.
●
The system may not operate correctly if
more than one electr onic key is in the
vicinity or if the smart access system with
push-button start is used to unlock a pas-
senger door.
●
The doors that can recall the air condi- tioning setting when unlocked using the
smart access system with push-button
start can be changed. *
For details, con-
tact your Lexus dealer. *
: The doors that can recall the driving posi-
tion memory are changed at the same
time. ■
Operation of the air conditioning sys-
tem in Eco mode ●
In the Eco mode, the air conditioning sys-
tem is controlled as follows to prioritize
fuel efficiency
• Engine speed and compressor operation
controlled to restrict heating/cooling
capacity
• Fan speed restricted when automatic
mode is selected ●
To improve air conditioning performance,
perform the following operations
• Adjust the fan speed
• Adjust the temperature setting
• Turn off Eco mode ●
Even when the drive mode is set to Eco
mode, the air conditioning eco mode can
be turned off by pressing the ■
When the outside temperature is low
The dehumidification function may not
operate even when “A/C” is pressed or “A/
C” is selected. ■
Ventilation and air conditioning odors ●
To let fresh air in, set the air conditioning
system to the outside air mode. ●
During use, various odors from inside and
outside the vehicle may enter into and
accumulate in the air conditioning sys-
tem. This may then cause odor to be
emitted from the vents.
●
To reduce potential odors from occur-
ring:
• It is recommended that the air condition-
ing system be set to outside air mode
prior to turning the vehicle off.
• The start timing of the blower may be
delayed for a short pe riod of time imme-
diately after the air conditioning system is
started in automatic mode.

322 6-2. Maintenance
LEXUS NX300h Owners Manu-
al_USA_OM78212U The OBD system determines that a
problem exists somewhere in the emis-
sion control system. Your vehicle may
not pass the I/M test and may need to
be repaired. Contact your Lexus
dealer to service the vehicle.
 When the 12-volt battery is discon-
nected or discharged
Readiness codes that are set during
ordinary driving are erased.
Also, depending on your driving
habits, the readiness codes may not
be completely set.
 When the fuel tank cap is loose
The malfunction indicator lamp
comes on indicating a temporary
malfunction and your vehicle may
not pass the I/M test.Fluid leaks • There should not be any
signs of fluid leakage
after the vehicle has
been parked.
Tires • Is the tire inflation pres-
sure correct?
• The tires should not be
damaged or excessively
worn.
• Have the tires been
rotated according to the
maintenance schedule?
• The wheel nuts should
not be loose.
Windshield
wipers/
rear window
wiper •The wiper blades should
not show any signs of
cracking, splitting, wear,
contamination or defor-
mation.
•The wiper blades should
clear the windshield/
rear window without
streaking or skipping.Items Check points
Emission inspection and
maintenance (I/M) pro-
grams Some states have vehicle emission
inspection programs which include
OBD (On Board Diagnostics)
checks. The OBD system monitors
the operation of the emission con-
trol system.
If the malfunction indicator lamp
comes on
Your vehicle may not pass the I/
M test in the following situations:

344 6-3. Do-it-yourself maintenance
LEXUS NX300h Owners Manu-
al_USA_OM78212U 1 Remove the tire valve cap.
2 Press the tip of the tire pressure
gauge onto the tire valve.
3 Read the pressure using the gauge
gradations.
4 If the tire inflation pressure is not at
the recommended level, adjust the
pressure.
If you add too much air, press the
center of the valve to deflate.
5 After completing the tire inflation
pressure measurem ent and adjust-
ment, apply soapy water to the
valve and check for leakage.
6 Put the tire valve cap back on. ■
Tire inflation pressure check interval
You should check tire inflation pressure
every two weeks, or at least once a month.
Do not forget to check the spare. ■
Effects of incorrect tire inflation pres-
sure
Driving with incorrect ti re inflation pressure
may result in the following: ●
Reduced fuel economy●
Reduced driving comfort and poor han-
dling●
Reduced tire life due to wear●
Reduced safety●
Damage to the drive train
If a tire needs frequent inflating, have it
checked by your Lexus dealer.
■
Instructions for checking tire inflation
pressure
When checking tire inflation pressure,
observe the following:
●
Check only when the tires are cold.
If your vehicle has been parked for at
least 3 hours or has not been driven for
more than 1 mile or 1.5 km, you will get an
accurate cold tire in flation pressure read- ing. ●
Always use a tire pressure gauge.
It is difficult to judge if a tire is properly
inflated based only on its appearance. ●
It is normal for the ti re inflation pressure
to be higher after driving as heat is gen-
erated in the tire. Do not reduce tire infla-
tion pressure after driving. ●
Never exceed the vehicle capacity
weight.
Passengers and luggage weight should
be placed so that the vehicle is balanced.
WARNING■
Proper inflation is critical to save tire
performance
Keep your tires properly inflated.
If the tires are not properly inflated, the
following conditions may occur which
could lead to an accident resulting in
death or serious injury: ●
Excessive wear ●
Uneven wear ●
Poor handling ●
Possibility of blowouts resulting from
overheated tires ●
Air leaking from between tire and
wheel
●
Wheel deformation and/or tire dam-
age
●
Greater possibility of tire damage
while driving (due to road hazards,
expansion joints, sharp edges in the
road, etc.)
NOTICE
■
When inspecting and adjusting tire
inflation pressure
Be sure to put the tire valve caps back on.
If a valve cap is not installed, dirt or mois-
ture may get into the valve and cause an
air leak, resulting in decreased tire infla-
tion pressure.

3717-2. Steps to take in an emergency
LEXUS NX300h Owners Manu-
al_USA_OM78212U 7
When trouble arises ■
Brake Override System/Drive-S tart Control warning light *
*
: This light illuminates on the multi-information display.
■
SRS warning light
This warning light system monitors the air-
bag sensor assembly, fr ont impact sensors,
side impact sensors (front door), side
impact sensors (rear), driver’s seat position
sensor, driver’s seat be lt buckle switch, front
passenger occupant cl assification system
(ECU and sensors), “AIR BAG ON” indi-
cator light, “AIR BAG OFF” indicator light,
front passenger’s seat belt buckle switch,
driver’s seat belt pretensioner, front passen-
ger’s seat belt pretensioner and force lim-
iter, airbags, interconnecting wiring and
power sources. ( → P.32)
■
Front passenger detection sensor, seat
belt reminder and warning buzzer
●
If luggage is placed on the front passen-
ger seat, the front passenger detection
sensor may cause th e warning light to
flash and the warning buzzer to sound even if a passenger is not sitting in the
seat. ●
If a cushion is placed on the seat, the sen-
sor may not detect a passenger, and the
warning light may no t operate properly.■
Electric power steering system warning
light (warning buzzer)
When the 12-volt battery charge becomes
insufficient of the voltage temporarily drops,
the electric power steering system warning
light may come on and the warning buzzer
may sound.
■
If the malfunction indicator lamp comes
on while driving
First check the following:
●
Is the fuel tank empty?
If it is, fill the fuel tank immediately.
●
Is the fuel tank cap loose?
If it is, tighten it securely.Warning light Details/Actions
Brake Override System
Indicates that the accelerato r and brake pedals are being
depressed simultaneously, and the Brake Override System
is operating.
→ Release the accelerator pedal and depress the brake
pedal.
Indicates a malfunction in the Brake Override System (with
warning buzzer)
→ Have the vehicle inspected by your Lexus dealer
immediately.
Drive-Start Control
Indicates that the shift position was changed and Drive-
Start Control was operated wh ile depressing the accelera-
tor pedal. (with warning buzzer)
→ Momentarily release th e accelerator pedal.
Indicates a malfunction in th e Drive-Start Control system
(with warning buzzer)
→ Have the vehicle inspected by your Lexus dealer
immediately.
