MAZDA MODEL CX-5 2017 Owners Manual (in English)

4–127
When Driving
i-ACTIVSENSE
Turning on the system
When the MODE switch is pressed once, the Mazda Radar Cruise Control with Stop & Go
function (MRCC with Stop & Go function) system turns on, and the Mazda\
Radar Cruise
Control with Stop & Go function (MRCC with Stop & Go function) system \
main indication
(white) turns on and the vehicle speed and the distance between the ve\
hicles while in
headway control can be set.


In addition, the Mazda Radar Cruise Control with Stop & Go function (MR\
CC with Stop &
Go function) system display indication is displayed on the multi-inform\
ation display and the
active driving display at the same time.
NOTE
   If the ignition is switched off while the Mazda Radar Cruise Control with Stop & Go
function (MRCC with Stop & Go function) system is operating, the syste\
m will be
operable when the ignition is switched ON the next time.
  When the MODE switch is pressed a second time while the Mazda Radar Cruise Control
with Stop & Go function (MRCC with Stop & Go function) system is operating, the system
switches to the cruise control function.
 Refer to Cruise Control Function on page 4-133 .
CX-5_8FN1-EA-16L_Edition1.indb 1272016/12/12 10:06:10

4–128
When Driving
i-ACTIVSENSE
How to set the speed
1. Adjust the vehicle speed to the desired setting using the accelerator pe\
dal.
2. Headway control begins when the SET
or SET switch is pressed.
The set speed and the inter-vehicle distance display fi lled with white lines is displayed.
The Mazda Radar Cruise Control with Stop & Go function (MRCC with Stop \
& Go
function) main indicator (white) switches to the Mazda Radar Cruise C\
ontrol with Stop
& Go function (MRCC with Stop & Go function) set indicator (green) a\
t the same time.



Travel status Multi-information display Active driving display
During travel at constant speed


During travel under headway control



NOTE
 
 If a vehicle ahead is detected while traveling at a constant speed, the \
vehicle-ahead
indication is displayed and headway control is performed. Additionally, when a vehicle
ahead is no longer detected, the vehicle-ahead indication turns off and \
the system
switches back to travel at constant speed.
  The lowest possible speed which can be set on the Mazda Radar Cruise Con\
trol with Stop
& Go function (MRCC with Stop & Go function) system is 30 km/h (20 mp\
h).
  Headway control is not possible if the vehicle ahead is driving faster than your vehi\
cle's
set speed. Adjust the system to the desired vehicle speed using the accelerator pedal.

CX-5_8FN1-EA-16L_Edition1.indb 1282016/12/12 10:06:10

4–129
When Driving
i-ACTIVSENSE
How to set the distance-between-vehicles during headway control
The distance-between-vehicles is set to a shorter distance by pressing t\
he
switch. The
distance-between-vehicles is set to a longer distance by pressing the
switch. The distance-
between-vehicles can be set to 4 levels; Long, medium, short, and extrem\
ely short distance.

Distance-between-vehicles guideline
(at 80 km/h (50 mph) vehicle speed) Indication on multi-information
display Indication on active driving
display
*1
Long (about 50 m (164 ft))


Medium (about 40 m (131 ft))


Short (about 30 m (98 ft))


Extremely short (about 25 m (82 ft))


*1 Displays a pop-up image in the active driving display only when the driv\
er operates the switch.


NOTE
   The distance-between-vehicles differs depending on the vehicle speed, an\
d the slower the
vehicle speed, the shorter the distance.
  When the ignition is switched to ACC or OFF and then the engine is started again, the
system automatically sets the distance-between-vehicles to the previous setting.

CX-5_8FN1-EA-16L_Edition1.indb 1292016/12/12 10:06:11

4–130
When Driving
i-ACTIVSENSE
How to change the set vehicle speed
To accelerate/decelerate using the SET
switch
When you press the SET
switch, the
vehicle accelerates and when you press the
SET
switch, it decelerates.

Short press 1 km/h (1 mph)
Long press 10 km/h (5 mph)

NOTE
For example, the set vehicle speed is
changed by pressing the SET switch four
times as follows:
The vehicle speed accelerates or
decelerates by 4 km/h (4 mph).

To increase speed using accelerator
pedal
Depress the accelerator pedal and press
and release the SET
switch or SET
switch at the desired speed. If the switch is
not operated, the system returns to the set
speed after you release your foot from the
accelerator pedal.
CAUTION
The warnings and brake control do not
operate while the accelerator pedal is
depressed.

NOTE
   The setting speed can be changed by
operating the SET
switch or SET
switch during stop hold control.
   When accelerating using the SET
switch while in headway control, the set
vehicle speed can be adjusted but
acceleration is not possible. If there is
no longer a vehicle ahead, acceleration
continues until reaching the set vehicle
speed. For the set vehicle speed, check
the set vehicle speed indication in the
display.
   When depressing the accelerator pedal,
the inter-vehicle distance indication in
the display changes to the white-line
indication.

Canceling the system
When the following operations are
performed, the Mazda Radar Cruise
Control with Stop & Go function (MRCC
with Stop & Go function) system is
canceled, and the Mazda Radar Cruise
Control with Stop & Go function (MRCC
with Stop & Go function) set indicator
(green) switches to the Mazda Radar
Cruise Control with Stop & Go function
(MRCC with Stop & Go function) main
indicator (white) at the same time.
  The OFF/CAN switch is pressed.  The brake pedal is depressed.  The electric parking brake (EPB) is
applied.
   The selector lever is in the P (Park), N
(Neutral), or R (Reverse) position.
   Any of the doors is opened.  The driver's seat belt is unfastened.

CX-5_8FN1-EA-16L_Edition1.indb 1302016/12/12 10:06:12

4–131
When Driving
i-ACTIVSENSE
Under the following conditions, the
Mazda Radar Cruise Control with Stop
& Go function (MRCC with Stop & Go
function) cancel indication is displayed in
the multi-information display and a single
beep sound is heard.
  The DSC has operated.  The Smart Brake Support (SBS) has
operated.
   The Smart City Brake Support (SCBS)
has operated.
   When traveling on a downslope for a
long period of time.
   There is a problem with the system.  The engine has stalled.  The electric parking brake (EPB) is
automatically applied during stop hold
control.
   The radar sensor (front) cannot detect
target objects (during rain, fog, snow or
other inclement weather conditions, or
when the radiator grille is dirty).

Resuming control
If the Mazda Radar Cruise Control with
Stop & Go function (MRCC with Stop &
Go function) system is canceled, you can
resume control at the previously set speed
by pressing the RES switch and after all of
the operation conditions have been met.
NOTE
If the set speed is not indicated in the
display, the control does not resume even
if the RES switch is pressed.

Turning off the system
Press the OFF/CAN switch two times
while the Mazda Radar Cruise Control
with Stop & Go function (MRCC with
Stop & Go function) system is operating to
switch off the system.
CX-5_8FN1-EA-16L_Edition1.indb 1312016/12/12 10:06:12

4–132
When Driving
i-ACTIVSENSE
Stop Hold Control
While in headway control using the Mazda Radar Cruise Control with Stop \
& Go function
(MRCC with Stop & Go function) system, your vehicle will stop when a v\
ehicle ahead
stops. When the vehicle is stopped and the stop hold control operates, the Mazd\
a Radar
Cruise Control with Stop & Go function (MRCC with Stop & Go function) \
indicator light
turns on.


NOTE
  If the Mazda Radar Cruise Control with Stop & Go function (MRCC with Stop & Go
function) system is canceled during stop hold control, the vehicle is held in its stopped
position. The stop hold control can be canceled by performing one the following actions.
  Press the accelerator pedal and resume driving the vehicle.  While forcefully depressing the brake, switch the Mazda Radar Cruise Control with
Stop & Go function (MRCC with Stop & Go function) system off.
  The electric parking brake (EPB) is automatically applied and the vehi\
cle is held in its
stopped position when 10 minutes have elapsed since the stop hold control operated. At
this time, the Mazda Radar Cruise Control with Stop & Go function (MRCC with Stop &
Go function) system is canceled.
  The brake lights turn on during stop hold control.
To resume driving
After the vehicle ahead starts moving while your vehicle is stopped unde\
r stop hold control,
press the RES switch or depress the accelerator pedal to cancel the stop hold control\
and
resume driving.
NOTE
  When you resume driving by pressing the RES switch, your vehicle does not start moving
until the distance between your vehicle and the vehicle ahead lengthens \
to the speci fi ed
distance or farther.
   If the Mazda Radar Cruise Control with Stop & Go function (MRCC with Stop & Go
function) is temporarily canceled during stop hold control, you cannot resume driving by
pressing the RES switch when there are no vehicles in front of your vehicle. Depress the
accelerator pedal and resume driving the vehicle.

CX-5_8FN1-EA-16L_Edition1.indb 1322016/12/12 10:06:13

4–133
When Driving
i-ACTIVSENSE
Resume driving information
If you do not resume driving within a few seconds after the vehicle ahea\
d starts moving,
the multi-information display vehicle-ahead indication fl ashes to urge the driver to resume
driving.
Cruise Control Function
While this function is operating, the
headway control operation is canceled and
only the cruise control function operates.
The vehicle speed can be set more than
about 25 km/h (16 mph).
Use the cruise control function on
expressways and other highways which do
not require a lot of repeated acceleration
and deceleration.
WARNING
Do not use the cruise control function in
the following locations: Otherwise, it could lead to an accident.
 Roads with sharp curves and where vehicle traffi c is heavy and there is
insuffi cient space between vehicles.
(Driving under these conditions
using the cruise control function is
not possible)
 Steep down slopes (Set speed may be exceeded because suffi cient
engine braking cannot be applied)
 Slippery roads such as ice or snow- bound roads (Tires could spin
causing you to lose vehicle control)

Always drive carefully: The warnings and brake control
will not operate after the headway
control function is canceled and the
system is switched to only the cruise
control function. Depress the brake
pedal to decelerate according to the
surrounding conditions while keeping
a safer distance from the vehicle ahead
and always driving carefully.

Switching to cruise control function
When the MODE switch is pressed while
the Mazda Radar Cruise Control with Stop
& Go function (MRCC with Stop & Go
function) system is turned on, the system
switches to the cruise control function.
When the system switches to the cruise
control function, the indicator and multi-
information display notify the driver as
follows:
  The Mazda Radar Cruise Control with
Stop & Go function (MRCC with Stop
& Go function) set indication (green)
or the Mazda Radar Cruise Control
with Stop & Go function (MRCC with
Stop & Go function) main indication
(white) is turned off, and the cruise main
indication (white) is turned on.
   A message is displayed in the multi-
information display.

WARNING
Always turn off the cruise control
function when it is not in use: Leaving the cruise control function
turned on when it is not in use
is dangerous as it could operate
unexpectedly, resulting in an accident.

How to set the speed
Adjust the system to the desired vehicle
speed using the accelerator pedal.
When the SET
or SET switch is
pressed, the cruise set indication (green) is
turned on and headway control begins.
CX-5_8FN1-EA-16L_Edition1.indb 1332016/12/12 10:06:13

4–134
When Driving
i-ACTIVSENSE
NOTE
  The system may not be able to maintain
the set speed constantly depending on
driving conditions such as steep up or
down slopes.
  The speed will continue increasing
while the SET
switch is pressed and
held. The speed will continue
decreasing while the SET
switch is
pressed and held.

How to increase the set speed
The set speed can be increased using the
following operations:
To increase speed using the SET

switch
Press and hold the SET
switch and
release the switch at the desired speed.
The set speed can be adjusted
incrementally (1 km/h (1 mph)
increments) by pressing the switch and
releasing it immediately. For example, if
the switch is pressed 4 times, the set speed
increases by about 4 km/h (4 mph).
To increase speed using accelerator
pedal
Depress the accelerator pedal and press the
SET
or SET switch at the desired
speed.
If the switch is not operated, the system
returns to the set speed after you release
your foot from the accelerator pedal.
How to Decrease the Set Speed
Press the SET
switch continuously and
release the switch at the desired speed.
The set speed can be adjusted
incrementally (1 km/h (1 mph) increments)
by pressing the switch and releasing it
immediately. For example, if the switch
is pressed 4 times, the set vehicle speed
decreases by about 4 km/h (4 mph).
Cancelling the function
Cancelling using OFF/CAN switch
When the OFF/CAN switch is pressed
once, the cruise control function is
cancelled.
Cancelling using MODE switch
When the MODE switch is pressed, the
cruise control function is canceled and
the headway control function is made
available for operation.
The cruise control function is canceled
automatically in the following cases. If the
RES switch is pressed while the vehicle
speed is 25 km/h (16 mph) or higher, the
speed returns to the original set speed.
   The OFF/CAN switch is pressed once.  The brake pedal is depressed.  The parking brake is applied.   The selector lever is shifted to P or N
position.

NOTE
   If the vehicle speed decreases by about
15 km/h (9.4 mph) or more than the set
speed, the cruise control function may
be canceled.
  When the vehicle speed is less than
21 km/h (13 mph), the cruise control
function is canceled. In this case, the
vehicle speed will not return to the
original set speed even if the vehicle
is accelerated to 25 km/h (16 mph) or
higher and the RES switch is pressed.
Reset the cruise control function.

CX-5_8FN1-EA-16L_Edition1.indb 1342016/12/12 10:06:13

4–135
When Driving
i-ACTIVSENSE
*Some models.
Lane-keep Assist System (LAS) & Lane Departure
Warning System (LDWS)
*
The Lane-keep Assist System (LAS) & Lane Departure Warning System (LDWS) alerts the
driver that the vehicle may be deviating from its lane and it provides s\
teering assistance to
help the driver stay within the vehicle lanes.
The Forward Sensing Camera (FSC) detects the white lines (yellow line\
s) of the vehicle
lane in which the vehicle is traveling and if the system determines that\
the vehicle may
deviate from its lane, it operates the electric power steering to assist\
the driver's steering
operation. The system also alerts the driver by activating a lane departure warning\
sound,
vibrating the steering wheel, and indicating an alert in the display.
Refer to Forward Sensing Camera (FSC) on page 4-156 .
Forward Sensing
Camera (FSC)

CX-5_8FN1-EA-16L_Edition1.indb 1352016/12/12 10:06:13

4–136
When Driving
i-ACTIVSENSE
WARNING
Do not rely completely on the Lane-keep Assist System (LAS) & Lane Departure
Warning System (LDWS):
 The Lane-keep Assist System (LAS) & Lane Departure Warning System (LDWS) is not an automatic driving system. In addition, the system is not designed to compensate for a
driver's lack of caution, and over-reliance on the system could lead to an accident.
 The detection ability of the Lane-keep Assist System (LAS) & Lane Departure Warning System (LDWS) is limited. Always stay on course using the steering wheel and drive
with care.

Do not use the Lane-keep Assist System (LAS) & Lane Departure Warning System
(LDWS) in the following cases: The system may not operate adequately according to the actual driving conditions,
resulting in an accident.
 Driving on roads with tight curves. Driving under bad weather conditions (rain, fog, and snow). Slippery roads such as ice or snow-bound roads. Roads with heavy traffi c and insuffi cient distance between vehicles. Roads with no white (yellow) lane lines. Narrow roads resulting from road construction or lane closures. The vehicle is driven on a temporary lane or section with a closed lane resulting from road construction where there may be multiple white (yellow) lane lines or they are
interrupted.
 The tire pressures are not adjusted to the specifi ed pressure. Tires of a diff erent specifi ed size are used, such as an emergency spare tire.
CAUTION
Heed the following cautions so that the Lane-keep Assist System (LAS) & Lane Departure
Warning System (LDWS) can operate normally.
 Do not modify the suspensions. Always use wheels of the specifi ed type and size for the front and rear wheels. Consult an Authorized Mazda Dealer for tire replacement.

CX-5_8FN1-EA-16L_Edition1.indb 1362016/12/12 10:06:13
