60 Getting started
Driving
Diesel engine
Make sure the automatic transmission
is set toP.
The transmission position indicator in
the multifunction display should be
on
P.
Depress the brake pedal during the
starting procedure.
Do not depress the accelerator.
Press KEYLESS-GO start / stop
button1 once.
The engine preglows and starts if the
SmartKey with KEYLESS-GO is in the
vehicle.Starting difficulties
If the engine does not start as described,
carry out the following steps:
If you are starting the engine with the
SmartKey, turn SmartKey in starter
switch to position0 and repeat starting
procedure.
If you are starting the engine with
KEYLESS-GO*: Close any doors that
may be open to allow for better
detection of the SmartKey with
KEYLESS-GO*.
Or:
Remove KEYLESS-GO* start/stop
button from starter switch (
page 43).
Start the engine with the SmartKey as
radio signals from another source may
be interfering with the SmartKey with
KEYLESS-GO*.
Repeat the starting procedure
(
page 57). Remember that extended
starting attempts can drain the battery.
Get a jump start (page 538).
If the engine does not start after several
starting attempts, there could be a mal-
function in the engine electronics or in the
fuel supply system.
Contact an authorized Mercedes-Benz
Light Truck Center or call Roadside
Assistance.
Parking brake
1Parking brake pedal
2Release handle
iIf the engine is at operating temperature,
the time the engine needs to preglow is reduced.

61 Getting started
Driving
Release the parking brake by pulling on
release handle2.
The warning lamp; (USA only)
or3(Canada only) in the
instrument cluster goes out.
Driving off
Depress the brake pedal.
The gear selector lever can now be
used.
Shift automatic transmission toD orR
(
page 194).
Release the brake pedal.
Carefully depress the accelerator
pedal.After a cold start, the automatic transmis-
sion shifts at a higher engine revolution.
This allows the catalytic converter (gaso-
line engine) or the oxidation catalyst (die-
sel engine) to reach its operating
temperature earlier.
Warning!G
When leaving the vehicle, always remove the
SmartKey or SmartKey with KEYLESS-GO*
from the starter switch, take it with you and
lock the vehicle. Do not leave children unat-
tended in the vehicle, or with access to an
unlocked vehicle. Children could release the
parking brake, which could result in an acci-
dent and/or serious personal injury.
iWait for the gear selection process to com-
plete before setting the vehicle in motion.
iShifting from gear positionP to positionR,
N, orD is only possible with the brake pedal
depressed. Without the brake pedal depressed,
the gear selector lever can be moved, but the
parking pawl remains engaged, not allowing
shifting to occur.
!If you hear a warning signal and the
message
Release parking brake appears in
the multifunction display when driving off, you
have forgotten to release the parking brake.
Release the parking brake (
page 60).
iOnce the vehicle is in motion, the automatic
central locking system engages and the locking
knobs drop down.
The automatic door lock feature can be
deactivated (
page 183).
You can open a locked door from the inside.
Open door only when conditions are safe to do
so.

62 Getting started
Driving
For more information, see “Driving instruc-
tions” (
page 349).
For information on off-road driving, see
“Off-road driving” (
page 357).
Switching on headlamps
Low beam headlamps
The exterior lamp switch is located on the
dashboard to the left of the steering wheel.
Exterior lamp switch
1Off
2Low beam headlamps on
Turn the exterior lamp switch to
positionB.
The low beam headlamps come on.
Warning!G
On slippery road surfaces, never downshift
in order to obtain braking action. This could
result in drive wheel slip and reduced vehi-
cle control. Your vehicle’s ABS will not pre-
vent this type of loss of control.
Warning!G
It is dangerous to shift the automatic trans-
mission out ofP orN if the engine speed is
higher than idle speed. If your foot is not
firmly on the brake pedal, the vehicle could
accelerate quickly forward or in reverse. You
could lose control of the vehicle and hit
someone or something. Only shift into gear
when the engine is idling normally and when
your right foot is firmly on the brake pedal.
!Shift the automatic transmission to
positionPorR only when the vehicle is stopped
in order to avoid damaging the transmission.
!Do not run cold engine at high engine
speeds. Running a cold engine at high engine
speeds may shorten the service life of the
engine.
!Simultaneously depressing the accelerator
pedal and applying the brakes reduces engine
performance and causes premature brake and
drivetrain wear.

63 Getting started
Driving
High beam
The combination switch is located on the
left of the steering column.
Combination switch
1High beam
2High beam flasher
Push the combination switch in
direction of arrow1.
The high beam headlamp indicator
lampA in the instrument cluster
comes on (
page 26).
For more information on headlamps, see
“Lighting” (
page 145).
Turn signals
The combination switch is located on the
left of the steering column.
Combination switch
1Turn signals, right
2Turn signals, left
Press the combination switch in
direction of arrow1 or2.
The corresponding turn signal indicator
lampL orK in the instrument
cluster flashes (
page 26).The combination switch resets automati-
cally after major steering wheel move-
ment.
Windshield wipers
The combination switch is located on the
left of the steering column.
Combination switch
1Single wipe
Wiping with windshield washer fluid
2Switching on windshield wipers
iTo signal minor directional changes such as
changing lanes, press combination switch only
to point of resistance and release. The corre-
sponding turn signal will flash three times.

64 Getting started
Driving
Switch on the ignition (page 42).
Switching on windshield wipers
Turn the combination switch to the
desired position depending on the
intensity of the rain.
MWindshield wipers off
USlow intermittent wiping
Rain sensor operation with low
sensitivity.
VFast intermittent wiping
Rain sensor operation with high
sensitivity.
uSlow continuous wiping
tFast continuous wipingIntermittent wiping
Only switch on intermittent wiping under
wet weather conditions or in the presence
of precipitation.
When you select intermittent wiping, the
rain sensor is activated. The rain sensor
automatically sets a suitable wiping
interval depending on the wetness of the
sensor surface.
Turn the combination switch to
positionU orV.
!Do not operate the windshield wipers when
the windshield is dry. Dust that accumulates on
a windshield might scratch the glass and/or
damage the wiper blades when wiping occurs on
a dry windshield. If it is necessary to operate the
windshield wipers in dry weather conditions,
always operate the windshield wipers with wind-
shield washer fluid (
page 65).
!If anything blocks the windshield wipers
(leaves, snow, etc.), switch them off immediate-
ly.

For safety reasons, stop the vehicle in a safe
location and

remove SmartKey from starter switch
or

turn off the engine by pressing the
KEYLESS-GO* start/stop button and
open the driver’s door (with the driver’s
door open, starter switch is in
position0, same as with SmartKey
removed from starter switch)
before attempting to remove any blockage.

Remove blockage.

Turn the windshield wipers on again.If windshield wipers fail to function at all in the
combination switch positionU orV,

set the combination switch to the next
higher wiper speed

have the windshield wipers checked at the
nearest authorized Mercedes-Benz Light
Truck Center
!Do not leave windshield wipers on an inter-
mittent setting when the vehicle is taken to an
automatic car wash or during windshield clean-
ing. Wipers will operate in the presence of water
sprayed on the windshield, and windshield
wipers may be damaged as a result.
!If you have set intermittent wiping, dirt on
the surface of the rain sensor or optical effects
may cause the windshield wipers to wipe in an
undesired fashion. This could then damage the
windshield wiper blades or scratch the windows.
You should therefore switch off the windshield
wipers when weather conditions are dry.

65 Getting started
Driving
After the initial wipe, pauses between
wipes are automatically controlled by the
rain sensor.
Single wipe
Press the combination switch briefly in
direction of arrow1 to the resistance
point.
The windshield wipers wipe one time
without washer fluid.Wiping with windshield washer fluid
Press the combination switch in direc-
tion of arrow1 past the resistance
point.
The windshield wipers operate with
washer fluid.
For information on filling up the washer
reservoir, see “Windshield/rear window
washer system and headlamp cleaning
system*” (
page 384).
Rear window wiper/washer
The combination switch is located on the
left of the steering column.
Combination switch
1Rear window wiper switch
2Wiping rear window with washer fluid
3Intermittent wiping
4Rear window wiper off
5Wiping rear window with washer fluid
iIntermittent wiping is interrupted when the
vehicle is at a standstill and a front door is
opened. This protects persons getting into or out
of the vehicle from being sprayed.
Intermittent wiping will be continued when all
doors are closed and

the automatic transmission is set to
positionD orR
or

the wiper setting is changed using the
combination switch
iTo prevent smears on the windshield or
noisy/chattering wiper blades, wipe with
windshield washer fluid every now and then even
when it is raining.


66 Getting started
Driving
6Rear window wiper indicator
Switch on the ignition (page 42).
Activating intermittent wipe
Turn rear window wiper switch1 to
position3 (
page 65).
In the lower multifunction display you
will see indicator6, indicating that
the rear window wiper is activated.Deactivating intermittent wipe
Turn rear window wiper switch1 to
position4 (
page 65).
Indicator6 (
page 66) for the rear
window wiper is cleared from the lower
multifunction display, indicating that
the rear window wiper is deactivated.
Wiping with windshield washer fluid
Turn and hold rear window wiper
switch1 in position2 or5
(
page 65) until the rear window is
clean.
The rear window wiper operates with
washer fluid.
For information on filling up the washer
reservoir, see “Windshield/rear window
washer system and headlamp cleaning
system*” (
page 384).
Problems while driving
The engine runs erratically and misfires

An ignition cable may be damaged
(gasoline engine only).

The engine electronics may not be
operating properly.

Unburned gasoline may have entered
the catalytic converter and damaged it
(gasoline engine only).
Give very little gas.
Have the problem repaired by an
authorized Mercedes-Benz Light Truck
Center as soon as possible.
iThe rear window wiper engages automatical-
ly when the automatic transmission is shifted to
positionR with the windshield wipers switched
on.


67 Getting started
Driving
The coolant temperature is above
248°F (120°C)
The coolant is too hot and is no longer
cooling the engine.
Stop the vehicle in a safe location as
soon as possible and turn off the en-
gine. Allow engine and coolant to cool
off.
Check the coolant level and add cool-
ant if necessary (
page 382).In case of accident
If the vehicle is leaking fuel:
Do not start the engine under any
circumstances.
Notify local fire and/or police authori-
ties.
If the extent of the damage cannot be de-
termined:
Contact an authorized Mercedes-Benz
Light Truck Center or call Roadside
Assistance.
If no damage can be determined on the

major assemblies

fuel system

engine mount:
Start the engine in the usual manner.

68 Getting started
Parking and locking
You have now completed your first drive.
You have properly stopped and parked
your vehicle. End your drive as follows.Parking brake
1Parking brake pedal
2Release handle
Warning!G
With the engine not running, there is no
power assistance for the brake and the
steering system. In this case, it is important
to keep in mind that a considerably higher
degree of effort is necessary to brake and
steer the vehicle.
Warning!G
Do not park this vehicle in areas where com-
bustible materials such as grass, hay or
leaves can come into contact with the hot
exhaust system, as these materials could be
ignited and cause a vehicle fire.
To reduce the risk of personal injury, or
damage to the vehicle drivetrain, as a result
of vehicle movement, before turning off the
engine and leaving the vehicle always:

Keep right foot on brake pedal.

Firmly depress parking brake pedal.

Shift the automatic transmission to
positionP.

Slowly release brake pedal.

When parked on an incline, turn front
wheel towards the road curb.

Turn the SmartKey or the SmartKey with
KEYLESS-GO* to starter switch
position0 and remove, or press
KEYLESS-GO* start/stop button.

Take the SmartKey or the SmartKey with
KEYLESS-GO* with you and lock vehicle
when leaving.
Warning!G
Engaging the parking brake while the vehicle
is in motion can cause the rear wheels to
lock up. You could lose control of the vehicle
and cause an accident. In addition, the vehi-
cle’s brake lights do not light up when the
parking brake is engaged.

69 Getting started
Parking and locking
Step firmly on parking brake pedal1.
When the engine is running, the
warning lamp; (USA only) or3
(Canada only) in the instrument cluster
comes on.
Switching off headlamps
Turn the exterior lamp switch toM
(
page 62).
For more information, see “Lighting”
(
page 145).
Turning off the engine
Shift the automatic transmission to
positionP (
page 194).
Apply the parking brake (page 68).
Warning!G
When leaving the vehicle, always remove the
SmartKey or SmartKey with KEYLESS-GO*
from the starter switch, take it with you and
lock the vehicle. Do not leave children unat-
tended in the vehicle, or with access to an
unlocked vehicle. Children could release the
parking brake and/or shift the automatic
transmission out of positionP, either of
which could result in an accident and/or
serious personal injury.
Warning!G
Getting out of your vehicle with the
automatic transmission not fully engaged in
positionP is dangerous. Also, when parked
on an incline, positionP alone may not
prevent your vehicle from moving, possibly
hitting people or objects.
Always set the parking brake in addition to
shifting to positionP (
page 194).
When parked on an incline, also turn front
wheel towards the road curb.
iIf the engine cannot be turned off as
described, see “Emergency engine shut-down”
(
page 546).
Warning!G
Do not turn off the engine before the vehicle
has come to a complete stop. With the en-
gine not running, there is no power assis-
tance for the brake and steering systems. In
this case, it is important to keep in mind that
a considerably higher degree of effort is nec-
essary to brake and steer the vehicle.
iAlways set the parking brake in addition to
shifting the automatic transmission to positionP
(
page 194).
When parked on an incline, also turn front wheel
towards the road curb.
