MAZDA MODEL 3 4-DOOR 2015 Owners Manual
Manufacturer: MAZDA, Model Year: 2015, Model line: MODEL 3 4-DOOR, Model: MAZDA MODEL 3 4-DOOR 2015Pages: 592, PDF Size: 6.08 MB
Page 571 of 592
9–5
Specifi cations
Specifi cations
Lubricant Quality
Lubricant Classifi cation
Engine oil Refer to Recommended Oil on page 6-27 .
Manual transaxle oil API Service GL-4
SAE 75W-80
Automatic transaxle fl uid Mazda Genuine ATF FZ
Brake/Clutch fl uid SAE J1703 or FMVSS116 DOT-3
NOTE
Refer to Introduction on (page 6-2 ) for owner's responsibility in protecting your investment.
Capacities
(Approximate Quantities)
Item Capacity
Engine oil SKYACTIV-G
2.0
With oil fi
lter replacement 4.2 L (4.4 US qt, 3.7 Imp qt)
Without oil fi lter replacement 4.0 L (4.2 US qt, 3.5 Imp qt)
SKYACTIV-G
2.5 With oil fi
lter replacement 4.5 L (4.8 US qt, 4.0 Imp qt)
Without oil fi lter replacement 4.3 L (4.5 US qt, 3.8 Imp qt)
Coolant SKYACTIV-G
2.0 For vehicle
identifi
cation
number beginning
with JM1
*1
Manual transaxle 6.3 L (6.7 US qt, 5.5 Imp qt)
Automatic transaxle 6.5 L (6.9 US qt, 5.7 Imp qt)
For vehicle
identifi cation
number beginning
with 3MZ
*1
Manual transaxle 6.7 L (7.1 US qt, 5.9 Imp qt)
Automatic transaxle 6.9 L (7.3 US qt, 6.1 Imp qt)
SKYACTIV-G
2.5 U.S.A. and
Canada
Manual transaxle 6.5 L (6.9 US qt, 5.7 Imp qt)
Automatic transaxle 6.8 L (7.2 US qt, 6.0 Imp qt)
Mexico Manual transaxle 6.5 L (6.9 US qt, 5.7 Imp qt)
Automatic transaxle 6.7 L (7.1 US qt, 5.9 Imp qt)
Manual transaxle oil 1.70 L (1.80 US qt, 1.50 Imp qt)
Automatic transaxle fl uid 7.8 L (8.2 US qt, 6.9 Imp qt)
Fuel tank U.S.A. and Canada 50.0 L (13.2 US gal, 11.0 Imp gal)
Mexico 51.0 L (13.5 US gal, 11.2 Imp gal)
Check oil and fl uid levels with dipsticks or reservoir gauges.
*1 Check the vehicle identifi cation number on the vehicle identifi cation number plate. Refer to Vehicle
Identifi cation Number on page 9-2 .
. B [ E B @ % 9 & " ' @ & E J U J P O J O E C . B [ E B @ % 9 & " ' @ & E J U J P O J O E C
Page 572 of 592
9–6
Specifi cations
Specifi cations
Dimensions
4-Door
(U.S.A. and Canada)
Item Vehicle specifi cation
Overall length 4,580 mm (180.3 in)
Overall width 1,795 mm (70.7 in)
Overall height 1,455 mm (57.3 in)
Front tread 1,555 mm (61.2 in)
Rear tread 1,560 mm (61.4 in)
Wheelbase 2,700 mm (106.3 in)
(Mexico)
Item Vehicle specifi cation
Overall length 4,580 mm (180.3 in)
Overall width 1,795 mm (70.7 in)
Overall height 1,450 mm (57.1 in)
Front tread 1,555 mm (61.2 in)
Rear tread 1,560 mm (61.4 in)
Wheelbase 2,700 mm (106.3 in)
5-Door
(U.S.A. and Canada)
Item Vehicle specifi cation
Overall length 4,460 mm (175.6 in)
Overall width 1,795 mm (70.7 in)
Overall height
*1 Type A 1,470 mm (57.9 in)
Type B 1,455 mm (57.3 in)
Front tread 1,555 mm (61.2 in)
Rear tread 1,560 mm (61.4 in)
Wheelbase 2,700 mm (106.3 in)
. B [ E B @ % 9 & " ' @ & E J U J P O J O E C . B [ E B @ % 9 & " ' @ & E J U J P O J O E C
Page 573 of 592
9–7
Specifi cations
Specifi cations
(Mexico)
Item Vehicle specifi cation
Overall length 4,460 mm (175.6 in)
Overall width 1,795 mm (70.7 in)
Overall height
*1 Type A 1,465 mm (57.7 in)
Type B 1,450 mm (57.1 in)
Front tread 1,555 mm (61.2 in)
Rear tread 1,560 mm (61.4 in)
Wheelbase 2,700 mm (106.3 in)
*1 The overall height is categorized according to the antenna type as follo\
ws:
Type A
Antenna
Type B
Except above.
Weights
U.S.A. and Canada
SKYACTIV-G 2.0
Item Weight
Manual transaxle Automatic transaxle
GVWR (Gross Vehicle Weight Rating) 1,772 kg (3,907 lbs) 1,815 kg (4,001 lbs)
GAWR (Gross Axle Weight Rating) Front 925 kg (2,039 lbs) 975 kg (2,149 lbs)
Rear 855 kg (1,885 lbs) 848 kg (1,870 lbs)
SKYACTIV-G 2.5
Item Weight
Manual transaxle Automatic transaxle
GVWR (Gross Vehicle Weight Rating) 1,815 kg (4,001 lbs) 1,847 kg (4,072 lbs)
GAWR (Gross Axle Weight Rating) Front 970 kg (2,138 lbs) 997 kg (2,198 lbs)
Rear 865 kg (1,907 lbs) 854 kg (1,883 lbs)
. B [ E B @ % 9 & " ' @ & E J U J P O J O E C . B [ E B @ % 9 & " ' @ & E J U J P O J O E C
Page 574 of 592
9–8
Specifi cations
Specifi cations
Mexico
SKYACTIV-G 2.0
Item Weight
Manual transaxle Automatic transaxle
GVW (Gross Vehicle Weight) Total 1,815 kg (4,001 lbs) 1,835 kg (4,045 lbs)
Front 920 kg (2,028 lbs) 940 kg (2,072 lbs)
Rear 895 kg (1,973 lbs) 895 kg (1,973 lbs)
GAW (Permissible axle load) Front 945 kg (2,083 lbs) 965 kg (2,127 lbs)
Rear 945 kg (2,083 lbs) 945 kg (2,083 lbs)
SKYACTIV-G 2.5
Item
Weight
GVW (Gross Vehicle Weight) Total
1,865 kg (4,112 lbs)
Front 970 kg (2,138 lbs)
Rear 895 kg (1,973 lbs)
GAW (Permissible axle load) Front
995 kg (2,194 lbs)
Rear 945 kg (2,083 lbs)
Air Conditioner
The type of refrigerant used is indicated on a label attached to the ins\
ide of the engine
compartment. Check the label before recharging the refrigerant. Refer to Climate Control
System on page 5-2 .
Item Classifi cation
Refrigerant Type HFC134a (R-134a)
. B [ E B @ % 9 & " ' @ & E J U J P O J O E C . B [ E B @ % 9 & " ' @ & E J U J P O J O E C
Page 575 of 592
*Some models.9–9
Specifi cations
Specifi cations
Light Bulbs
Exterior light
Light bulb Category
Wattage UNECE *1 (SAE)
Headlights Halogen High beam 65 HB3 (9005)
Low beam 55 H11 (H11)
Xenon fusion High/Low beam 35 D4S (D4S)
Daytime
running lights With halogen bulb headlights 65 HB3 (9005)
With xenon fusion bulb headlights LED
*2
— (—)
Parking lights
(Front side-
marker lights) With halogen bulb headlights 5 WY5W (—)
Front side-
marker lights With xenon fusion bulb headlights 5 W5W (—)
Parking lights With xenon fusion bulb headlights LED
*2 — (—)
Front turn signal lights 21 WY21W (7443NA)
Fog lights
* 55 H11 (H11)
Side turn signal lights * LED *2 — (—)
High-mount brake light LED *2 — (—)
Rear turn signal lights 21 WY21W (7443NA)
Brake lights/
Taillights/Rear
side-marker
lights LED type LED
*2
— (—)
Bulb type 21/5 W21/5W (7443)
Taillights (Liftgate side/Trunk lid side)
* LED *2 — (—)
Reverse lights 4–Door 18 W16W (921)
5–Door 21 W21W (7440)
License plate lights 5 W5W (—)
*1 UNECE stands for United Nations Economic Commission for Europe.
*2 LED is the abbreviation for Light Emitting Diode.
. B [ E B @ % 9 & " ' @ & E J U J P O J O E C . B [ E B @ % 9 & " ' @ & E J U J P O J O E C
Page 576 of 592
*Some models.9–10
Specifi cations
Specifi cations
Interior light
Light bulb Category
Wattage UNECE *1
Trunk light (4–Door) 3 —
Luggage compartment light (5–Door) 5 —
Overhead lights (Front)/Map lights
* 8 —
Overhead light (Front) * 10 —
Overhead light (Rear) * 10 —
Vanity mirror lights * 2 —
*1 UNECE stands for United Nations Economic Commission for Europe.
Tires
NOTE
The tires have been optimally matched with the chassis of your vehicle.
When replacing tires, Mazda recommends that you replace tires of the same type originally
fi tted to your vehicle. For details, contact an Authorized Mazda Dealer.
Check the tire pressure label for tire size and infl ation pressure.
Refer to Tire Infl ation Pressure on page 6-42 .
After adjusting the tire pressure, initialization of the tire pressure m\
onitoring system is
necessary to make the system operates normally.
Refer to Tire Pressure Monitoring System Initialization on page 4-106 .
Standard tire
(U.S.A. and Canada)
Tire size Infl
ation pressure
Front Rear
P205/60R16 91H 250 kPa (36 psi) 250 kPa (36 psi)
215/45R18 89W 250 kPa (36 psi) 250 kPa (36 psi)
. B [ E B @ % 9 & " ' @ & E J U J P O J O E C . B [ E B @ % 9 & " ' @ & E J U J P O J O E C
Page 577 of 592
9–11
Specifi cations
Specifi cations
(Mexico)
Tire size Infl
ation pressure
Front Rear
P205/60R16 91H 250 kPa (2.5 bar, 36 psi) 250 kPa (2.5 bar, 36 psi)
Tire size Infl
ation pressure
Up to 3 persons —Full load
215/45R18 89W Front 240 kPa (2.4 bar, 35 psi) 280 kPa (2.8 bar, 41 psi)
Rear 230 kPa (2.3 bar, 33 psi) 300 kPa (3.0 bar, 44 psi)
1 person's weight: About 75 kg
Temporary spare tire
Tire size
Infl ation pressure
T125/70D16 96M 420 kPa (60 psi)
Lug nut tightening torque
When installing a tire, tighten the lug nut to the following torque.
108—147 N•m (12—14 kgf•m, 80—108 ft•lbf)
Fuses
Refer to Fuses on page 6-59 .
. B [ E B @ % 9 & " ' @ & E J U J P O J O E C . B [ E B @ % 9 & " ' @ & E J U J P O J O E C
Page 578 of 592
9–12
Specifi cations
Personalization Features
Personalization Features
The following personalization features can be set or changed by an Authorized Mazda
Dealer. Consult an Authorized Mazda Dealer for details.
Additionally, some of the personalization features can be changed by the customer
depending on the feature.
Personalization features which can be changed differ depending on the market and
specifi cation.
Settings can be changed by operating the center display screen.
Settings can be changed by operating the vehicle switches.
Settings can be changed by an Authorized Mazda Dealer.
Item Feature Factory
Setting Available
Settings Settings change method
Safety Forward
Obstruction
Warning
(FOW)
Refer to
Forward
Obstruction
Warning
(FOW) on
page 4-115 . The system can be
changed so that
Forward Obstruction
Warning (FOW)
does not operate.
*1
On On/Off Refer to
Settings on page 5-55 . — —
The distance at
which the collision
warning activates
can be changed. Near Near/Far
Refer to
Settings on page 5-55 . — —
The volume of the
collision warning
can be changed. High
High/Low/
Off
Refer to Settings on page 5-55 . — —
Smart
City Brake
Support
(SCBS)
Refer to
Smart
City Brake
Support
(SCBS) on
page 4-71 . The system can be
changed so that
Smart City Brake
Support (SCBS)
does not operate.
*1
On On/Off Refer to
Settings on page 5-55 . — —
. B [ E B @ % 9 & " ' @ & E J U J P O J O E C . B [ E B @ % 9 & " ' @ & E J U J P O J O E C
Page 579 of 592
9–13
Specifi cations
Personalization Features
Item Feature Factory
Setting Available
Settings Settings change method
Safety Lane
Departure
Warning
System
(LDWS)
Refer
to Lane
Departure
Warning
System
(LDWS) on
page 4-118 . The warning
sound for the Lane
Departure Warning
System (LDWS) can
be changed.
*2
Beep Beep/Rumbl. Refer to
Settings on page 5-55 . —
The
volume
of the
warning
sound for
the Lane
Departure
Warning
System
(LDWS)
can be
changed. Rumbl. High
High/Mid/
Low
Refer to Settings on page 5-55 . —
Beep High High/Low Refer to
Settings on page 5-55 . —
The sensitivity of
the warning for the
Lane Departure
Warning System
(LDWS) can be
changed. Low High/Low
Refer to
Settings on page 5-55 . —
The warning timing
in which the Lane
Departure Warning
System (LDWS)
determines that
the vehicle may be
deviating from its
lane can be changed. Before At/Before
Refer to
Settings on page 5-55 . —
Blind Spot
Monitoring
(BSM)
system
Refer to
Blind Spot
Monitoring
(BSM)
System on
page 4-107 . The volume of the
BSM warning beep
can be changed.
*3 High
High/
Low/ Off Refer to Settings on page 5-55 . —
. B [ E B @ % 9 & " ' @ & E J U J P O J O E C . B [ E B @ % 9 & " ' @ & E J U J P O J O E C
Page 580 of 592
9–14
Specifi cations
Personalization Features
Item Feature Factory
Setting Available
Settings Settings change method
Vehicle Power door
lock
Refer to
Auto Lock/
Unlock
Function on
page 3-16 .
Changes the auto
lock/unlock function
setting for all the
doors according to
the vehicle speed,
the vehicle power
supply condition,
and the selector
lever position.
Lock: When
Driving
Unlock: IGN Off Lock: Out of
Park Unlock: In Park/ Lock:
Shifting Out of Park/
Lock: When Driving
Unlock: IGN Off/
Lock: When Driving/ Off
Refer to Settings on page 5-55 . Refer to
Auto Lock/ Unlock
Function on page 3-16 .
Keyless
entry system
Refer to
Keyless
Entry
System on
page 3-3 . The method for
unlocking the doors
using the transmitter
can be changed.
Driver's: Once,
All Doors: Twice All Doors:
Once/
Driver's:
Once, All
Doors: Twice Refer to Settings on page 5-55 . Refer to
Transmitter
on page 3-4 .
The time required
for the doors to
relock automatically
after unlocking with
the transmitter can
be changed. 60 seconds
90 seconds/
60 seconds/
30 seconds
Refer to Settings on page 5-55 . —
. B [ E B @ % 9 & " ' @ & E J U J P O J O E C . B [ E B @ % 9 & " ' @ & E J U J P O J O E C
