MERCEDES-BENZ E350 4MATIC WAGON 2007 S211 Owner's Manual

490 Technical dataFuels, coolants, lubricants etc.Premium unleaded gasoline
Fuel requirements
Only use premium unleaded fuel:

The octane number (posted at the
pump) must be 91 min. It is an average
of both the Research Octane Number
(RON) and the Motor Octane Number
(MON): (RON+MON) / 2). This is also
known as the ANTI-KNOCK INDEX.
Unleaded gasoline containing oxygenates
such as ethanol, IPA, IBA and TBA can be
used provided the ratio of any one of these
oxygenates to gasoline does not
exceed 10%; MTBE must not exceed 15%.
The ratio of methanol to gasoline must not
exceed 3% plus additional cosolvents.
Using mixtures of ethanol and methanol is
not allowed. Gasohol, which contains
10% ethanol and 90% unleaded gasoline,
can be used.
These blends must also meet all other fuel
requirements, such as resistance to spark
knock, boiling range, vapor pressure, etc.
Warning!
G
Gasoline is highly flammable and poisonous.
It burns violently and can cause serious per-
sonal injury.
Never allow sparks, flame or smoking mate-
rials near gasoline!
Turn off the engine before refueling.
Whenever you are around gasoline, avoid in-
haling fumes and skin or clothing contact,
extinguish all smoking materials.
Direct skin contact with fuels and the inha-
lation of fuel vapors can damage your
health.
!
To maintain the engine’s durability and per-
formance, premium unleaded gasoline must be
used. If premium unleaded gasoline is not avail-
able and low octane fuel is used, follow these
precautions:


Have the fuel tank only partially filled with
unleaded regular gasoline and fill up with
premium unleaded gasoline as soon as
possible.


Avoid full throttle driving and abrupt
acceleration.


Do not exceed an engine speed of 3 000 rpm
if the vehicle is loaded with a light load such
as two persons and no luggage.


Do not exceed
2/3 of maximum accelerator
pedal position if the vehicle is fully loaded or
operating in mountainous terrain.

491 Technical data
Fuels, coolants, lubricants etc.
Gasoline additives
A major concern among engine
manufacturers is carbon build-up caused
by gasoline. Mercedes-Benz recommends
only the use of quality gasoline containing
additives that prevent the build-up of
carbon deposits.
After an extended period of using fuels
without such additives, carbon deposits
can build up, especially on the intake
valves and in the combustion area, leading
to engine performance problems such as:

Warm-up hesitation


Unstable idle


Knocking/pinging


Misfire


Power lossIn areas where carbon deposits may be
encountered due to lack of availability of
gasolines which contain these additives,
Mercedes-Benz recommends the use of
additives approved by us for use on
Mercedes-Benz vehicles. Refer to Factory
Approved Service Products pamphlet
(USA only) or contact an authorized
Mercedes-Benz Center for a listing of
approved product(s). Follow directions on
product label.
Do not blend other fuel additives with fuel.
This only results in unnecessary cost and
may be harmful to the engine operation.
Coolants
The engine coolant is a mixture of water
and anticorrosion/antifreeze, which pro-
vides:

Corrosion protection


Freeze protection


Boiling protection (by increasing the
boiling point)
The cooling system was filled at the factory
with a coolant providing freeze protection
to approximately -35°F (-37°C) and corro-
sion protection.
If the antifreeze mixture is effective to
-35°F (-37°C), the boiling point of the cool-
ant in the pressurized cooling system is
reached at approximately 266°F (130°C).
!
Damage or malfunction resulting from poor
fuel quality or from blending additional fuel
additives other than those tested and approved
by us for use on Mercedes-Benz vehicles are not
covered by the Mercedes-Benz Limited
Warranty.
For a listing of approved products, refer to the
Factory Approved Service Products pamphlet
(USA only) or contact an authorized
Mercedes-Benz Center.
!
Add premixed coolant solution only. Adding
water and MB 325.0 Anticorrosion/Antifreeze
separately from each other, could cause engine
damage not covered by the Mercedes-Benz
Limited Warranty.

492 Technical dataFuels, coolants, lubricants etc.The coolant solution must be used year
round to provide the necessary corrosion
protection and increase boil-over protec-
tion. Refer to Maintenance Booklet for re-
placement interval.
Coolant system design and coolant used
determine the replacement interval. The
replacement interval published in the
Maintenance Booklet is only applicable if
MB 325.0 Anticorrosion/Antifreeze solu-
tion or other Mercedes-Benz approved
products of equal specification are used to
renew the coolant concentration or bring it
back up to the proper level.
For information on other Mercedes-Benz
approved products of equal specification,
refer to the Factory Approved Service
Products pamphlet (USA only) or contact
an authorized Mercedes-Benz Center.To provide important corrosion protection,
the solution must be at least 50% anticor-
rosion/antifreeze (equivalent to freeze
protection to approximately -35°F
[-37°C]). If you use a solution that is more
than 55% anticorrosion/antifreeze (freeze
protection to approximately - 49°F
[-45°C]), the engine temperature will in-
crease due to the lower heat transfer capa-
bility of the solution. Therefore, do not use
more than this amount of anticorro-
sion/antifreeze.If the coolant level is low, water and
MB 325.0 Anticorrosion/Antifreeze
should be used to bring it up to the proper
level (have cooling system checked for
signs of leakage). Please make sure the
mixture is in accordance with label instruc-
tions.
The water in the cooling system must meet
minimum requirements, which are usually
satisfied by normal drinking water. If you
are not sure about the water quality, con-
sult an authorized Mercedes-Benz Center.

493 Technical data
Fuels, coolants, lubricants etc.
Anticorrosion/antifreeze
Your vehicle contains a number of
aluminum parts. The use of aluminum com-
ponents in motor vehicle engines necessi-
tates that anticorrosion/antifreeze
coolant used in such engines be
specifically formulated to protect the aluminum parts. Failure to use such anti-
corrosion/antifreeze coolant will result in
a significantly shortened service life.
Therefore, the following product is strongly
recommended for use in your vehicle:
MB 325.0 Anticorrosion/Antifreeze agent.Before the start of the winter season (or
once a year in hot southern regions), you
should have the anticorrosion/antifreeze
concentration checked. The coolant is also
regularly checked each time you bring your
vehicle to an authorized Mercedes-Benz
Center for service.
Anticorrosion/antifreeze quantityModel
Approx. freeze protection-35°F (-37°C)
-49°F (-45°C)
E 350 4MATIC
5.3 US qt (5.0 l)
5.9 US qt (5.5 l)
E63AMG
6.2 US qt (5.9 l)
6.9 US qt (6.5 l)

494 Technical dataFuels, coolants, lubricants etc.Windshield washer system and head-lamp cleaning system*
Both the windshield washer system and
headlamp cleaning system* are supplied
from the windshield washer reservoir.
The windshield washer reservoir has a ca-
pacity of approximately:

6.9 US qt (6.5 l) in vehicles with a
headlamp cleaning system*


4.8 US qt (4.5 l) in vehicles without a
headlamp cleaning system*

Refill the reservoir with MB Windshield
Washer Concentrate and water (or con-
centrate and commercially available
premixed windshield washer sol-
vent/antifreeze, depending on ambient
temperatures).Windshield and headlamp washer fluid
mixing ratio
For temperatures above freezing point, use
MB Windshield Washer Concentrate
“MB SummerFit” and water:


1 part “MB SummerFit” to 100 parts
water
(1.34 fl oz [40 ml] “MB SummerFit” to
1 gal [4.0 l] water).
For temperatures below freezing point use
MB Windshield Washer Concentrate
“MB SummerFit” and commercially avail-
able premixed windshield washer
solvent/antifreeze:


1 part “MB SummerFit” to 100 parts
solvent
(1.34 fl oz [40 ml] “MB SummerFit” to
1 gal [4.0 l] solvent).
Warning!
G
Washer solvent/antifreeze is highly flamma-
ble. Do not spill washer solvent/antifreeze
on hot engine parts, because it may ignite
and burn. You could be seriously burned.

495 Index
A
ABS 97
Indicator lamp 378
Messages in display 396, 411
Accelerator position, automatic
transmission 191
Accessory weight 358
Accident 60
Active Bi-Xenon headlamps* see Head-
lamps
Active head restraints 87
Adaptive Damping System see ADS
ADS 261
Air bags 70
Children 71
Front, Driver 74
Front, Passenger 74
Safety guidelines 72
Side impact 75
Window curtain 75
Air conditioning refrigerant 489
Air conditioning system see Climate con-
trol system
Air conditioning, Cooling 218, 235
Air distribution 213, 230
Air pressure 358Air pressure see Tire inflation
pressure 341
Air pump, electric
Turning on 460
Air recirculation mode 216, 233
Air vents 213, 230
Air volume 214, 231
Airmatic DC (Dual Control)
Messages in display 428
Suspension tuning 262
Airmatic DC (Dual Control) 261
Vehicle level control 262
Alarm system see Anti-theft systems
Alignment bolt (vehicle tool kit) 430, 458
AMG menu 161
Anticorrosion/antifreeze 493
Antilock Brake System see ABS
Anti-theft systems 106
Anti-theft alarm system 106
Immobilizer 106
Aquaplaning see Hydroplaning 314
Ashtrays 285
Aspect ratio 358AUDIO menu 165
Operating CD player 166
Selecting radio station 165
Selecting satellite radio* station 165
Audio search function 180
Audio system
CD mode 166
Auto-dimming
Rear view mirrors 200
Automatic central locking, Control
system 180
Automatic headlamp mode 142
Automatic lighting control, Interior
lighting 149
Automatic locking when driving 180
Automatic shift program 193

496 IndexAutomatic transmission
Accelerator position 191
Automatic shift program 193
Emergency operation (Limp-Home
Mode) 199
Gear ranges 192
Gear selector lever 187
Gear selector lever control one-touch
gearshifting 194
Gear selector lever positions 189
Gear shifting malfunctions 199
Kickdown 191
Kickdown, manual shift program 199
Manual shift program E 63 AMG 197
Program mode selector switch 193
Shifting procedure 188
Starting engine 52
Steering wheel gearshift control
one-touch gearshifting
E63AMG 195
B
BabySmart
TM
Airbag deactivation system 81
Self-test 81Backrest 266
Folding rearward 267
Seat 43
Seat, multicontour* 131
Backup lamps
Messages in display 420
Replacing bulbs 442
Bar 358
BAS 99
Batteries, SmartKey
Checking battery condition 119
Replacing 440
Batteries, SmartKey with KEYLESS-GO*
Checking battery condition 119
Replacing 440
Batteries, Vehicle
Charging 465
Disconnecting 464
Installing 465
Jump starting 466
Messages in display 410
Reconnecting 465
Removing 464
Bead 358
Beverage holder see Cup holders
Bi-Xenon headlamps* see HeadlampsBlock heater* (Canada only) 364
Brake fluid
Checking 322
Messages in display 411
Brake lamp
Cleaning lenses 371
Replacing bulbs 442
Brake pads
Message in display 410
Brake-in recommendations 308
Brakes 310
High-performance brake system
(E 63 AMG only) 312
Warning lamp 381
Break-in period 308
Bulbs see Replacing bulbs
Button, In instrument cluster 27
C
California retail buyers and lessees, impor-
tant notice for 11
Can holder see Cup holders
Capacities and recommended
fuel/lubricants 486

497 Index
Cargo compartment
Closing the tailgate 123
Fuse box 472
Lamp 151
Message in display 428
Opening 121
Tie-down rings 270
Cargo compartment cover 276
Cargo management system* 271
Belt reel 272
Cargo tie-down ring 272
Mounting elements 271
Telescoping rod 273
Cargo net 275
Cargo tie-down rings 270
Carpets, cleaning 374
Catalytic converter 318
CD player 166
Center console
Lower part 30
PASS AIR BAG OFF indicator
lamp 391
Upper part 29
Central locking
Automatic 126, 180
Locking/unlocking from inside 127Central locking switch 127
Certification label 476
Checking
Oil level 326
Checking tire pressure electronically with
the Advanced Tire Pressure Monitoring
System (Advanced TPMS)*,
(Canada only) 344
Children in the vehicle 88
Air bags 71
Blocking of rear window operation 95
Indicator lamp, front passenger front
air bag 81
Infant and child restraint systems 89
LATCH-type child seat anchors 94
Cigarette lighter 286Climate control system
4-zone automatic climate
control 222
Air conditioning refrigerant 489
Air conditioning, Cooling 218, 235
Air distribution 213, 230
Air recirculation mode 216, 233
Air volume 214, 231
Automatic mode 211, 228
Control panel, Rear 220, 237
Deactivating system 211, 227
Dual-zone automatic climate
control 206
Front defroster 214, 231
Maximum cooling MAX COOL 216,
232
Rear climate control 237
Residual engine heat (REST) 219,
236
Clock 27, 174
Setting time 175
Cockpit 24
Cold tire inflation pressure 358
Collapsible tire 483
Collapsible wheel chock 434

498 IndexCOMAND see separate COMAND operat-
ing instructions
Combination filter with pollutant-sensitive
air-recirculation mode 235
Combination switch 56, 145
Control system 155
Multifunction display 155
Multifunction steering wheel 156
Resetting to factory settings 170
Control system menus 158, 159
AMG 161
AUDIO 165
Distronic* 167
NAV* 167
Settings 169
Standard display 161
TEL* 184
Trip computer 183
Vehicle status message memory 168
Control system submenus 157
Convenience 181
Instrument cluster 172
Lighting 176
Time/Date 174
Vehicle 180Convenience submenu
Activating easy-entry/exit
feature 181
Setting parking position for exterior
rear view mirror 182
Coolant
Anticorrosion/antifreeze mixing ratio
and quantity 493
Capacities 487
Checking coolant level 329
Messages in display 412, 413, 414
Temperature 320
Temperature indicator 153
Warning lamp 384
Corner-illuminating front fog lamps* 146
Cruise control 246
Cup holders 282
Curb weight 358
Customer Assistance Center (CAC) 17
D
Date display, setting 175, 176
Daytime running lamp mode 143
Setting 176, 177
Deep water see Standing water
Defogging windshield 215, 232
Defrosting, Front 214, 231Defrosting, Rear 204
Delayed shut-off
Exterior lamps 178
Interior lighting 179
Department of Transportation see DOT
Difficulties
While driving 60
With starting 53
Digital clock see Clock
Digital speedometer 161
Dimensions, vehicle 485
Direction of rotation (tires) 335
Displays
Digital speedometer 161
Distronic* 252
Maintenance service indicator 365
Messages in display 409
Multifunction display 155
Outside temperature 155, 173
Symbol messages 409
Text messages 396
Vehicle status message memory 169
Vehicle system settings, Control
system 155
Distance to empty (Range), Trip
computer 184

499 Index
Distronic* 249
Activating/deactivating 255
Cleaning system sensor 372
Control system 167
Distance warning function 258
Driving hints 259
Menu 253
Messages in display 397
Sensor cover 372
Warning and indicator lamps 252
Door
Entry lamps 151
Locking/unlocking, SmartKey 36,
112
Locking/unlocking, SmartKey with
KEYLESS-GO* 37, 117
Message in display 428
Opening from inside/outside 120
Remote door unlock (Tele Aid) 299
Unlocking, Mechanical key 435
Door control panel 34
Door handle 34
DOT 359
Drinking and driving 309Driving
Abroad 317
Hydroplaning 314
In winter 316
Instructions 49, 309
Problems 60
Safety systems 97
Through standing water 317
With Distronic* 259
Driving safety systems
4MATIC 104
ABS 97
BAS 99
EBP 100
ESP
®
100
Driving systems
Airmatic DC (Dual Control) 261
Cruise control 246
Distronic* 249
Driving tips 191
Accelerator position 191
Kickdown 191E
Easy-entry/exit feature 46, 181
EBP 100
Electrical fuses see Fuses
Electrical system, Technical data 484
Electronic Stability Program see
ESP
®
100
Emergency calls
Tele Aid calls 294
Emergency operation (Limp-Home
Mode) 199
Emergency operations
Gear selector lever, Unlocking 437
Locking/unlocking the vehicle 435
Remote door unlock 299
Tilt/sliding sunroof, Manual
operation 438
Emergency Tensioning Device see ETD
