77
Windshield Wipers and WasherTo turn on the windshield wipers, the ignition key
must be turned to the ON or ACC position.
Rotate the knob towards ªSº to activate the wipers.
The first seven detents are interval wipe positions,
the eighth detent is the LO position and the ninth
detent is the HI position.
To turn the wipers off, turn the knob to the OFF
position.Variable Interval WipersIn addition to two speed wipers, your vehicle has
wipers that you can set to operate at varying
intervals. For example, you can set the interval so
they wipe less often when it drizzles or more often
in heavier rain.
To set the interval wipers, turn the knob at the end
of the turn signal lever between ªSº (slow) and ªFº
(fast) until the desired interval between wipes is
achieved.
File:05fncft.ex
Update:Mon Jun 17 13:49:49 1996

78
WindshieldWasherWARNING
Alway swar mup thewindshiel dwith

79
The control switch for the hazard flashersHornTo sound the horn, push the center pad area of the
steering wheel.
The horn on the steering wheel Ð Executive
series
File:05fncft.ex
Update:Mon Jun 17 13:49:49 1996

80
Thehor non the steerin gwhee lÐ Signature
TiltSteering
WARNING
Neve radjus tth esteerin gwhee lwhen

81
The lever to tilt the steering wheel
To change the position of the steering wheel, pull
the release lever on the column toward you. Tip
the steering wheel to the desired position. Release
the lever to lock the steering wheel in place.Speed ControlThe speed of the vehicle cannot be automatically
controlled until the vehicle speed is at or above 30
mph (48 km/h).
Use of radio transmitting equipment that is not
Federal Communications Commission (FCC) or in
Canada the Canadian Radio and
Telecommunications Commission (CRTC) approved
may cause the speed control to malfunction.
Therefore, use only properly installed FCC (CRTC in
Canada) approved radio transmitting equipment in
your vehicle.
NOTE:Do not shift to N (Neutral) when using the
speed control. This will cause the engine to
overspeed.
File:05fncft.ex
Update:Mon Jun 17 13:49:49 1996

82The speed control switches on the steering
wheel Ð Executive series
The speed control switches on the steering
wheel Ð Signature and Cartier series
File:05fncft.ex
Update:Mon Jun 17 13:49:49 1996

83
WARNING
To kee pyou rvehicl eunde rcontrol ,do

84q
Accelerate with your accelerator pedal, then
press SET ACCEL.
You may accelerate with the accelerator pedal at
any time during speed control usage. Releasing the
accelerator pedal will return your vehicle speed to
the previously programmed set speed.
To Set a Lower Set Speedq
Press and hold COAST. Release the switch
when the desired vehicle speed is reached. OR
q
Press and release COAST. Each press will
decrease the set speed by 1 mph (1.6 km/h).
OR
q
Depress the brake pedal. When the desired
vehicle speed is reached, press SET ACCEL.
To Disengage Speed Controlq
Depress the brake pedal.
Disengaging the speed control will not erase the
previously programmed set speed.
To Return to a Set Speedq
Press RES (RESUME). For RES (RESUME) to
operate, the vehicle speed must be faster than
30 mph (48 km/h).
Indicator Light (If Equipped)Lights when either the SET ACCEL or RES
(RESUME) switches are pressed and remains lighted
until it is either disengaged or turned off.
File:05fncft.ex
Update:Mon Jun 17 13:49:49 1996

85
Remote Control Buttons
(If equipped)Your vehicle may be equipped with remote control
buttons, located on the steering wheel, which allow
you to control some radio and climate control
features.
The remote control buttons on the steering
wheel
Radio Control FeaturesWith the remote radio control features you are able
to:q
Select a preset station from memory by pressing
the ªMEMº button.
q
Select AM, FM1, or FM2 by pressing the
ªBANDº button.
q
Adjust the volume to the desired level by
pressing either the ªVOLº up or ªVOLº down
button.
Climate Control FeaturesWith the remote climate control features you are
able to:q
Adjust the temperature level by pressing the
ªTEMPº up or ªTEMPº down button.
q
Adjust the fan speed by pressing the ªFANº up
or the ªFANº down button.
File:05fncft.ex
Update:Mon Jun 17 13:49:49 1996

86Turning On the LampsFront and Rear Courtesy/Reading
LampsYour vehicle is equipped with two courtesy/reading
lamps located at the front-center and rear-center of
the headliner (roof). The right lamps are for the
right side passengers and the left lamps are for the
driver and rear left side passenger.
With the lens in the flat position, the
courtesy/reading lamp will illuminate when any
door is opened or when the headlamp dimmer knob
is rotated to the courtesy lamp position.
With the lens in the rotated position, the
courtesy/reading lamp will illuminate.
File:05fncft.ex
Update:Mon Jun 17 13:49:49 1996
