diagram LINCOLN AVIATOR 2004 Owners Manual

To replace the battery:
1. Twist a thin coin between the two
halves of the transmitter near the
key ring. DO NOT TAKE THE
FRONT PART OF THE
TRANSMITTER APART.
2. Do not wipe off any grease on the
battery terminals on the back
surface of the circuit board.
3. Place the positive (+) side of new
battery in the same orientation.
Refer to the diagram inside the transmitter unit. Press the battery down
to ensure that it is fully seated in the battery housing cavity.
4. Snap the two halves back together.
Replacement of the battery willnotcause the remote transmitter to
become deprogrammed from your vehicle. The remote transmitter should
operate normally after battery replacement.
Replacing lost transmitters
If a remote transmitter has been lost
and you would like to remove it
from the vehicle's memory, or you
would like to purchase additional
remote transmitters and have them
programmed to your vehicle:
²Takeallyour vehicle's
transmitters to your dealer for
programming, or
²Perform the programming
procedure yourself.
Locks and Security
141

²Front Wheel Drive (FWD)
vehicles (front tires at top of
diagram)
²Rear Wheel Drive (RWD)
vehicles/Four Wheel Drive (4WD)
vehicles (front tires at top of
diagram)
Maintenance and Specifications
308
