ROUTE PREFERENCES
You can select certain preferences for your route.
• AVOID FREEWAYS / TOLL
ROADS / FERRIES: The system
will search for routes attempting
to avoid the use of freeways, toll
roads and/or ferries whenever
possible.
• PREFERRED ROUTE: The
system can search for up to three
routes: fastest route, shortest route and unrestricted route (the fastest
or shortest route without any avoidsettings). If there are not any
Avoid settings, only two routes will be calculated and displayed. The
preferred route will be automatically highlighted on the map for route
selection.
ADDRESS BOOK
The ADDRESS BOOK tab allows
you to view and edit the address
book entries. The maximum number
of entries that can be stored in the
address book is 25. Five of these
entries can be set as Destination
Presets (to be easily accessed), and
one entry can be saved as the Home
location. To set an Address Book entry as a destination preset, select the
address book entry and select the view/edit button.
Select the set button at the bottom of the screen adjacent to Quick Dest.
The list of entries can be sorted by:
• A-Z: List entries by alphabetical order.
• DATE: List entries by date of entry.
• ICON: List entries by icon type.
2007(nv2)
Supplement
USA (fus)
Navigation features
60

QUICK POINTS OF INTEREST (POIS)
This tab allows you to set the five
most frequently used Point of
Interest (POI) categories.
• QUICK POI LIST: Lists five preset POI categories. You can change
any of them.
• EDIT: Press to select a different POI category/subcategory from a list.
AVOID AREAS
You can search avoiding all roads
(even freeways) within specified
avoid areas. If any road within an
avoid area is used for the route, an
icon will be displayed on the screen
for route selection. A maximum of
five areas can be stored as Avoid
Areas. They are represented on the
map as colored squares. If a road is specified as an avoid area, it is
represented by a different color to other roads.
VIEW/EDIT: After entries are programmed, they are shown in a list.
Highlight your selection to change/edit the following attributes:
• NAME: Select to enter a different name for the area.
• LOCATION: A map with the selected location will appear on the
screen. You can then:
REDUCE AREA
SAVE AREA
EXPAND AREA
• RETURN: Saves changes to the selected area.
ADD: Add an avoid area by selecting an input method and entering the
required information:
• PREVIOUS DEST
• POI
• ADDRESS
2007 (nv2)
Supplement
USA (fus)
Navigation features
62

•INTERSECTION
• MAP
• FREEWAY ENTRANCE/EXIT
• PHONE NUMBER
• CANCEL
DELETE: Press to delete the selected entry.
DELETE ALL: Press to delete all entries in the Avoid Area list.
SETTINGS
UNITS: The system can be set to
display different units:
• ENGLISH (MILES)
• METRIC (KILOMETERS)
AUTO-FILL STATE/PROV: When selected, the State/Province field will
be automatically filled in based on current location for destination entry.
If it is not selected, the last State/Province will be displayed.
AVERAGE SPEED (MPH): You can preset speeds based on driving
habits for calculation of travel time and ETA (Estimated Time Arrival).
• RESIDENTIAL
• MAIN ROADS
• FREEWAY
CALIBRATE: The navigation system supports a quick method to
calibrate the vehicle position. Under normal circumstances this
calibration is done automatically, but over a longer period of time. The
user may want to recalibrate the system if the vehicle icon is not
tracking proper position resulting in inaccurate route guidance
instructions.
• POSITION: The system supports manual adjustment of the vehicle’s
position and heading via the Map. Press to scroll on map until the
desired location is reached and press ENTER. Adjust the vehicle
heading by pressing the arrow buttons until the desired heading is
reached. Press ENTER to save the new settings.
DEFAULT SETTINGS: Press to set all the features in this screen back
to system default.
2007 (nv2)
Supplement
USA (fus)
Navigation features
63

•Inside or in between buildings
• By forests or tree-lined avenues
• In heavy rain showers and thunderstorms
• In valleys and in mountainous regions
• Roads under cliffs
Ensure that you do not have any metal objects on the dashboard and
that if your windows are tinted, they use non-metal tinting instead of
metal oxide tinting. Both of these factors can also interrupt GPS
reception.
If the vehicle has been parked for a long period of time, the navigation
function may be temporarily unresponsive. The navigation system will
operate reliably again once GPS reception is available for a few minutes.
SYSTEM LIMITATIONS
Cold temperature start: When operating the system below 32° F
(0°C), the display screen requires a 2–3 minutes warm-up time to
achieve maximum brightness.
Other conditions: When calculating a route, the system doesn’t take
into consideration any of the following conditions:
• Traffic Conditions
• Weather Conditions
• Driving Habits
• Construction Zones
• New Roads
GLOSSARY
COMP: Compression
DEST: Destination
DSP: Digital Signal Processing
ETA : Estimated Time of Arrival
FCC: Federal Communications Commission
GPS: Global Positioning System
MAP/NAVIGATION DVD: The disc containing a map database to
operate the navigation system.
POI: Point(s) Of Interest
2007 (nv2)
Supplement
USA (fus)
General Information
70

A
Address book ..............................46
AM/FM .........................................12
Auxiliary Input Jack ...................27
Avoid areas ..................................62
C
CD ................................................15
Cleaning Map DVDs ....................36
D
Date/time settings .......................29
Destination entry ........................43
Destination map ..........................55
Destination way points ...............56
Displays .......................................28
DVD - Loading and Unloading ...34
DVD (if equipped) ................18, 20
F
Freeway entrance/exit ................54
G
GPS reception .............................69
H
Help ..............................................32
How to get going ..........................4
I
Intersection .................................53 L
Latest map DVDs ........................36
M
Map icons ....................................41
Map preferences .........................58
O
Ordering additional map DVDs..37
P
Point of Interest (POI) ...............49
Previous destination ...................45
Q
Quick destination ........................43
Quick POIs ..................................62
Quick touch buttons ...................39
S
Satellite Radio (if equipped) .....22
Security .......................................31
Select route .................................57
Settings ........................................63
Sound features ............................16
Speed compensated volume ......18
System information .....................33
System introduction .....................3
System limitations ......................70
System overview ...........................8
T
Troubleshooting ..........................64
2007 (nv2)
Supplement
USA (fus)
Index
72
