MAZDA CX90 2024 Owners Manual

Warnings and CautionsFor Child-restraint Systems
WARNING
Use the correct size child-restraint
system.
For effective protection in vehicle
accidents and sudden stops, a child
must be properly restrained using a
seat belt or child-restraint system
depending on age and size. If not, the
child could be seriously injured or even
killed in an accident.
Follow the manufacturer's
instructions and always keep the
child-restraint system buckled down.
An unsecured child-restraint system is
dangerous. In a sudden stop or a
collision it could move causing serious
injury or death to the child or other
occupants. Make sure any
child-restraint system is properly
secured in place according to the
child-restraint system manufacturer's
instructions. When not in use, remove
it from the vehicle or fasten it with a
seat belt, or attach it to BOTH LATCH
lower anchors for LATCH
child-restraint systems and the
corresponding tether anchor.
Always secure a child in a proper
child-restraint system.
Holding a child in your arms while the
vehicle is moving is extremely
dangerous. No matter how strong the
person may be, he or she cannot hold
onto a child in a sudden stop or
collision and it could result in serious
injury or death to the child or other
occupants. Even in a moderate
accident, the child may be exposed to
air bag forces that could result in
serious injury or death to the child, or
the child may be slammed into an
adult, causing injury to both child and
adult.
Never use a rear-facing child-restraint
system in the front seat with an air
bag that could deploy.
Rear-facing child-restraint systems on
the front seat are particularly
dangerous even though you may feel
assured that a front passenger air bag
will not deploy based on the fact that
the front passenger air bag
deactivation indicator light illuminates.
The child-restraint system can be hit by
a deploying air bag and moved
violently backward resulting in serious
injury or death to the child.
Equipment to Protect Occupants/Pedestrians
Child-restraint Systems
3-52
CX-90_8KG7-EA-22L_Edition1_new 2022-11-17 16:05:04

Ve h i c l e s w i t h a f r o nt passenger air bag
have the following warning label. The
warning label reminds you not to put a
rear-facing child-restraint system on
the front passenger seat at any time.
Do not install a front-facing
child-restraint system on the front
passenger seat unless it is
unavoidable.
In a collision, the force of a deploying
air bag could cause serious injury or
death to the child. If installing a
front-facing child-restraint system on
the front passenger seat is
unavoidable, move the front passenger
seat as far back as possible and adjust
the seat bottom (height adjustable seat
bottom) to the highest position at
which the seat belt fastening the
child-restraint system is securely
tightened.
Seating a child in a child-restraint
system on the front passenger seat is
dangerous under certain conditions .
Your vehicle is equipped with front
passenger seat weight sensors. Even
with the front passenger seat weight
sensors, if you must use the front
passenger seat to seat a child, using a
child-restraint system on the front
passenger seat un der the following
conditions increases the danger of the
front passenger air bag deploying and
could result in serious injury or death
to the child.
 The front passenger air bag
deactivation indicator light does not
illuminate when seating a child in the
child-restraint system.
 Luggage or other items are placed on
the seat with the child in the
child-restraint system.
 A rear passenger or luggage pushing
or pulling down on the front
passenger seatback.
 Luggage or other items are placed on
the seatback or hung on the head
restraint.
 The seat is washed.
 Liquids are spilled on the seat.
 The front passenger seat is moved
backward, pushing into luggage or
other items placed behind it.
 The front passenger seatback
contacts the rear seat.
 Luggage or other items are placed
between the front passenger seat
and driver seat.
 An electric device is put on the front
passenger's seat.
 An additional electrical device, such
as a seat warmer is installed to the
surface of the front passenger seat.
 Any accessories, which might
increase the total seated weight on
the front passenger seat, are
attached to the front passenger seat.
Equipment to Protect Occupants/Pedestrians
Child-restraint Systems
3-53
CX-90_8KG7-EA-22L_Edition1_new 2022-11-17 16:05:04

The designated positions with seat
belts on the rear seats are the safest
places for children. Always use seat
belts and child restraints.
Never use one seat belt on more than
one person at a time.
Using one seat belt for more than one
person at a time is dangerous. A seat
belt used in this way cannot spread the
impact forces properly and the two
passengers could be crushed together
and seriously injured or even killed.
Never use one belt for more than one
person at a time and always operate
the vehicle with each occupant
properly restrained.
Tethered Child-Restraint Systems
Work Only on Tether-Equipped Rear
Seats.
Installation of a tether equipped
child-restraint system in the front
passenger's seat defeats the safety
design of the system and will result in
an increased chance of serious injury if
the child-restraint system goes forward
without benefit of being tethered.
Place tether equipped child-restraint
systems where there are tether
anchors.
CAUTION
A seat belt or child-restraint system can
become very hot in a closed vehicle
during warm weather. To avoid burning
yourself or a child, check them before
you or your child touches them.
Equipment to Protect Occupants/Pedestrians
Child-restraint Systems
3-54
CX-90_8KG7-EA-22L_Edition1_new 2022-11-17 16:05:04

Types of Child-restraint Systems
Child-Restraint System Types
In this owner's manual, explanation of child-restraint systems is provided for the
following three types of popular child-restraint systems: infant seat, child seat,
booster seat.
NOTE
Installation position is determined by the type of child-restraint system. Always
read the manufacturer's instructions and this owner's manual carefully.
Due to variations in the design of chil d-restraint systems, vehicle seats and seat
belts, all child-restraint systems may not fit all seating positions. Before purchasing
a child-restraint system, it should be tested in the specific vehicle seating position
(or positions) where it is intended to be used. If a previously purchased
child-restraint system does not fit, you may need to purchase a
different one that
will.
Infant seat
An infant seat provides restraint by bracing the infant's head, neck and back against
the seating surface.
Child seat
A child seat restrains a child's body using the harness.
Equipment to Protect Occupants/Pedestrians
Child-restraint Systems
3-55
CX-90_8KG7-EA-22L_Edition1_new 2022-11-17 16:05:04

Booster seat
A booster seat is a child restraint accessory designed to improve the fit of the seat
belt system around the child's body.
1. Full booster seat
2. Backless booster seat

When using a backless booster seat, always install the vehicle head restraint to the
seat where the backless booster seat is installed.
Installing Child-RestraintSystems
Accident statistics reveal that a child is
safer in the rear seat. The front
passenger's seat is clearly the worst
choice for any child under 12, and
with rear-facing child-restraint systems
it is clearly unsafe due to air bags.

NOTE
Even if your vehicle is equipped with
front passenger occupant classification
sensor (page 3-16), which
automatically deactivates the front
passenger air bag , a rear seat is the
safest place for a child of any age or
size.

Some child-restraint systems now
come with tethers and therefore must
be installed on the seats that take
tethers to be effective.

Some child-restraint systems also
employ specially designed LATCH
attachments; refer to " How to Use the
LATCH Lower Anchor"(page 3-66).
Equipment to Protect Occupants/Pedestrians
Child-restraint Systems
3-56
CX-90_8KG7-EA-22L_Edition1_new 2022-11-17 16:05:04

Anchor Bracket Overview
Anchor brackets for securing
child-restraint systems are equipped in
the vehicle. Locate each anchor
position using the illustration.
To install a child-restraint system, if the
seat is equipped with a head restraint,
remove it. Always follow the
instruction manual accompanying the
child-restraint system.

Anchor bracket location
Use the indicated anchor bracket
locations when installing a
child-restraint system equipped with a
tether.
Second-row seats
1. For right
2. For center
3. For left
Third-row seats
1. For right
2. For center
*
3. For left
Warnings and Cautionsfor Using the Anchor Bracket
WARNING
Always attach the tether strap to the
correct tether anchor position.
Attaching the tether strap to the
incorrect tether anchor position is
dangerous. In a collision, the tether
strap could come off and loosen the
child-restraint system. If the
child-restraint system moves it could
result in death or injury to the child.
Use the tether and tether anchor only
for a child-restraint system.
Using the tether or tether anchor to
secure anything but a child-restraint
system is dangerous. This could
weaken or damage the tether or tether
anchor and result in injury.
Always remove the head restraint and
install child-restraint system (except
when installing a backless booster
seat) (Except third-row outboard
seat).
Installing a child-restraint system
without removing the head restraint is
dangerous. The child-restraint system
cannot be installed correctly which
may result in death or injury to the
child in a collision.
If the top tether strap does not reach
the anchor bracket, purchase and use
an extension strap provided by the CRS
manufacturer.
Equipment to Protect Occupants/Pedestrians
Child-restraint Systems
*Some models.3-57
CX-90_8KG7-EA-22L_Edition1_new 2022-11-17 16:05:04

Second-row outboard seat
Second-row/Third-row center seats
1. Tether strap
2. Anchor bracket
3. Forward

Always install the head restraint and
adjust it to the appropriate position
after removing the child-restraint
system (Except third-row outboard
seat).
Driving with the head restraint
removed is dangerous as impact to the
occupant's head cannot be prevented
during emergency braking or in a
collision, which could result in a
serious accident, injury or death.
Refer to How to Use the Head
Restraints on page 3-48.
Only use a tether anchor designed for
the second-row seats.
Using a third-row seat tether anchor
on the second-row seat is dangerous.
The child-restraint system cannot be
installed correctly which may result in
death or injury to the child in a
collision.
1. Tether strap
2. Second-row outboard/center seat
3. Third-row seat
Always route the tether straps to the
sides of the head restraint (Third-row
outboard seat).
Routing the tether straps on top of the
head restraint is dangerous. In a
collision the tether straps could slide
off the head restraint and loosen the
child-restraint system. The
child-restraint system could move
which may result in death or injury to
the child.
Equipment to Protect Occupants/Pedestrians
Child-restraint Systems
3-58
CX-90_8KG7-EA-22L_Edition1_new2022-11-17 16:05:04

How to Use the
Automatic Locking Mode
NOTE
Follow the child-restraint system
manufacturer's instructions carefully. If
you are not sure whether you have a
LATCH system or tether, check in the
child-restraint system manufacturer's
instructions and follow them
accordingly. Depending on the type of
child-restraint system, it may use
LATCH system instead of seat belts or if
the belt goes across the child's chest,
may recommend against using
automatic locking mode.
1. (Second-row seat)
Adjust the second-row seat
position using the following
procedure.
1. Fold the second-row seatback
forward.
2. Raise the second-row seatback until a click sound is heard and
it is locked in place.
2.(Second-row seat)
Adjust the angle of the second-row
seatback so that there is no gap
between the child-restraint system
and the second-row seatback.
3. Make sure the seatback is securely latched by pushing it back until it is
fully locked.
4. If a removable head restraint isequipped, remove it. However,
when installing a backless booster
seat, always install the vehicle head
restraint to the seat where the
backless booster seat is installed.
Refer to How to Use the Head
Restraints on page 3-48.
5. Secure the child-restraint system with the lap portion of the lap/
shoulder belt. See the
manufacturer's instructions on the
child-restraint system for belt
routing instructions.
6. To get the retractor into the automatic locking mode, pull the
shoulder belt portion of the seat
belt until the entire length of the
belt is out of the retractor.
Equipment to Protect Occupants/Pedestrians
Child-restraint Systems
3-59
CX-90_8KG7-EA-22L_Edition1_new 2022-11-17 16:05:04

7. Push the child-restraint systemfirmly into the vehicle seat. Be sure
the belt retracts as snugly as
possible. A clicking noise from the
retractor will be heard during
retraction if the system is in the
automatic locking mode. If the belt
does not lock the seat down tight,
repeat this step.
NOTE
Inspect this function before each
use of the child-restraint system.
You should not be able to pull the
shoulder belt out of the retractor
while the system is in the automatic
locking mode. When you remove
the child-restraint system, be sure
the belt fully retracts to return the
system to emergency locking mode
before occupants use the seat belts.
8. If your child-restraint system requires the use of a tether strap,
refer to the manufacturer's
instructions to hook and tighten the
tether strap.
If You Must Use the Front
Seat for Children
If you cannot put all children in the
rear seat, at least put the smallest
children in the rear and be sure the
largest child up front uses the shoulder
belt over the shoulder.
NEVER put a rear-facing child-restraint
system on the front passenger seat
whether your vehicle is equipped with
an occupant classification sensor or
not.
This seat is also not set up for tethered
child-restraint systems, put them in
one of the rear seat positions set up
with tether anchors.
Likewise the LATCH child-restraint
system cannot be secured in the front
passenger's seat and should be used in
the second-row seat.
Do not allow anyone to sleep against
the side window since your vehicle has
side and curtain air bags, it could
cause serious injuries to an out of
position occupant. As children more
often sleep in cars, it is better to put
them in the rear seat. If installing the
child-restraint system on the front seat
is unavoidable, follow these
instructions when using a front-facing
child-restraint system in the front
passenger's seat.
NOTE
To check if your front seats have side
air bags:
Mazda vehicles equipped with side
air bag will have a "SRS AIRBAG" tag
on the outboard shoulder of the
front seats.
To check if your vehicle has curtain
air bags:
Equipment to Protect Occupants/Pedestrians
Child-restraint Systems
3-60
CX-90_8KG7-EA-22L_Edition1_new 2022-11-17 16:05:04

Mazda vehicles equipped with
curtain air bag will have an "SRS
AIRBAG" marking on the window
pillars along the roof edge.Warnings and Cautions
for Using the Front Seat for Children
WARNING
Always move the front passenger seat
as far back as possible if installing a
front-facing child-restraint system on
it is unavoidable.
As your vehicle has front air bags and
doubly so because your vehicle has
side air bags, a front-facing
child-restraint system should be put on
the front passenger seat only when it is
unavoidable.
Even if the front passenger air bag
deactivation indicator light illuminates,
always move the seat as far back as
possible, because the force of a
deploying air bag could cause serious
injury or death to the child.
Never use a rear-facing child-restraint
system in the front seat with an air
bag that could deploy.
Rear-facing child-restraint systems on
the front seat are particularly
dangerous.
Even in a moderate collision, the
child-restraint system can be hit by a
deploying air bag and moved violently
backward resulting in serious injury or
death to the child. Even though you
may feel assured that the front
passenger air bag will not deploy
based on the fact that the front
passenger air bag deactivation
indicator light illuminates, you should
not use a rear-facing child-restraint
system in the front seat.
Equipment to Protect Occupants/Pedestrians
Child-restraint Systems
3-61
CX-90_8KG7-EA-22L_Edition1_new 2022-11-17 16:05:04
