LEXUS SC400 1991 Service Repair Manual

OKNG
10Check sub±throttle position sensor (See page EG±609 or EG±389 ).
Adjust or replace sub±throttle position sensor (See page
EG±333 or EG±205 ).
Check and replace ECM.
±
BRAKE SYSTEM TRACTION CONTROL SYSTEM (TRAC)BR±215
WhereEverybodyKnowsYourName

IN±29).
WIRING DIAGRAM
DTC49Engine Communication Circuit
CIRCUIT DESCRIPTION
This circuit is used to send ignition timing retard request signals from the TRAC ECU to\
the ECM in order to retard
the engine ignition timing.
DTC No.DTC Detecting ConditionTrouble Area
49TR2 output voltage differs from TR2 monitorvoltage in
TRAC ECU.
Open or short in TR2 circuit

ECM

TRAC ECU
DIAGNOSTIC CHARTDIAGNOSTIC CHART
BR±216±
BRAKE SYSTEM TRACTION CONTROL SYSTEM (TRAC)
WhereEverybodyKnowsYourName

NGOK
OKNG
INSPECTION PROCEDURE
1Check voltage between terminal TR2 of TRAC ECU and body ground.
C
OK
Hint
P1. Disconnect TRAC ECU connector.
2. Turn ignition switch on.
Measure voltage between terminal TR2 of TRAC ECU
and body ground.
Voltage: 8 ± 14 V
Check and replace TRAC ECU.
2Check for open and short in harness and connector between TRAC ECU and E\
CM (See page
IN±29).
Repair or replace harness or connector.
Check and replace ECM.
±
BRAKE SYSTEM TRACTION CONTROL SYSTEM (TRAC)BR±217
WhereEverybodyKnowsYourName

TR±11
WIRING DIAGRAM
DTC51Engine Malfunction Detection Circuit
CIRCUIT DESCRIPTION
If trouble (trouble which causes the malfunction indicator light to light\
up) occurs in the engine control system,
this circuit senses the trouble and prohibits TRAC control.
DTC No.DTC Detecting ConditionTrouble Area
51
Either of the following (1) and (2) continues formore
than 1 sec.:
(1) Engine speed: 500 RPM or more
(2) Voltage of TRAC ECU terminal TR5: 1 V or less
Short in TR5 circuit

ECM

TRAC ECU
DIAGNOSTIC CHARTDIAGNOSTIC CHART
BR±218±
BRAKE SYSTEM TRACTION CONTROL SYSTEM (TRAC)
WhereEverybodyKnowsYourName

±MEMO±
±
BRAKE SYSTEM TRACTION CONTROL SYSTEM (TRAC)BR±219
WhereEverybodyKnowsYourName

WIRING DIAGRAM
DTC61ABS & TRAC ECU Communication Circuit
Malfunction
CIRCUIT DESCRIPTION
DTC No.DTC Detecting ConditionTrouble Area
61Malfunction in ABS & TRAC ECU communication cir-
cuit.
Open or short in ABSO, BRC, BRP circuit

ABS & TRAC ECU

TRAC ECU
DIAGNOSTIC CHARTDIAGNOSTIC CHART
BR±220±
BRAKE SYSTEM TRACTION CONTROL SYSTEM (TRAC)
WhereEverybodyKnowsYourName

OKNG
NGOK
OKNG
INSPECTION PROCEDURE
1Check voltage between terminals ABSO, BRC, BRP of TRAC ECU and body ground.
C
OK
Hint
PRemove TRAC ECU with connectors still connected.
Measure voltage between terminals ABSO, BRC, BRP
of TRAC ECU and body ground when ignition switch is
turned ON.
Voltage: ABSO, BRC: 6 ± 14 VBRP: About 7 V (Pulse)\
(Reference)
Check and replace TRAC ECU.
2Check voltage between terminals ABSO, BRC, BRP or TRAC ECU and body ground wi\
th TRAC
ECU connector is disconnected.
C
OK
Hint
PDisconnect TRAC ECU connector.
Measure voltage between terminals ABSO, BRC, BRP
or TRAC ECU connector and body ground when ignition
switch is turned ON.
Voltage: See step 1.
Check and replace TRAC ECU.
3Check for open and short in harness and connector between ABS & TRAC ECU and TRAC ECU
(See page IN±33).
Repair or replace harness or connector.
Check and replace ABS & TRAC ECU.
±
BRAKE SYSTEM TRACTION CONTROL SYSTEM (TRAC)BR±221
WhereEverybodyKnowsYourName

TRAC OFF Indicator, TRAC Cut Switch Circuit
CIRCUIT DESCRIPTION
This is the TRAC control main switch. When the TRAC cut switch is pushed on,\
TRAC control goes off and
the TRAC OFF indicator lights up. This indicator is also used for warnings \
when the trouble occurs.
DIAGNOSTIC CHARTDIAGNOSTIC CHART
BR±222±
BRAKE SYSTEM TRACTION CONTROL SYSTEM (TRAC)
WhereEverybodyKnowsYourName

WIRING DIAGRAM
±
BRAKE SYSTEM TRACTION CONTROL SYSTEM (TRAC)BR±223
WhereEverybodyKnowsYourName

NOYES
OKNG
OKNG
OKNG
OKNG
INSPECTION PROCEDURES
1Is diagnostic trouble code output?
Perform diagnostic trouble code check on page BR±184.
Repair circuit indicated by the code output.
2Check TRAC cut switch
C
OK
P1. Remove TRAC cut switch.
2. Disconnect TRAC cut switch connector.
Measure re sistance between terminals 1 and 2 of TRAC
cut switch when TRAC cut switch is on and off.
Replace TRAC cut switch.
3Check for open and short in harness and connector between terminal CSW of TRA\
C ECU and
TRAC cut switch and body ground (See page IN±33
).
Repair or replace harness or connector.
4Check TRAC OF indicator light.
See combination meter troubleshooting on page BE±191.
Repair or replace combination meter.
5Check for open and short in harness and connector between terminal WT of TRAC ECU \
and bat-
tery or TRAC solenoid relay (See page IN±33
).
Repair or replace harness or connector.
Check and replace TRAC ECU.
BR±224±
