Welcome to the world of Mercedes-Benz
Before you first drive off, read this Owner's
Manual carefully and familiarise yourself with
yourv ehicle. For your own safety and a longer
vehicle life, follow the instructions and warn-
ing notices in this manual. Disregarding them
may lead to damage to the vehicle or personal
injury.
The equipment or model designation of your
vehicle may vary according to:
R model
R order
R country variant
R availability
The illustrations in this manual show a left-
hand-drive vehicle. On right-hand-drive vehi-
cles, the layout of components and controls
differs accordingly.
Mercedes-Benzi s constantly updating its
vehicles to the state of the art.
Mercedes-Benz therefore reserves the right
to introduce changes in the following areas:
R design
R equipment
R technical features
Therefore, descriptions may vary from those
of your own vehicle.
The following are integral components of the
vehicle:
R Owner's Manual
R Service Booklet
R equipment-dependent supplements
Keep printed copies of the documents in the
vehicle at all times. If you sell the vehicle,
always pass the documents on to the new
owner.
i You can get to know the important fea-
tures of your vehicle in the interactive Own-
er's Manual on the Internet at:
http://www.mercedes-benz.de/
betriebsanleitung The technical documentation team at
Daimler AG wishes you safe and pleasant
motoring.
2125847981Z102 É2125847981Z102(ËÍ
Page 5 of 457
Page 6 of 457
Index
....................................................... 4Introduction
......................................... 23 At
ag lance ........................................... 29 Safety
................................................... 41 Opening and closing
...........................81 Seats, steering wheel and mirrors
..105 Lights and windscreen wipers
.........123 Climate control
................................. 141 Driving and parking
..........................159 On-board computer and displays
....243 Stowing and features
.......................309 Maintenance and care
......................343 Breakdown assistance
.....................359 Wheels and tyres
.............................. 379 Technical data
................................... 431 Contents
3
