Page 161 of 748

1613-3. Adjusting the seats
3
Operation of each component
RX350_U_OM48E90U WA R N I N G ■
Jam protection function (power seat)
Observe the following precautions.
Failure to do so may result in death or serious injury.●
Never use any part of your body to intentio nally activate the jam protection function.●
The jam protection function may not work if something gets caught just before the
rear seatback is fully folded forward. Be careful not to get fingers or anything else
caught. ●
The jam protection function may not work depending on the shape of the object that
is caught. Be careful not to get fingers or anything else caught.
NOTICE ■
Stowing the seat belts
The seat belt for the rear center seat, seat belt buckles and armrest must be stowed
before you fold down the rear seatbacks. ( P. 5 3 4 )
Page 162 of 748

162 3-3. Adjusting the seats
RX350_U_OM48E90U The seat and steering wheel are automati cally adjusted to allow the driver to
enter and exit the vehicle easily.
When all of the following have been
performed, the seat and steering wheel
are automatically adjusted to a position
that allows driver to enter and exit the
vehicle easily.
• The shift lever has been shifted to P.
• The engine switch has been turned
off.
• The driver’s seat belt has been unfastened.
When any of the following has been performed, the seat and steering wheel
automatically return to their original positions.
• The engine switch has been turn ed to ACCESSORY mode or IGNITION
ON mode.
• The driver’s seat belt has been fastened. ■
Operation of the power easy access system
When exiting the vehicle, the power easy acc ess system may not operate if the seat is
already close to the rearmost position, etc. ■
Customization
Some functions can be customized. ( P. 6 9 9 )Driving position memory
: If equippedThis feature automatically adjusts the dr iver’s seat (on some models), steering
wheel and outside rear view mirrors to make entering and exiting the vehicle
easier or to suit your preferences.
Power easy access system (driver’s side only)
Page 163 of 748

1633-3. Adjusting the seats
3
Operation of each component
RX350_U_OM48E90U Your preferred driving position (the posi tion of the driver’s seat, steering wheel
and outside rear view mirrors) can be recorded and recalled by pressing a but-
ton.
Three different driving positions can be recorded into memory. ■
Recording procedure
Check that the shift lever is in P.
Turn the engine switch to IGNITION ON mode.
Adjust the driver’s seat, steering wheel, and outside rear view mirrors to the
desired positions.
While pressing the “SET” button,
or within 3 seconds after the
“SET” button is pressed, press
button “1”, “2” or “3” until the
buzzer sounds. If the selected button has already
been preset, the previously recorded
position will be overwritten.Driving position memory 1
2
3
4
Page 164 of 748

164 3-3. Adjusting the seats
RX350_U_OM48E90U ■
Recall procedure
Check that the shift lever is in P.
Turn the engine switch to IGNITION ON mode.
Press one of the buttons for the
driving position you want to recall
until the buzzer sounds. ■
To stop the position recall operation part-way through
Perform any of the following: ●
Press the “SET” button. ●
Press button “1”, “2” or “3”. ●
Operate any of the seat adjustment switch es (only cancels seat position recall).●
Operate the tilt and telescopic steering co ntrol switch (only ca ncels steering wheel
position recall). ■
Seat positions that can be memorized ( P. 1 5 2 )
The adjusted positions other than the position adjusted by lumbar support switch can be
recorded. ■
Operating the driving position memory after turning the engine switch off
Recorded seat positions can be activated up to 180 seconds after the driver’s door is
opened and another 60 seconds after it is closed again. ■
In order to correctly use the dr iving position memory function
If a seat position is already in the furthest po ssible position and the seat is operated in the
same direction, the recorded position may be slightly different when it is recalled.1
2
3
Page 165 of 748

1653-3. Adjusting the seats
3
Operation of each component
RX350_U_OM48E90U Each electronic key can be registered to recall your preferred driving position.■
Registering procedure
Record your driving position to button “1”, “2” or “3” before performing the
following:
Carry only the key you want to regist er, and then close the driver’s door.
If 2 or more keys are in the vehicle, the driving position cannot be recorded
properly.
Check that the shift lever is in P.
Turn the engine switch to IGNITION ON mode.
Recall the driving position that you want to record.
While pressing the recalled but-
ton, press and hold the door lock
switch (either lock or unlock) until
the buzzer sounds. If the button could not be registered,
the buzzer sounds continuously for
approximately 3 seconds.
■
Recall procedure
Carry the electronic key that has been registered to the driving position,
and then unlock and open the driver’s door using the smart access system
with push-button start or wireless remote control. The driving position will move to the reco rded position (not including the steering
wheel). However, the seat will move to a po sition slightly behind the recorded posi-
tion in order to make entering the vehicle easier.
If the driving position is in a position th at has already been recorded, the seat and
outside rear view mirrors will not move.
Turn the engine switch to ACCESSORY mode or IGNITION ON mode,
or fasten a seat belt. The seat and steering wheel will move to the recorded position.Memory recall function (driver’s side only) 1
2
3
4
1
2
Page 166 of 748

166 3-3. Adjusting the seats
RX350_U_OM48E90U ■
Cancelation procedure
Carry only the key you want to cancel and then close the driver’s door.
If 2 or more keys are in the vehicle, the driving position cannot be canceled
properly.
Turn the engine switch to IGNITION ON mode.
While pressing the “SET” button, press and hold the door lock switch
(either lock or unlock) unt il the buzzer sounds twice.If it button could not be canceled, the buzzer sounds continuously for approxi-
mately 3 seconds.■
Recalling the driving position using the memory recall function ●
Different driving positions can be registered for each electronic key. Therefore, the
driving position that is recalled may be different depending on the key being carried. ●
If a door other than the driver’s door is unlocked with the smart access system with
push-button start, the driving position cannot be recalled. In this case, press the driving
position button which has been set. ■
Customization
Some functions can be customized. ( P. 6 9 9 )
WA R N I N G ■
Seat adjustment caution
Take care during seat adjustment so that th e seat does not strike the rear passenger or
squeeze your body against the steering wheel. 1
2
Page 167 of 748

1673-3. Adjusting the seats
3
Operation of each component
RX350_U_OM48E90U ◆ Vertical adjustment
Up Pull the head restraints up.
Down Push the head restraint down while
pressing the lock release button.
◆ Horizontal adjustment (if equipped)
The position of the head restraint
can be adjusted forward in 4 stages. If the head restraint is pulled forward
from the foremost position, it will
return to the rearmost position.
Up Pull the head restraints up.
Down Push the head restraint down while
pressing the lock release button.Head restraints Head restraints are provided for all seats.
Front seats
Lock release button1
2
Rear seats
Lock release button1
2
Page 168 of 748

168 3-3. Adjusting the seats
RX350_U_OM48E90U ■
Removing the head restraints
■
Installing the head restraints
■
Adjusting the height of the head restraints
■
Adjusting the center rear seat head restraint
Always raise the head restraint one level from the stowed position when using.Pull the head restraint up while pressing the lock
release button.
If the head restraint to uches the ceiling, making
the removal difficult, change the seat height or
angle. ( P. 1 5 2 , 1 5 3 )
Align the head restrain t with the installation
holes and push it down to the lock position.
Press and hold the lock release button when
lowering the head restraint.
Make sure that the head restraints are adjusted
so that the center of the head restraint is closest
to the top of your ears.
WA R N I N G ■
Head restraint precautions
Observe the following precautions regarding the head restraints.
Failure to do so may result in death or serious injury.●
Use the head restraints design ed for each respective seat.●
Adjust the head restraints to the correct position at all times. ●
After adjusting the head restraints, push down on them and make sure they are
locked in position. ●
Do not drive with the head restraints removed. Lock release button
Lock release button
Page 169 of 748

169
3
Operation of each component
RX350_U_OM48E90U 3-4. Adjusting the steering wheel and mirrors
Operating the switch moves the steering wheel in the following directions:
Up
Down
Toward the driver
Away from the driver
When the engine switch is turned off,
the steering wheel returns to its stowed
position by moving up and away to
enable easier driver entry and exit. Turning the engine switch to ACCES-
SORY or IGNITION ON mode will
return the steering wheel to the original
position.
To sound the horn, press on or close to
the mark.Steering wheel Adjustment procedure 1
2
3
4
Auto tilt away
Horn
Page 170 of 748

170 3-4. Adjusting the steering wheel and mirrors
RX350_U_OM48E90U ■
The steering wheel can be adjusted when
The engine switch is in ACCESSORY or IGNITION ON mode
* .
* : If the driver’s seat belt is fastened, the steering wheel can be adjusted regardless of
engine switch mode. ■
Automatic adjustment of the steering position (if equipped)
A desired steering position can be entered to memory and recalled automatically by the
driving position memory system. ( P. 1 6 2 )■
Power easy access system
The steering wheel and driver’s seat (on so me models) move in accordance with engine
switch mode and the driver’s seat belt condition. ( P. 1 6 2 )■
Customization
Some functions can be customized. ( P. 6 9 9 )
WA R N I N G
Do not adjust the steering wheel while driving.
Doing so may cause the driver to mishandle the vehicle and cause an accident, result-
ing in death or serious injury.
