180 Controls in detailControl system
Press buttonæ orç repeatedly
until the desired speed is shown in the
multifunction display.
When DSR is switched on, DSR will use
the programmed default speed to regu-
late the vehicle’s speed.
Trip computer menu
Use the trip computer menu to call up
statistical data on your vehicle.
The following information is available:Fuel consumption statistics from start

Press buttonÿ orè repeatedly
until the message
From start
appears
in the multifunction display.
1Distance driven since start
2Time elapsed since start
3Average speed since start
4Average fuel consumption since start
i
Once DSR is switched on, you can adjust the
set speed using the cruise control lever
(
page 266).
Function
Page
Fuel consumption statistics
from start
180
Fuel consumption statistics
since the last reset
181
Distance to empty
181
i
When you enter the trip computer menu, you
will always see the fuel consumption statistics
from start first.
i
All statistics stored since the last engine
start will be reset approximately 4 hours after
the SmartKey in the starter switch is turned to
position0 or removed from the starter switch.
Resetting will not occur if you turn the SmartKey
back to position1 or2 within this time period.


181 Controls in detail
Control system
Resetting fuel consumption statistics
Press buttonÿ orè repeatedly
until the message
From start
appears
in the multifunction display.

Press and hold the reset button in the
instrument cluster (
page 145) until
the value is reset to 0.
Fuel consumption statistics since the
last reset

Press buttonÿ orè repeatedly
until the message
From start
appears
in the multifunction display.

Press buttonj ork repeatedly
until the message
After reset
appears
in the multifunction display.1Distance driven since last reset
2Time elapsed since last reset
3Average speed since last reset
4Average fuel consumption since last
reset
Resetting fuel consumption statistics
manually

Press buttonÿ orè repeatedly
until the message
From start
appears
in the multifunction display.

Press buttonj ork repeatedly
until the message
After reset
appears
in the multifunction display.

Press and hold the reset button in the
instrument cluster (
page 145) until
the value is reset to 0.Distance to empty

Press buttonÿ orè repeatedly
until the message
From start
appears
in the multifunction display.

Press buttonj ork repeatedly
until the message
Range:
appears in
the multifunction display.
The calculated remaining driving range
based on the current fuel tank level
appears in the multifunction display.
i
The fuel consumption statistics reset auto-
matically to 0 when either of the following values
is exceeded:


distance covered: 100 000 miles


time elapsed: 10 000 hours

182 Controls in detailControl systemTel menu*
You can use the functions in the
Tel
menu
to operate your telephone, provided it is
connected to a hands-free system and
switched on.

Switch on the telephone and COMAND
system.

Press buttonÿ orè on the
multifunction steering wheel repeated-
ly until the message
Tel
appears in the
multifunction display.Which messages will appear in the multi-
function display depends on whether your
telephone is switched on or off:


If the telephone is off, the message Phone off
appears in the multifunction
display.


If the telephone is on:
The telephone will then search for a
network. During this time the multi-
function display is empty.
As soon as the telephone has found a
network, the message
Ready
appears in
the multifunction display.
This standby message indicates that your
telephone is ready for use and you can
operate it using the control system.
Warning!
G
A driver’s attention to the road must always
be his/her primary focus when driving. For
your safety and the safety of others, we rec-
ommend that you pull over to a safe location
and stop before placing or taking a tele-
phone call. If you choose to use the tele-
phone while driving, please use the
hands-free device and only use the tele-
phone when weather, road and traffic condi-
tions permit.
Some jurisdictions prohibit the driver from
using a cellular telephone while driving a ve-
hicle.
Bear in mind that at a speed of just 30 mph
(approximately 50 km/h), your vehicle is
covering a distance of 44 feet
(approximately 14 m) every second.
Never operate radio transmitters equipped
with a built-in or attached antenna (i.e. with-
out being connected to an external antenna)
from inside the vehicle while the engine is
running. Doing so could lead to a malfunc-
tion of the vehicle’s electronic system, pos-
sibly resulting in an accident and/or
personal injury.

183 Controls in detail
Control system
Answering a call
When your telephone is ready to receive
calls, you can answer a call at any time. In
the multifunction display you will then see
the message:
Press buttons.
You have answered the call. The
duration of the call appears in the
multifunction display.Ending a call

Press buttont.
You have ended the call. The standby
message appears in the multifunction
display.
Dialing a number from the phone book
If your telephone is ready to receive calls,
you may select and dial a number from the
phone book at any time.

Press buttonÿ orè repeatedly
until the message
Tel
appears in the
multifunction display.

Press buttonj ork.
The control system reads the phone
book which is stored in the telephone.
This may take several minutes. The
message
Please wait
appears in the
multifunction display.
When the message
Please wait

disappears, the phone book has been
loaded.

Press buttonj ork repeatedly
until the desired name appears in the
multifunction display.
The stored names are displayed in
ascending or descending alphabetical
order.
1Name from the phone book
i
If you do not wish to accept a call, press
buttont.
i
If you press and holdj ork for
longer than 1 second, the system scrolls rapidly
through the list of names until you release the
button again.
Cancel the quick search mode by pressing
buttont.


184 Controls in detailControl system
Press buttons.
The system dials the selected phone
number.

If the connection is successful and
this feature is supported by your
network provider, the name of the
party (if stored in your phone book)
you are calling and the duration of
the call will appear in the multifunc-
tion display.


If no connection is made, the
control system stores the dialed
number in the redial memory.Redialing
The control system stores the most
recently dialed phone numbers. This
eliminates the need to search through your
entire phone book.

Press buttonÿ orè repeatedly
until the message
Tel
appears in the
multifunction display.

Press buttons.
The first number in the redial memory
appears in the multifunction display.

Press buttonj ork repeatedly
until the desired name appears in the
multifunction display.

Press buttons.
The control system dials the selected
phone number.


185 Controls in detail
Automatic transmission
Automatic transmission
For more information on driving with an
automatic transmission, see “Automatic
transmission” (
page 54).
Your vehicle’s transmission adapts its gear
shifting process to your individual driving
style by continually adjusting the shift
points up or down. These shift point adjust-
ments are performed based on current
operating and driving conditions.
If the operating conditions change, the
automatic transmission reacts by
adjusting its shift program.
Gear selector lever
The gear selector lever is located on the
right of the steering column.Gearshift pattern for automatic
transmissionPPark position
RReverse gear
NNeutral
DDrive position
i
During the brief warm-up, transmission
upshifting is delayed. This allows the catalytic
converter (gasoline engine) or the oxidation
catalyst (diesel engine) to heat up more quickly
to operating temperature.
Warning!
G
Make sure that absolutely no objects are
obstructing the pedal’s range of movement.
Keep the driver’s footwell clear of all obsta-
cles. If there are any floormats or carpets in
the footwell, make sure that the pedals still
have sufficient clearance.
During sudden driving or braking maneuvers
the objects could get caught between the
pedals. You could then no longer brake or
accelerate. This could lead to accidents and
injury.

186 Controls in detailAutomatic transmission
Shifting from P to N
Moving the gear selector lever up or down
shifts the automatic transmission out of
park positionP:
With the vehicle at a standstill, depress
the brake pedal and keep it pressed.

Move gear selector lever up or down to
resistance point to select neutral
positionN.Shifting from N to R or from N to D

With the vehicle at a standstill, depress
the brake pedal and keep it pressed.

Move gear selector lever up past the
resistance point to select reverse
gearR.
or

Move gear selector lever down past the
resistance point to select drive
positionD.

Release the parking brake (
page 57).

Release the brake pedal.

Carefully depress the accelerator pedal
to drive off when it is safe to do so.
i
The current transmission positionP, R, N,
orD appears in the multifunction display
(
page 189).Warning!
G
It is dangerous to shift the automatic trans-
mission out of park positionP or neutral
positionN if the engine speed is higher than
idle speed. If your foot is not firmly on the
brake pedal, the vehicle could accelerate
quickly forward or reverse. You could lose
control of the vehicle and hit someone or
something. Only shift into gear when the
engine is idling normally and when your right
foot is firmly on the brake pedal.
i
The gear selector lever returns to its original
position.
i
The gear selector lever returns to its original
position.

187 Controls in detail
Automatic transmission
Shifting from P to R
With the vehicle at a standstill, depress
the brake pedal and keep it pressed.

Move gear selector lever up past the
resistance point to select reverse
gearR.

Release the parking brake (
page 57).

Release the brake pedal.

Carefully depress the accelerator pedal
to drive off when it is safe to do so.Shifting from P to D

With the vehicle at a standstill, depress
the brake pedal and keep it pressed.

M o v e g e a r s e l e c t o r l e v e r d o w n p a s t t h e
resistance point to select drive
positionD.

Release the parking brake (
page 57).

Release the brake pedal.

Carefully depress the accelerator pedal
to drive off when it is safe to do so.Shifting from D, R, or N to P
If you want to select park positionP with
the transmission being in drive positionD,
reverse gearR or neutral positionN:

With the vehicle at a standstill, depress
the brake pedal and keep it pressed.

Step firmly on parking brake pedal
(page 65).

Press button on gear selector lever in
direction of arrow (
page 185) to
select park positionP.

Release the brake pedal.
i
The gear selector lever returns to its original
position.
i
The gear selector lever returns to its original
position.
!
Shift the automatic transmission directly
from drive positionD to reverse gearR, from
reverse gearR to drive positionD or directly to
park positionP only when the vehicle is stopped.
Otherwise the automatic transmission could be
damaged.
When trying to free a vehicle stuck in mud or
snow, see “Rocking the vehicle” (
page 192).

188 Controls in detailAutomatic transmissionShifting from D or R to N
If you want to select neutral positionN
with the transmission being in drive
positionD or reverse gearR:
With the vehicle at a standstill, depress
the brake pedal and keep it pressed.

Step firmly on parking brake pedal
(page 65).

Move gear selector lever up to resis-
tance point when in drive positionD or
down to resistance point when in
reverse gearR to select neutral
positionN.

Release the brake pedal.
Shifting procedure
The automatic transmission selects indi-
vidual gears automatically, depending on:

drive positionD (
page 189) with gear
ranges (
page 193)


the selected program mode (M/C/S)
(ML 63 AMG only) (
page 195)


the position of the accelerator pedal
(page 191)


the vehicle speedWith drive positionD selected, you can use
the steering wheel gearshift control
buttons (
page 194) to influence trans-
mission shifting by:


limiting the gear range


changing gears manually
i
When the vehicle needs to be moved with
the engine switched off and the transmission set
to neutral positionN (
page 186), e.g. in an
automatic car wash, do not depress the parking
brake pedal.
!
Allow engine to warm up under low load use.
Do not place full load on the engine until the
operating temperature has been reached.
Shift into reverse gearR or park positionP only
when the vehicle is stopped.
Avoid spinning of a drive wheel for an extended
period when driving off on slippery road
surfaces. This may cause serious damage to the
drivetrain which is not covered by the
Mercedes-Benz Limited Warranty.

189 Controls in detail
Automatic transmission
Transmission positions
The current transmission position appears
in the multifunction display.
1Current transmission position!
If the current transmission position does not
appear in the multifunction display due to a
malfunction, for example, make sure that the
automatic transmission is in the desired position
by carefully driving off with the transmission in
drive positionD.
ML 63 AMG:
Select program modeC (
page 195).
Do not limit the gear range.
Effect
ì
Park position
Shift into park positionP only
when vehicle is stopped. The
park position is not intended to
serve as a brake when the vehi-
cle is parked. Rather, the driver
should always set the parking
brake in addition to shifting into
park positionP to secure the
vehicle.
If the vehicle’s electrical system
is malfunctioning, the automatic
transmission could remain
locked in park positionP.
Have the vehicle checked as
soon as possible by an autho-
rized Mercedes-Benz Light
Truck Center.
!
SmartKey:
If you turn off the engine using the SmartKey and
remove the SmartKey from the starter switch,
the transmission will shift to park positionP
automatically. Keep in mind that turning off the
engine with the SmartKey alone will not auto-
matically shift the transmission to park
positionP. Only when the SmartKey is removed
from the starter switch, will the transmission
automatically shift to park positionP.
KEYLESS-GO*:
If you turn off the engine using the KEYLESS-GO
start/stop button and open the driver’s door, the
transmission will shift to park positionP auto-
matically. Keep in mind that turning off the en-
gine using the KEYLESS-GO start/stop button
alone will not automatically shift the transmis-
sion to park positionP. Only when the driver’s
door is opened, will the transmission automati-
cally shift to park positionP.
Even though this is possible, make it a practice
to always shift into park positionP before turning
off the engine and removing the SmartKey from
the starter switch, or when using KEYLESS-GO*,
before turning off the engine with the start/stop
button and opening the driver’s door.
