MAZDA MODEL CX-5 2017 Owners Manual (in English)

4–67
When Driving
Switches and Controls
Pre-programming the HomeLink System
NOTE
It is recommended that a new battery be
placed in the hand-held transmitter of the
device being programmed to HomeLink
for quicker training and accurate
transmission of the radio-frequency signal.
   Verify that there is a remote control
transmitter available for the device you
would like to program.
   Disconnect the power to the device.
Programming the HomeLink
System
CAUTION
When programming a garage door
opener or a gate, disconnect the power
to these devices before performing
programming. Continuous operation
of the devices could damage the
motor.

The HomeLink system provides 3 buttons
which can be individually selected and
programmed using the transmitters for
current, on-market devices as follows:

1. Disconnect the power to the garage
door opener or gate programmed to the
hand-held transmitter.
2. Position the end of your hand-held transmitter 2.5—7.5 cm (1—3 inches)
away from the HomeLink button you
wish to program while keeping the
indicator light in view. 3. Simultaneously press and hold both
the chosen HomeLink and hand-held
transmitter buttons. Do not release
the buttons until step 3 has been
completed.
NOTE
Some gate operators and garage door
openers may require you to replace this
Programming Step 2 with procedures
noted in the “Gate Operator/Canadian
Programming” section.

4. After the HomeLink indicator light changes from a slow to a rapidly
blinking light, release both the
HomeLink and hand-held transmitter
buttons.
NOTE
If the HomeLink indicator light does not
change to a rapidly blinking light, contact
HomeLink at www.homelink.com or call
1-800-355-3515 for assistance.

5. Connect the power to the garage door opener or gate programmed to the
hand-held transmitter.
CX-5_8FN1-EA-16L_Edition1.indb 672016/12/12 10:05:59

4–68
When Driving
Switches and Controls
6. Firmly press and hold the programmed HomeLink button for fi ve seconds,
and then release it. Perform this
operation two times to activate the door
or gate. If the door or gate does not
activate, press and hold the just-trained
HomeLink button and observe the
indicator light.
If the indicator light stays on constantly, programming is complete
and your device should activate when
the HomeLink button is pressed and
released.
NOTE
To program the remaining two HomeLink
buttons, begin with “Programming” —
step 1

If the indicator light blinks rapidly
for two seconds and then turns
to a constant light, continue with
“Programming” steps 7—9 to
complete the programming of a rolling
code equipped device (most commonly
a garage door opener).
7. At the garage door opener receiver (motor-head unit) in the garage, locate
the “learn” or “smart” button. This can
usually be found where the hanging
antenna wire is attached to the motor-
head unit.
8. Firmly press and release the “learn” or “smart” button. (The name and color of
the button may vary by manufacturer.)
NOTE
Complete the programming within
30 seconds.

9. Return to the vehicle and fi rmly press,
hold for two seconds and release the
programmed HomeLink button. Repeat
the “ press/hold/release ” sequence a
second time, and, depending on the
brand of the garage door opener (or
other rolling code equipped device),
repeat this sequence a third time to
complete the programming process.

HomeLink should now activate your
rolling code equipped device.
NOTE
To program the remaining two HomeLink
buttons, begin with “Programming” —
step 1

For questions or comments, please contact
HomeLink at www.homelink.com or
1-800-355-3515 .
CX-5_8FN1-EA-16L_Edition1.indb 682016/12/12 10:05:59

4–69
When Driving
Switches and Controls
Gate operator/Canadian Programming
Canadian radio-frequency laws require
transmitter signals to “time-out” (or quit)
after several seconds of transmission
— which may not be long enough for
HomeLink to pick up the signal during
programming. Similar to this Canadian
law, some U.S. gate operators are designed
to “time-out” in the same manner.

If you live in Canada or you are having
diffi culties programming a gate operator
by using the “Programming” procedures
(regardless of where you live), replace
“Programming HomeLink” step 3 with
the following:
NOTE
If programming a garage door opener or
gate operator, it is advised to unplug the
device during the “cycling” process to
prevent possible overheating.

Continue to press and hold the HomeLink
button while you press and release
— every two seconds (“cycle”) your
hand-held transmitter until the frequency
signal has successfully been accepted by
HomeLink. (The indicator light will fl ash
slowly and then rapidly.)
Proceed with “Programming” step 4 to
complete.
Operating the HomeLink System
Press the programmed HomeLink button
to operate a programmed device. The
code will continue being transmitted for a
maximum of 20 seconds.
Reprogramming the HomeLink system
To program a device to HomeLink using
a HomeLink button previously trained,
follow these steps:

1. Press and hold the desired HomeLink
button. DO NOT release the button.
2. The indicator light will begin to fl ash
after 20 seconds. Without releasing
the HomeLink button, proceed with
“Programming” - step 1.

Erasing Programmed HomeLink Buttons
To erase the existing programming from
all three operating channels, press and
hold the two outside buttons (
, ) on
the auto-dimming mirror until the
HomeLink indicator light begins to fl ash
after approximately 10 seconds.
Verify that the programming has been
erased when you resell the vehicle.
CX-5_8FN1-EA-16L_Edition1.indb 692016/12/12 10:05:59

4–70
When Driving
Brake
Brake System
Foot Brake
This vehicle has power-assisted brakes
that adjust automatically through normal
use.

Should power-assist fail, you can stop by
applying greater force than normal to the
brake pedal. But the distance required to
stop will be greater than usual.
WARNING
Do not coast with the engine stalled or
turned off , fi nd a safe place to stop: Coasting with the engine stalled or
turned off is dangerous. Braking will
require more eff ort, and the brake's
power-assist could be depleted if
you pump the brake. This will cause
longer stopping distances or even an
accident.

Shift to a lower gear when going down
steep hills: Driving with your foot continuously on
the brake pedal or steadily applying
the brakes for long distances is
dangerous. This causes overheated
brakes, resulting in longer stopping
distances or even total brake failure.
This could cause loss of vehicle
control and a serious accident. Avoid
continuous application of the brakes.

Dry off brakes that have become
wet by driving slowly, releasing the
accelerator pedal and lightly applying
the brakes several times until the brake
performance returns to normal: Driving with wet brakes is dangerous.
Increased stopping distance or the
vehicle pulling to one side when
braking could result in a serious
accident. Light braking will indicate
whether the brakes have been aff ected.

CX-5_8FN1-EA-16L_Edition1.indb 702016/12/12 10:05:59

4–71
When Driving
Brake
CAUTION
 Do not drive with your foot held on the clutch pedal or brake pedal, or hold
the clutch pedal depressed halfway
unnecessarily. Doing so could result in
the following:
 The clutch and brake parts will wear out more quickly.
 The brakes can overheat and adversely aff ect brake performance.
 Always depress the brake pedal with
the right foot. Applying the brakes with
the unaccustomed left foot could slow
your reaction time to an emergency
situation resulting in insuffi cient braking
operation.

 Wear shoes appropriate for driving in order to avoid your shoe contacting
the brake pedal when depressing the
accelerator pedal.

Electric Parking Brake (EPB)
The electric parking brake (EPB)
equipment applies the parking brake
using an electric motor. When the
electric parking brake (EPB) is applied,
the electric parking brake (EPB) switch
indicator light turns on.

Indicator light

WARNING
Do not drive the vehicle with the electric
parking brake (EPB) applied: If the vehicle is driven with the parking
brake applied, the brake parts may
generate heat and the brake system
may not operate, leading to an
accident.
Before driving, release the electric
parking brake (EPB) and verify that the
electric parking brake (EPB) indicator
light is turned off .

NOTE
  The electric parking brake (EPB)
cannot be applied or released while the
vehicle battery is dead.
  If the electric parking brake (EPB) is
repeatedly applied and released it may
stop operating to prevent overheating
of the motor. If this occurs, wait approx.
1 minute before operating the electric
parking brake (EPB) switch again.
CX-5_8FN1-EA-16L_Edition1.indb 712016/12/12 10:05:59

4–72
When Driving
Brake
  An operation sound occurs when
applying or releasing the electric
parking brake (EPB), however, this does
not indicate a malfunction.
  If the electric parking brake (EPB) is
not used for long periods, an automatic
inspection of the system is performed
while the vehicle is parked. An
operation sound can be heard, however,
this does not indicate a problem.
  When the electric parking brake (EPB)
is applied and the ignition is switched
OFF, an operation sound can be heard,
however, this does not indicate a
problem.
  The brake pedal may move while the
electric parking brake (EPB) is being
applied or released, however, this does
not indicate a problem.
  If the electric parking brake (EPB)
switch is continually pulled while
driving the vehicle, the electric parking
brake (EPB) will be applied and the
electric parking brake (EPB) warning
beep will be activated. When the switch
is released, the electric parking brake
(EPB) is released and the beep stops.
  If the electric parking brake (EPB) is
applied with the ignition switched off
or in ACC, the electric parking brake
(EPB) indicator light in the instrument
cluster and the indicator light in the
switch may turn on for 15 seconds.
  When running the vehicle through an
automatic car wash, it may be necessary
to switch the ignition off with the
parking brake released depending on
the type of automatic car wash.

When applying the electric parking
brake (EPB)
The electric parking brake (EPB) can be
applied regardless of the ignition switch
position.
Securely depress the brake pedal and
pull up the electric parking brake (EPB)
switch.
The electric parking brake (EPB) is
applied and the electric parking brake
(EPB) indicator light and the electric
parking brake (EPB) switch indicator light
turn on.
Refer to Warning/Indicator Lights on page
4-32 .


CX-5_8FN1-EA-16L_Edition1.indb 722016/12/12 10:06:00

4–73
When Driving
Brake
When releasing the electric parking
brake (EPB)
The electric parking brake (EPB) can be
released while the ignition is switched
ON or the engine is running. When the
electric parking brake (EPB) is released,
the electric parking brake (EPB) indicator
light and the electric parking brake (EPB)
switch indicator light turn off.
electric parking brake (EPB) manual
release
Securely depress the brake pedal and press
down the electric parking brake (EPB)
switch.
Indicator light

Firmly depress the brake pedal and press
the electric parking brake (EPB) switch.
If the electric parking brake (EPB) switch
is pressed without depressing the brake
pedal, the display or indicator light in the
instrument cluster noti fi es the driver that
the brake is not depressed.
(Type A instrument cluster)
A message is displayed on the multi-
information display in the instrument
cluster.
Refer to Message Indicated in Multi-
information Display on page 7-35 . (Type B instrument cluster)
The brake pedal operation demand
indicator light (green) in the instrument
cluster turns on.

(Green)
electric parking brake (EPB) automatic
release
If the accelerator pedal is depressed with
the electric parking brake (EPB) applied
and all of the following conditions met, the
parking brake is released automatically.
   The engine is running.  The driver's door is closed.  The driver's seat belt is fastened.
(Manual transaxle)   The change lever is in a position other
than neutral.
   The clutch pedal is depressed halfway
(Automatic transaxle)   Selector lever is in the D, M, or R
position

NOTE
If something such as the driver's foot
contacts the accelerator pedal with the
engine running and the electric parking
brake (EPB) applied, the parking brake
may be released automatically. If you
do not intend to drive immediately, shift
the change lever (manual transaxle) to
the neutral position, or shift the selector
lever (automatic transaxle) to the P or N
position.

CX-5_8FN1-EA-16L_Edition1.indb 732016/12/12 10:06:00

4–74
When Driving
Brake
Warning Light
The warning light turns on when the
system has a malfunction.
Refer to Warning Indication/Warning
Lights on page 4-33 .
Brake Pad Wear Indicator
When the disc brake pads become worn,
the built-in wear indicators contact the
disc plates. This causes a screeching noise
to warn that the pads should be replaced.

When you hear this noise, consult an
Authorized Mazda Dealer as soon as
possible.
WARNING
Do not drive with worn disc pads: Driving with worn disc pads is
dangerous. The brakes could fail and
cause a serious accident. As soon as
you hear a screeching noise consult an
Authorized Mazda Dealer.

Brake Assist
During emergency braking situations
when it is necessary to depress the brake
pedal with greater force, the brake assist
system provides braking assistance, thus
enhancing braking performance.

When the brake pedal is depressed hard or
depressed more quickly, the brakes apply
more fi rmly.
NOTE
  When the brake pedal is depressed hard
or depressed more quickly, the pedal
will feel softer but the brakes will apply
more fi rmly. This is a normal effect of
the brake assist operation and does not
indicate a malfunction.
   When the brake pedal is depressed
hard or depressed more quickly, a
motor/pump operation noise may be
heard. This is a normal effect of the
brake assist and does not indicate a
malfunction.
  The brake assist equipment does not
supersede the functionality of the
vehicle's main braking system.

CX-5_8FN1-EA-16L_Edition1.indb 742016/12/12 10:06:00

4–75
When Driving
Brake
AUTOHOLD
The AUTOHOLD function automatically holds the vehicle stopped, even if you take your
foot off the brake pedal. This function can be best used while stopped in traffi c or at a traf fi c
light. The brakes will automatically release when you start driving again (rel\
easing the
clutch pedal while in gear (manual transaxle) or depressing the accele\
rator pedal (automatic
transaxle)).
CX-5_8FN1-EA-16L_Edition1.indb 752016/12/12 10:06:01

4–76
When Driving
Brake
WARNING
Do not rely completely on the AUTOHOLD function: The AUTOHOLD function is only designed to assist the brake operation while the vehicle
is stopped. Neglecting to operate the brakes and relying only on the AUTOHOLD system
is dangerous and could result in an unexpected accident if the vehicle were to suddenly
move. Operate the brakes appropriately in accordance with the road and surrounding
conditions.

Do not release your foot from the brake pedal while the vehicle is stopped on a steep
grade: Because there is a possibility of the vehicle not being held in the stopped position by the
AUTOHOLD function, the vehicle may move unexpectedly and result in an accident.

Do not use the AUTOHOLD function on slippery roads such as icy or snow-covered
roads, or unpaved roads: Even if the vehicle is held in the stopped position by the AUTOHOLD function, the vehicle
may move unexpectedly and result in an accident. Operate the accelerator pedal, brakes,
or steering wheel appropriately as necessary.

Immediately depress the brake pedal in the following cases: Because the AUTOHOLD function is canceled forcibly, the vehicle may move unexpectedly
and result in an accident.
 The brake pedal operation request warning light (red) fl ashes and the warning sound is activated at the same time.

(Red)  [Brake Hold Unavailable Depress Brake to Hold Position] is displayed in the multi-information display and the warning sound is activated at the same time.

Always apply the electric pa rking brake (EPB) when parking the vehicle:
Not applying the electric parking brake (EPB) when parking the vehicle is dangerous as
the vehicle may move unexpectedly and result in an accident. When parking the vehicle,
shift the selector lever to the P position (automatic transaxle vehicle) and apply the
electric parking brake (EPB).

CX-5_8FN1-EA-16L_Edition1.indb 762016/12/12 10:06:01
