50 Getting startedDrivingBelt outlet height adjustment
1Release button
Press release button1 and move the
seat belt height adjuster upward or
downward.
Proper use of seat belts


Do not twist the belt when fastening.


Adjust seat belt so that the shoulder
portion is located as close as possible
to the middle of the shoulder (it should
not touch the neck). Never pass the
shoulder portion of the belt under your
arm.


Position the lap belt as low as possible
on your hips (over hip joint) and not
across the abdomen.


Place the seat backrest in a nearly
upright position.


Never use a seat belt for more than one
person at a time.


Do not fasten a seat belt around a per-
son and another object at the same
time. When using a seat belt to secure
infant or toddler restraints or children
in booster seats, always follow the
child seat manufacturer’s instructions.


Check your seat belt periodically dur-
ing travel to make sure that it is proper-
ly positioned.


Make sure that the seat belt is always
fitted snugly. Take special care of this
when wearing loose clothing.
Warning!
G
Do not pass belts over sharp edges. They
could tear.
Do not allow the belt to get caught in the
door or in the seat adjustment mechanism.
This could damage the belt.
Never attempt to make modifications to
seat belts. This could impair the effective-
ness of the belts.
Do not bleach or dye seat belts as this may
severely weaken them. In a crash they may
not be able to provide adequate protection.
Damaged seat belts or belts that were highly
stressed in an accident must be replaced.
Contact an authorized Mercedes-Benz
Center.

51 Getting started
Driving
Starting the engine Automatic transmission
Gearshift pattern for automatic
transmissionPPark position with gear selector lever
lock
RReverse gear
NNeutral
DDrive position
For more information, see the “Controls in
detail” section (
page 176).Starting with the SmartKey
For information on turning off the engine
with the SmartKey, see “Turning off en-
gine” (
page 60).

Make sure the gear selector lever is set
toP.

Do not depress the accelerator.

Turn the SmartKey in the starter switch
to position3 and hold until the engine
starts (
page 38).
Warning!
G
Inhalation of exhaust gas is hazardous to
your health. All exhaust gas contains carbon
monoxide (CO), and inhaling it can cause un-
consciousness and possible death.
Do not run the engine in confined areas
(such as a garage) which are not properly
ventilated. If you think that exhaust gas
fumes are entering the vehicle while driving,
have the cause determined and corrected
immediately. If you must drive under these
conditions, drive only with at least one win-
dow fully open.
i
You can also use the “touch-start” function.
Turn the SmartKey to position3 and release it
again immediately. The engine then starts auto-
matically.

52 Getting startedDrivingStarting with KEYLESS-GO*
You can start your vehicle without the
SmartKey in the starter switch using the
KEYLESS-GO start/stop button on the
gear selector lever.
For information on turning off the engine
with KEYLESS-GO, see “Locking with
KEYLESS-GO*” (
page 62).
The SmartKey with KEYLESS-GO must be
located in the vehicle.
KEYLESS-GO start/stop button1USA only
2Canada only
Make sure the gear selector lever is set
toP.

Depress the brake pedal during the
starting procedure. Do not depress
accelerator.
The selector lever lock is released.

Press KEYLESS-GO start/stop
button1 once.
The engine starts if the SmartKey with
KEYLESS-GO is in the vehicle.Starting difficulties
If the engine does not start as described,
carry out the following steps:

If you are starting the engine with the
SmartKey, turn SmartKey in starter
switch to position0 and repeat starting
procedure.

If you are starting the engine with
KEYLESS-GO: Close any doors that
may be open to allow for better detec-
tion of the SmartKey with
KEYLESS-GO.
Or:
Start the engine with the SmartKey as
radio signals from another source may
be interfering with the SmartKey with
KEYLESS-GO.

Repeat the starting procedure
(page 51). Remember that extended
starting attempts can drain the battery.

Get a jump start (
page 423).
Warning!
G
As long as the SmartKey with KEYLESS-GO
is in your vehicle, the vehicle can be started.
Therefore, never leave children unattended
in the vehicle, as they could otherwise acci-
dentally start the engine.
When leaving the vehicle, always take the
SmartKey with KEYLESS-GO with you and
lock the vehicle. Do not leave children unat-
tended in the vehicle, or with access to an
unlocked vehicle.

53 Getting started
Driving
If the engine does not start after several
starting attempts, there could be a mal-
function in the engine electronics or in the
fuel supply system.
Notify an authorized Mercedes-Benz
Center.
Parking brake
1Release handle
2Parking brake pedal

Release the parking brake pedal by
pulling on handle1.
The warning lamp; (USA only) or
3(Canada only) in the instrument
cluster goes out.
Driving off
Depress the brake pedal.

Move selector lever to positionD orR.

Release the brake pedal.

Carefully depress the accelerator
pedal.
Once the vehicle is in motion, the automat-
ic central locking system engages and the
locking knobs drop down.
Warning!
G
When leaving the vehicle, always remove the
SmartKey or the SmartKey with
KEYLESS-GO* from the starter switch, take
it with you and lock the vehicle. Do not leave
children unattended in the vehicle, or with
access to an unlocked vehicle. Children
could release the parking brake, which
could result in an accident and/or serious
personal injury.
i
Wait for the gear selection process to com-
plete before setting the vehicle in motion.
!
If you hear a warning signal and the
message
Release parking brake
appears in
the multifunction display when driving off, you
have forgotten to release the parking brake.
Release the parking brake (
page 53).


54 Getting startedDrivingAfter a cold start, the automatic transmis-
sion engages at a higher revolution. This
allows the catalytic converter to reach its
operating temperature earlier.
For more information on driving, see “Driv-
ing instructions” (
page 271).
i
Once the vehicle is in motion, the automatic
central locking system engages and the locking
knobs drop down.
The automatic door lock feature can be deacti-
vated (page 165).
You can open a locked door from the inside.
Open door only when conditions are safe to do
so.
Warning!
G
On slippery road surfaces, never downshift
in order to obtain braking action. This could
result in drive wheel slip and reduced vehi-
cle control. Your vehicle’s ABS will not pre-
vent this type of loss of control.Warning!
G
It is dangerous to shift the gear selector
lever out ofP orN if the engine speed is
higher than idle speed. If your foot is not
firmly on the brake pedal, the vehicle could
accelerate quickly forward or in reverse. You
could lose control of the vehicle and hit
someone or something. Only shift into gear
when the engine is idling normally and when
your right foot is firmly on the brake pedal.
!
Simultaneously depressing the accelerator
pedal and applying the brakes reduces engine
performance and causes premature brake and
drivetrain wear.
!
Do not run cold engine at high engine
speeds. Running a cold engine at high engine
speeds may shorten the service life of the en-
gine.
CLS 63 AMG:
At engine temperatures below 68°F (20°C), the
engine’s maximum speed is restricted in order to
protect it from damage. Avoid driving your vehi-
cle at full speed when the engine is cold to pre-
vent premature engine wear and/or diminished
comfort.


55 Getting started
Driving
Switching on headlamps
Low beam headlamps
The exterior lamp switch is located on the
dashboard to the left of the steering wheel.Exterior lamp switch1Off
2Low beam headlamps on
Turn the exterior lamp switch to
positionB.
The low beam headlamps and the
green indicator lamp C in the exte-
rior lamp switch comes on.High beam
The combination switch is located on the
left of the steering column.
Combination switch1High beam
2High beam flasher
Push the combination switch in direc-
tion of arrow1.
The high beam headlamps and the high
beam headlamp indicator lampA in
the instrument cluster comes on
(page 26).
For more information on headlamps, see
“Lighting” (
page 128).
Turn signals
The combination switch is located on the
left of the steering column.Combination switch1Turn signals, right
2Turn signals, left
Press combination switch in direction
of arrow1 or2.
The corresponding turn signal indicator
lamp L or K in the instrument
cluster flashes (
page 26).


56 Getting startedDrivingThe combination switch resets automati-
cally after major steering wheel move-
ments.
Windshield wipers
The combination switch is located on the
left of the steering column.Combination switch1Single wipe
Wiping with windshield washer fluid
2Switching on windshield wipers
Switch on the ignition (
page 38).
i
To signal minor directional changes such as
changing lanes, press combination switch only
to point of resistance and release. The corre-
sponding turn signals will flash three times.
!
Do not operate the wipers when the wind-
shield is dry. Dust that accumulates on a wind-
shield might scratch the glass and/or damage
the wiper blades when wiping occurs on a dry
windshield. If it is necessary to operate the wip-
ers in dry weather conditions, always operate
the wipers with windshield washer fluid
(
page 58).
!
If anything blocks the windshield wipers
(leaves, snow, etc.), switch them off immediate-
ly.


For safety reasons, stop the vehicle in a safe
location

turn off the engine by turning the
SmartKey to position0 and withdraw
SmartKey from starter switch
or


turn off the engine by pressing the
KEYLESS-GO* start/stop button and
open the driver’s door (with the driver’s
door open, starter switch is in
position0, same as with SmartKey re-
moved from starter switch)
before attempting to remove any blockage.


Remove blockage.


Turn the windshield wipers on again.


57 Getting started
Driving
Switching on windshield wipers
Turn the combination switch to the de-
sired position depending on the inten-
sity of the rain.
MWindshield wipers off
USlow intermittent wiping
Rain sensor operation with low
sensitivity.
VFast intermittent wiping
Rain sensor operation with high
sensitivity.
uSlow continuous wiping
tFast continuous wipingIntermittent wiping
Only switch on intermittent wiping under
wet weather conditions or in the presence
of precipitation.Intermittent wiping interval is dependent
on wetness of windshield.

Turn the combination switch to
positionU or V.
After the initial wipe, pauses between
wipes are automatically controlled by the
rain sensor.
!
If windshield wipers fail to function at all in
combination switch positionU or V,


set the combination switch to the next high-
est wiper speed


have the windshield wipers checked at the
nearest authorized Mercedes-Benz Center
!
Do not leave windshield wipers in
intermittent setting when the vehicle is taken to
an automatic car wash or during windshield
cleaning. Windshield wipers will operate in the
presence of water sprayed on the windshield,
and windshield wipers may be damaged as a re-
sult.
!
If you have set intermittent wiping, dirt on
the surface of the rain sensor or optical effects
may cause the windshield wipers to wipe in an
undesired fashion. This could then damage the
windshield wiper blades or scratch the windows.
You should therefore switch off the windshield
wipers when weather conditions are dry.
i
Intermittent wiping is interrupted when the
vehicle is at a standstill and a front door is
opened. This protects persons getting into or out
of the vehicle from being sprayed.
Intermittent wiping will be continued when


all doors are closed
and


the gear selector lever is in positionD orR
or


the wiper setting is changed using the com-
bination switch

58 Getting startedDrivingSingle wipe
Press the combination switch briefly in
direction of arrow1 (
page 56) to
the resistance point.
The windshield wipers wipe one time
without washer fluid.
Wiping with windshield washer fluid

Push the combination switch in direc-
tion of arrow1 (
page 56) past the
resistance point.
The windshield wipers operate with
washer fluid.
For information on filling up the washer
reservoir, see “Windshield washer system
and headlamp cleaning system*”
(
page 292).
Problems while driving
The engine runs erratically and misfires

An ignition cable may be damaged.


The engine electronics may not be
operating properly.


Unburned gasoline may have entered
the catalytic converter and damaged it.

Give very little gas.

Have the problem repaired by an
authorized Mercedes-Benz Center as
soon as possible.
The coolant temperature is above
248°F (120°C)
The coolant is too hot and is no longer
cooling the engine.

Stop the vehicle in a safe location as
soon as possible and turn off the en-
gine. Allow engine and coolant to cool
off.

Check the coolant level and add cool-
ant if necessary (
page 290).
In case of accident
If the vehicle is leaking fuel:

Do not start the engine under any
circumstances.

Notify local fire and/or police authori-
ties.
If the extent of the damage cannot be
determined:

Notify an authorized Mercedes-Benz
Center.
If no damage can be determined on the


major assemblies


fuel system


engine mount:

Start the engine in the usual manner.
i
To prevent smears on the windshield or
noisy/chattering wiper blades, wipe with wind-
shield washer fluid every now and then even
when it is raining.

59 Getting started
Parking and locking
Parking and locking
You have now completed your first drive.
You have properly stopped and parked
your vehicle. End your drive as follows.
Parking brake
Warning!
G
With the engine not running, there is no
power assistance for the brake and steering
systems. In this case, it is important to keep
in mind that a considerably higher degree of
effort is necessary to brake and steer the ve-
hicle.Warning!
G
If you have selected the Comfort suspension
tuning (
page 231), the vehicle lowers
slightly when it is locked. You should there-
fore make sure that no one is standing near
the wheel arches or lying underneath the ve-
hicle when it is being locked. Otherwise,
personal injury could result.
Warning!
G
Do not park this vehicle in areas where com-
bustible materials such as grass, hay or
leaves can come into contact with the hot
exhaust system, as these materials could be
ignited and cause a vehicle fire.
To reduce the risk of personal injury, or
damage to the vehicle drivetrain, as a result
of vehicle movement, before turning off the
engine and leaving the vehicle always:

Keep right foot on brake pedal.


Firmly depress parking brake pedal.


Move the gear selector lever to
positionP.


Slowly release brake pedal.


When parked on an incline, turn front
wheel towards the road curb.


Turn the SmartKey in the starter switch
to position0 and remove the SmartKey
from the starter switch, or press
KEYLESS-GO* start/stop button.


Take the SmartKey or the SmartKey with
KEYLESS-GO* with you and lock vehicle
when leaving.
!
If you have selected the Comfort suspen-
sion tuning (
page 231), the vehicle lowers
slightly when you lock it within approximately
60 seconds after switching off the engine. When
parking, make sure that your vehicle cannot
come into contact with other objects, such as a
curb, while lowering. Your vehicle could
otherwise be damaged.
Warning!
G
Engaging the parking brake while the vehicle
is in motion can cause the rear wheels to
lock up. You could lose control of the vehicle
and cause an accident. In addition, the vehi-
cle’s brake lights do not light up when the
parking brake is engaged.
