111 Controls in detailSeats
Rear seats head restraints Raising rear head restraints
1Rear seat head restraint

Pull head restraint1 to its highest
position.Lowering rear head restraints
1Rear head restraint lowering switch

Turn the SmartKey in the starter switch
to position1or2 or press the
KEYLESS-GO* start/stop button once
or twice.

Push the rear head restraints lowering
switch1.
The rear head restraints are lowered.
Warning!
G
For safety reasons, always drive with the
rear head restraints in the raised position
when the rear seats are occupied.
Keep the area around head restraints clear
of articles (e.g. clothing) to not obstruct the
lowering/raising operation of the head re-
straints.
ProCarManuals.com

112 Controls in detailSeatsMulticontour seat*
The multicontour seat has a movable seat
cushion and inflatable air cushions built
into the backrest to provide additional lum-
bar and side support.
The seat cushion movement, backrest
cushion height and curvature can be con-
tinuously varied with switches on the right
side of the seat after starting the engine.
1Seat cushion depth
2Backrest bottom
3Backrest center
4Side bolster adjustment

Start the engine.Seat cushion depth

Adjust the seat cushion depth to the
length of your upper leg using
switch1.
Backrest contour

Adjust the contour of the backrest to
the desired position using switches2
and3.
Backrest side bolsters

Adjust the backrest side bolsters so
that they provide good lateral support
using switch4.
ProCarManuals.com

113 Controls in detailSeats
Seat ventilation*
Both switches for the front seats are locat-
ed in the center console.
1Seat ventilation
The blue indicator lamps on the switch
show which ventilation level you have
selected:

Make sure the ignition is switched on.
All lamps in the instrument cluster
come on.
Switching on seat ventilation

Press lower switch position1.
Two blue indicator lamps on the switch
come on.

Continue pressing switch1 until the
desired seat ventilation level is
reached.
Switching off seat ventilation

Press lower switch position1 repeat-
edly until all blue indicator lamps go
out.
Level2
Two indicator lamps on
1
One indicator lamp on
off
No indicator lamp on
!If one or all of the lamps flash on the
seat ventilation switch, there is insuffi-
cient voltage due to too many electrical
consumers being switched on. The seat
ventilation switches off automatically.
The seat ventilation will switch back on
again automatically as soon as suffi-
cient voltage is available.
ProCarManuals.com

114 Controls in detailSeatsSeat heating*
Vehicles without seat ventilation*
Both switches for the front seats are locat-
ed in the center console.
1Normal heating
2Rapid heating
Make sure the ignition is switched on.
All the lamps in the instrument cluster
come on.Switching on seat heating

Press upper switch position1.
A red indicator lamp on the switch
comes on.
Switching off seat heating

Press upper switch position1 again.
Switching on rapid seat heating

Press lower switch position2.
Both red indicator lamps on the switch
come on.Switching off rapid seat heating

Press lower switch position2.
iThe seat heating will be automatically
switched off after approximately
20 minutes. iThe system switches over to normal
heating mode after approximately ten
minutes. Only one indicator lamp re-
mains lit.
!If one or both of the lamps on the seat
heater switch are flashing, there is in-
sufficient voltage available since too
many electrical consumers are turned
on. The seat heater switches off auto-
matically.
The seat heater will switch back on
again automatically as soon as suffi-
cient voltage is available.
ProCarManuals.com

115 Controls in detailSeats
Vehicles with seat ventilation*
Both switches for the front seats are locat-
ed in the center console.
1Seat heating
The red indicator lamps on the switch
show the heating level you have selected:

Make sure the ignition is switched on.
All the lamps in the instrument cluster
come on.
Switching on seat heating

Press upper switch position1 twice.
A red indicator lamp on the switch
comes on.
Switching off seat heating

Press upper switch position1 again.
Switching on rapid seat heating

Press upper switch position1 once.
Both red indicator lamps on the switch
come on. Switching off rapid seat heating mode

Press switch position1 twice.
Level2
Two indicator lamps on
1
One indicator lamp on
off
No indicator lamp on
iThe seat heating will be automatically
switched off after approximately
20 minutes.
iThe system switches over to normal
heating mode after approximately ten
minutes. Only one indicator lamp re-
mains lit. !If one or both of the lamps on the seat
heating switch are flashing, there is in-
sufficient voltage due to too many elec-
trical consumers are turned on. The
seat heating switches off
automatically.
The seat heating will switch back on
again automatically as soon as suffi-
cient voltage is available.
ProCarManuals.com

116 Controls in detailMemory function
Memory function
The memory button and stored position
switch are located on the door.
You can store up to three different settings
per SmartKey or SmartKey with
KEYLESS-GO*.
The following settings are saved for each
stored position:

Driver’s seat, backrest and restraint
position


Settings for multicontour seat*


Steering wheel position


Driver’s side exterior rear view mirror
position


Passenger side exterior rear view mir-
ror position
These key-dependent memory settings
can be deactivated if desired
(
page 151).1Memory button
2Stored position button

Make sure the ignition is switched on
or the relevant door is open and the
SmartKey is inserted in the starter
switch.
!Prior to operating the vehicle, the driv-
er should check and adjust the seat
height, seat position fore and aft, and
seat backrest angle if necessary, to en-
sure adequate control, reach and com-
fort. The head restraint should also be
adjusted for proper height. See also the
section on airbags (
page 59) for
proper seat positioning.
In addition, adjust the steering wheel to
ensure adequate control, reach, opera-
tion and comfort. Both the inside and
outside rear view mirrors should be ad-
justed for adequate rear vision.
Fasten seat belts. Infants and small
children should be seated in a properly
secured restraint system that complies
with U.S. Federal Motor Vehicle Safety
Standards 213 and 225 and Canadian
Motor Vehicle Safety Standards 213
and 210.2.
Warning!
G
Do not activate the memory function while
driving. Activating the memory function
while driving could cause the driver to lose
control of the vehicle.
ProCarManuals.com

117 Controls in detail
Memory function
Storing positions into memory
Adjust the seats, steering wheel and
rear view mirrors to the desired posi-
tion (
page 34).

Turn button2 to selected memory po-
sition.

Press memory button1.

Release memory button and push
button2 within three seconds.
All the settings are stored at the select-
ed position.
Recalling positions from memory
Turn button2 to s ele c ted me m ory p o-
sition.

Press and hold button2 until the seat,
steering wheel and rear view mirrors
have fully moved to the stored posi-
tions.iReleasing the button immediately
stops movement to the stored posi-
tions.
Warning!
G
Do not operate the power seats using the
memory button if the seat backrest is in an
excessively reclined position. Doing so
could cause damage to front or rear seats.
First move the seat backrest to an upright
position.
ProCarManuals.com

118 Controls in detailMemory functionStoring exterior rear view mirror park-ing position
For easier parking, you can adjust the pas-
senger-side exterior rear view mirror so
that you can see the right rear wheel as
soon as you engage reverse gearR.
For information on activating the parking
position feature, see “Setting parking posi-
tion for exterior rear view mirror”
(page 151).1Memory button
2Adjustment button
3Passenger side exterior rear view mir-
ror button

Stop the vehicle.

Switch on ignition (if not already on).

Press button3.
The passenger-side exterior rear view
mirror is selected.

Adjust the exterior rear view mirror
with button2 so that you see the rear
wheel and the road curb.

Press memory button1.

Within three seconds, press bottom of
adjustment button2.
The parking position is stored if the
mirror does not move.
iYou can store a parking position for the
passenger-side exterior rear view mir-
ror for each SmartKey or SmartKey
with KEYLESS-GO*.
iIf the mirror does move, repeat the
above steps. After the setting is stored
you can move the mirror again.
ProCarManuals.com

119 Controls in detail
Lighting
Lighting
For notes on how to switch on the head-
lamps and use the turn signals, see
“Switching on headlamps” (
page 47).
Exterior lamp switch
The exterior lamp switch is located on the
dashboard to the left of the steering wheel.MOff
UAutomatic headlamp mode
CParking lamps (also side marker
lamps, tail lamps, license plate
lamps, instrument panel lamps)
Canada only:
When engine is running, the low
beam is also switched on.
BLow beam plus parking lamps or
high beam headlamps (combination
switch pushed forward).
ˆStanding lamps, right (turn left one
stop)
‚Standing lamps, left (turn left two
stops)
iIf you drive in countries where vehicles
drive on the other side of the road than
the country where the vehicle is regis-
tered, you must have the headlamps
modified for symmetrical low beams.
Relevant information can be obtained
at your authorized Mercedes-Benz
Center
ProCarManuals.com

120 Controls in detailLighting
Manual headlamp mode
The low beam headlamps and parking
lamps can be switched on and off with the
exterior lamp switch. For exterior lamp
switch, see “Exterior lamp switch”
(page 119).
Automatic headlamp mode
The parking lamps, low beam headlamps
and license plate lamps switch on and off
automatically depending on the brightness
of the ambient light.

Turn the exterior lamp switch toU.
iIf you remove the SmartKey and open
the driver’s door while the parking
lamps or low beam headlamps are
switched on,

a warning sounds


$ appears in the multifunction
display


the message
Turn off lamps!
ap-
pears in the multifunction display
iWith the daytime running lamp mode
activated and the engine running, the
low beam headlamps cannot be
switched off manually.
Warning!
G
If the exterior lamp switch is set toU,

the headlamps may switch off unexpect-
edly when the system senses bright am-
bient light, for example light from
oncoming traffic.


the headlamps will not be automatically
switched on under foggy conditions.
To minimize risk to you and to others, acti-
vate headlamps by turning exterior lamp
switch to B when driving or when traffic
and / or ambient lighting conditions require
you to do so.
In low ambient lighting conditions, only
switch from position U to B with the
vehicle at a standstill. Switching from U
to B will briefly switch off the head-
lamps. Doing so while driving in low ambient
lighting conditions may result in an acci-
dent.
The automatic headlamp feature is only an
aid to the driver. The driver is responsible for
the operation of the vehicle's lights at all
times.
ProCarManuals.com
