91 Controls in detail
Locking and unlocking
The trunk lid can also be opened from its
inside in an emergency, see “Trunk lid
emergency release” (
page 105).Loss of SmartKey or mechanical key
If you lose a SmartKey or mechanical key,
you should do the following:

Have the SmartKey deactivated by an
authorized Mercedes-Benz Center.

Report the loss of the SmartKey or the
mechanical key immediately to your
car insurance company.

If necessary, have the mechanical lock
replaced.
Your authorized Mercedes-Benz Center
will be glad to supply you with a replace-
ment.
SmartKey with KEYLESS-GO*
Specially equipped vehicles come with two
SmartKeys with KEYLESS-GO, each with
remote control and a removable mechani-
cal key. The locking tabs for the mechani-
cal key portion of the two SmartKeys are a
different color to help distinguish each
SmartKey unit.
The KEYLESS-GO function is integrated
into the SmartKey. On these vehicles, the
validity of the SmartKey with KEYLESS-GO
is checked every time you pull a door
handle.
iIf the trunk lid does not open, it is still
locked separately (if applicable)
(page 106)
If the vehicle was previously centrally
locked, the trunk lid will lock automati-
cally when closed (
page 100). The
turn signals will flash three times to
confirm locking.
!To prevent possible malfunction, avoid
exposing the SmartKey with
KEYLESS-GO to high levels of electro-
magnetic radiation.
ProCarManuals.com

92 Controls in detailLocking and unlockingIf the SmartKey with KEYLESS-GO* is valid,
your vehicle unlocks

the doors


the glove box


the trunk lid


the fuel filler flap
SmartKey with KEYLESS-GO1‹ Lock button
2Š Opening button for trunk lid
3Mechanical key locking tab
4ΠUnlock button
5Battery check lamp
6Â Panic button (
page 75)For more information on using the
SmartKey buttons, see “SmartKeys”
(
page 88)
Important notes on using KEYLESS-GO*


You can also use the SmartKey with
KEYLESS-GO like a normal SmartKey
(page 88).


You can combine KEYLESS-GO func-
tions with normal SmartKey functions
(e.g. unlocking with KEYLESS-GO and
locking with the remote control).


Always carry the SmartKey with
KEYLESS-GO with you.


Never store the SmartKey with
KEYLESS-GO together with:

electronic items such as a cellular
phone or another SmartKey with
KEYLESS-GO


metallic objects such as coins or
metal foil
Warning!
G
When leaving the vehicle, always remove the
SmartKey from the starter switch, take the
SmartKey with KEYLESS-GO with you and
lock the vehicle. Do not leave children unat-
tended in the vehicle, or with access to an
unlocked vehicle. Unsupervised use of vehi-
cle equipment may cause an accident
and/or serious personal injury.iYou can also open and close the soft
top (
page 222) and the power win-
dows (page 213) using the
SmartKey.
iIf the vehicle has been parked for a
longer period of time, you must pull the
door handle in order to activate the
KEYLESS-GO function.
ProCarManuals.com

93 Controls in detail
Locking and unlocking
Doing so could impair the function of
the KEYLESS-GO system.


To lock or unlock the vehicle, the
SmartKey with KEYLESS-Go must be lo-
cated outside the vehicle within ap-
proximately 3 ft (1 m) of a door or the
trunk.


In order to start the engine with the
SmartKey with KEYLESS-GO:

the SmartKey with KEYLESS-GO
must be located in the vehicle


all the doors must be closed


the brake pedal must be depressed


If you have started the engine with the
KEYLESS-GO start/stop button, you
can only turn it off again with this but-
ton, even if you have put the SmartKey
in the starter switch in the meantime.


This does not apply if, after starting, the
gear selector lever is still in positionP.
and the SmartKey is then inserted in
the starter switch. The SmartKey will
then have priority over the
KEYLESS-GO function and the vehicle’s
electrical system will operate accord-
ing to the position of the SmartKey in
the starter switch, even stopping the
engine.


If the SmartKey with KEYLESS-GO is
positioned farther away from the vehi-
cle the system may no longer recognize
the SmartKey with KEYLESS-GO. The
vehicle cannot be locked or the engine
started via the KEYLESS-GO system.


If the SmartKey with KEYLESS-GO is re-
moved from the vehicle while the igni-
tion is switched on (e.g. if passenger
exits the vehicle with the SmartKey
with KEYLESS-GO), the message
Key
not recognized!
will appear in the
multifunction display.
Find the SmartKey with KEYLESS-GO or
change its present location immediate-
ly (e.g. place it on the front passenger
seat or insert it in shirt pocket).


Remember that the engine can be
started by anyone with a SmartKey
with KEYLESS-GO that is left inside the
vehicle. If you leave the SmartKey with
KEYLESS-GO behind when exiting and
locking the vehicle, the message
Key
recognized in vehicle!
will appear in
the multifunction display.
ProCarManuals.com

94 Controls in detailLocking and unlockingFactory setting
Global unlocking
Pull the door handle.
The vehicle will lock again automatically
within approximately 40 seconds of un-
locking if neither door nor trunk is opened.
Global locking

Press lock button at door handle
(page 56) or trunk lid (
page 95).Selective setting
If you frequently travel alone, you may wish
to reprogram the SmartKey with
KEYLESS-GO so when you, grasp the driv-
er’s door handle only the driver’s door and
the fuel filler flap unlocks.

Press and hold buttonsŒ and‹
simultaneously for about five seconds
until battery check lamp5 flashes
twice.
The SmartKey with KEYLESS-GO will
then function as follows:
Unlocking driver’s door and fuel filler
flap
Grasp the driver’s door handle.
Global unlocking

Grasp the door handle on the pas-
senger side.
Global locking

Press lock button at door handle or
trunk lid.Restoring to factory setting

Press and hold buttonsŒ and‹
simultaneously for about six seconds
until battery check lamp5 flashes
twice.
iThe vehicles could inadvertently be un-
locked if the SmartKey with
KEYLESS-GO is within 3 ft (1 m) of the
vehicle and:

the door handle is splashed with
water, or


you attempt to clean the door
handle.
Warning!
G
When leaving the vehicle, always remove the
SmartKey from the starter switch, take the
SmartKey with KEYLESS-GO* with you and
lock the vehicle. Do not leave children unat-
tended in the vehicle, or with access to an
unlocked vehicle. It is possible for children
to open a locked door from the inside, which
could result in an accident and/or serious
personal injury.
ProCarManuals.com

95 Controls in detail
Locking and unlocking
Locking the vehicle
1Lock button at trunk
Press the lock button 1.
or

Press the lock button at the driver’s
door (
page 56).
or

Vehicles with trunk lid opening/closing
system*, press the KEYLESS-GO lock-
ing/closing switch at the trunk lid
(page 104).
The vehicle locks. The turn signals
blinks three times to confirm locking.Checking the batteries

Press button‹ orŒ.
Battery check lamp5 comes on brief-
ly to indicate that the SmartKey batter-
ies are in order.
!If you can no longer lock or unlock the
vehicle with the SmartKey with
KEYLESS-GO, then the batteries in the
SmartKey are discharged, the
SmartKey with KEYLESS-GO is mal-
functioning or the vehicle battery is
drained.

Check the batteries in the
SmartKey and replace them if nec-
essary (
page 350).


Use the mechanical key to unlock
the doors (
page 348) and the
trunk (
page 349).


Have the vehicle battery and the
battery connections checked.


Use the mechanical key to lock the
doors and the trunk (if applicable)
(page 349).
If the SmartKey is malfunctioning, con-
tact an authorized Mercedes-Benz Cen-
ter.
!If battery check lamp5 does not
come on briefly during check, then the
SmartKey batteries are discharged.
Replace the batteries (
page 350).
You can obtain the required batteries
at any authorized Mercedes-Benz Cen-
ter.
iIf the batteries are checked within sig-
nal range of the vehicle, pressing
the‹ orŒ button will lock or
unlock the vehicle accordingly.
ProCarManuals.com

96 Controls in detailLocking and unlockingUnlocking and opening the trunk lid
A minimum height clearance of 5.41 ft
(1.65 m) is required to open the trunk lid.
The handle is located in the rear license
plate recess.
1Handle
Pull on handle1.
The trunk opens.
or

Press and hold button Š until the
trunk unlocks and begins to open.The trunk can also be opened from its in-
side in an emergency, see “Trunk lid emer-
gency release” (
page 105).Closing the side windows

Press and hold lock button at door
(page 56) until the side windows are
closed.
!The trunk lid swings open upwards au-
tomatically. Always make sure there is
sufficient overhead clearance.
Vehicles with trunk lid opening/closing
system*: To stop the opening proce-
dure, press buttonŠ. The Trunk lid
stops moving.iIf the trunk lid does not open, it is still
locked separately (if applicable)
(page 106)
If the vehicle was previously centrally
locked, the trunk lid will lock automati-
cally when closed (
page 100). The
turn signals will flash three times to
confirm locking.
Warning!
G
When closing the windows, make sure there
is no danger of anyone being harmed by the
closing procedure.
If potential danger exists, proceed as fol-
lows:

Release the lock button.


Pull on the door handle and hold firmly.
The side windows will open for about
two seconds if the door handle is held
but the door not opened.
ProCarManuals.com

97 Controls in detail
Locking and unlocking
Loss of the SmartKey with KEYLESS-GO
If you lose your SmartKey with
KEYLESS-GO, you should do the following:
Have the SmartKey with KEYLESS-GO
deactivated by an authorized
Mercedes-Benz Center.

Report the loss immediately to your car
insurance company.

Have the mechanical lock replaced if
necessary.
Your authorized Mercedes-Benz Center
will be glad to supply you with a
replacement.
Opening the doors from the inside
You can open a locked door from the in-
side. Open doors only when conditions are
safe to do so.
1Locking knob
2Inside door handle
Pull on door handle2.
If door was locked, locking knob1 will
move up.
iIf the vehicle has previously been
locked from the outside with the
SmartKey, opening a door from the in-
side will trigger the anti-theft alarm sys-
tem.
To cancel the alarm, do one of the
following:
With the SmartKey

Insert the SmartKey in the starter
switch.


Press button‹ orŒ on the
SmartKey.
With KEYLESS-GO*


Grasp the outside door handle.


Press the KEYLESS-GO* start/stop
button.
ProCarManuals.com

98 Controls in detailLocking and unlocking
Opening the trunk
Opening the trunk from outside
(vehicles without KEYLESS-GO*)
A minimum height clearance of 5.41 ft
(1.65 m) is required to open the trunk lid.
The handle is located in the rear license
plate recess.
1Handle
Pull on handle1.
The trunk opensThe trunk can also be opened using the
SmartKey (
page 90) or from its inside in
an emergency, see “Trunk lid emergency
release” (
page 105).
iIf you open a door, the side windows on
that side of the vehicle will lower slight-
ly. The windows close again when you
close the door.
!The trunk lid swings open upwards au-
tomatically. Always make sure there is
sufficient overhead clearance.iIf the trunk lid does not open, it is still
locked separately (if applicable)
(page 106).
The vehicle must be unlocked.
ProCarManuals.com

99 Controls in detail
Locking and unlocking
Opening the trunk from the inside
You can open the trunk from the inside if
the vehicle is stationary.
A minimum height clearance of 5.41 ft
(1.65 m) is required to open the trunk lid.
The switch is located on the driver’s door.
1Remote trunk lid switch with indicator
lamp
Press remote trunk lid switch1.
The trunk lid opens. The indicator lamp
in the switch remains lit as long as the
trunk is open.The trunk can also be opened using the
SmartKey (
page 90) or from its inside in
an emergency, see “Trunk lid emergency
release” (
page 105).
!The trunk lid swings open upwards au-
tomatically. Always make sure there is
sufficient overhead clearance.iIf the trunk lid does not open, it is still
locked separately (if applicable)
(page 106).
If the vehicle was previously centrally
locked, the trunk lid will lock automati-
cally when closed (
page 100). The
turn signals will flash three times to
confirm locking.
ProCarManuals.com

100 Controls in detailLocking and unlockingClosing the trunk
1Handle
Lower trunk lid by pulling firmly on
handle1.

Close trunk lid with hands placed flat
on it.
Trunk lid opening/closing system*
Opening the trunk from the inside
You can open the trunk from the inside if
the vehicle is stationary.
A minimum height clearance of 5.41 ft
(1.65 m) is required to open the trunk lid.
The switch for opening and closing the
trunk is located on the driver’s door.
1Remote trunk lid opening switch
2Remote trunk lid closing switch
Press remote trunk lid opening
switch1 until the trunk lid begins to
open.
Warning!
G
To prevent possible personal injury, always
keep hands and fingers away from the trunk
lid opening when closing the trunk. Be espe-
cially careful when small children are
around.
Warning!
G
Only drive with the trunk closed. Among oth-
er dangers, such as your view being blocked,
exhaust fumes may enter the vehicle
interior.iDo not place the SmartKey in the open
trunk. You may lock yourself out.iVehicles with KEYLESS-GO*:
To prevent a possible inadvertent lock-
out, the trunk lid will open automatical-
ly if a SmartKey with KEYLESS-GO* is
recognized inside the vehicle or in the
trunk.
ProCarManuals.com
