MERCEDES-BENZ CLS500 2006 W219 Owner's Manual

160 Controls in detailControl systemInstrument cluster submenu
Access the
Instr. cluster
submenu via
the
Settings
menu. Use the
Instr. clus-
ter
submenu to change the instrument
cluster display settings. The following
functions are available:Selecting speedometer display mode

Move the selection marker with the
æ or çbutton to the
Instr.
cluster
submenu.

Press buttonj ork repeatedly
until you see
Display unit
Speed-/odometer
in the multifunction
display.
The selection marker is on the current
setting.

Press button æ or ç to set
speedometer unit to
km or
miles
.Selecting language

Move the selection marker with the
æ or çbutton to the
Instr.
cluster
submenu.

Press buttonj ork repeatedly
until you see
Language
in the
multifunction display.
The selection marker is on the current
setting.
Function
Page
Select speedometer display
mode
160
Select language
160
Select display (speed display or
outside temperature) for status
display
161
Select display (speed display or
outside temperature) for basic
display
161

161 Controls in detail
Control system

Press buttonæ orç to select
the language to be used for the multi-
function display messages.
Available languages:

German
(Deutsch)


English
(English)


French
(Français)


Italian
(Italiano)


Spanish
(Español)


Dutch
(Nederlands)


Danish
(Dansk)


Swedish
(Svenska)


Portuguese
(Português)


Turkish
(Türkçe)
Selecting display (speed display or out-
side temperature) for status display
Move the selection marker with the
æ orçbutton to the
Instr.
cluster
submenu.

Press buttonj ork repeatedly
until you see
Status line display
in
the multifunction display.
The selection marker is on the current
setting.

Press buttonæ orç to select
the status line to
Speed
or
Outside
temp.
Selecting display (speed display or out-
side temperature) for basic display
Move the selection marker with the
æ or çbutton to the
Instr.
cluster
submenu.

Press buttonj ork repeatedly
until you see
Basic display
in the
multifunction display.
The selection marker is on the current
setting.

Press buttonæ orç to select
the display permanently shown in the
multifunction display.
iYou will see the status indicator when
you have called up a different display
from the standard display.

162 Controls in detailControl systemTime/Date submenu
Access the
Time/Date
submenu via the
Settings
menu. Use the
Time/Date
sub-
menu to change the time and date display
settings. The following functions are avail-
able:Synchronizing the time
This function can only be seen on vehicles
with COMAND and navigation module*.

Move the selection marker with the
æ or çbutton to the
Time/Date

submenu.

Press buttonj ork repeatedly
until you see
Time sync. with head
unit
in the multifunction display.
The selection marker is on the current
setting.

Press buttonæ orç to select
the desired setting.Set time (hours)
This function can only be seen when time
synchronization is switched off.

Move the selection marker with the
æ or çbutton to the
Time/Date

submenu.

Press buttonj ork repeatedly
until you see
Clock, hours
in the
multifunction display.
The selection marker is on the hour set-
ting.

Press buttonæ orç to set the
hour.

Confirm by pressing reset button
(page 24).
Function
Page
Synchronizing the time
162
Set time (hours)
162
Set time (minutes)
163
Set date (month)
163
Set date (day)
163
Set date (year)
164
iInformation on setting the time, refer to
separate COMAND instructions.

163 Controls in detail
Control system
Set time (minutes)
This function can only be seen when time
synchronization is switched off.
Move the selection marker with the
æ orçbutton to the
Time/Date

submenu.

Press buttonj ork repeatedly
until you see
Clock, minutes
in the
multifunction display.
The selection marker is on the minute
setting.

Press buttonæ orç to set the
minutes.

Confirm by pressing reset button
(page 24).Set date (month)

Move the selection marker with the
æ or çbutton to the
Time/Date

submenu.

Press buttonj ork repeatedly
until you see
Set date month
in the
multifunction display.
The selection marker is on the month
setting.

Press buttonæ orç to set the
month.Set date (day)

Move the selection marker with the
æ or çbutton to the
Time/Date

submenu.

Press buttonj ork repeatedly
until you see
Set date day
in the
multifunction display.
The selection marker is on the day
setting.

Press buttonæ orç to set the
day.

164 Controls in detailControl systemSet date (year)
Move the selection marker with the
æ or çbutton to the
Time/Date

submenu.

Press buttonj ork repeatedly
until you see
Set date year
in the
multifunction display.
The selection marker is on the year
setting.

Press buttonæ orç to set the
year.Lighting submenu
Access the
Lighting
submenu via the
Set-
tings
menu. Use the
Lighting
submenu
to change the lamp and lighting settings on
your vehicle. The following functions are
available:Setting daytime running lamp mode
(USA only)

Move the selection marker with
buttonæ orç to the
Lighting

submenu.

Press buttonj ork repeatedly
until you see
Lamp circuit headlamp
in
the multifunction display.
The selection marker is on the current
setting.
Function
Page
Set daytime running lamp mode
(USA only)
164
Setting locator lighting
165
Setting ambient lighting
166
Setting night security illumina-
tion
166
Setting interior lighting delayed
shut-off
167
iThis function is not available in coun-
tries where the daytime running lamp
mode is mandatory and therefore in a
constant mode.

165 Controls in detail
Control system

Press buttonæ orç to select
manual operation (
manual
) or daytime
running lamp mode (
constant
).
With daytime running lamp mode activated
and the exterior lamp switch at
positionM orU, the low beam
headlamps are switched on when the
engine is running.
In low ambient light conditions the follow-
ing lamps will switch on additionally:


Parking lamps


Tail lamps


License plate lamps


Side marker lamps
For more information on the daytime
running lamp mode, see “Lighting”
(
page 134).Setting locator lighting
With the locator lighting feature activated
and the exterior lamp switch in
positionU, the following lamps will
switch on during darkness when the vehi-
cle is unlocked with the SmartKey or
KEYLESS-GO*:


Parking lamps


Tail lamps


License plate lamps


Side marker lamps


Front fog lamps
The locator lighting switches off when the
driver’s door is opened.
If you do not open a door after unlocking
the vehicle with the SmartKey, the lamps
will switch off automatically after approxi-
mately 40 seconds.

Move the selection marker with
buttonæ orç to the
Lighting

submenu.
iFor safety reasons, resetting the Lighting
submenu to factory settings
while driving (
page 157) will not
deactivate the daytime running lamp
mode.
The following message appears in the
multifunction display:
Cannot be com-
pletely reset to factory settings
while driving.


166 Controls in detailControl system
Press buttonj ork repeatedly
until you see
Function Surround
lighting
in the multifunction display.
The selection marker is on the current
setting.

Press buttonæ orç to switch
the locator lighting function
on.

Turn the exterior lamp switch to
positionU when exiting the vehicle.
The locator lighting feature is activat-
ed.
Setting ambient lighting
Use this function to adjust the brightness
of the ambient lighting.

Move the selection marker with
buttonæ orç to the
Lighting

submenu.

Press buttonj ork repeatedly
until you see
Ambient light Level
in
the multifunction display.
The selection marker is on the current
setting.

Press buttonæ orç to select
the desired brightness of the ambient
lighting.
The setting 1 represents the darkest
level and setting 5 the brightest level.
The ambient light is switched off at set-
ting 0.Setting night security illumination
(Headlamps delayed shut-off)
Use this function to set whether you would
like the exterior lamps to remain on for
15 seconds during darkness after exiting
the vehicle and closing all doors.
With the delayed shut-off feature activated
and the exterior lamp switch in
positionU before the engine is turned
off, the following lamps will switch on
when the engine is turned off.


Parking lamps


Tail lamps


License plate lamps


Side marker lamps


Front fog lamps
If after turning off the engine you do not
open a door or do not close an opened
door, the lamps will automatically switch
off after 60 seconds.


167 Controls in detail
Control system

Move the selection marker with
buttonæ orç to the
Lighting
submenu.

Press buttonj ork repeatedly
until you see
Headlamps delayed
shut-off
in the multifunction display.
The selection marker is on the current
setting.

Press buttonæ orç to switch Headlamps delayed shut-off
on or
off
.

Turn the exterior lamp switch to
positionU before turning off the
engine.
The headlamps delayed shut-off fea-
ture is activated.
You can temporarily deactivate the de-
layed shut-off feature:

Before exiting the vehicle, turn the
SmartKey in the starter switch to
position0.

Then turn it to position2 and back to
position0.
The delayed shut-off feature is deacti-
vated. It will reactivate as soon as you
reinsert the SmartKey in the starter
switch.
Vehicles with KEYLESS-GO*:

Press the KEYLESS-GO start/stop but-
ton on the gear selector lever
(page 37).Setting interior lighting delayed shut-off
Use this function to set whether you would
like the interior lighting to remain lit during
darkness for 10 seconds after you have
removed the SmartKey from the starter
switch.

Move the selection marker with
buttonæ orç to the
Lighting
submenu.

Press buttonj ork repeatedly
until you see
Interior lighting de-
layed shut-off
in the multifunction
display.
The selection marker is on the current
setting.


168 Controls in detailControl system
Press buttonæ orç to switch Interior lighting delayed shut-off

on or
off
.
Vehicle submenu
Access the Vehicle
submenu via the
Set-
tings
menu. Use the
Vehicle
submenu to
make general vehicle settings. The follow-
ing functions are available:Setting automatic locking
Use this function to activate or deactivate
the automatic central locking. With the au-
tomatic central locking system activated,
the vehicle is centrally locked at vehicle
speeds of approximately 9 mph
(15 km/h).

Move the selection marker with the
æ or çbutton to the
Vehicle
submenu.

Press buttonj ork repeatedly
until you see
Automatic door lock
in
the multifunction display.
The selection marker is on the current
setting.

Press buttonæ orç to switch Automatic door lock
on or
off
.Convenience submenu
Access the
Convenience
submenu via the
Settings
menu. Use the
Convenience
sub-
menu to change the settings for a number
of convenience features. The following
functions are available:
Activating easy-entry/exit feature
Use this function to activate and deacti-
vate the easy-entry/exit feature
(
page 42).
Function
Page
Set automatic locking
168
Function
Page
Activate easy-entry/exit feature
168
Set parking position for exterior
rear view mirror
169


169 Controls in detail
Control system

Move the selection marker with the
æ or çbutton to the Convenience
submenu.

Press buttonj ork repeatedly
until you see
Function Easy-entry
feature
in the multifunction display.
The selection marker is on the current
setting.

Press buttonæ orç to switch Function Easy-entry feature
on or
off
.Setting parking position for exterior rear
view mirror
Use the
Mirror adjustment parking aid

function to select whether the passen-
ger-side exterior rear view mirror should be
turned downward during parking maneu-
vers when reverse gearR is engaged. For
additional information, see “Activating ex-
terior rear view mirror parking position”
(
page 192).

Move the selection marker to the Convenience
submenu using theæ
or çbutton.

Press buttonj ork repeatedly
until you see
Mirror adjustment park-
ing aid
in the multifunction display.
The selection marker is on the current
setting.
Warning!
G
You must make sure no one can become
trapped or injured by the moving steering
wheel when the easy-entry/exit feature is
activated.
To cancel steering wheel movement, do one
of the following:

Move steering column stalk
(page 42).


Press one of the memory position but-
tons or the memory buttonM
(page 132).
Do not leave children unattended in the ve-
hicle, or with access to an unlocked vehicle.
Children could open the driver’s door and
unintentionally activate the easy-entry/exit
feature, which could result in an accident
and/or serious personal injury.
