MAZDA CX90 2024 Owners Manual

Key
All doors, fuel-filler lid/charging port
lid, and the liftgate can be locked/
unlocked by pressing the key switch.
The key must be carried by the driver.
Key Code Number Plate
An auxiliary key can be ordered based
on the key code number printed on
the key code number plate at an
Authorized Mazda Dealer.
Store the key code number plate in a
safe place (not in the vehicle).
Do not divulge the key number to
others.
Warnings and Cautionsfor Using the Key
WARNING
Do not leave the key in your vehicle
with children and keep them in a
place where your children will not
find or play with them.
Leaving children in a vehicle with the
key is dangerous. This could result in
someone being badly injured or even
killed. Children may find these keys to
be an interesting toy to play with and
could cause the power windows or
other controls to operate, or even
make the vehicle move.
CAUTION
Radio equipment like this is
governed by laws in the United
States.
Changes or modifications not
expressly approved by the party
responsible for compliance could
void the user's authority to operate
the equipment.
 Because the key (transmitter) uses
low-intensity radio waves, it may not
function correctly under the
following conditions:
 The key (transmitter) is carried with
communication devices such as
cellular phones.
 The key (transmitter) contacts or is
covered by a metal object.
 The key (transmitter) is near
electronic devices such as personal
computers.
 Non-Mazda genuine electronic
equipment is installed in the
vehicle.
Opening/closing
Key
4-4
CX-90_8KG7-EA-22L_Edition1_new 2022-11-17 16:05:04

There is equipment which
discharges radio waves near the
vehicle.
 The key (transmitter) may consume
battery power excessively if it
receives high-intensity radio waves.
Do not place the key (transmitter)
near electronic devices such as
televisions or personal computers.
 To avoid damage to the key
(transmitter), DO NOT:
 Drop the key (transmitter).
 Get the key (transmitter) wet.
 Disassemble the key (transmitter).
 Expose the key (transmitter) to
high temperatures on places such
as the dashboard, under direct
sunlight.
 Expose the key (transmitter) to any
kind of magnetic
field.
 Place heavy objects on the key
(transmitter).
 Put the key (transmitter) in an
ultrasonic cleaner.
 Put any magnetized objects close
to the key (transmitter).How to Use the Key
When pressing the button, the
operation indicator light turns on.
1. Operation indicator light
2. Lock button (
)
3. Unlock button (
)
4. Power liftgate button (
)*
5. Panic button ()
Lock button
Press the lock button with all of the
following conditions met.
The vehicle power is switched OFF.
The doors, liftgate, fuel-filler lid/
charging port lid are locked, the hazard
warning lights operate 1 time.
A beep sound will be heard once.

To confirm that all the doors, liftgate,
and fuel-filler lid/charging port lid
have been locked, press the lock
button again within 5 seconds. If they
are closed and locked, the horn will
sound.
Opening/closing
Key
*Some models.4-5
CX-90_8KG7-EA-22L_Edition1_new 2022-11-17 16:05:04

NOTE
When any door or the liftgate is open
and the lock button is pressed, the
closed doors can be locked. After
that, any other open door or the
liftgate can be locked by closing
them.
To prevent the transmitter from being
left in the vehicle, make sure that the
driver carries the transmitter when
locking the doors with any door
open.
(With theft-deterrent system)
If the lock button is pressed with all
the doors and liftgate closed, the
hazard warning lights will flash and
the theft-deterrent system is armed.
Unlock button
Press the unlock button while the
vehicle power is switched OFF.
The driver’s door and the charging port
lid are unlocked, the hazard warning
lights operate 2 times, and then a
warning sound is activated 2 times.
Press the unlock button again within 5
seconds to unlock the other doors.

(With the advanced keyless function)
The hazard warning lights operate and
a sound is activated 2 times at the
same time.
NOTE
(With the advanced keyless
function)
The sound can be switched on/off
using the Mazda Connect.
Refer to the Settings section in the
Mazda Connect Owner's Manual.
The 2-step unlocking function can be
set to on/off using Mazda Connect.
Refer to the Settings section in the
Mazda Connect Owner's Manual.
Liftgate open/close button *
Opening the liftgate
Press the liftgate open/close button on
the key for about 1 second or longer
when all of the following conditions
are met.
The vehicle power is switched OFF.
After the hazard warning lights flash 2
times is activated, the liftgate fully
opens.
Closing the liftgate
Press the liftgate open/close button for
about 1 second or longer when the
vehicle power is switched OFF.
After the hazard warning lights flash 2
times is activated, the liftgate fully
closes.
NOTE
If the liftgate open/close button is
pressed while the liftgate is opening/
closing automatically, a warning sound
is activated and the liftgate stops.
When pressing the liftgate open/close
button again, the liftgate moves in the
reverse direction.
Panic button
If you witness from a distance
someone attempting to break into or
damage your vehicle, press and hold
the panic button to activate the
vehicle's alarm. Call emergency
services if necessary.
NOTE
The panic button will work whether
any door or the liftgate is open or
closed.
Opening/closing
Key
4-6*Some models.
CX-90_8KG7-EA-22L_Edition1_new 2022-11-17 16:05:04

Turning on the alarm
Pressing the panic button for 1 second
or more will trigger the alarm for about
2 minutes and 30 seconds, and the
following will occur:
The horn sounds intermittently.The hazard warning lights flash.
Tu r n i n g off the alarm
The alarm stops by pressing any button
on the key.
Operational Range
The system operates only when the
driver is in the vehicle or within
operat ional range while the key is
being carried.
Starting the hybrid system
NOTE
Starting the hybrid system may be
possible even if the key is outside of
the vehicle and extremely close to a
door and window, however, always
start the hybrid system from the
driver's seat.
If the vehicle is started and the key is
not in the vehicle, the vehicle will not
restart after it is shut off and the
vehicle power is switched off.
The luggage compartment is out of
the assured operational range,
however, if the key (transmitter) is
operable the hybrid system will start.
With the advanced keyless function

1. Interior antenna
2. Operational range

Without the advanced keyless
function

1. Interior antenna
2. Operational range

NOTE
The hybrid system may not start if the
key is placed in the following areas:
Around the dashboardIn the storage compartments such as
the glove compartment or the center
console
Opening/closing
Key
4-7
CX-90_8KG7-EA-22L_Edition1_new 2022-11-17 16:05:04

Convenient Ways to Usethe Key
Sound function
The function that the sound notifies
you of unlocking/locking can be
turned on or off by changing the
setting in Mazda Connect. The volume
of the warning sound can also be
changed.
Auto re-lock function
All doors, the liftgate, and the fuel lid
are locked automatically if any of the
following operations are not
performed within about 60 seconds
after they are unlocked by pressing the
unlock button.
Open any door or liftgate.The vehicle power is switched to any
position other than off.
NOTE
The time until the door is automatically
locked can be changed.
Refer to the Settings section in the
Mazda Connect Owner's Manual.
Power Saving Function
By turning on the power saving
function of the key, the advanced
keyless entry and the function to start
the hybrid system without removing
the key from a pocket or purse/case
are turned off, and the battery power
consumption of the key can be
reduced.
The remote control function is still
operational by pressing a button on
the key even while the power saving
function is turned on. However, the
remote operation indicator light does
not turn on or flash.
Turning on the power saving function
1. Press the lock button on the key 4
times within 3 seconds.
The key operation indicator light
turns on.
2. Press the lock button for 2 seconds or longer while the key operation
indicator light is turned on.
The hazard warning lights and a
warning sound operate 1 time, and
the power saving function is turned
on.
Turning off the power saving function
1. Press the lock button on the key 4 times within 3 seconds.
The key operation indicator light
turns on.
2. Press the lock button for 2 seconds or longer while the key operation
indicator light is turned on.
The hazard warning lights and a
warning sound operate 1 time, and
the power saving function is turned
off.
Opening/closing
Key
4-8
CX-90_8KG7-EA-22L_Edition1_new 2022-11-17 16:05:04

Advanced Keyless EntrySystem
*
The advanced keyless function allows
you to lock/unlock the door, liftgate,
and fuel-filler lid/charging port lid, or
open the liftgate starting the hybrid
system while carrying the key.
Warnings and Cautions
for Using the Advanced
Keyless Entry System
WARNING
Radio waves from the key may affect
medical devices such as pacemakers.
Before using the key near people who
use medical devices, ask the medical
device manufacturer or your physician
if radio waves from the key will affect
the device.
Opening/closing
Advanced Keyless Entry System
*Some models.4-9
CX-90_8KG7-EA-22L_Edition1_new 2022-11-17 16:05:04

How to Use the
Advanced Keyless Entry System
The system operates only when the
driver is in the vehicle or within
operational range while the key is
being carried (Except during power
saving function operation).
NOTE
The advanced keyless entry system
functions can be deactivated to
prevent any possible adverse effect
on a user wearing a pacemaker or
other medical device. If the system is
deactivated, you will be unable to
start the hybrid system by carrying
the key. Consult an Authorized
Mazda Dealer for details. If the
advanced keyless entry system has
been deactivated, you can start the
hybrid system by following the
procedure indicated when the key
battery goes dead.
Refer to Starting the hybrid system
with a dead key battery on page
8-9.
When the battery power is low, or in
places where there are high-intensity
radio waves or noise, the operational
range may become narrower or the
system may not operate.
Locking/Unlocking Using Touch
Sensor
1. Exterior antenna
2. 80 cm (31 in)
3. Operational range

NOTE
The system may not operate if you
are too close to the windows or door
handles, or liftgate.
If the key is left in the following areas
and you leave the vehicle, the doors
may be locked depending on the
radio wave conditions even if the key
is left in the vehicle.
Around the dashboardIn the storage compartments such
as the glove compartment or the
center console
Next to a communication device
such as a mobile phone
Locking Using Door-Lock Switch/
Unlocking Using Electric Liftgate
Opener
1. Exterior antenna
2. 80 cm (31 in)
3. Operational range
Opening/closing
Advanced Keyless Entry System
4-10
CX-90_8KG7-EA-22L_Edition1_new 2022-11-17 16:05:04

Warnings and CautionsWhen Using the Doors
WARNING
Opening/closing of the doors must be
done by an adult.
If a person's hand, foot, or neck is
pinched in a door, it could result in
serious injury.
Do not drive the vehicle with the
door-ajar warning light/indication
turned on/displayed.
Otherwise, the door may open
unexpectedly and result in an accident.
Always take all children and pets with
you or leave a responsible person
with them.
Leaving a child or a pet unattended in
a parked vehicle is dangerous. In hot
weather, temperatures inside a vehicle
can become high enough to cause
brain damage or even death.
Do not leave the key in your vehicle
with children and keep them in a
place where your children will not
find or play with them.
Leaving children in a vehicle with the
key is dangerous. This could result in
someone being badly injured or even
killed.
Keep all doors locked when driving.
Unlocked doors in a moving vehicle
are dangerous. Passengers can fall out
if a door is accidentally opened and
can more easily be thrown out in an
accident.
Always close all the windows and
Panorama sunroof/moonroof, lock
the doors, fuel-filler lid, and liftgate
and take the key with you when
leaving your vehicle unattended.
Leaving your vehicle unlocked is
dangerous as children could lock
themselves in a hot vehicle, which
could result in death. Also, a vehicle
left unlocked becomes an easy target
for thieves and intruders.
After closing the doors and the
liftgate, always verify that they are
securely closed.
Doors and the liftgate not securely
closed are dangerous, if the vehicle is
driven with a door and the liftgate not
securely closed, the door and the
liftgate could open unexpectedly
resulting in an accident.
Always confirm the safety around the
vehicle before opening a door and the
liftgate.
Suddenly opening a door and the
liftgate is dangerous. A passing vehicle
or a pedestrian could be hit and cause
an accident.
CAUTION
Always confirm the conditions around
the vehicle during strong winds or
when parked on an incline before
opening/closing the doors. Neglecting
to check the conditions around the
vehicle could result in fingers getting
caught in the door or a passing
pedestrian being hi t, resulting in an
unexpected accident or injury.
Opening/closing
Doors
4-11
CX-90_8KG7-EA-22L_Edition1_new 2022-11-17 16:05:04

How to Use the DoorLock
To prevent the key from being left in
the vehicle, make sure that you carry
the key before locking.
Locking/Unlocking Using the Key
Refer to How to Use the Key on page
4-5.
Locking/Unlocking Using the Touch
Sensor (Vehicles with Advanced
Keyless Function)
Locking
Touch the sensing area of the door lock
touch sensor when all of the following
conditions are met.
The vehicle power is switched OFF.All the doors are closed.The key is on the sensing area of the
touch sensor.
The hazard warning lights operate
once, and all the doors, liftgate,
fuel-filler lid/charging port lid are
locked.
A beep sound operates one time.
Unlocking
When all of the following conditions
are met, touch the sensing area of the
door release touch sensor.
The vehicle power is switched OFF.The driver’s door is locked.Three seconds or longer have passed
since the doors were locked.
The key is on the sensing area of the
touch sensor.
Unlocking from the driver's door
The following locations are unlocked
by touching the sensing area of the
door release touch sensor of the
driver's door.
Driver’s doorCharging port lid

When unlocking , the hazard warning
lights operate two times.
A beep sound operates two times.
Unlocking from the front passenger’s
door
The following locations are unlocked
by touching the sensing area of the
door release touch sensor of the front
passenger's door.
All doorsCharging port lidLiftgate
When unlocking , the hazard warning
lights operate two times.
A beep sound operates two times.
NOTE
The location to be unlocked can be
changed.
Refer to Settings section in the
Mazda Connect Owner's Manual or
consult an Authorized Mazda Dealer.
Opening/closing
Doors
4-12
CX-90_8KG7-EA-22L_Edition1_new 2022-11-17 16:05:04

The beep sound can be turned
on/off using Mazda Connect.
Refer to Settings section in the
Mazda Connect Owner's Manual or
consult an Authorized Mazda Dealer.
The system may not operate normally
under the following conditions.
You touch the sensing area of the
door lock touch sensor and the
sensing area of the door release
touch sensor at the same time.
You touch the sensing area of the
touch sensor while wearing gloves.
Foreign matter such as water, ice,
snow, or dirt is on the detection
area of the touch sensor.
The system may operate if the outer
side door handle of a front door is
splashed with water by a car wash or
rain while the key is in the operation
range.
Locking/Unlocking Using the
Door-Lock Switch
The following locations are locked/
unlocked.
All doorsLiftgateFuel-filler lid (locking only)
Charge port lid
1. Unlocking
2. Locking
Locking the doors from the outside
using the door-lock switch
Doors can be locked from the outside
of the vehicle without using the
transmitter.
You can lock the doors by pressing the
lock side of the door-lock switch with
all of the following conditions met,
and then closing all the doors.
The vehicle power is switched OFF.Any door is open.The key is not in the vehicle.
After locking by pressing the door-lock
switch, closing all the doors with the
transmitter left in the vehicle unlocks
all doors, the liftgate, and the fuel-filler
lid/charging port lid.
Door-lock switch on liftgate (With the
advanced keyless function)
With power liftgate
Refer to How to Use the Power Liftgate
on page 4-21.
Without power liftgate
When all of the following conditions
are met, press the door-lock switch
and then close the liftgate.
Opening/closing
Doors
4-13
CX-90_8KG7-EA-22L_Edition1_new 2022-11-17 16:05:04
