LEXUS RX350 2016 Owners Manual
Manufacturer: LEXUS, Model Year: 2016, Model line: RX350, Model: LEXUS RX350 2016Pages: 748, PDF Size: 12.36 MB
Page 171 of 748

1713-4. Adjusting the steering wheel and mirrors
3
Operation of each component
RX350_U_OM48E90U The height of the rear view mirror can be adjusted to suit your driving posture.
Adjust the height of the rear view mir-
ror by moving it up and down.
Responding to the level of brightness of the headlights of vehicles behind, the
reflected light is automatically reduced.
Changing automatic anti-glare func-
tion mode
ON/OFF When the automatic anti-glare function
is in ON mode, the indicator illuminates.
The function will set to ON mode each
time the engine switch is turned to
IGNITION ON mode.
Pressing the button turns the function to
OFF mode. (The indicator also turns
off.)Inside rear view mirror The rear view mirror’s position can be adjusted to enable sufficient confirma-
tion of the rear view.
Adjusting the height of rear view mirror
Auto anti-glare function
Indicator
Page 172 of 748

172 3-4. Adjusting the steering wheel and mirrors
RX350_U_OM48E90U ■
To prevent sensor error
To ensure that the sens ors operate properly, do
not touch or cover them.
WA R N I N G
Do not adjust the position of the mirror while driving.
Doing so may lead to mishandling of the vehicle and cause an accident, resulting in
death or serious injury.
Page 173 of 748

1733-4. Adjusting the steering wheel and mirrors
3
Operation of each component
RX350_U_OM48E90U To select a mirror to adjust, press the
switch.
Left
Right Pressing the same switch again will
put the switch in neutral.
To adjust the mirror, press the switch.
Up
Right
Down
Left
Push the mirror back in the direction of
the vehicle’s rear. Outside rear view mirrors Adjustment procedure 1
1
2
2
1
2
3
4
Folding the mirrors (manual type)
Page 174 of 748

174 3-4. Adjusting the steering wheel and mirrors
RX350_U_OM48E90U ■
Using the switch
Press the switch to fold the mirrors. Press it again to extend them to the
original position.
■
Setting automatic mode (if equipped)
Automatic mode allows the folding or extending of the mirrors to be linked to
locking/unlocking of the doors.
Press the “AUTO” switch to set auto-
matic mode. The indicator will come on.
Pressing the switch once more will
return to manual mode.Folding and extending the mirrors (power type)
Indicator
Page 175 of 748

1753-4. Adjusting the steering wheel and mirrors
3
Operation of each component
RX350_U_OM48E90U When the mirror select switch is in the “L” or “R” position, the outside rear view
mirrors will automatically angle downwards when the vehicle is reversing in
order to give a better view of the ground.
To disable this function, select neither “L” nor “R” of the mirror select switch. ■
Adjusting the mirror angle when the vehicle is reversing
With the shift lever in R, adjust the mirror angle at a desired position.
The adjusted angle will be memorized and the mirror will automatically tilt to
the memorized angle whenever the shift lever is shifted to R from next time. The memorized downward tilt position of the mirror is linked to the normal position
(angle adjusted with the shif t lever in other than R). Therefore, if the normal posi-
tion is changed after adjustment, th e tilt position will also change.
When the normal position is chang ed, readjust the angle in reversing.■
Mirror angle can be adjusted when
The engine switch is in ACCESSORY or IGNITION ON mode. ■
When disconnecting and reconn ecting battery terminals (v ehicles with an automatic
folding/extending mirror function)
The automatic folding/extending mirror function will return to off as default. To turn the
function on, press the switch again to select on. ■
When the mirrors are fogged up
The outside rear view mirrors can be cleare d using the mirror defoggers. Turn on the
rear window defogger to turn on the outside rear view mirror defoggers. ( P. 5 0 0 )■
Automatic adjustment of the mirror angle (if equipped)
A desired mirror face angle can be entered to memory and recalled automatically by the
driving position memory. ( P. 1 6 2 )■
Auto anti-glare function (if equipped)
When the anti-glare inside rear view mirror is set to automatic mode, the outside rear
view mirrors will activate in conjunction with the anti-glare inside rear view mirror to
reduce reflected light. ( P. 1 7 1 )■
Using automatic mode in cold weather (if equipped)
When automatic mode is used in cold weather, the door mirror could freeze up and
automatic stowing and return may not be possible. In this case, remove any ice and snow
from the door mirror, then either operate th e mirror using manual mode or move the mir-
ror by hand. ■
Customization
Some functions can be customized. ( P. 6 9 9 )Linked mirror function when reversing
Page 176 of 748

176 3-4. Adjusting the steering wheel and mirrors
RX350_U_OM48E90U WA R N I N G ■
Important points while driving
Observe the following precautions while driving.
Failing to do so may result in loss of contro l of the vehicle and cause an accident, result-
ing in death or serious injury. ●
Do not adjust the mirrors while driving. ●
Do not drive with the mirrors folded. ●
Both the driver and passenger side mirror s must be extended and properly adjusted
before driving. ■
When a mirror is moving
To avoid personal injury and mirror malfunct ion, be careful not to get your hand caught
by the moving mirror. ■
When the mirror defoggers are operating
Do not touch the rear view mirror surfaces, as they can become very hot and burn you.
Page 177 of 748

177
3
Operation of each component
RX350_U_OM48E90U 3-5. Opening, closing the windows and moon roof
The power windows can be opened and closed using the switches.
Operating the switch moves the windows as follows:
Closing
One-touch closing
*Opening
One-touch opening
*
* : To stop the window partway, operate the
switch in the opposite direction.
Press the switch down to lock the pas-
senger windows. The indicator light will
come on when the passenger windows
are locked. Use this switch to prevent children from
accidentally opening or closing a pas-
senger window.
The passenger windows can still be
opened and closed using the driver’s
switch even if the lock switch is on.Power windows Opening and closing procedures 1
2
3
4
Window lock switch
Indicator
Page 178 of 748

178 3-5. Opening, closing the windows and moon roof
RX350_U_OM48E90U ■
The power windows can be operated when
The engine switch is in IGNITION ON mode. ■
Operating the power windows after turning the engine off
The power windows can be operated for approximately 45 seconds even after the
engine switch is turned to ACCESSORY mode or turned off. They cannot, however, be
operated once either front door is opened. ■
Jam protection function
If an object becomes caught between the window and the window frame, window travel
is stopped and the window is opened slightly. ■
Pinch protection function
While the window is opening, if an object is caught between the door and window, win-
dow travel is stopped. ■
If the power window does not close or open normally
If the jam protection function or pinch prot ection function is malfunctioning and a win-
dow cannot be closed or opened completely, perform the following operations using the
power window switch of the relevant door: ●
When not closing normally
With the vehicle stopped and the engine sw itch in IGNITION ON mode, within 4 sec-
onds of the jam protection function operat ing, pull and hold the power window switch
in the one-touch closing position. When the window is closed completely, release the
switch. ●
When not opening normally
With the vehicle stopped and the engine sw itch in IGNITION ON mode, within 4 sec-
onds of the pinch protection function operating, press and hold the power window
switch in the one-touch opening position. When the window is opened completely,
release the switch.
If the window still cannot be closed or open ed completely even though the above opera-
tions have been carried out, perform the following initialization procedure.
Turn the engine switch to IGNITION ON mode.
Pull and hold the power window switch in the one-touch closing position.
When the window is closed completely, release the power window switch. Pull and
hold the switch in the one-touch closing position again for approximately 4 seconds.
Press and hold the power window switch in the one-touch opening position. Continue
pressing the switch for 1 second after the window has opened completely.
Pull and hold the power window switch in the one-touch closing position. Continue
pulling the switch for 1 second after the window has closed.
If you release the switch while the window is moving, perform the procedure again from
the beginning.
If, after performing the above procedure correctly, the window continues to close but
then re-open slightly or open but then clos e again slightly, have the vehicle inspected by
your Lexus dealer. 1
2
3
4
5
Page 179 of 748

1793-5. Opening, closing the windows and moon roof
3
Operation of each component
RX350_U_OM48E90U ■
Door lock linked window operation ●
The power windows can be opened an d closed using the mechanical key.
* ( P. 6 6 2 )●
The power windows can be opened us ing the wireless remote control.
* (
P. 1 2 4 )
* : These settings must be cust omized at your Lexus dealer.■
Alarm
The alarm may be triggered if the alarm is set and a power window is closed using the
door lock linked power window operation function. ( P. 76 )■
When the battery is disconnected
The window lock switch is disabled. If nece ssary, press the window lock switch after
reconnecting the battery. ■
Power windows open warning buzzer
The buzzer sounds and a message is shown on the multi-information display in the instru-
ment cluster when the engine switch is turned off and the driver’s door is opened with the
power windows open. ■
Customization
Some functions can be customized. ( P. 6 9 9 )
Page 180 of 748

180 3-5. Opening, closing the windows and moon roof
RX350_U_OM48E90U WA R N I N G
Observe the following precautions.
Failing to do so may result in death or serious injury. ■
Opening and closing the windows ●
The driver is responsible for all the power window operations, including the operation
for the passengers. In order to prevent acci dental operation, especially by a child, do
not let a child operate the power windows. It is possible for children and other passen-
gers to have body parts caught in the power window. Also, when riding with a child, it
is recommended to use the window lock switch. ( P. 177)
●
When using the wireless remote control or mechanical key and operating the power
windows, operate the power window after checking to make sure that there is no pos-
sibility of any passenger having any of their body parts caught in the window. Also do
not let a child operate power window by th e wireless remote control or mechanical
key. It is possible for children and other passengers to get caught in the power win-
dow. ●
When exiting the vehicle, turn the engine sw itch off, carry the key and exit the vehicle
along with the child. There may be accidental operation, due to mischief, etc., that
may possibly lead to an accident. ■
Jam protection function ●
Never use any part of your body to intentio nally activate the jam protection function.●
The jam protection function may not work if something gets caught just before the
power window fully closes. ■
Pinch protection function ●
Do not use a hand, arm, or clothing to inte ntionally activate the pinch protection func-
tion. ●
The pinch protection function may not operate if something gets caught just before
the power window is fully opened. Take care so that your hands, arms, or clothing do
not get caught. ●
Check to make sure that all passengers do
not have any part of their body in a position
where it could be caught when a window is
being operated.
