5. Depress the accelerator pedal completely with your heel set on the floor and make sure
that your ankle does not feel over-stretched.
Manual Seat Power Seat
Adjusting the seat height
Adjust the seat height to a position where you have a clear for ward view and you can drive
the vehicle easily.
1. With your back resting against the seatback, adjust the seat to the height where you can
see the first quarter part of the hood from the windshield.
With the manual seat, if you raise the seat height, the seat moves forward. Adjust the
seat forward or back again.
Manual Seat Power Seat
1/4
Adjusting the steering wheel position
Adjust the steering wheel to the position where it can be opera ted easily and the gauges can
be viewed easily.
Essential Safety Equipment
Seats
2-9
CX-9_8HB2-EA-18G_Edition1 2018-5-11 13:09:27

1. With your back resting against the seatback, extend both arms, place them on the top of
the steering wheel, and pull the steering wheel towards you to the position of your
wrists.
2. Adjust the steering wheel height so that the gauges can be vi ewed easily.
3. Raise the lever to securely lock the steering wheel.
Adjusting the head r estraint position
To prevent shock to the head and neck, adjust the head restrain ts to their correct positions.
Refer to Height Adju stment on page 2-21.
Essential Safety Equipment
Seats
2-10
CX-9_8HB2-EA-18G_Edition1 2018-5-11 13:09:27

▼Driving Position Memory*
The desired driving position can be called
up after programming the position.
The following driving positions can be
programmed.
Driver’s seat position (seat slide, height
adjustment, front edge of seat bottom,
seat recline)
Refer to Adjusting the Driver's Seat on
page 2-5.
Active driving display (display position,
brightness level, display information)
Refer to Active Driving Display on page
4-56.
CAUTION
Do not place fingers or hands around the
bottom of the seat while the seat memory
function is operatin
g. The seat moves
automatically while the seat memory
function is operating and fingers or hands
could get pinched and injured.
SET button
A driving position can be programmed or
operated using the buttons on the side of
the seat or the key.
NOTE
Lumbar support adjustment cannot be
programmed.
A driving position can be programmed
to the buttons on the side of the seat and
the key in use for driving the vehicle.
If the vehicle has been serviced and the
battery cables disconnected, the
programmed seat positions will have
been erased. Re-program the seat
positions.
Programming
1. Make sure the parking brake is on.
2. Make sure the selector lever is in the P position.
3. Start the engine.
4. Adjust the seat and the active driving display to the desired driving position.
5. Press the SET button on the seat until a beep sound is heard 1 time.
6. Perform one of the following settings
within 5 seconds of completing step 5
above:
Programming using a button on
the side of the seat
Press the button you want to
program, either bu tton 1 or 2, until a
beep sound is heard 1 time.
Programming using the key
Press the key
button until a beep
sound is heard 1 time.
NOTE
If a beep sound is heard 3 times, the
operation is canceled.
To move the driving position to a
programmed position
(Using a button on the side of the seat)
1. Make sure the parking brake is on.
Essential Safety Equipment
Seats
*Some models.2-11
CX-9_8HB2-EA-18G_Edition1 2018-5-11 13:09:27

2. Make sure the selector lever is in the Pposition.
3. Start the engine.
4. Press the programming button for the driving position you want to call up
(button 1 or 2).
5. A beep sound is heard when the driving position adjustment is
completed.
NOTE
If the driving position movement is not
changed, only the beep sounds.
A seat position can be called up even
with the engine not running.
The driving position adjustment is
canceled in the following cases:
Any of the seat adjustment switches is
operated.
The SET button is pressed.
Programming button 1 or 2 is pressed.
The key button or button is
operated.
The vehicle starts moving.
The active driving display is adjusted.
(Using a programmed key)
1. Unlock the doors by pressing a request switch or the key
button.
2. After unlocking the doors, the seat position adjustment begins within 40
seconds of opening the driver's door,
and a beep sounds when the operation
is finished.
3. Make sure the parking brake is on.
4. Make sure the selector lever is in the P position.
5. Start the engine.
6. The active driving display adjustment begins.
NOTE
If there is no driving position movement,
a beep is not heard.
The driving position adjustment is
canceled in the following cases:
Any of the seat adjustment switches is
operated.
The SET button is pressed.
Programming button 1 or 2 is pressed.
The key button or button is
operated.
The vehicle starts moving.
The active driving display is adjusted.
Erasing programmed driving positions
(Erasing the driving positions
programmed to the key)
1. Switch the ignition OFF.
2. Press the SET button on the side of the seat until a beep sound is heard 1 time.
3. After the beep sounds, press the key
button within 5 seconds until a beep
sound is heard 1 time.
NOTE
If a beep sound is heard 3 times, the
operation is canceled.
Essential Safety Equipment
Seats
2-12
CX-9_8HB2-EA-18G_Edition1 2018-5-11 13:09:27

▼Adjusting the Fron
t Passenger's Seat
Power operation
Seat Slide
(Manual Seat)
To move a seat forward or backward, raise the lever and slide t he seat to the desired position
and release the lever.
Make sure the lever returns to i ts original position and the seat is locked in place by
attempting to push it forward and backward.
(Power Seat)
To slide the seat, move the slide lifter switch on the outside of the seat to the front or back
and hold it. Release the sw itch at the desired position.
Height Adjustment (Power Seat)*
To adjust the seat height, move the switch up or down.
Seat Recline
(Manual Seat)
To change the seatback angle, lean forward slightly while raisi ng the lever. Then lean back
to the desired position and release the lever.
Make sure the lever returns to i ts original position and the seatback is locked in place by
attempting to push it forward and backward.
(Power Seat)
To change the seatback angle, press the front or rear side of t he reclining switch. Release the
switch at the desired position.
Essential Safety Equipment
Seats
*Some models.2-13
CX-9_8HB2-EA-18G_Edition1 2018-5-11 13:09:27

Lumbar Support Adjustment (Power Seat)*
To increase the seat firmness, press and hold the front part of the switch to the desired
position, then release it.
Press the rear part of the switch to decrease firmness.
Essential Safety Equipment
Seats
2-14*Some models.
CX-9_8HB2-EA-18G_Edition1 2018-5-11 13:09:27

Second-Row Seat
▼Seat Operation

Seat Slide (Forward-back adjustment)
To move a seat forward or backward, raise the lever and slide t he seat to the desired position
and release the lever.
Make sure the lever returns to i ts original position and the seat is locked in place by
attempting to push it forward and backward.
Seat Recline
To change the seatback angle, lean forward slightly while raisi ng the lever. Then lean back
to the desired position and release the lever.
The lever can also be used when flattening down the seats.
Refer to How to Split Folding the Second-Row Seats on page 2-18 .
Make sure the lever returns to i ts original position and the seatback is locked in place by
attempting to push it forward and backward.
Third-Row Seat Access
To access to the third-row seats , pull up the lever on the side of the head restraint to fold the
seatback and slide the seat forward.
Refer to How to Third-Row Seat Access on page 2-16.
Make sure the lever returns to i ts original position and the seatback is locked in place by
attempting to push it forward and backward.
Essential Safety Equipment
Seats
2-15
CX-9_8HB2-EA-18G_Edition1 2018-5-11 13:09:27

▼Armrest
The armrest in the center of the
second-row seatback can be used (no
occupant in the center seat) or placed
upright.

WA R N I N G
Never put your hands and
fingers around
the moving parts of the seat and armrest:
Putting your hands and fingers around the
moving parts of the seat and armrest is
dangerous as they could get injured.
CAUTION
 When storing the armrest, make sure
that any cables connected to the USB
power outlets in the armrest box are
stored away in the armrest box.
If the cables are not stored away in the
armrest box, the cables and connection
devices may become damaged when
storing the armrest.
 Be careful not to apply excessive force to
the armrest such as by sitting on it.
Otherwise, it could be deformed or
damaged.
▼ Third-Row Seat Access
Occupants can get into and out of the
third-row seats eas
ily by sliding the
second-row seats forward.
WA R N I N G
Make sure there is nobody in the
second-row seat area before operating the
levers:
Not checking the second-row seat area for
persons before folding the seatbacks with
the levers is dangerous. The second-row
seat area is difficult to see from the rear of
the vehicle. Operating the levers without
checking could cause injury to a person
when a seatback suddenly flips forward.
Do not operate the lever on the side of the
head restraint under the following
conditions:
Operating the lever on the side of the head
restraint under the following conditions is
dangerous as the seat may move
unexpectedly and cause an injury such as a
foot getting pinched between the seat and
floor.
 Occupant is seated in second-row seat

Essential Safety Equipment
Seats
2-16
CX-9_8HB2-EA-18G_Edition1 2018-5-11 13:09:27

Second-row seatback is folded forward

Child is seated on child restraint in
second-row seat

Entering/exiting the third-row seat area
1. Lower the head restraint all the way
down.
Refer to Head Restraints on page
2-21.
2. Pull up the lever on the side of the
head restraint to unl ock the seat, fold
the seatback forward, and slide the seat
forward.
CAUTION
 Do not operate the lever on the side of a
second-row seat while the seatback is
folded down and the seat is slid forward.
If the lever is forcefully operated, it could
damage the lever.
 After entering/exiting the third-row seat
area, return the second-row seatback to
its upright position and lock it after
sliding it rearward.
Make sure it is locked by attempting to
lightly move it back and forth.
Otherwise, it could move unexpectedly
and cause injury.
Entering/exiting the third-row seat area
with child-restraint system installed
(Right-side seat only)
Access to the third-row seats is possible
even when a child-restraint system is
installed to the second-row seat.
Essential Safety Equipment
Seats
2-17
CX-9_8HB2-EA-18G_Edition1 2018-5-11 13:09:27

Pull up the lever on the side of the head
restraint to lower the front side of the seat
and slide the seat forward.
CAUTION
After entering/exiting the third-row seat
area, lock the seat after sliding it rearward.
Make sure it is lock ed by attempting to
lightly move it back and forth.
Otherwise, it could move unexpectedly and
cause injury.
Second-row seat
fixed position Third-row seat
in
gress/egress
NOTE
The second-row seat cannot be moved
forward while the seat belt is securing the
child-restraint system.
▼
Split folding the Second-Row Seats
To create a flat luggage compartment
space, fold the seatbacks forward.
Folding the seatbacks
WA R N I N G
Make sure the adjustable components of a
second-row seat are locked after folding
down the seatback:
A second-row seat that is not securely
locked is dangerous. In a sudden stop or
collision, the second-row seat could move,
causing injury.
After folding down the seatback of a
second-row seat, make
sure the adjustable
components of the seat are locked in place
by attempting to slide the seat forward and
backward.
CAUTION
 When folding the seatback forward,
always support the seatback with your
hand. If it is not supported by a hand,
fingers or the hand raising the lever
could be injured.
 Check the position of a front seat before
folding a second-row seatback.
Depending on the position of a front
seat, it may not be possible to fold a
second-row seatback all the way down
because it may hit the seatback of the
front seat which could scratch or
damage the front seat or its pocket.
Remove the head restraint on the
second-row outboard seat if necessary.
1. Lower the head restraint all the way down.
Refer to Head Restraints on page
2-21.
Essential Safety Equipment
Seats
2-18
CX-9_8HB2-EA-18G_Edition1 2018-5-11 13:09:27
