Page 4 of 356
ContentsControls in detail ............................... 81
Locking and unlocking ......................... 82 SmartKey ........................................ 82
Opening the doors from the inside . 85
Opening the trunk lid ...................... 85
Closing the trunk lid ....................... 86
Trunk lid emergency release .......... 86
Automatic central locking .............. 87
Locking and unlocking from
the inside ....................................... 87
Seats .................................................... 89 Easy-entry/exit feature* ................ 89
Head restraints............................... 90
Heated seats* ................................ 91
Memory function* ................................ 93 Storing positions into memory ....... 94
Recalling positions from memory ... 94
Storing exterior rear view mirror
parking position ............................. 95
Lighting ................................................ 96 Exterior lamp switch ....................... 96
Combination switch ........................ 99
Hazard warning flasher ................... 99
Interior lighting ............................. 100 Instrument cluster ............................. 102
Instrument cluster illumination .... 102
Coolant temperature gauge ......... 102
Trip odometer .............................. 103
Tachometer .................................. 103
Outside temperature indicator ..... 104
Control system .................................. 105 Multifunction display .................... 105
Multifunction steering wheel ........ 106
Menus .......................................... 108
Standard display menu ................ 110
AUDIO menu ................................ 110
NAV menu .................................... 112
Malfunction memory menu .......... 112
Settings menu .............................. 114
Trip computer menu ..................... 125
TEL menu* ................................... 126
Manual transmission ......................... 130 Shifting into reverse ..................... 131
Automatic transmission* ................... 132 One-touch gearshifting ................. 133
Gear ranges .................................. 134
Gear selector lever position ......... 135
Program mode selector switch ..... 136
Accelerator position ..................... 137 Emergency operation
(Limp Home Mode) ...................... 137
Good visibility .................................... 138 Rear view mirror ........................... 138
Headlamp cleaning system* ........ 140
Sun visors .................................... 141
Climate control .................................. 142 Setting the temperature ............... 145
Adjusting air distribution and
volume ......................................... 145
Defrosting .................................... 146
Air recirculation mode .................. 146
Rear window defroster ................. 147
Air conditioning ............................ 148
Ventilated storage compartment . 148
Rear passenger compartment
adjustable air vents ...................... 149
Deactivating the climate control
system ......................................... 149
Automatic climate control*
(Canada only) .................................... 150 Setting the temperature ............... 152
Adjusting air distribution .............. 153
Adjusting air volume .................... 153
Maximum cooling MAXCOOL ....... 154
Defrosting .................................... 154
Page 144 of 356
144 Controls in detailClimate controlThe climate control is operational whenev-
er the engine is running. You can operate
the climate control system in either the au-
tomatic or manual mode. The system cools
or heats the interior depending on the se-
lected interior temperature and the cur-
rent outside temperature.
Nearly all dust particles, pollutants and
odors are filtered out before outside air en-
ters the passenger compartment through
the air distribution system.The air conditioning will not engage (no
cooling) if the
AC
OFF
mode is selected
(
page 148)Warning!
G
Follow the recommended settings for heat-
ing and cooling given on the following pag-
es. Otherwise the windows could fog up,
impairing visibility and endangering you and
others.
iIf the vehicle interior is hot, ventilate
the interior before driving off.
Keep the air intake grille in front of the
windshield free of snow and debris.
Page 146 of 356
146 Controls in detailClimate controlDefrosting
Activating
Press button
P
(page 143).
The indicator lamp on the button
comes on
or
Switch off air recirculation, if selected.
Press button
O
(page 143).
The indicator lamp on the button goes
out.
Close center air vents.
Open left and right side air vents and
adjust side air vents upwards. Deactivating
Press button
P
(page 143).
The indicator lamp on the button goes
out. Defrosting is turned off.
Air recirculation mode
Switch to air recirculation mode to prevent
unpleasant odors from entering the vehicle
from the outside. This setting cuts off the
intake of outside air and recirculates the
air in the passenger compartment. Activating
Press button
O
(page 143).
The indicator lamp on the button
comes on.
iThese settings should only be selected
for a short time.
Warning!
G
When the outside temperature is below
41°F (5°C), only switch to air recirculation
mode for short periods to prevent window
fogging.
iIf you keep button
O
pressed the
side windows and panorama slid-
ing/pop-up roof will be closed.
The air recirculation mode is activated
automatically at high outside tempera-
tures.
If you have turned off the air condition-
ing (
page 148) or the outside
temperature is below 41°F (5°C), the
air recirculation mode will not switch
on automatically.
Page 152 of 356
152 Controls in detailAutomatic climate control* (Canada only)The automatic climate control is operation-
al whenever the engine is running. You can
operate the climate control system in ei-
ther the automatic or manual mode. The
system cools or heats the interior depend-
ing on the selected interior temperature
and the current outside temperature.
Nearly all dust particles, pollutants and
odors are filtered out before outside air en-
ters the passenger compartment through
the air distribution system.
The air conditioning will not engage (no
cooling) if the economy mode AC
OFF
mode
is selected (
page 151).
Setting the temperature
Use temperature controls 1 and 14 for the
left side or 6 and 7 for the right side to
separately adjust the air temperature on
each side of the passenger compartment.
You should raise or lower the temperature
setting in small increments, preferably
starting at 72°F (22°C). Increasing
Push temperature control
1 and/or 6.
The automatic climate control system
will correspondingly adjust the interior
air temperature.
Decreasing
Push temperature control 7
and/or 14.
The automatic climate control system
will correspondingly adjust the interior
air temperature.
Adding outside air
Turn thumbwheel 5 in dashboard
(page 150) to increase flow of out-
side air through air vents for center, left
and right sides and rear passenger
compartment.
Warning!
G
Follow the recommended settings for heat-
ing and cooling given on the following pag-
es. Otherwise the windows could fog up,
impairing visibility and endangering you and
others.
iIf the vehicle interior is hot, ventilate
the interior before driving off.
Keep the air intake grille in front of the
windshield free of snow and debris.iWhen operating the climate control
system in automatic mode, you will
only rarely need to adjust the tempera-
ture, air volume and air distribution.
Page 154 of 356
154 Controls in detailAutomatic climate control* (Canada only)Maximum cooling MAXCOOL
If the left and right air distribution controls
as well as the airflow volume control are
set to
U
and there is a high need for
cooling, the display “AUTO MAXCOOL” ap-
pears.
This provides the fastest possible cooling
of the vehicle interior (when windows and
panorama sliding/pop-up roof* are
closed).
Defrosting
Activating
Press button
P
(page 151).
The indicator lamp on the button lights
up
Switch off air recirculation, if selected.
Press button
O
(page 151).
The indicator lamp on the button goes
out.
Close center air vents.
Adjust side air vents upwards.
Deactivating
Press button
P
(page 151).
The indicator lamp on the button goes
out. Defrosting is turned off.
Air recirculation mode
Switch to air recirculation mode to prevent
unpleasant odors from entering the vehicle
from the outside. This setting cuts off the
intake of outside air and recirculates the
air in the passenger compartment.
Activating
Press button
O
(page 151).
The indicator lamp on the button lights
up.
iThese settings should only be selected
for a short time.
Warning!
G
When the outside temperature is below
41°F (5°C), only switch to air recirculation
mode for short periods to prevent window
fogging.
Page 337 of 356
337
Index
Cockpit 20, 327
Cockpit management and data system
(COMAND*) 328
Collapsible tire 328
COMAND* 328
COMAND* see separate operating instructions
Combination switch 99 High beam flasher 48, 99
Turn signals 47
Windshield wipers 48
Consumer information 325
Control and operation of radio transmitters 222
Control system 105, 328 AUDIO menu 110
Convenience submenu 123
Display digital speedometer 110
Functions 106, 109
Instrument cluster submenu 116
Lighting submenu 119
Malfunction memory menu 112
Menus 108, 109, 329
Multifunction display 105
Multifunction steering wheel 106
NAV menu 112 Selecting radio system 111
Settings menu 114
Standard display menu 110
Submenus 107, 109
TEL* menu 126
Trip computer menu 125
Vehicle submenu 122
Convenience submenu 123 Activating easy-entry/exit feature 123
Setting key dependency 124
Setting parking position for exterior rear view mirror 124
Coolant 229, 321 Adding 230
Anticorrosion/antifreeze quantity 322
Capacities 317
Checking level 229
Messages in display 257, 258
Temperature 223
Temperature gauge 102
Warning lamp 258
Coolant level Checking 225, 229
Cruise control 189, 328 Canceling 190
Driving downhill 190 Driving uphill 190
Fine adjustment 191
Saving current speed 190
Setting speeds 191
Cruise control lever 189
Cup holder Cleaning 243
In front seat armrest 196
Customer Assistance Center (CAC) 327
D
Daytime running lamp mode 98 Setting 119
Deactivating Air conditioning (cooling) 148
Air recirculation mode 147, 155
Alarm 79
Anti-theft alarm system 79
Automatic climate control 151
Central locking (control system) 122
Climate control 143
Cruise control 190
Defrost 146, 154
Engine with the key 53
ESP 76
Exterior lamps 97
Exterior lamps delayed shut-off 120
