warning MAZDA MODEL CX-5 2017 (in English) Owner's Guide

2–57
Essential Safety Equipment
SRS Air Bags
Curtain Air Bags
The curtain air bags are mounted in the front and rear window pillars, a\
nd the roof edge
along both sides.
When the air bag crash sensors detect a side impact of greater than mode\
rate force, the
curtain air bag infl ates quickly and helps to reduce injury mainly to the rear outboard
passenger's head caused by directly hitting interior parts such as a doo\
r or window.
For more details about air bag deployment, refer to "SRS Air Bag Deployment Criteria"
(page 2-58 ).
In a side impact:
Greater than moderate impact to one side of the vehicle will cause the c\
urtain air bag on that
side only to in fl ate.


Only one side curtain air bag will
deploy on the side of the vehicle
that receives the force of an impact.

(With Front Passenger Occupant Classifi cation System)
In a roll-over:
In response to a vehicle roll-over, both curtain air bags in fl ate.


Both curtain air bags will
deploy after the roll-over
accident is detected.

Warning Light/Beep
A system malfunction or operation conditions are indicated by a warning.
Refer to Warning/Indicator Lights on page 4-32 .
Refer to Warning Sound is Activated on page 7-39 .
CX-5_8FN1-EA-16L_Edition1.indb 572016/12/12 10:05:25

2–61
Essential Safety Equipment
SRS Air Bags
*Some models.
Front Passenger Occupant Classifi cation System *
First, please read "Supplemental Restraint System (SRS) Precautions" (page 2-46 )
carefully.
Front Passenger Occupant Classifi cation Sensor
Your vehicle is equipped with a front passenger occupant classi fi cation sensor as a part
of the supplemental restraint system. This sensor is equipped in the front passenger's seat
cushion. This sensor measures the electrostatic capacity of the front passenger's\
seat. The
SAS unit is designed to prevent the front passenger front and side air b\
ags and seat belt
pretensioner system from deploying if the front passenger air bag deacti\
vation indicator
light turns on.
To reduce the chance of injuries caused by deployment of the front passen\
ger air bag,
the system deactivates the front passenger front and side air bags and a\
lso the seat belt
pretensioner system when the front passenger air bag deactivation indica\
tor light turns
on. Refer to the following table for the front passenger air bag deactiv\
ation indicator light
illumination conditions.

This system shuts off the front passenger front and side air bags and seat belt pretensioner\

system, so make sure the front passenger air bag deactivation indicator \
light turns on
according to the following table.

The air bag/front seat belt pretensioner system warning light fl ashes and the front passenger
air bag deactivation indicator light illuminates if the sensors have a p\
ossible malfunction.
If this happens, the front passenger front and side air bags and seat be\
lt pretensioner system
will not deploy.
Front passenger air bag deactivation indicator light
This indicator light turns on to remind you that the front passenger fro\
nt and side air bags
and seat belt pretensioner will not deploy during a collision.


CX-5_8FN1-EA-16L_Edition1.indb 612016/12/12 10:05:27

2–63
Essential Safety Equipment
SRS Air Bags
WARNING
Do not allow an occupant in the front passenger's seat to sit with a posture which
makes it diffi cult for the front passenger occupant classifi cation sensor to detect the
occupant correctly: Sitting in the front passenger's seat with a posture which makes it diffi cult for the front
passenger occupant classifi cation sensor to detect the occupant correctly is dangerous.
If the front passenger occupant classifi cation sensor cannot detect the occupant sitting
on the front passenger's seat correctly, the front passenger front and side air bags
and pretensioner system may not operate (non-deploy) or they may operate (deploy)
accidentally. The front passenger will not have the supplementary protection of the air
bags or the accidental operation (deployment) of the air bags could result in serious
injury or death.
Under the following conditions, the front passenger occupant classifi cation sensor
cannot detect a passenger sitting on the front passenger's seat correctly and the
deployment/non-deployment of the air bags cannot be controlled as indicated in the
front passenger air bag deactivation indicator light on/off condition chart. For example:
 A front passenger is seated as shown in the following fi gure:

 A rear passenger pushes up on the front passenger seat with their feet. Luggage or other items placed under the front passenger seat or between the front passenger seat and driver seat that push up the front passenger seat bottom.
CX-5_8FN1-EA-16L_Edition1.indb 632016/12/12 10:05:27

2–65
Essential Safety Equipment
SRS Air Bags
NOTE
  The system requires about 10 seconds to alternate between turning the front passenger
front and side air bags and seat belt pretensioner system on or off.
  The front passenger air bag deactivation indicator light may turn on repeatedly if luggage
or other items are put on the front passenger seat, or if the temperature of the vehicle's
interior changes suddenly.
  The front passenger air bag deactivation indicator light may turn on for 10 se\
conds if the
electrostatic capacity on the front passenger seat changes.
  The air bag/front seat belt pretensioner system warning light might turn on if the front
passenger seat receives a severe impact.
  If the front passenger air bag deactivation indicator light does not turn on afte\
r installing
a child-restraint system on the front passenger seat, fi rst, re-install your child-restraint
system according to the procedure in this owner's manual. Then, if the front passenger air
bag deactivation indicator light still does not turn on, install the chi\
ld-restraint system on
the rear seat and consult an Authorized Mazda Dealer as soon as possible.
   If the front passenger air bag deactivation indicator light turns on when an occu\
pant
is seated directly in the front passenger seat, have the passenger re-adjust their posture
by sitting with their feet on the fl oor, and then re-fastening the seat belt. If the front
passenger air bag deactivation indicator light remains turned on, move the passenger to
the rear seat. If sitting in the rear seat is not possible, slide the front passenger seat as far
back as possible. Consult an Authorized Mazda Dealer as soon as possible.

CX-5_8FN1-EA-16L_Edition1.indb 652016/12/12 10:05:28

2–66
Essential Safety Equipment
SRS Air Bags
Constant Monitoring
The following components of the air bag systems are monitored by a diagn\
ostic system:

  Crash sensors, and diagnostic module (SAS unit)  Front air bag sensors  Air bag modules  Side crash sensors  Air bag/Front seat belt pretensioner system warning light  Front seat belt pretensioners  Related wiring
(With Front Passenger Occupant Classifi cation System)   Front passenger air bag deactivation indicator light  Front passenger occupant classi fi cation sensor   Front passenger occupant classi fi cation module

The diagnostic module continuously monitors the system's readiness. This begins when the
ignition is switched ON and continues while the vehicle is being driven.\

CX-5_8FN1-EA-16L_Edition1.indb 662016/12/12 10:05:28

3–2
Before Driving
Keys
Keys
WARNING
Do not leave the key in your vehicle with
children and keep them in a place where
your children will not fi nd or play with
them: Leaving children in a vehicle with the
key is dangerous. This could result in
someone being badly injured or even
killed. Children may fi nd these keys to
be an interesting toy to play with and
could cause the power windows or
other controls to operate, or even make
the vehicle move.

CAUTION
 Because the key (transmitter) uses low-intensity radio waves, it may not
function correctly under the following
conditions:
 The key is carried with communication devices such as
cellular phones.
 The key contacts or is covered by a metal object.
 The key is near electronic devices such as personal computers.
 Non-Mazda genuine electronic equipment is installed in the vehicle.
 There is equipment which discharges radio waves near the vehicle.
 The key (transmitter) may consume battery power excessively if it receives
high-intensity radio waves. Do not place
the key near electronic devices such as
televisions or personal computers.
 To avoid damage to the key (transmitter), DO NOT:
 Drop the key. Get the key wet. Disassemble the key. Expose the key to high temperatures on places such as the dashboard or
hood, under direct sunlight.
 Expose the key to any kind of magnetic fi eld.
 Place heavy objects on the key. Put the key in an ultrasonic cleaner. Put any magnetized objects close to the key.



CX-5_8FN1-EA-16L_Edition1.indb 22016/12/12 10:05:28

3–3
Before Driving
Keys
A code number is stamped on the plate
attached to the key set; detach this plate
and store it in a safe place (not in the
vehicle) for use if you need to make a
replacement key (auxiliary key).
Also write down the code number and
keep it in a separate safe and convenient
place, but not in the vehicle.

If your key (auxiliary key) is lost, consult
your Authorized Mazda Dealer and have
your code number ready.
NOTE
The driver must carry the key to ensure the
system functions properly.


Auxiliary key
Transmitter
Key code number plate

To use the auxiliary key, pull out the
auxiliary key from the transmitter while
pressing the knob.

Knob

Keyless Entry System
This system uses the key buttons to
remotely lock and unlock the doors and
the liftgate, and opens/closes the liftgate.
The system can start the engine without
having to take the key out of your purse or
pocket.
It can also help you signal for attention or
help.
Operating the theft-deterrent system is
also possible on theft-deterrent system-
equipped vehicles.

System malfunctions or warnings are
indicated by the following warning lights
or beeps.
For vehicles with the type A instrument
cluster, check the displayed message for
more information and, if necessary, have
the vehicle inspected at an Authorized
Mazda Dealer, according to the indication.
  KEY Warning Light (Red) Refer to Warning/Indicator Lights on
page 4-32 .
  Ignition Not Switched Off (STOP)
Warning Beep
 Refer to Ignition Not Switched Off (STOP) Warning Beep on page 7-40 .
  Key Removed from Vehicle Warning
Beep
 Refer to Key Removed from Vehicle Warning Beep on page 7-41 .

If you have a problem with the key,
consult an Authorized Mazda Dealer.

If your key is lost or stolen, consult an
Authorized Mazda Dealer as soon as
possible for a replacement and to make the
lost or stolen key inoperative.
CX-5_8FN1-EA-16L_Edition1.indb 32016/12/12 10:05:28

3–4
Before Driving
Keys
CAUTION
Radio equipment like this is governed
by laws in the United States.
Changes or modifi cations not expressly
approved by the party responsible
for compliance could void the user's
authority to operate the equipment.

NOTE
  The keyless entry system operation may
vary due to local conditions.
  The keyless entry system is fully
operational (door/liftgate lock/unlock)
when the ignition is switched off. The
system does not operate if the ignition is
switched to any position other than off.
  If the key does not operate when
pressing a button or the operational
range becomes too small, the battery
may be weak. To install a new battery,
refer to Key Battery Replacement (page
6-36 ).
  Battery life is about one year. Replace
the battery with a new one if the KEY
indicator light (green) fl ashes in the
instrument cluster (for vehicles with
a type A instrument cluster (page
4-32 ), messages are displayed in
the instrument cluster). Replacing
the battery about once a year is
recommended because the KEY warning
light/indicator light may not illuminate
or fl ash depending on the rate of battery
depletion.

  Additional keys can be obtained at
an Authorized Mazda Dealer. Up to
6 keys can be used with the keyless
functions per vehicle. Bring all keys
to an Authorized Mazda Dealer when
additional keys are required.

CX-5_8FN1-EA-16L_Edition1.indb 42016/12/12 10:05:28

3–5
Before Driving
Keys
Transmitter

Operation buttons
Operation indicator light

NOTE
 
 The headlights turn on/off by operating
the transmitter. Refer to Leaving Home
Light on page 4-55 .
  (With theft-deterrent system)  The hazard warning lights fl ash when
the theft-deterrent system is armed or
turned off.
 Refer to Theft-Deterrent System on page 3-47 .
  (With the advanced keyless function)  A beep sound can be heard for
confi rmation when the doors and the
liftgate are locked/unlocked using the
key. If you prefer, the beep sound can be
turned off.
 The volume of the beep sound can also be changed.
 Refer to Personalization Features on page 9-11 .

Use the following procedure to change the
setting.

1. Switch the ignition off and close all of the doors and the liftgate.
2. Open the driver's door.
3. Within 30 seconds of opening the driver's door, press and hold the
LOCK button on the key for
5 seconds or longer.
All of the doors and the liftgate lock and the beep sound activates at the
currently set volume. The setting
changes each time the LOCK button
on the key is pressed and the beep
sound activates at the set volume. (If
the beep sound has been set to not
activate, it will not activate.)
4. The setting change is completed by doing any one of the following:
  Switching the ignition to ACC or
ON.
  Closing the driver's door.  Opening the liftgate.  Not operating the key for
10 seconds.
  Pressing any button except the
LOCK button on the key.
  Pressing a request switch.

The operation indicator light fl ashes when
the buttons are pressed.
CX-5_8FN1-EA-16L_Edition1.indb 52016/12/12 10:05:29

3–6
Before Driving
Keys
Lock button
To lock the doors and the liftgate, press the
lock button and the hazard warning lights
will fl ash once.
(With the advanced keyless function)
A beep sound will be heard once.

To confi rm that all doors and the liftgate
have been locked, press the lock button
again within 5 seconds. If they are closed
and locked, the horn will sound.


NOTE
  The doors and the liftgate can be locked
by pressing the lock button while any
other door or the liftgate is open. The
hazard warning lights will not fl ash.
 When the lock button is pressed while
any door is open and then the door is
closed, all the doors and the liftgate are
locked.
  Confi rm that all doors and the liftgate
are locked visually or audibly by use of
the double click.
   Make sure all doors and the liftgate are
locked after pressing the button.
  (With theft-deterrent system)  When the doors are locked by pressing
the lock button on the key while the
theft-deterrent system is armed, the
hazard warning lights will fl ash once to
indicate that the system is armed.

Unlock button
To unlock the driver's door, press the
unlock button and the hazard warning
lights will fl ash twice.
(With the advanced keyless function)
A beep sound will be heard twice.

To unlock all doors and the liftgate, press
the unlock button again within 3 seconds
and two more beep sounds will be heard.


CX-5_8FN1-EA-16L_Edition1.indb 62016/12/12 10:05:29
