Page 581 of 592
9–15
Specifi cations
Personalization Features
Item Feature Factory
Setting Available
Settings Settings change method
Vehicle Advanced
keyless
entry system
Refer to
Advanced
Keyless
Entry
System on
page 3-9 . The volume of the
answer-back beep
during advanced
keyless entry system
operation can be
changed.
Medium
High/
Medium/ Low/ Off
Refer to Settings on page 5-55 .
Refer to
Locking,
Unlocking
with Request
Switch (With the advanced keyless
function) on page 3-13 .
The function to
automatically lock
the doors when
leaving the vehicle
while carrying the
key can be changed. Off On/Off
Refer to
Settings on page 5-55 . —
The method for
unlocking the doors
using the request
switch/transmitter
can be changed. Driver's: Once,
All Doors: Twice All Doors:
Once/
Driver's:
Once, All
Doors: Twice Refer to Settings on page 5-55 .
Refer to
Locking,
Unlocking
with Request
Switch (With the advanced keyless
function) on page 3-13 . Refer to
Transmitter
on page 3-4 .
The time required
for the doors to
relock automatically
after unlocking with
the request switch/
transmitter can be
changed. 60 seconds
90 seconds/
60 seconds/
30 seconds
Refer to Settings on page 5-55 . —
Illumination
entry
Refer to
Illuminated
Entry
System on
page 5-136 . The time required
for the interior
lamp to turn off
automatically can be
changed (prevents
battery depletion
when a door is open/
ajar).
30 minutes
60 minutes/
30 minutes/
10 minutes Refer to Settings on page 5-55 . —
The time required
for the interior
lamp to turn off
automatically after
all doors are closed
can be changed. 15 seconds
60 seconds/
30 seconds/
15 seconds/
7.5 seconds
Refer to Settings on page 5-55 . —
. B [ E B @ % 9 & " ' @ & E J U J P O J O E C . B [ E B @ % 9 & " ' @ & E J U J P O J O E C
Page 582 of 592
9–16
Specifi cations
Personalization Features
Item Feature Factory
Setting Available
Settings Settings change method
Vehicle Auto-wiper
control
Refer to
Windshield
Wipers and
Washer on
page 4-51 .
The auto-wiper
control function can
be changed.
On On/Off
*4 Refer to
Settings on page 5-55 . —
Daytime
running
lights
Refer to
Daytime
Running
Lights on
page 4-46 . The function of the
daytime running
lights can be
changed.
On
On/
Off — —
Auto
headlight
off
*5
Refer to
Headlights
on page
4-40 . The time required
for headlights
to turn off after
ignition is switched
off can be changed.
30 seconds 120 seconds/
90 seconds/
60 seconds/
30 seconds/ Off
*6
Refer to Settings on page 5-55 . —
Auto-light
control
Refer to
Headlights
on page
4-40 . The headlight
illumination on/
off timing based
on surrounding
lightness/darkness
can be changed.
Medium
High/
Med. High/ Medium/
Med. Low/ Low
Refer to Settings on page 5-55 . —
High Beam
Control
System
(HBC)
Refer to
High Beam
Control
System
(HBC) on
page 4-47 . The High Beam
Control System
(HBC) function can
be changed.
*1
On On/Off Refer to
Settings on page 5-55 . —
Lights-on
reminder*7
Refer to
Lights-On
Reminder
on page
7-35 . The volume of the
lights-on reminder
warning alarm can
be changed.
Off
High/Low/
Off Refer to Settings on page 5-55 . —
. B [ E B @ % 9 & " ' @ & E J U J P O J O E C . B [ E B @ % 9 & " ' @ & E J U J P O J O E C
Page 583 of 592
9–17
Specifi cations
Personalization Features
Item Feature Factory
Setting Available
Settings Settings change method
Vehicle Turn
indicator
Refer to
Turn and
Lane-
Change
Signals on
page 4-50 .
The turn indicator
beep volume level
can be changed.
High High/Low
Refer to
Settings on page 5-55 . —
Three-fl
ash
turn signal
Refer to
Three-Flash
Turn Signal
on page
4-51 . The three-time fl
ash
function can be
changed. On On/Off
Refer to
Settings on page 5-55 . —
System Distance
unit
The distance unit
can be changed.
mi or km mi/km
Refer to
Settings on page 5-55 . —
Language
The display
language can be
changed.*8 English English/
French/
Spanish Refer to Settings on page 5-55 . —
Temperature
unit
The temperature unit
can be changed.
°F or °C °F/°C Refer to
Settings on page 5-55 . —
Fuel
Economy
Monitor
Refer
to Fuel
Economy
Monitor
on page
4-85 . Ending
display
Setting can be
changed so that the
ending display of
the Fuel Economy
Monitor is
displayed.
Off On/Off
Refer
to Fuel
Economy Monitoron page 4-85 . —
Fuel
economy
resetting
procedure Setting can be
changed so that the
fuel economy reset
is linked with the
trip meter reset.
Off On/Off Refer
to Fuel
Economy Monitoron page 4-85 . —
. B [ E B @ % 9 & " ' @ & E J U J P O J O E C . B [ E B @ % 9 & " ' @ & E J U J P O J O E C
Page 584 of 592
9–18
Specifi cations
Personalization Features
Item Feature Factory
Setting Available
Settings Settings change method
Active
driving
display
Refer to
Active
Driving
Display
on page
4-18 . Turn-by-
Turn (TBT)
Setting can be
changed so that
the Turn-by-Turn
(TBT) of the Active
driving display is
not displayed.
On On/Off
Refer to
Active
driving
display
on page 4-18 . —
*1 Though these systems can be turned Off, doing so will defeat the purpose of the system and Mazda recommends
that these systems remain On.
*2 For vehicles with an audio system other than the on-screen function type\
, the warning sound cannot be changed. The warning sound is only a beep.
*3 Only the volume of the warning beep during Blind Spot Monitoring (BSM)\
operation can be changed. The volume of the warning beep during Rear Cross Traffi c Alert (RCTA) operation cannot be changed.
*4 If the auto-wiper control is set to Off, the wiper lever
position is set to intermittent operation.
*5 If the setting is changed to Off, the following operation is performed according to the headlight switc\
h position:
y At position: Headlights turn off immediately after the ignition is switched off. y At any position other than : Headlights do not turn off after the ignition is switched off.
*6 When set to Off, the lights-on reminder is operable.
*7 The setting of the lights-on reminder can be changed with the time setti\
ng of auto headlight off function set to Off. Refer to Lights-On Reminder on page 7-35 .
*8 Available only in display from the center display.
. B [ E B @ % 9 & " ' @ & E J U J P O J O E C . B [ E B @ % 9 & " ' @ & E J U J P O J O E C
Page 585 of 592
10–1
10Index
. B [ E B @ % 9 & " ' @ & E J U J P O J O E C . B [ E B @ % 9 & " ' @ & E J U J P O J O E C
Page 586 of 592
10–2
Index
A
Accessory Socket .............................. 5-137
Active Driving Display ....................... 4-18
Adaptive Front Lighting System
(AFS)................................................... 4-45
Add-On Non-Genuine Parts and
Accessories ......................................... 8-18
Advanced Key Advanced keyless entry system ...... 3-9
Operational range .......................... 3-10
Advanced Key removed from vehicle
warning beep ....................................... 7-36
Air Bag/Front Seat Belt Pretensioner
System Warning Beep ......................... 7-35
Air Bag Systems ................................. 2-41
Ambient Temperature Display ............ 4-15
Antilock Brake System (ABS) ............ 4-78
Audio Control Switch Adjusting the Volume .................... 5-58
Mute Switch .................................. 5-58
Seek Switch ................................... 5-58
Audio System ...................................... 5-16 AUX/USB/iPod mode ................... 5-59
Antenna ......................................... 5-16
Audio Control Switch ................... 5-57
Audio Set (Type A) ....................... 5-26
Audio Set (Type B) ....................... 5-38
Operating Tips for Audio System ... 5-17
Satellite Radio ............................... 5-47
Automatic Transaxle ........................... 4-29 Active Adaptive Shift (AAS) ........ 4-31
Direct Mode .................................. 4-38
Driving tips.................................... 4-39
Manual shift mode......................... 4-32
Shift-lock system ........................... 4-31
Shift position indication ................ 4-30
Warning light ................................. 4-30
B
Battery ................................................. 6-37 Maintenance .................................. 6-39
Replacement .................................. 6-39
Specifi cations .................................. 9-4
Battery runs out ................................... 7-15
Jump-Starting ................................ 7-15
Blind Spot Monitoring (BSM)
System ............................................... 4-107 BSM OFF switch......................... 4-113
BSM warning light ...................... 4-112
Blind Spot Monitoring (BSM) .... 4-108
Care of radar sensors ................... 4-114
Blind Spot Monitoring (BSM) System
warning beep ....................................... 7-37
Blind Spot Monitoring (BSM) system
Rear Cross Traffi c Alert (RCTA) ... 4-110
Bluetooth® ........................................... 5-77
Bluetooth® Audio (Type A) ......... 5-115
Bluetooth® Audio (Type B) ......... 5-117
Bluetooth® Hands-Free (Type A) ... 5-99
Bluetooth® Hands-Free (Type B) ... 5-105
Troubleshooting .......................... 5-131
Body Lubrication ................................ 6-32
Bottle Holder ..................................... 5-139
Brakes Brakes assist .................................. 4-69
Foot brake...................................... 4-67
Pad wear indicator ......................... 4-68
Parking brake ................................ 4-68
Warning light ................................. 4-68
Break-In Period ................................... 3-45
C
Capacities .............................................. 9-5
Carbon Monoxide ............................... 3-29
Cell Phones ......................................... 8-19
Center Console .................................. 5-141
. B [ E B @ % 9 & " ' @ & E J U J P O J O E C . B [ E B @ % 9 & " ' @ & E J U J P O J O E C
Page 587 of 592
10–3
Index
Child Restraint Child-restraint precautions ............ 2-23
Installing child-restraint systems... 2-29
LATCH child-restraint systems ..... 2-37
Child Safety Locks for Rear Doors ..... 3-20
Climate Control System ........................ 5-2 Automatic Climate Control ............. 5-9
Dual-Zone Automatic Climate
Control........................................... 5-12
Gas specifi cations ............................ 9-8
Manual Climate Control .................. 5-5
Operating Tips ................................. 5-2
Vent Operation ................................ 5-3
Clock ................................................... 5-30
Collision warning ................................ 7-38
Control Status Display ........................ 4-86
Cruise Control ..................................... 4-99 Cruise Control Switch ................... 4-99
Cruise Control Set Vehicle Speed
Display ................................................ 4-16
Cup Holder ........................................ 5-138
Customer Assistance ............................. 8-2
D
Dashboard Illumination ...................... 4-15
Daytime Running Lights ..................... 4-46
Defogger Mirror ............................................ 4-57
Rear window ................................. 4-56
Dimensions ........................................... 9-6
Direct Mode Automatic transaxle ...................... 4-38
Door Locks .......................................... 3-11
Drive selection .................................... 4-87
Driving In Flooded Area ..................... 3-49 Driving Tips
Automatic transaxle ...................... 4-39
Break-in period.............................. 3-45
Driving in fl ooded area.................. 3-49
Driving on uneven road ................. 3-51
Floor mat ....................................... 3-46
Hazardous driving ......................... 3-46
Overloading ................................... 3-50
Rocking the vehicle ....................... 3-47
Winter driving ............................... 3-47
Driving on Uneven Road .................... 3-51
Dynamic Stability Control (DSC) ....... 4-80 DSC OFF Indicator Light.............. 4-81
DSC OFF Switch........................... 4-81
TCS/DSC Indicator Light ............. 4-80
E
Emergency Starting Push-Starting ................................. 7-18
Starting a Flooded Engine ............. 7-18
Emergency Towing Tiedown Hooks ............................. 7-22
Towing Description ....................... 7-21
Emission Control System .................... 3-28
Ending Screen Display ........................ 4-86
Engine Coolant .......................................... 6-29
Engine Compartment Overview .... 6-26
Exhaust gas.................................... 3-29
Hood release .................................. 6-24
Oil .................................................. 6-27
Starting ............................................ 4-5
Essential information ............................ 6-2
Event Data Recorder ........................... 8-20
Exhaust Gas ........................................ 3-29
Exterior Care ....................................... 6-64 Aluminum Wheel Maintenance .... 6-69
Bright-Metal Maintenance ............ 6-68
Maintaining the Finish .................. 6-66
Plastic Part Maintenance ............... 6-69
. B [ E B @ % 9 & " ' @ & E J U J P O J O E C . B [ E B @ % 9 & " ' @ & E J U J P O J O E C
Page 588 of 592
10–4
Index
F
Flasher Hazard warning ............................. 4-58
Headlights ..................................... 4-40
Flat Tire ................................................. 7-3 Mounting the Spare Tire................ 7-11
Removing a Flat Tire ....................... 7-7
Floor Mat ............................................ 3-46
Fluid Brake/Clutch ................................. 6-31
Washer ........................................... 6-31
Fluids Classifi cation ................................... 9-5
Fog Lights ........................................... 4-50
Foot Brake ........................................... 4-67
Forward Obstruction Warning
(FOW) ............................................... 4-115 Collision Warning ....................... 4-117
Forward Obstruction Warning (FOW)
Indicator Light (Red)................... 4-117
Rader Sensor ............................... 4-117
Forward Sensing Camera .................... 4-62
Front Seat .............................................. 2-5
Fuel Filler lid and cap............................ 3-30
Gauge ............................................ 4-14
Requirements................................. 3-27
Tank capacity .................................. 9-5
Fuel Consumption Display ................. 4-85
Fuel Economy Monitor ....................... 4-85 Control status display .................... 4-86
Ending screen display ................... 4-86
Fuel consumption display ............. 4-85
G
Gauges ................................................. 4-11
Glove Compartment .......................... 5-140
H
Hazard Warning Flasher ...................... 4-58
Hazardous Driving .............................. 3-46
Head Restraint ..................................... 2-11
Headlights Control........................................... 4-40
Flashing ......................................... 4-44
High-low beam .............................. 4-44
Leveling......................................... 4-44
High Beam Control System (HBC) .... 4-47
Hill Launch Assist (HLA) ................... 4-69
HomeLink Wireless Control System ... 4-58
Hood Release ...................................... 6-24
Horn .................................................... 4-57
I
i-ELOOP ............................................. 4-82 Control status display .................... 4-84
Display .......................................... 4-82
i-ELOOP indicator light ................ 4-84
i-ELOOP warning beep ....................... 7-37
If a Warning Light Turns On or
Flashes................................................. 7-24
If the Active Driving Display does not
operate ................................................. 7-41
Ignition Switch .............................................. 4-4
Ignition not switched off (STOP) warning
beep ..................................................... 7-36
Immobilizer System ............................ 3-41
Indicator Lights ................................... 4-23 AFS OFF ....................................... 4-45
BSM OFF .................................... 4-113
Low engine coolant temperature ... 4-25
Wrench .......................................... 4-25
Inside Trunk Release Lever ................ 3-25
Inspecting Brake/Clutch Fluid Level ... 6-31
Inspecting Coolant Level .................... 6-29
Inspecting Engine Oil Level ............... 6-28
Inspecting Washer Fluid Level............ 6-31
. B [ E B @ % 9 & " ' @ & E J U J P O J O E C . B [ E B @ % 9 & " ' @ & E J U J P O J O E C
Page 589 of 592
10–5
Index
Interior Care ........................................ 6-70 Cleaning the Lap/Shoulder Belt
Webbing ........................................ 6-72
Cleaning the Upholstery and Interior
Trim ............................................... 6-70
Cleaning the Window Interiors ..... 6-72
Dashboard Precautions .................. 6-70
Maintenance of the Active Driving
Display .......................................... 6-71
Interior Lights ................................... 5-135 Luggage Compartment Light ...... 5-135
Map Lights .................................. 5-135
Overhead Lights .......................... 5-135
J
Jack ....................................................... 7-4
Jump-Starting ...................................... 7-15
K
Key Suspend Function .......................... 3-8
Key left-in-luggage compartment warning
beep (With the advanced keyless
function) .............................................. 7-36
Key left-in-vehicle warning beep (With the
advanced keyless function) ................. 7-37
Keyless Entry System ........................... 3-3
Key removed from vehicle warning
beep ..................................................... 7-36
Keys ...................................................... 3-2 Key suspend function ...................... 3-8
Transmitter ...................................... 3-4
L
Label Information ................................. 9-2
Lane-Change Signals .......................... 4-51
Lane Departure Warning System
(LDWS) ............................................. 4-118 Canceling the system................... 4-122
LDWS warning ........................... 4-123
When the system operates ........... 4-121 Lane departure warning system (LDWS)
warning sound ..................................... 7-37
Liftgate ................................................ 3-20
When liftgate/trunk lid cannot be
opened ........................................... 7-39
Light Bulbs Replacement .................................. 6-46
Specifi cations .................................. 9-9
Lighting Control.................................. 4-40
Lights-on reminder .............................. 7-35
Lubricant Quality .................................. 9-5
Luggage Compartment Light ............ 5-135
M
Maintenance Information ...................................... 6-2
Scheduled ........................................ 6-4
Maintenance Monitor .......................... 6-20
Manual Transaxle Operation ............... 4-26 Recommendations for shifting ...... 4-28
Map Lights ........................................ 5-135
Mazda Radar Cruise Control (MRCC) ... 4-90
Close Proximity Warning .............. 4-93
Display Indication ......................... 4-93
Radar Sensor Handling ................. 4-98
Setting the System ......................... 4-94
Shift-up/Shift-down Request
Display .......................................... 4-98
Mazda Radar Cruise Control (MRCC)
System warnings ................................. 7-38
Meters and Gauges .............................. 4-11
Mirror Defogger .................................. 4-57
Mirrors Outside mirrors.............................. 3-33
Rearview mirror ............................ 3-34
Moonroof ............................................ 3-39
O
Odometer and Trip Meter .................... 4-12
Outside Mirrors ................................... 3-33
Outside Temperature Display .............. 4-15
. B [ E B @ % 9 & " ' @ & E J U J P O J O E C . B [ E B @ % 9 & " ' @ & E J U J P O J O E C
Page 590 of 592
10–6
Index
Over Rev. buzzer ................................. 7-38
Overhead Console ............................. 5-140
Overhead Lights ................................ 5-135
Overheating ......................................... 7-19
Overloading ......................................... 3-50
Owner Maintenance Battery replacement ...................... 6-39
Closing the Hood........................... 6-25
Engine Compartment Overview .... 6-26
Opening the Hood ......................... 6-24
Owner Maintenance Precautions... 6-22
P
Parking Brake ...................................... 4-68
Personalization Features ..................... 9-12
Power Steering .................................... 4-89
Power Windows .................................. 3-36
Power steering warning buzzer ........... 7-38
R
Radar Sensor ....................................... 4-64
Rear Coat Hooks ............................... 5-141
Rear Cross Traffi c Alert (RCTA) ...... 4-110
Rear Door Child Safety Locks ............ 3-20
Rear Seat ............................................... 2-8
Rear View Monitor............................ 4-124
Displayable range on the screen ... 4-126
Picture quality adjustment ........... 4-131
Rear view monitor operation ....... 4-128
Rear view parking camera
location ........................................ 4-125
Switching to the rear view monitor
display ......................................... 4-125
Variance between actual aoad
conditions and displayed Image
... 4-130
Viewing the display ..................... 4-127
Rear Window Defogger ...................... 4-56
Rear Window Washer .......................... 4-55
Rear Window Wiper ............................ 4-55
Rearview Mirror .................................. 3-34
Recommended Oil .............................. 6-27 Recording of Vehicle Data .................. 8-21
Recreational Towing ........................... 3-52
Registering Your Vehicle in A Foreign
Country ............................................... 8-17
Replacement
Electrical battery ........................... 6-39
Fuse ............................................... 6-59
Light Bulbs .................................... 6-46
Tires ............................................... 6-44
Wheel ............................................ 6-45
Wiper ............................................. 6-33
Rocking the Vehicle ............................ 3-47
S
SRS Air Bags Front passenger occupant classifi cation
system ............................................ 2-57
How the SRS air bags work .......... 2-50
Limitations to SRS air bag ............ 2-55
Monitoring..................................... 2-62
SRS air bag deployment criteria ... 2-54
Supplemental restraint system
components ................................... 2-48
Safety Defects, Reporting ................... 8-13
Satellite Radio ..................................... 5-47
Saving Fuel and Protection of the
Environment ........................................ 3-45
Scheduled Maintenance ........................ 6-4
Seat Belt System 2-point type ................................... 2-19
3-point type ................................... 2-16
Automatic locking ......................... 2-15
Emergency locking ........................ 2-15
Extender ........................................ 2-21
Pregnant women ............................ 2-15
Seat belt warning beep ........................ 7-36
Seats
Front seat ......................................... 2-5
Head restraint ................................ 2-11
Rear seat .......................................... 2-8
Seat warmer ..................................... 2-7
. B [ E B @ % 9 & " ' @ & E J U J P O J O E C . B [ E B @ % 9 & " ' @ & E J U J P O J O E C
