LINCOLN LS 2000 Owner's Guide

FUEL DOOR RELEASE
Press the remote fuel door release
control on the instrument panel to
open the fuel door.
The fuel door has a manual override
release located in the trunk. Pull the
tab to open the fuel door.
CLIMATE CONTROL SYSTEM
Dual Automatic Temperature Control (DATC) system
The Dual Automatic Temperature Control (DATC) system will maintain a
selected temperature and automatically control air flow.
You can override the automatic operation with any of the override
controls or the fan speed control.
AUTO OFFA/C
R EXT
F C
FF
Controls and features
31

The dual temperature zone feature allows the driver and front passenger
to set their own independent temperature set points for individual
comfort. The system uses common controls for air distribution and fan
speed for both driver and passenger.
Turning the DATC system on
Press AUTO, any of the override controls, the fan speed control, or
either of the temperature selection controls. The DATC system will only
operate when the ignition is in the RUN position.
Turning the DATC system off
Press OFF. The outside temperature
(EXT) function (if selected) will
continue to operate until the
ignition is turned off.
DATC automatic operation
Press AUTO and select the desired
temperature. The selected
temperature will appear in the
display window, and an indicator
above the AUTO control will light.
The DATC system will either heat or
cool the vehicle to achieve the
selected temperature. The system
AUTO OFFA/C
R EXT
F C
FF
AUTO OFFEXT
F C
AUTO OFFEXT
F C
F
Controls and features
32

will automatically determine the fan speed, airflow location and whether
outside or recirculated air is required.
When in AUTO and weather conditions require heat, the DATC directs
the majority of the airflow to the floor area. The system will allow some
airflow out the defroster and demister outlets and outer instrument
panel registers in order to reduce window fogging. Additionally, if the
engine is not warm enough to provide heat, the fan will operate at a low
speed and the airflow will be directed to the windshield or to the floor.
In 3
1¤2minutes or less, the fan speed will start to increase and the airflow
location will change to the floor area.
When in AUTO mode, the DATC system automatically controls the air
conditioning operation, the fan speed, the airflow direction and
determines whether outside or recirculated air is required. Manual
control of the A/C, air recirculation and fan speed are available in auto
mode.
If unusual conditions exist (i.e.-window fogging, etc.), the manual
override controls allow you to select airflow locations as necessary. To
return to full automatic control, press the AUTO control.
DATC system AUTO temperature balance
Press and hold the AUTO control for about two seconds to equalize the
passenger set temperature with the driver side temperature. This feature
is useful when the driver is alone in the vehicle.
AUTO OFFA/C
R EXT
F C
FF
Controls and features
33

Driver side temperature selection
The display window indicates the selected temperature and manual
control of fan speed (
) if automatic fan speed is not desired.
To control the temperature, select any temperature between 19ÉC (65ÉF)
and 29ÉC (85ÉF) by pressing the temperature control on the driver side
of the system.
For continuous maximum cooling, press the temperature control until
16ÉC (60ÉF) is shown in the display window. The DATC will continue
maximum cooling (disregarding the displayed temperature) until a
warmer temperature is selected by pressing the temperature control. If
maximum cooling is selected, the passenger set point is not displayed
and the passenger temperature adjustments will be disabled.
For continuous maximum heating, press the temperature control until
32ÉC (90ÉF) is shown in the display window. The DATC will continue
maximum heating (disregarding the displayed temperature) until a
cooler temperature is selected by pressing the temperature control. If
maximum heating is selected, the passenger set point is not displayed
and the passenger temperature adjustments will be disabled.
A change of the driver-selected temperature to a temperature other than
16ÉC (60ÉF) or 32ÉC (90ÉF) will display the passenger set point. The
passenger side set point will increase or decrease along with the driver
side temperature set point until a change is made using the passenger
temperature control.
AUTO OFFA/C
R EXT
F C
FF
Controls and features
34

Passenger side temperature selection
To control the temperature, select
any temperature between 19ÉC
(65ÉF) and 29ÉC (85ÉF) by pressing
the temperature control on the
passenger side of the system.
If the driver side temperature
selection is set for maximum cooling
(16ÉC (60ÉF)) or maximum heating
(32ÉC (90ÉF)), the passenger side
temperature adjustments will be
disabled and the passenger set point will not be displayed.
Temperature conversion
Press the Fahrenheit/Celsius (ÉF ÉC)
control to switch between
Fahrenheit and Celsius temperature
on the DATC display only. The
temperature in Celsius will be
displayed in half-degree increments.
The English/Metric control on the
trip computer and message center
(if equipped) will not change the
DATC temperature display. Refer toElectronic Message Centerin the
Instrumentationchapter.
Fan speed ()
When AUTO is pressed, fan speed is adjusted automatically for existing
conditions. You can override fan speed at any time. To control fan speed
A/C
R
F
AUTO OFFEXT
F C
C
,
AUTO OFFA/C
R EXT
F C
FF
Controls and features
35

manually, press the fan control to cancel the automatic fan speed
operation. Press the control up for higher fan speed or down for lower
fan speed. The display will show
and a bar graph to indicate manual
fan operation and relative speed.
When the fan is adjusted in the AUTO mode, the AUTO indicator will
remain lit and the system will remain in auto operation.
To return to automatic fan operation, press AUTO. The fan icon and bars
will disappear from the display, and the DATC system will return to full
automatic operation.
²A/C control
A/C(air conditioning) Ð Used to manually enable or disable the
operation of the air conditioning in all modes except defrost. In all
modes, the air conditioning will only function if the outside temperature
is about 2ÉC (35ÉF) or higher.
When manual A/C is selected (ON) the indicator will be lit. When manual
A/C is selected (OFF) the indiator will not be lit.
In defrost or floor/defrost mode, if the temperature is about 2ÉC (35ÉF)
or higher, the air conditioner will automatically dehumidify the air to
reduce fogging. However, the A/C indicator will be off and the A/C
override control cannot be selected.
When AUTO is selected, the A/C operates automatically for existing
conditions. You may override the A/C at any time. To manually control
the A/C, press the A/C control to cancel the A/C automatic operation.
AUTO OFFA/C
R EXT
F C
FF
Controls and features
36

In AUTO mode, the air conditioner will operate automatically. When the
A/C is adjusted in the AUTO mode, the AUTO indicator will remain lit
and the system will remain in AUTO operation.
²Recirculation control
(air recirculation) Ð The recirculation feature is used to
manually select whether the DATC system uses outside or recirculated
air. The use of recirculated air when the air conditioning is operating
helps to reduce the amount of time to cool down the interior of the
vehicle in very hot conditions. Recirculated air may also help to keep
unwanted odors from the outside from reaching the vehicle interior. It is
recommended to allow the DATC system to automatically control the
selection of outside or recirculated air.
The recirculation mode cannot be selected in the defrost mode, as
interior fogging may occur. When the recirculation and floor/defrost
override modes are selected, the DATC system will automatically return
to outside air to help reduce window fogging.
In AUTO mode, the air recirculation feature will operate automatically.
However, the air recirculation indicator will be off. The selection of the
air recirculation override control will automatically enable a manual
airflow override.
DO NOT leave the DATC system in recirculated air mode for extended
periods of time while the system is in a heating mode or in cold or damp
conditions as this may cause interior fogging of the front, side and rear
windows.
In AUTO mode, the air conditioner will operate automatically. When the
fan is adjusted in the AUTO mode, the AUTO indicator will remain lit,
and the system will remain in A/C operation.
AUTO OFFA/C
R EXT
F C
FF
Controls and features
37

Manual override controls
The override controls allow you to:
²manually control where the airflow is directed.
²manually control the air conditioning operation.
²turn the DATC system OFF.
²manually select between outside or recirculated air.
To return to full automatic control, press AUTO.
When a manual override control is selected, the DATC system will turn
off the AUTO indicator and display the indicators of all operating
override controls. More than one override control indicator may turn on
when an override control is selected.
The air conditioning can operate in all modes except OFF. However, the
air conditioning will only function if the outside temperature is about 2ÉC
(35ÉF) or higher.
Since the air conditioner removes considerable moisture from the air
during operation, it is normal if clear water drips on the ground under
the air conditioner drain while the system is working and even after you
have stopped the vehicle.
²Airflow direction control
(panel) Ð Distributes air through the instrument panel, and center
console registers.
(panel/floor) Ð Distributes air through the instrument panel and
center console registers, and the front and rear seat floor ducts. For
added customer comfort, the air distributed through the floor ducts may
be slightly warmer than the air sent to the instrument panel registers.
(floor) Ð Distributes air through the front and rear seat floor ducts.
The system will allow some airflow out the defroster ducts, the demister
outlets and outer instrument panel registers.
AUTO
A/C
R EXT
F C
FF
OFF
Controls and features
38

(floor/defrost) Ð Distributes air through the windshield defroster
ducts, the demister outlets and the front and rear seat floor ducts. The
system will allow some airflow out the outer instrument panel registers.
If the temperature is about 2ÉC (35ÉF) or higher, the air conditioner will
automatically dehumidify the air to reduce fogging when manually
selected. For added customer comfort, the air distributed through the
floor ducts may be slightly warmer than the air sent to the windshield
defroster ducts.
(defrost) Ð Distributes outside air through the windshield
defroster ducts and the demister outlets. It can be used to clear ice or
fog from the windshield. The system will allow some airflow out the
outer instrument panel registers. If the outside air temperature is about
2ÉC (35ÉF) or higher, the air conditioner will automatically dehumidify
the air to reduce fogging. (Note that the A/C indicator does not
illuminate when this mode is selected.) Recirculation and A/C override
controls cannot be selected.
²Turn DATC off
OFF-Outside air is shut out. The fan, heating and air conditioning will
not operate. The outside temperature will still display when selected
with the ignition in the RUN position.
Electric window heaters
(heated wiper rest) Ð Located at the base of the windshield, this
feature heats the front glass area below the area heated by the front
defroster where the windshield wipers sit in their parked position. When
activated, the feature keeps the wiper blades warm and reduces the
chance of ice build up on the blades. The indicator will light when the
feature is in operation.
With the ignition in RUN and the engine running, the feature will be
automatically enabled if the temperature is below 5ÉC (40ÉF). The
feature can be manually selected or deselected at any time.
In cold, dry conditions where wet snow or ice is not present it is
acceptable to manually deselect the operation of this feature.
The feature will run continuously unless a low battery condition is
detected, or unless the feature is manually deselected, and will only
activate when the vehicle engine is running (to prevent excessive drain
of the vehicle battery).
R(rear window defroster) Ð Refer toRear Window Defroster.
Controls and features
39

Displaying outside temperature
Press EXT to display the outside air temperature. It will remain selected
until the EXT control is pressed again.
If the driver or passenger temperature or the fan speed is changed, or
the AUTO or
(defrost) modes selected while the outside
temperature is displayed, the driver and passenger temperature display
will be displayed for 4 seconds. Following this, the outside temperature
display will return to the window.
If the outside temperature is displayed while the DATC system is in the
OFF mode and the DATC is turned on, the driver and passenger
temperatures will be displayed for 4 seconds. Following this, the outside
temperature display will return to the window.
The outside temperature reading is most accurate when the vehicle is
moving. Higher readings may be obtained when the vehicle is not
moving. The readings that you get may not agree with temperatures
given on the radio due to differences in vehicle and station locations.
Operating tips
²In humid weather, select(defrost) andR(rear window
defrost) before driving. This will reduce fogging on your windshield.
After a few minutes, select any desired position.
²To prevent humidity buildup inside the vehicle, don't drive with the
climate control system in the OFF position.
²DO NOT leave the DATC system in recirculated air mode for extended
periods of time while the system is in a heating mode or in cold or
damp conditions as this may cause interior fogging of the front, side
and rear windows.
²Don't put objects under the front seat that will interfere with the
airflow to the back seats.
AUTO OFFA/C
R EXT
EXT TEMP
F C
F
Controls and features
40
