Page 271 of 344

MERCEDES-BENZ ML350 2004 W163 Owners Manual 271 Practical hints
Replacing bulbs
7Tabs
Squeeze tabs7 together and remove
bulb holder.

Gently push bulb into socket, turn
counterclockwise and remove.

Insert new bulb in socket, push in and

Page 272 of 344

MERCEDES-BENZ ML350 2004 W163 Owners Manual 272 Practical hintsReplacing bulbs
Insert reflector from the left so that it
engages on the right.

Position tabs of cover in slots and rein-
stall cover until properly seated.
Adjusting headlamp a

Page 273 of 344

MERCEDES-BENZ ML350 2004 W163 Owners Manual 273 Practical hints
Replacing wiper blades
Replacing wiper blades
Removing
Fold the wiper arm forward.

Turn wiper blade at a right angle to wip-
er arm.
1Wiper blade
2Safety tab

Press safety tab

Page 274 of 344

MERCEDES-BENZ ML350 2004 W163 Owners Manual 274 Practical hintsFlat tire
Flat tireMounting the spare wheel Preparing the vehicle

Park the vehicle as far as possible from
moving traffic on a hard surface.

Turn on the hazard warning flasher

Page 275 of 344

MERCEDES-BENZ ML350 2004 W163 Owners Manual 275 Practical hints
Flat tire

On wheel to be changed, loosen but do
not yet remove the wheel bolts (ap-
proximately one full turn with wrench).
The jack take-up brackets are located di-
rectly beh

Page 276 of 344

MERCEDES-BENZ ML350 2004 W163 Owners Manual 276 Practical hintsFlat tireRemoving the wheel
Unscrew and remove all wheel bolts.

Remove the remaining bolts.

Grip the wheel from the sides and re-
move it.
Mounting the new wheel

Clean contac

Page 277 of 344

MERCEDES-BENZ ML350 2004 W163 Owners Manual 277 Practical hints
Flat tire
1-5Wheel bolts
Tighten the five wheel bolts evenly, fol-
lowing the diagonal sequence illustrat-
ed (1 to 5), until all bolts are tight.
Observe a tightening torque of

Page 278 of 344

MERCEDES-BENZ ML350 2004 W163 Owners Manual 278 Practical hintsBattery
BatteryThe battery is located on the passenger
side of the engine compartment.
1Negative terminal
2Positive terminal
Warning!
G
Failure to follow these instructions can re

Page 279 of 344

MERCEDES-BENZ ML350 2004 W163 Owners Manual 279 Practical hints
Battery
Disconnecting the battery
Depress parking brake firmly or move
gear selector lever to positionP.

Turn off all electrical consumers.

Remove key from the steering lock.

Page 280 of 344

MERCEDES-BENZ ML350 2004 W163 Owners Manual 280 Practical hintsBattery
Batteries contain materials that can harm
the environment if disposed of improperly.
Large 12-volt storage batteries contain
lead. Recycling of batteries is the preferred
