370 Controls in detailStarter switch positionsSmartKeyStarter switch
0For removing SmartKey
1Power supply for some electrical con-
sumers
2Ignition (power supply for all electrical
consumers) and driving position.
All lamps (except high beam headlamp
indicator lamp and turn signal indicator
lamps unless activated) in the instru-
ment cluster come on. If a lamp in the
instrument cluster fails to come on
when the ignition is switched on, have
it checked and replaced if necessary.
If a lamp in the instrument cluster re-
mains on after starting the engine or
comes on while driving, refer to “Lamps
in instrument cluster” (
page 628).
3Starting positionFor information on starting the engine us-
ing the SmartKey, see “Starting with the
SmartKey” (
page 417).
Warning!
G
When leaving the vehicle, always remove the
SmartKey or SmartKey with KEYLESS-GO*
from the starter switch, take it with you, and
lock the vehicle. Do not leave children unat-
tended in the vehicle, or with access to an
unlocked vehicle. A child’s unsupervised ac-
cess to a vehicle could result in an accident
and/or serious personal injury.
i
When you switch on the ignition, the indica-
tor and warning lamps (except high beam head-
lamp indicator lamp and turn signal indicator
lamps unless activated) in the instrument cluster
come on. The indicator and warning lamps (ex-
cept high beam headlamp indicator lamp and
turn signal indicator lamps if activated) should go
out when the engine is running. This indicates
that the respective systems are operational.
i
When the SmartKey is removed from the
starter switch and the automatic transmission is
in a position other than park positionP, the auto-
matic transmission automatically shifts to park
positionP.
!
If the SmartKey cannot be turned in the
starter switch, the battery may not be sufficient-
ly charged.


Check the battery and charge it if necessary
(page 729).


Have the vehicle jump-started (
page 734).
To prevent accelerated battery discharge or a
completely discharged battery, always remove
the SmartKey from the starter switch when the
engine is not in operation.

371 Controls in detail
Starter switch positions
SmartKey with KEYLESS-GO*
Vehicles equipped with the KEYLESS-GO
feature are supplied with a SmartKey with
integrated KEYLESS-GO function and a re-
movable KEYLESS-GO start/stop button.
With the KEYLESS-GO start/stop button
inserted and the SmartKey with
KEYLESS-GO present in the vehicle, press-
ing the KEYLESS-GO start/stop button

without the brake pedal depressed
corresponds to the various starter
switch positions (
page 372)


with the brake pedal firmly depressed
will start the engine (
page 417)If you wish or should there be a need to in-
sert the SmartKey with KEYLESS-GO in the
starter switch, the KEYLESS-GO start/stop
button can be easily removed by pulling it
out of the starter switch.
1KEYLESS-GO start/stop button
2Starter switch

Insert KEYLESS-GO start/stop
button1 into starter switch 2 (if not
inserted already).
i
The function of the SmartKey overrules the
KEYLESS-GO function.
i
The KEYLESS-GO start/stop button does
not need to be removed from the starter switch
when you leave the vehicle. However, always
take the SmartKey with KEYLESS-GO with you
when you leave the vehicle. As long as the
S m a r t K e y w i t h K E Y L E S S - G O i s i n t h e v e h i c l e , t h e
vehicle’s electrical systems can be switched on
or the engine can be started using the
KEYLESS-GO start/stop button.
i
When you switch from SmartKey mode back
to KEYLESS-GO mode, the system requires
2 seconds of detection time before you can use
the KEYLESS-GO button as usual.


372 Controls in detailStarter switch positionsThe SmartKey with KEYLESS-GO must be
located in the vehicle.
Make sure the automatic transmission
is set to park positionP.

Do not depress the brake pedal.
KEYLESS-GO start/stop button1USA only
2Canada only
Position 0
Before you press the KEYLESS-GO
start/stop button, the vehicle’s on-board
electronics have status 0 (as with
SmartKey removed).Position 1

Press the KEYLESS-GO start/stop but-
ton once.
This supplies power for some electrical
consumers.
Ignition (or position 2)

Press the KEYLESS-GO start/stop but-
ton twice.
This supplies power for all electrical
consumers.
All lamps (except high beam headlamp
indicator lamp and turn signal indicator
lamps unless activated) in the instru-
ment cluster come on. If a lamp in the
instrument cluster fails to come on
when the ignition is switched on, have
it checked and replaced if necessary. If a lamp in the instrument cluster re-
mains on after starting the engine or
comes on while driving, refer to “Lamps
in instrument cluster” (
page 628).
For information on starting the engine us-
ing the KEYLESS-GO start/stop button,
see “Starting with KEYLESS-GO*”
(
page 417).
i
If you now press the KEYLESS-GO
start/stop button


once again, the ignition (position2) is
switched on


twice, the power supply is again switched off
i
If you now press the KEYLESS-GO
start/stop button once, the power supply is
again switched off.
i
When you switch on the ignition, the indica-
tor and warning lamps (except high beam head-
lamp indicator lamp and turn signal indicator
lamps unless activated) in the instrument cluster
come on. The indicator and warning lamps (ex-
cept high beam headlamp indicator lamp and
turn signal indicator lamps if activated) should go
out when the engine is running. This indicates
that the respective systems are operational.


373 Controls in detailSeats
Seats
Seat adjustmentWarning!
G
All seat, head restraint adjustments, as well
as fastening of seat belts, must be done be-
fore the vehicle is put into motion.Warning!
G
Do not adjust the driver’s seat while driving.
Adjusting the seat while driving could cause
the driver to lose control of the vehicle.
Never ride in a moving vehicle with the seat
back in an excessively reclined position as
this can be dangerous. You could slide un-
der the seat belt in a collision. If you slide
under it, the seat belt would apply force at
the abdomen or neck. That could cause se-
rious or fatal injuries. The seat backrest and
seat belts provide the best restraint when
the wearer is in a nearly upright position and
seat belts are properly positioned on the
body.
Warning!
G
Your seat must be adjusted so that you can
correctly fasten your seat belt
(page 395).
Observe the following points:


Adjust the backrest until your arms are
slightly angled when holding the steer-
ing wheel.


Adjust the seat to a comfortable seating
position that still allows you to reach the
accelerator/brake pedal safely. The po-
sition should be as far back as possible
with the driver still able to operate the
controls properly.


Adjust the head restraint so that it is as
close to the head as possible and the
center of the head restraint supports
the back of the head at eye level.


Never place hands under the seat or
near any moving parts while a seat is be-
ing adjusted.
Failure to do so could result in injury to per-
sons.
Warning!
G
When leaving the vehicle, always remove the
SmartKey or SmartKey with KEYLESS-GO*
from the starter switch, take it with you, and
lock the vehicle.
Even with the SmartKey or SmartKey with
KEYLESS-GO* removed from the starter
switch or the SmartKey with KEYLESS-GO*
removed from the vehicle, the power seats
can be operated. Therefore, do not leave
children unattended in the vehicle, or with
access to an unlocked vehicle. A child’s un-
supervised access to a vehicle could result
in an accident and/or serious personal
injury.

374 Controls in detailSeats
You can adjust the lumbar support, multi-
contour seats* for driver and front passen-
ger, as well as drive-dynamic multicontour
seats* using COMAND (
page 282).
Front power seat adjustment
Example driver’s door1Head restraint height (
page 379)
2Seat height
3Seat cushion tilt
4Seat cushion depth
5Seat fore and aft
6Seat backrest tilt

Seat height: Press the switch up or
down in the direction of arrow2.

Seat cushion tilt: Press the switch up
or down in the direction of
arrow3until your upper legs are
lightly supported.

Seat cushion depth: Press the switch
forward or backward in the direction of
arrow4 until your legs are supported
comfortably.
Warning!
G
According to accident statistics, children
are safer when properly restrained in the
rear seating positions than in the front seat-
ing position. Thus, we strongly recommend
that children be placed in the rear seats
whenever possible. Regardless of seating
position, children 12 years old and under
must be seated and properly secured in an
appropriately sized infant restraint, toddler
restraint, or booster seat recommended for
the size and weight of the child. For addi-
tional information, see “Children in the vehi-
cle” (
page 58).
A child’s risk of serious or fatal injuries is
significantly increased if the child restraints
are not properly secured in the vehicle and
the child is not properly secured in the child
restraint.
i
If PRE-SAFE
® has been activated, the front
passenger’s seat and/or electrically adjustable
rear seats* will be moved to a more favorable
seat position.
i
The memory function (
page 392) lets you
store the settings for the seat positions together
with the settings for the steering wheel and the
exterior rear view mirrors.
!
When moving the seats, make sure there are
no items in the footwell or behind the seats; oth-
erwise, you could damage the seats.

375 Controls in detailSeats

Seat fore and aft: Press the switch for-
ward or backward in the direction of
arrow5.

Seat backrest tilt: Press the switch
forward or backward in the direction of
arrow6.Rear power seat* adjustment
(rear outer seats)
Example rear right door1Seat cushion tilt
2Seat backrest tilt
3Folding down and placing upright head
restraint (
page 382)
4Head restraint tilt (
page 382)
5Seat fore and aft

Adjust desired seat using seat
switches1,2 and5.
i
Depending on the set height of the head re-
straint, the seat fore and aft position is automat-
ically pre-set.
i
Depending on vehicle production date you
have to switch on the ignition or open the re-
spective door before adjusting the rear power
seats.

376 Controls in detailSeatsAdjusting front passenger seat from
driver’s seat/rear*
Adjusting front passenger seat from
driver’s seat*
You can adjust the front passenger seat
using the seat switches on the driver’s
side.
1Adjusting front passenger seat

Press button1.When the indicator lamp on button1 is
on, you can operate the following features
of the front passenger seat:


seat adjustment


seat heating/ventilation*


memory function
Warning!
G
When adjusting the front passenger seat,
make sure the seat, if occupied, is as far
from the passenger front air bag as possi-
ble.
Otherwise, the passenger could be seriously
or even fatally injured in the event of an ac-
cident or braking maneuver.
Make sure no one is caught or injured while
the seat is being adjusted.
Even with the SmartKey or SmartKey with
KEYLESS-GO* removed from the starter
switch or the SmartKey with KEYLESS-GO*
removed from the vehicle, the power seats
can be operated. Therefore, do not leave
children unattended in the vehicle, or with
access to an unlocked vehicle. A child’s un-
supervised access to a vehicle could result
in an accident and/or serious personal
injury.
!
Do not move the front passenger seat com-
pletely forward if objects are stored in the parcel
net in the front passenger-side footwell. Items in
the net may be damaged.

377 Controls in detailSeats
Setting front passenger seat position
from rear*
The switch is located on the right rear pas-
senger door.
1To select front or rear passenger seat
2Seat height
3Head restraint height (
page 379)
4Backrest tilt
5Seat fore and aft

Press button1 to adjust the front
passenger seat.
The indicator lamp in button1 comes
on.

Adjust front passenger seat using seat
switches2,3,4 and5.

To adjust right rear passenger seat
(page 375), press button1 again.
The indicator lamp in button1 goes
out.
Seat heating
The buttons for seat heating are located on
the respective door. The red indicator
lamps on the button come on to show the
heating level selected.
i
Adjusting the passenger seat position from
the rear is not possible if you deactivate the over-
ride switch (
page 64).
Level3
Three indicator lamps on
(highest level)
The seat heating automatically
switches to level2 after approxi-
mately 5 minutes.
2
Two indicator lamps on
The seat heating automatically
switches to level1 after approxi-
mately 10 minutes.
1
One indicator lamp on
(lowest level)
The seat heating automatically
switches off after approximately
20 minutes.
off
No indicator lamp on

378 Controls in detailSeatsExample illustration driver’s door1Seat heating button
Switch on the ignition (
page 370).

Switching on: Press button1 repeat-
edly until the desired heating level is
set.
One or more red indicator lamps on the
button show the selected heating level.

Switching off: Press button1 repeat-
edly until all indicator lamps go out.
Seat ventilation*
The buttons for seat ventilation are located
on the respective door. The blue indicator
lamps on the button come on to show the
ventilation level selected.
Example illustration driver’s door1Seat ventilation button
Switch on the ignition (
page 370).

Switching on: Press button1 repeat-
edly until the desired ventilation level is
set.
One or more blue indicator lamps on
the button show the selected ventila-
tion level.
i
If one or more of the lamps on the seat heat-
ing button are flashing, there is insufficient volt-
age available since too many electrical
consumers are turned on. The seat heating
switches off automatically.
The seat heating will switch back on again auto-
matically as soon as sufficient voltage is avail-
able.
Level3
Three indicator lamps on
(highest level)
2
Two indicator lamps on
1
One indicator lamp on
(lowest level)
off
No indicator lamp on
i
The seat ventilation for the driver’s seat can
be activated using summer opening feature
(
page 412).

379 Controls in detailSeats

Switching off: Press button1 repeat-
edly until all indicator lamps go out.
Head restraints Front seat active head restraints
You cannot remove the active head re-
straint on the driver’s and front passen-
ger’s seats.
For removal contact an authorized
Mercedes-Benz Center.
For information on active head restraints,
see “Active head restraints” (
page 56).
Head restraint height
1Head restraint height

Press the switch up or down in the di-
rection of arrow1.
i
If one or more of the lamps on the seat ven-
tilation button are flashing, there is insufficient
voltage available since too many electrical con-
sumers are turned on. The seat ventilation
switches off automatically.
The seat ventilation will switch back on again au-
tomatically as soon as sufficient voltage is avail-
able.
Warning!
G
For your protection, drive only with properly
positioned head restraints.
Adjust the head restraint so that it is as
close to the head as possible and the center
of the head restraint supports the back of
the head at eye level. This will reduce the po-
tential for injury to the head and neck in the
event of an accident or similar situation.
Do not drive the vehicle without the seat
head restraints. Head restraints are intend-
ed to help reduce injuries during an acci-
dent.i
Adjust the head restraint in such a way that
it is as close to the head as possible.
