MERCEDES-BENZ R500 2006 W251 Owner's Manual

260 Controls in detailPanorama roof with power tilt/sliding panel*Opening and closing the panorama roof with power tilt/sliding panel
The tilt/sliding panel is opened and closed
electrically. The switch for the tilt/sliding
panel is on the overhead control panel.
The tilt/sliding panel only operates with
the roller sunblinds opened.
Roof panel switch1Push back to slide roof panel open
2Push forward to slide roof panel closed
3Push up to raise roof panel
4Pull down to lower roof panel
Warning!
G
When opening or closing the tilt/sliding pan-
el, make sure that there is no danger of any-
one being harmed by the opening or closing
procedure.
The opening procedure of the tilt/sliding
panel can be immediately halted by releas-
ing the switch or, if the switch was moved
past the resistance point and released, by
moving the switch in any direction.
The closing procedure of the tilt/sliding
panel can be immediately halted by releas-
ing the switch.
The panorama roof with power tilt/sliding
panel is made out of glass. In the event of an
accident, the glass may shatter. This may re-
sult in an opening in the roof.

261 Controls in detail
Panorama roof with power tilt/sliding panel*

Switch on the ignition (
page 38).
Opening

Pull and hold the roof panel switch to
resistance point in direction of
arrow1 (
page 260).
Release the roof panel switch when the
tilt/sliding panel has reached the de-
sired position.
Closing

Press and hold the roof panel switch in
direction of arrow2 (
page 260).
Release the roof panel switch when the
tilt/sliding panel has reached the de-
sired position.
In a vehicle rollover, occupants not wearing
their seat belts or not wearing them properly
may be thrown out of the opening. Such an
opening also presents a potential for injury
for occupants wearing their seat belts prop-
erly as entire body parts or portions of them
may protrude from the passenger compart-
ment.
When leaving the vehicle, always remove the
SmartKey or the SmartKey with
KEYLESS-GO* from the starter switch, take
it with you, and lock the vehicle. Do not
leave children unattended in the vehicle, or
with access to an unlocked vehicle. Unsu-
pervised use of vehicle equipment can
cause an accident and/or serious personal
injury.
!To avoid damaging the seals, do not
transport any objects with sharp edges
which can stick out of the tilt/sliding
panel.
Do not open the tilt/sliding panel if
there is snow or ice on the roof, as this
could result in malfunctions.iYou can also open or close the tilt/slid-
ing panel using the SmartKey or the
KEYLESS-GO* function, see “Summer
opening feature” (
page 251) and
“Convenience closing feature”
(
page 252).
iThe tilt/sliding panel may also open
when using the air recirculation
buttonÄ on the control panel of the
climate control (
page 218) or auto-
matic climate control (
page 232).

262 Controls in detailPanorama roof with power tilt/sliding panel*Raising
You can raise the tilt/sliding panel at the
rear for better ventilation of the vehicle in-
terior.
Press and hold the roof panel switch in
direction of arrow3 (
page 260).
Release the roof panel switch when the
tilt/sliding panel has reached the de-
sired position.
Lowering

Pull and hold the roof panel switch in
direction of arrow4 (
page 260) un-
til the tilt/sliding panel has lowered
and closed completely.Fully opening (Express-open) the pan-
orama roof with tilt/sliding panel

Pull the roof panel switch past the
resistance point in direction of
arrow1 (
page 260) and release.
The tilt/sliding panel opens complete-
ly.
Stopping the panorama roof with
tilt/sliding panel during Express-open

Move the roof panel switch in any di-
rection.
The tilt/sliding panel will stop in its cur-
rent position.Synchronizing the panorama roof with
power tilt/sliding panel
The tilt/sliding panel and its roller sun-
blinds must be synchronized

after the battery has been
disconnected or discharged


after a malfunction


if the tilt/sliding panel does not open
smoothly!Do not attempt to open or close the
tilt/sliding panel before the tilt/sliding
panel is properly synchronized. The
tilt/sliding panel could otherwise
lock-up in the open position.
If the tilt/sliding panel cannot be
closed or synchronized, see an autho-
rized Mercedes-Benz Light Truck
Center or call Roadside Assistance
(page 315).

263 Controls in detail
Panorama roof with power tilt/sliding panel*

Switch off the ignition (
page 38) and
remove the SmartKey from the starter
switch.
Vehicles with KEYLESS-GO*:

Switch off the ignition (
page 39).

Open the driver’s door (this puts the
starter switch in position 0, same as
with the SmartKey removed from the
starter switch). The driver’s door then
can be closed again.

Remove the fuse securing the
tilt/sliding panel from the fuse box
(page 504).

Reinsert the fuse in the fuse box.

Switch on the ignition (
page 38).

Push and hold the roof panel switch in
direction of arrow2 (
page 260) un-
til the roller sunblinds are fully closed.

Keep holding the roof panel switch in
direction of arrow2 (
page 260) for
approximately 1 second.

Pull and hold the roof panel switch in
direction of arrow1 (
page 260) un-
til the roller sunblinds are fully opened.

Keep holding the roof panel switch in
direction of arrow1 (
page 260) for
approximately 1 second.

Press and hold the roof panel switch in
direction of arrow3 (
page 260) un-
til the tilt/sliding panel is fully raised at
the rear.

Push and hold the roof panel switch in
direction of arrow2 (
page 260) un-
til the tilt/sliding panel is fully closed.

Keep holding the roof panel switch in
direction of arrow2 (
page 260) for
approximately 1 second.

Open the tilt/sliding panel using the
Express-open feature (
page 262).
If the tilt/sliding panel opens com-
pletely, the roof is synchronized.
If the tilt/sliding sunroof does not open
completely:

Repeat the above steps.
iFor information on which fuse box con-
tains the fuse for the power tilt/sliding
panel, see the fuse chart provided with
the vehicle tool kit (
page 455).

264 Controls in detailDriving systemsThe driving systems of your vehicle are de-
scribed on the following pages:

Cruise control, with which the vehicle
can maintain a preset speed.


Airmatic* adjusts the vehicle suspen-
sion characteristics automatically and
controls the vehicle level.


Parktronic*, which serves as a parking
assistant.
For information on the BAS, ABS, EBP,
4-ETS and ESP
® driving systems, see “Driv-
ing safety systems” (
page 97).
Cruise control
The cruise control automatically maintains
the speed you set for your vehicle.
The use of cruise control is recommended
for driving at a constant speed for extend-
ed periods of time. You can set or resume
cruise control at any speed above 20 mph
(30 km/h).
The cruise control function is operated by
means of the cruise control lever.
The cruise control lever is the uppermost
lever on the left-hand side of the steering
column (
page 22).
Warning!
G
The cruise control is a convenience system
designed to assist the driver during vehicle
operation. The driver is and must always
remain responsible for the vehicle’s speed
and for safe brake operation.
Only use the cruise control if the road, traffic
and weather conditions make it advisable to
travel at a steady speed.

The use of cruise control can be danger-
ous on winding roads or in heavy traffic
because conditions do not allow safe
driving at a steady speed.


The use of cruise control can be danger-
ous on slippery roads. Rapid changes in
tire traction can result in wheel spin and
loss of control.


Deactivate the cruise control when driv-
ing in fog.
The “Resume” function should only be oper-
ated if the driver is fully aware of the previ-
ously set speed and wishes to resume this
particular preset speed.

265 Controls in detail
Driving systems
1Setting current or higher speed
Adjustment in 1 mph or 5 mph
increments (Canada: 1 km/h or
10 km/h)
2Setting current or lower speed
Adjustment in 1 mph or 5 mph
increments (Canada: 1 km/h or
10 km/h)
3Canceling cruise control
4Resuming to last set speedSetting current speed

Accelerate or decelerate to the desired
speed.

Briefly lift1 or depress2 the cruise
control lever.
The current speed is set.

Remove your foot from the accelerator
pedal.
The cruise control is activated.
The last set speed appears in the multi-
function display for approximately
5 seconds.
Warning!
G
The cruise control brakes automatically so
that the set speed is not exceeded. The
brake pedal is depressed automatically to
do this.
Keep in mind that the cruise control is a con-
venience system designed to assist the driv-
er during vehicle operation. The driver is and
must always remain responsible for the ve-
hicle’s speed and for safe brake operation.
Keep driver’s foot area clear at all times, in-
cluding the area under the brake pedal. Ob-
jects stored in this area may impair pedal
movement which could interfere with the
braking ability of the cruise control system.
Do not place your foot under the brake pedal
- your foot could become caught.
iOn uphill grades, the cruise control
may not be able to maintain the set
speed. Once the grade eases, the set
speed will be resumed.
On downhill grades, the cruise control
maintains the set speed with active
braking action. In addition, on longer
downhill grades the automatic trans-
mission will automatically downshift.

266 Controls in detailDriving systemsCanceling cruise control
There are several ways to cancel the cruise
control:
Step on the brake pedal.
The cruise control is canceled. The last
speed set is stored for later use.
or

Briefly push the cruise control lever in
direction of arrow3 (
page 265).
The cruise control is canceled. The last
speed set is stored for later use.
iThe last stored speed is canceled when
you turn off the engine.
iThe cruise control switches off auto-
matically when

you step on the brake pedal


you depress the parking brake
pedal
The cruise control also switches off au-
tomatically when


the vehicle speed is below 20 mph
(30 km/h)


the ESP
® is in operation or switched
off with the ESP
® switch
(
page 101)


you set the automatic transmission
toN while driving
An acoustic warning sounds and the
message
Cruise control off
appears
in the multifunction display.
!Setting the automatic transmission
toN while driving cancels the cruise
control. However, the automatic trans-
mission should not be set toN while
driving except to coast when the vehi-
cle is in danger of skidding (e.g. on icy
roads).iDepressing the accelerator pedal does
not deactivate the cruise control. After
brief acceleration (e.g. for passing), the
cruise control will resume the last
speed set.

267 Controls in detail
Driving systems
Setting a higher speed
You can increase the speed in two stages.
Adjustment in 1 mph (Canada: 1 km/h)
increments
Lift the cruise control lever to the resis-
tance point in direction of arrow1
(page 265) and hold it up until the
desired speed is reached.

Release the cruise control lever.
The new speed is set.Adjustment in 5 mph
(Canada: 10 km/h) increments

Briefly lift the cruise control lever past
the resistance point in direction of
arrow1 (
page 265).
The vehicle speed increases in incre-
ments of 5 mph (Canada: 10 km / h).
Setting a lower speed
You can reduce the speed in two stages.
iThe set value is increased in 1 mph
(Canada: 1 km/h) increments each
time you lift the cruise control lever to
the resistance point.
Warning!
G
You can increase the vehicle speed in 5 mph
(Canada 10 km/h) increments. When using
this feature, keep in mind that it may take a
brief moment until the vehicle has reached
the set speed.
Increase the vehicle speed to a value that
the prevailing road conditions permit. Other-
wise, sudden and unexpected acceleration
of the vehicle could cause an accident
and/or serious injury to you and others.iThe set value is increased in 5 mph
(Canada: 10 km/h) increments each
time you lift the cruise control lever
past the resistance point.
iThe new speed is set and the vehicle
will accelerate. Keep in mind that it
may take a brief moment until the vehi-
cle has reached the set speed.iWhen you use the cruise control lever
to decelerate, the brake system will au-
tomatically brake the vehicle if the en-
gine’s braking power does not brake
the vehicle sufficiently.

268 Controls in detailDriving systemsAdjustment in 1 mph (Canada: 1 km/h)
increments
Press the cruise control lever down to
the resistance point in direction of
arrow2 (
page 265) and hold it
down until the desired speed is
reached.

Release the cruise control lever.
The new speed is set.Adjustment in 5 mph
(Canada: 10 km/h) increments

Briefly press the cruise control lever
down past the resistance point in direc-
tion of arrow2.
The vehicle speed decreases in incre-
ments of 5 mph (Canada: 10 km/h).
iThe set value is decreased in 1 mph
(Canada: 1 km/h) increments each
time you press the cruise control lever
down to the resistance point.
Warning!
G
You can decrease the vehicle speed in
5 mph (Canada 10 km/h) increments. When
using this feature, keep in mind that it may
take a brief moment until the vehicle has
reached the set speed.
Decelerate the vehicle speed to a value that
the prevailing road conditions permit. Other-
wise, sudden and unexpected deceleration
of the vehicle could cause an accident
and/or serious injury to you and others.iThe set value is decreased in 5 mph
(Canada: 10 km/h) increments each
time you press the cruise control lever
down past the resistance point.
iThe new speed is set and the vehicle
will decelerate. Keep in mind that it
may take a brief moment until the vehi-
cle has reached the set speed.

269 Controls in detail
Driving systems
Setting to last stored speed
(“Resume” function)
Briefly pull the cruise control lever in di-
rection of arrow4 (
page 265).
The cruise control resumes the last set
speed.

Remove your foot from the accelerator
pedal.
The last set speed appears in the multi-
function display for approximately
5seconds.
AIRMATIC*
AIRMATIC lets you set a suspension tuning
and automatically optimizes your vehicle’s
damping behavior and regulates the
vehicle level. The system consists of two
components:

Suspension tuning:
Adaptive Damping System (ADS)*
(page 269)


Vehicle level control* (
page 270)Adaptive Damping System (ADS)*
The fine tuning of the damping is depen-
dent on:


road surface conditions


your driving style


your personal settings
The ADS switch is located on the upper
part of the center console.
1ADS switch
2Indicator lamp for SPORT setting
3Indicator lamp for COMF setting
Warning!
G
The speed stored in memory should only be
set again if prevailing road conditions per-
mit. Possible acceleration or deceleration
differences arising from returning to the pre-
set speed could cause an accident and/or
serious injury to you and others.
