Page 51 of 336
Route preferences
After entering a destination, the
Route options will appear on the
screen showing what is currently
selected. You may choose to
activate/deactivate selections which
the system will factor in when
calculating your route. Those
options are:
²Minimize Time/Distance
²Use Major Roads
²Use Toll Roads
²Use Ferries
Navigation set up
The Navigation Set up screen will
allow you to make adjustments to
the navigation displays.
Entertainment Systems
51
Page 52 of 336
Average speed settings
Allows you to set approximate
speeds you drive. These speeds
enable the navigation system to aid
in calculating timing for routes.
Quick POI (Point of Interest)
Allows you to change the Quick POI
menu settings. Select the desired
Quick POI (Gas, ATM, etc.) and
then press 'List Categories' for
further categories, or 'Map Area
POIs' to show the desired POIs on
your current map.
Restore system defaults
Resets all system user-selectable
options to the default (automatic)
values (i.e. guidance, voice, search
area and route preferences).
Entertainment Systems
52
Page 53 of 336
Calibration
This feature is helpful if the car has
been towed, or if you notice it is not
registering at the correct vehicle
location on the map.
Press ªPositionº to reposition the
vehicle location. Press the screen to
scroll the map to the desired
location and press OK to confirm.
Press ªDistanceº to calibrate by
distance and improve the navigation
accuracy. It is recommended to
activate this function after every tire replacement. When the button is
highlighted, calibration is in process and will turn off automatically when
complete.
DVD map version
Displays the version of the inserted
navigation DVD. Refer toOrdering
additional map DVDsfor further
information.
Display Options
The Display Options screen will
allow you make adjustments to the
navigation display screen. You can
choose from:
²Map Mode (Dual or Full)
²Guidance Mode (Arrows or Turn
list)
²Guidance Display (On or Off)
Entertainment Systems
53
Page 54 of 336
²Time to destination (Show or
Hide)
Stored locations
The Stored locations screen will
allow you to choose from
destinations that have been saved
into the navigation system.
In this screen, you can select from
Memory Points, Special Memory
Points, Home, Avoid Area,
Destination and Way Point, or
Previous Destination. Please refer to
theDestination menusection for a
complete description of the
functions.
Entertainment Systems
54
Page 55 of 336
On route scroll
The system automatically scrolls
through the entire planned
navigation route either forwards or
backwards. To activate, press the
arrow buttons at the bottom left of
the map screen.
Voice guidance/volume
Allows you to turn the voice
guidance option on/off and to
determine the volume level of the
guidance voice prompts.
Destination menu
Press DEST on the main bezel to access the navigation mode.
Entertainment Systems
55
Page 56 of 336
Initial map display
After pressing AGREE to the initial
WARNING screen, you will move
into the initial map screen which
shows the current vehicle location.
Pressing the globe icon will take you
to the user settings Ð audible
feedback, navigation units, language
and clock.
Note:There may be a slight time
delay between the soft key and the
hard key functions.
Route options
Once in navigation mode and a
route is currently active, the ROUTE
OPTIONS screen will appear and
allow you to choose from the
following selections:
²DetourÐ Press to select a detour around the current route.
²Route PreferencesÐ When creating a destination, select from:
Minimize Time/Distance, Use Major Roads, Use Toll Roads, Use
Ferries.
²Display Whole Route:Will enter MAP mode and display your entire
chosen route.
²Destination Entry: Allows you to enter a new destination or select
from entries in: Address book, Points of Interest, Previous
Destinations, and Intersections.
While driving under route guidance, only follow an instruction
when it is safe to do so as the system cannot be aware of
changing conditions. Use voice guidance as much as possible, and only
view the display when driving conditions permit.
Entertainment Systems
56
Page 57 of 336
Ensure that you follow highway code restrictions and do not
take any risks. For example, if you are unable to make a U-turn,
continue on your journey. The navigation system will recalculate your
route to get you back to an appropriate road to your destination.
Destination entry
Selecting a destination
Press DEST to set a destination.
From this menu, you may select
from the following options:
²AddressÐ Use to select a
destination based on a known
street address or intersection.
²Point of InterestÐ Use to
select a destination that is a point
of interest location (i.e., airport,
restaurant, hospital).
²Select from mapÐUse to select a place on the map.
²Previous DestinationÐ Use to select a destination from among the
last 20 entered destinations
Press
'Next Page' to access
more selections:
²Memory pointÐ Use to select
from a memory point.
²Freeway exit/entranceÐ Use
to select a certain freeway exit or
entrance.
²Special Memory PointsÐ Use
to select a destination from
previously stored entries.
Entertainment Systems
57
Page 58 of 336
Search area
The mapped areas covered by your
map DVD are reflected in the
Search Area map that is displayed
on the Destination Entry screen.
Your navigation system uses a
regional search area. This area is
the area from which navigational
directions will be used. To check
your area or reset, press CHANGE under the search area listing. The
map will open and allow you to select another regional area. Ensure that
your search area is correct prior to setting your destination.
Points of interest (POI)
Select ªPoint of Interestº from the
Destination Entry Menu. In this next
menu, you will have the following
options:
²By NameÐ Enter POI name on
the keyboard. Touch ªListº to
display the list of matching points
of interest. If there are too many
matches being listed, try entering
the town name first.
²By CategoryÐ Press ªCategoryº. Scroll down the list to select the
category, then sub-category desired. Once you have selected a
category, your entry of the POI will be restricted to that category.
Previous destination
Press ªPrevious Destinationº on the
Destination Entry Menu.
²Select (touch) the desired item
from the list of destinations
previously reached. The item
details will be listed.
²Confirm destination details.
Entertainment Systems
58
Page 59 of 336
Deleting previous destination
²Press ªDeleteº. The list of
previous destinations is displayed
showing ªDelete Previous
Destinationº at the top of the
screen.
²Select (touch) the entry to be
deleted. The item details will be
listed.
²Press YES to confirm the
deletion.
²Press DELETE ALL to delete all previous destinations.
Memory point
Your navigation system allows you to
save special destinations you may
wish to again visit. Select ªMemory
Pointº from the Destination Entry
Menu.
²Select the desired item from the
list of stored memory points.
²Confirm destination details.
Note:The list can be sorted by date, name or icon by pressing the
appropriate button.
STORE MEMORY POINT
Entertainment Systems
59
Page 60 of 336
Adding a memory point
²Once in the Store Memory Point Menu, press ADD.
²Select (touch) the desired menu item.
²Enter/select any required details. The new point will be added to the
stored list of memory points.
To give the new memory point a name:
²Select it from the list.
²Press NAME.
²Enter the desired name.
Accessing memory point lists
²Press LIST
²Select the desired entry to view
its location details.
Sorting memory point lists
²Access the desired list.
²Press the button to sort the list
as desired (i.e. date, name, or
icon).
When sorted by distance, the points
are ordered by distance from the
current vehicle location. When
sorting by icon, the icons are listed
in the order they appear on the icon
selection screen.
Entertainment Systems
60
