If Trouble Arises
Flat Tire
1. Park on a hard, level surface off the right-of-way and fi rmly set the parking
brake.
2. Put a vehicle with an automatic transaxle in Park (P), a manual
transaxle in Reverse (R) or 1, and turn
off the engine.
3. Turn on the hazard warning fl asher.
4. Have everyone get out of the vehicle and away from the vehicle and traf fi c.
5. Remove the jack, tool, and spare tire (page 7-3 ).
6. Block the wheel diagonally opposite the fl at tire. When blocking a wheel,
place a tire block both in front and
behind the tire.


NOTE
When blocking a tire, use rocks or wood
blocks of suffi cient size if possible to hold
the tire in place.

Removing a Flat Tire
WARNING
When jacking-up a vehicle, always
shift the shift lever to 1st or R (manual
transaxle vehicle) or shift the selector
lever to P (automatic transaxle vehicle),
apply the parking brake, and place
wheel blocks in the position diagonally
opposed to the jack: Changing a fl at tire without using
wheel blocks is dangerous because
the vehicle may move and fall off the
jack even with the shift lever in 1st or
R, or the select lever is in P, which could
result in an accident.

1. If your vehicle is equipped with steel wheels, pry off the center cap with the
beveled end of the jack lever.



CAUTION
Use the jack lever when removing
the center cap. Using your hands to
remove it may cause an injury. In
addition, using a tool other than the
jack lever may cause damage to the
wheel or the center cap.

CX-5_8FN1-EA-16L_Edition1.indb 72016/12/12 10:07:19

7–27
If Trouble Arises
Warning/Indicator Lights and Warning Sounds
*Some models.
Signal Warning


(Red)
Brake Pedal
Operation Demand Warning Light
*
When only fl ashing
Flashes if there is the possibility of the vehicle not being held in the\
stopped position by the
AUTOHOLD function, such as on steep slopes. Depress and hold your foot on t\
he brake
pedal.
When fl ashing and beep sound is activated at the same time
The warning light fl ashes and the beep sound is activated for about fi ve seconds if there is
a problem with the system. If the warning light fl ashes and the warning sound is activated,
immediately depress the brake pedal and stop using the AUTOHOLD function then contact
an Authorized Mazda Dealer.
WARNING
Immediately depress the brake pedal if the warning light fl ashes and the beep sound is
activated while using the AUTOHOLD function: Because the AUTOHOLD function is canceled forcibly, the vehicle may move
unexpectedly and result in an accident.


Check Engine Light If this light illuminates while driving, the vehicle may have a problem.\
It is important to
note the driving conditions when the light illuminated and consult an Authorized Mazda
Dealer.
The check engine light may illuminate in the following cases:
 The fuel tank level being very low or approaching empty.
 The engine's electrical system has a problem.
 The emission control system has a problem.
 The fuel- fi ller cap is missing or not tightened securely.
If the check engine light remains on, or it fl ashes continuously , do not drive at high speeds
and consult an Authorized Mazda Dealer as soon as possible.


Automatic
Transaxle Warning
Indication/Warning Light
* The indication/light illuminates when the transaxle has a problem.
CAUTION
If the automatic transaxle warning indication/light illuminates, the transaxle has
an electrical problem. Continuing to drive your Mazda in this condition could cause
damage to your transaxle. Consult an Authorized Mazda Dealer as soon as possible.


AWD Warning Indication
*
“4WD System Malfunction” is displayed
The indication is displayed under the following conditions. The system may have a
malfunction. Have the vehicle checked at an Authorized Mazda Dealer.
 When there is a malfunction in the AWD system.
 When there is a large difference between the tire size of the front and rear wheels.
“4WD System High Load” is displayed
The indication is displayed under the following conditions. Park the veh\
icle in a safe place
and check that the warning indication light turns off, and then drive the vehicle. Contact an
Authorized Mazda Dealer if the indication is continuously displayed.
 When the differential oil temperature is excessively high.
 When there is a large difference between the front and rear wheel rotation, such as when
trying to remove the vehicle from mud.
CX-5_8FN1-EA-16L_Edition1.indb 272016/12/12 10:07:25

7–28
If Trouble Arises
Warning/Indicator Lights and Warning Sounds
*Some models.
Signal Warning


AWD Warning Light
*
When the light is turned on
The light turns on under the following conditions. The system may have a malfunction.
Have the vehicle checked at an Authorized Mazda Dealer.
 When there is a malfunction in the AWD system.
 When there is a large difference between the tire size of the front and rear wheels.
When the light is fl ashing
Park the vehicle in a safe place. After a few moments, if the warning light stops fl ashing,
you can resume driving. If the light does not stop fl ashing, contact an Authorized Mazda
Dealer.
 When the differential oil temperature is excessively high.
 When there is a large difference between the front and rear wheel rotation, such as when
trying to remove the vehicle from mud.

(Turns on)
TCS/DSC Indicator Light If the light stays on, the TCS, DSC or the brake assist system may have a malfunction and
they may not operate correctly. Take your vehicle to an Authorized Mazda Dealer.


Air Bag/Front Seat Belt Pretensioner System Warning Light A system malfunction is indicated if the warning light constantly
fl ashes, constantly
illuminates or does not illuminate at all when the ignition is switched \
ON. If any of these
occur, consult an Authorized Mazda Dealer as soon as possible. The system may not operate
in an accident. WARNING
Never tamper with the air bag/pretensioner systems and always have an Authorized
Mazda Dealer perform all servicing and repairs: Self-servicing or tampering with the systems is dangerous. An air bag/pretensioner
could accidentally activate or become disabled causing serious injury or death.


(Flashing)
Tire Pressure
Monitoring System Warning Light
* If the tire pressure monitoring system has a malfunction, the tire press\
ure warning light
fl
ashes. Have your vehicle checked by an Authorized Mazda Dealer as soon as possible.
WARNING
If the tire pressure monitoring system warning light illuminates or fl ashes, or the tire
pressure warning beep sound is heard, decrease vehicle speed immediately and avoid
sudden maneuvering and braking:
If the tire pressure monitoring system warning light illuminates or fl ashes, or the tire
pressure warning beep sound is heard, it is dangerous to drive the vehicle at high
speeds, or perform sudden maneuvering or braking. Vehicle drivability could worsen
and result in an accident.
To determine if you have a slow leak or a fl at, pull over to a safe position where you can
check the visual condition of the tire and determine if you have enough air to proceed
to a place where air may be added and the system monitored again by an Authorized
Mazda Dealer or a tire repair station.

Do not ignore the TPMS Warning Light: Ignoring the TPMS warning light is dangerous, even if you know why it is illuminated.
Have the problem taken care of as soon as possible before it develops into a more
serious situation that could lead to tire failure and a dangerous accident.
CX-5_8FN1-EA-16L_Edition1.indb 282016/12/12 10:07:25

7–30
If Trouble Arises
Warning/Indicator Lights and Warning Sounds
*Some models.
Signal Warning


Blind Spot
Monitoring (BSM) OFF Indicator Light
* A problem in the system may be indicated under the following conditions.
Have your vehicle inspected at an Authorized Mazda Dealer.
 The light does not turn on when the ignition is switched ON.
 The light remains on even when the Blind Spot Monitoring (BSM) system \
can be operated.
 It turns on while driving the vehicle.
NOTE
If the vehicle is driven on a road with less traf fi c and few vehicles that the radar sensors
can detect, the system may pause (The Blind Spot Monitoring (BSM) OFF\
indicator light in
the instrument cluster illuminates). However, it does not indicate a malfunction.


(Amber)
Mazda Radar
Cruise Control with Stop & Go function (MRCC with Stop & Go function)
Warning Indication
* The message is displayed when the system has a malfunction. Have your ve\
hicle inspected
at an Authorized Mazda Dealer.


(Amber)
Lane-keep Assist System (LAS) & Lane Departure
Warning System
(LDWS) Warning Indication
* The message is displayed when the system has a malfunction. Have your ve\
hicle inspected
at an Authorized Mazda Dealer.
The system does not operate when the warning message is displayed.
CAUTION

Always use tires for all wheels that are of the specifi ed size, and the same manufacture,
brand, and tread pattern. In addition, do not use tires with signifi cantly diff erent wear
patterns on the same vehicle. If such improper tires are used, the system may not operate
normally.
 When an emergency spare tire is used, the system may not operate normally.


LED Headlight Warning Light This light illuminates if there is a malfunction in the LED headlight. H\
ave your vehicle
inspected by an Authorized Mazda Dealer.

CX-5_8FN1-EA-16L_Edition1.indb 302016/12/12 10:07:26

8–25
Customer Information and Reporting Safety Defects
Tire Information (U.S.A.)
Tire Labeling
Federal law requires tire manufacturers to place standardized informatio\
n on the sidewall of
all tires. This information identifi es and describes the fundamental characteristics of the tire
and also provides a tire identi fi cation number for safety standard certi fi cation and in case of
a recall.
Information on Passenger Vehicle Tires
Please refer to the sample below.


1. TIN: U.S. DOT tire identifi cation number
2. Passenger car tire
3. Nominal width of tire in millimeters
4. Ratio of height to width (aspect ratio)
5. Radial
6. Run-fl at tire
7. Rim diameter code
8. Load index & speed symbol
9. Severe snow conditions
10. Tire ply composition and materials used
11. Max. load rating
12. Tread wear, traction and temperature grades
13. Max. permissible in fl ation pressure
14. SAFETY WARNING

P215/65R15 95H is an example of a tire size and load index rating. Here \
is an explanation
of the various components of that tire size and load index rating. Note \
that the tire size and
load index rating may be different from the example.
CX-5_8FN1-EA-16L_Edition1.indb 252016/12/12 10:07:33

8–26
Customer Information and Reporting Safety Defects
Tire Information (U.S.A.)
P
Indicates a tire that may be installed on cars, SUVs, minivans and light\
trucks as designated
by the Tire and Rim Association (T&RA).
NOTE
If your tire size does not begin with a letter this may mean it is designated by ei\
ther ETRTO
(European Tire and Rim Technical Organization) or JATMA (Japan Tire Manufacturing
Association).

215
“215” is the nominal width of the tire in millimeters. This three-digit number gives the
width in millimeters of the tire from sidewall edge to sidewall edge. In\
general, the larger
the number, the wider the tire.
65
“65” is the aspect ratio. This two-digit number indicates the tire's ratio of height to width.
R
“R” is the tire construction symbol. R indicates “Radial ply co\
nstruction”.
15
“15” is the wheel rim diameter in inches.
95
“95” is the Load Index. This two-or three-digit number indicates how much weight each tire
can support.
H
“H” is the speed rating. The speed rating denotes the maximum speed for which the use of
the tire is rated.

Letter Rating Speed Rating
Q 99 mph
R 106 mph
S 112 mph
T 118 mph
U 124 mph
H 130 mph
V 149 mph
W 168
* mph
Y 186 * mph

* For tires with a maximum speed capability over 149 mph, tire manufacture\
rs sometimes use the letters ZR. For tires with a maximum speed capability over 186 mph, tire manufacturers a\
lways use the letters ZR.

CX-5_8FN1-EA-16L_Edition1.indb 262016/12/12 10:07:33

8–27
Customer Information and Reporting Safety Defects
Tire Information (U.S.A.)
M S or M/S: Mud and Snow
AT: All Terrain.
AS: All Season. The “M
S” or “M/S” indicates that the tire has some functional use in \
mud
and snow.
U.S. DOT Tire Identifi cation Number (TIN)
This begins with the letters “DOT” which indicates the tire meets \
all federal standards. The
next two numbers or letters are the plant code where it was manufactured\
, and the last four
numbers represent the week and year the tire was manufactured. For examp\
le, the numbers
457 means the 45st week of 1997. After 2000 the numbers go to four digits. For example,
the number 2102 means the 21th week of 2002. The other numbers are marketing codes
used at the manufacturer's discretion. This information is used to contact consumers if a tire
defect requires a recall.
Tire Ply Composition and Materials Used
The number of plies indicates the number of layers of rubber-coated fabric in the tire.
In general, the greater the number of plies, the more weight a tire can \
support. Tire
manufacturers also must indicate the tire materials, which include steel\
, nylon, polyester,
and other.
Maximum Load Rating
This number indicates the maximum load in kilograms and pounds that can \
be carried by the
tire.
Maximum Permissible Infl ation Pressure
This number is the greatest amount of air pressure that should ever be p\
ut in the tire under
normal driving conditions.
Tread Wear, Traction and Temperature Grades
Tread wear: The tread wear grade is a comparative rating based on the wear rate of t\
he tire
when tested under controlled conditions on a speci fi ed government test course. For example,
a tire graded 150 would wear one and one-half (1 1/2) times as well on\
the government
course as a tire graded 100.
Traction: The traction grades, from highest to lowest are AA, A, B, and C. The grades
represent the tire's ability to stop on wet pavement as measured under c\
ontrolled conditions
on specifi ed government test surfaces of asphalt and concrete. A tire marked C may have
poor traction performance.
Temperature: The temperature grades are A (the highest), B and C, representing the
tire's resistance to the generation of heat and its ability to dissipate\
heat when tested under
controlled conditions on a speci fi ed indoor laboratory test wheel.
Snow Tires
In some heavy snow areas, local governments may require true snow tires,\
those with very
deeply cut tread. These tires should only be used in pairs or placed on all four wheels. M\
ake
sure you purchase snow tires that are the same size and construction typ\
e as the other tires
on your vehicle.
CX-5_8FN1-EA-16L_Edition1.indb 272016/12/12 10:07:33

8–28
Customer Information and Reporting Safety Defects
Tire Information (U.S.A.)
SAFETY WARNING
The following safety warning appears on the tire's sidewall.
SERIOUS INJURY MAY RESULT FROM:
  EXPLOSION OF TIRE/RIM ASSEMBLY DUE TO IMPROPER MOUNTING-MATCH
TIRE DIAMETER TO RIM DIAMETER; NEVER EXCEED 40 psi (275 kPa) TO SEAT
BEADS-ONLY SPECIALLY TRAINED PERSONS SHOULD MOUNT TIRES.
   TIRE FAILURE DUE TO UNDER-INFLATION/OVERLOADING/DAMAGE-
FOLLOW OWNER'S MANUAL AND PLACARD IN VEHICLE-FREQUENTLY
CHECK INFLATION PRESSURE AND INSPECT FOR DAMAGE.

Information on Temporary Tires
Please refer to the sample below.


1. Temporary tires
2. Nominal width of tire in millimeters
3. Ratio of height to width (aspect ratio)
4. Diagonal
5. Rim diameter code
6. Load index & speed symbol

T115/70D16 90M is an example of a tire size and load index rating. Here is an explanat\
ion
of the various components of that tire size and load index rating. Note \
that the tire size and
load index rating may be different from the example.
CX-5_8FN1-EA-16L_Edition1.indb 282016/12/12 10:07:33

8–30
Customer Information and Reporting Safety Defects
Tire Information (U.S.A.)
Location of the Tire Label (Placard)
You will fi nd the tire label containing tire in fl ation pressure by tire size and other important
information on the driver's side B-pillar or on the edge of the driver's\
door frame.

SAMPLE


Recommended Tire Infl ation Pressure
On the tire label you will fi nd the recommended tire in fl ation pressure in both kPa and
psi for the tires installed as original equipment on the vehicle. It is \
very important that the
infl ation pressure of the tires on your vehicle is maintained at the recomme\
nded pressure.
You should check the tire pressure regularly to insure that the proper in\
fl ation pressure is
maintained.
Refer to Tires on page 9-9 .
NOTE
Tire pressures listed on the vehicle placard or tire information label indicate the
recommended cold tire in fl ation pressure, measured when the tires are cold, after the vehicle
has been parked for at least 3 hours. As you drive, the temperature in the tire warms up,
increasing the tire pressure.

CX-5_8FN1-EA-16L_Edition1.indb 302016/12/12 10:07:33

8–32
Customer Information and Reporting Safety Defects
Tire Information (U.S.A.)
Glossary of Terms
Tire Placard: A label indicating the OE tire sizes, recommended in fl ation pressure, and the
maximum weight the vehicle can carry.
Tire Identifi cation Number (TIN): A number on the sidewall of each tire providing
information about the tire brand and manufacturing plant, tire size, and\
date of manufacture.
Infl ation Pressure: A measure of the amount of air in a tire.
kPa: Kilopascal, the metric unit for air pressure.
psi: Pounds per square inch, the English unit for air pressure.
B-pillar: The structural member at the side of the vehicle behind the front door.
Original Equipment (OE): Describes components originally equipped on the vehicle.
Vehicle Load Limit: The maximum value of the combination weight of occupants and
cargo.
Bead Area of the Tire: Area of the tire next to the rim.
Sidewall Area of the Tire: Area between the bead area and the tread.
Tread Area of the Tire: Area on the perimeter of the tire that contacts the road when it's
mounted on the vehicle.

Seating capacity means the total allowable number of vehicle occupants. Seating capacity\

is described on the tire label.

Production options weight is the combination weight of installed regular production
options weighing over 2.3 kilograms in excess of the standard items whic\
h they replace,
and not previously considered in the curb weight or accessory weight, in\
cluding heavy duty
brakes, ride levelers, roof rack, heavy duty battery, and special trim.

Rim is the metal support (wheel) for a tire or a tire and tube assembly u\
pon which the tire
beads are seated.
CX-5_8FN1-EA-16L_Edition1.indb 322016/12/12 10:07:33
