400 Controls in detailLightingLow beam headlamps
The low beam headlamps can be switched
on and off with the exterior lamp switch us-
ing the manual headlamp mode.
Switching on: Turn the exterior lamp
switch to positionB.
The following lamps switch on:

Low beam headlamps


Tail and parking lamps


License plate lamps


Side marker lampsAutomatic headlamp mode
The following lamps switch on and off au-
tomatically depending on the brightness of
the ambient light:


Low beam headlamps


Tail and parking lamps


License plate lamps


Side marker lamps
Warning!
G
If the exterior lamp switch is set to*,
the headlamps will not be automatically
switched on under foggy conditions.
To minimize risk to you and to others, acti-
vate headlamps by turning exterior lamp
switch to B when driving or when traffic
and/or ambient lighting conditions require
you to do so.
In low ambient lighting conditions, only
switch from position * to B with the
vehicle at a standstill in a safe location.
Switching from * to B will briefly
switch off the headlamps. Doing so while
driving in low ambient lighting conditions
may result in an accident.

401 Controls in detail
Lighting

Turn the exterior lamp switch to
position*.
With the SmartKey in starter switch po-
sition 1 or the KEYLESS-GO*
start/stop button pressed once, the
tail and parking lamps, the license
plate lamps and the side marker lamps
will switch on and off depending on the
brightness of the ambient light.
When the engine is running the low
beam headlamps, the tail and parking
lamps, the license plate lamps and the
side marker lamps will switch on and
off depending on the brightness of the
ambient light.Daytime running lamp mode
In Canada the daytime running lamp mode
is mandatory and therefore in a constant
mode.
By default, the daytime running lamp mode
is deactivated. Activate the daytime run-
ning lamp mode using the control system,
see “Setting daytime running lamp mode
(USA only)” (
page 306).

Turn exterior lamp switch to
positionM or*.
When the engine is running, the low
beam headlamps are switched on.
In low ambient light conditions, the fol-
lowing lamps will switch on additional-
ly:

Tail and parking lamps


License plate lamps


Side marker lampsCanada only
When the engine is running, and you shift
from a driving position to neutral
positionN or park positionP, with the ve-
hicle at a standstill the low beam head-
lamps will switch off with a delay of 3
minutes.
When the engine is running, and you


turn the exterior lamp switch to
positionC, the low beam head-
lamps, the tail and parking lamps, the
license plate lamps and the side mark-
er lamps switch on.


turn the exterior lamp switch to
positionB, the manual headlamp
mode has priority over the daytime run-
ning lamp mode.
The automatic headlamp feature is only an
aid to the driver. The driver is responsible for
the operation of the vehicle’s lights at all
times.i
Canada only:
High beam headlamps are only available with the
exterior lamp switch in positionB.
i
With the daytime running lamp mode activat-
ed and the engine running, the low beam head-
lamps cannot be switched off manually.
i
With the exterior lamp switch in position
M or *, you cannot switch on the high
beam headlamps.
The high beam flasher is available at all times.
For nighttime driving you should turn the exterior
lamp switch to positionB to permit activa-
tion of the high beam headlamps.

402 Controls in detailLighting
The corresponding exterior lamps
switch on (
page 399).
USA only
When the engine is running, and you turn
the exterior lamp switch to position C
orB, the manual headlamp mode has
priority over the daytime running lamp
mode.
The corresponding exterior lamps switch
on (
page 399).Locator lighting and night security illu-
mination
The locator lighting and night security illu-
mination are described in the COMAND ve-
hicle section under “Setting locator
lighting” (
page 265) and “Setting night
security illumination” (
page 264).
Fog lampsFront fog lamps

Turn the exterior lamp switch to
positionC orB (
page 399).

Pull out exterior lamp switch to first
stop.
The front fog lamps are switched on.
The green indicator lamp‡ in the
exterior lamp switch comes on
(page 399).

Push in the exterior lamp switch.
The front fog lamps are switched off.
The green indicator lamp‡ in the
exterior lamp switch goes out.
i
With the daytime running lamp mode
activated and the exterior lamp switch in
position M, you cannot switch on the high
beam headlamps.
The high beam flasher is available at all times.
For nighttime driving you should turn the exterior
lamp switch to positionB or * to permit
activation of the high beam headlamps.
Warning!
G
In low ambient lighting or foggy conditions,
only switch from position * to B with
the vehicle at a standstill in a safe location.
Switching from * to B will briefly
switch off the headlamps. Doing so while
driving in low ambient lighting conditions
may result in an accident.i
Fog lamps will operate with the parking
lamps and/or the low beam headlamps on. Fog
lamps should only be used in conjunction with
low beam headlamps. Consult your State or
Province Motor Vehicle Regulations regarding
permissible lamp operation.
i
Fog lamps cannot be switched on manually
with exterior lamp switch in position*. To
activate the fog lamps, turn exterior lamp switch
to positionB first.

403 Controls in detail
Lighting
Rear fog lamp (driver’s side only)
Turn the exterior lamp switch to
positionB (
page 399).

Pull out exterior lamp switch to second
stop.
The front fog lamps and the rear fog
lamp switch on.
The yellow indicator lamp† in the
exterior lamp switch comes on
(page 399).

Push in the exterior lamp switch to first
stop.
The rear fog lamp switches off.
The yellow indicator lamp† in the
exterior lamp switch goes out.
The front fog lamps remain lit.
High beamCombination switch1High beam
2High beam flasher
High beam headlamps: Turn the exte-
rior lamp switch to positionB
(page 399).

Push the combination switch in the di-
rection of arrow1.
The high beam indicatorA in the in-
strument cluster comes on
(page 28).

High beam flasher: Pull the combina-
tion switch briefly in the direction of
arrow2.
Headlamp cleaning system
With the engine running the headlamps will
automatically be cleaned with a high-pres-
sure water jet when you have

switched on the headlamps
and


the windshield wipers have wiped the
windshield with washer fluid five times
When you switch off the ignition the
counter resets.
For information on filling up the washer
reservoir, see “Windshield washer system
and headlamp cleaning system”
(
page 580).

404 Controls in detailLightingCorner-illuminating lamps
The corner-illuminating lamps improve illu-
mination of the area in the direction into
which you are turning.
The corner-illuminating lamps will operate
with the engine running and with:

the exterior lamp switch in
positionB or* (
page 399)
or


the daytime running lamp mode acti-
vated (
page 401).Switching on corner-illuminating lamps

Switch on the left or right turn signal
(page 399), depending on whether
you are turning left or right.
or

Turn steering wheel in desired direc-
tion.
The corner-illuminating lamp on the
side of your steering direction comes
on.
i
The corner-illuminating lamps will only come
on in low ambient lighting conditions.
i
If you are driving faster than 43 mph
(70 km/h), the corner-illuminating function is
not available.
i
If you have switched on the turn signal for
one side but turn the steering wheel in the other
direction, the corner-illuminating lamp lights up
on the side of the turn signal.
i
The corner-illuminating lamps temporarily
come on on both sides of the vehicle if you turn
the steering wheel in one direction and then in
the other direction shortly thereafter.
i
The corner-illuminating lamps will come on
automatically depending on the steering angle,
even if you did not switch on either turn signal. If
the corner-illuminating lamps came on automat-
ically, they will also go out automatically depend-
ing on the steering angle.
i
When you shift the automatic transmission
in reverse gearR, the corner-illuminating lamp
opposite to your steering direction comes on.
The turn signal has no influence on the corner-il-
luminating lamp on the outside of the curve.

405 Controls in detail
Lighting
Switching off the corner-illuminating
lamps
The combination switch for the turn signal
resets automatically after major steering
wheel movements. This will switch off the
corner-illuminating lamps if they were acti-
vated by switching on the left or right turn
signal.
If the turn signal should stay on after mak-
ing the turn, the turn signal and corner-illu-
minating lamp can be switched off by
returning the combination switch to its
original position.
Hazard warning flasher
The hazard warning flasher can be
switched on at all times, even with the
SmartKey removed from the starter switch
or with the SmartKey with KEYLESS-GO*
removed from the vehicle.
The hazard warning flasher is automatical-
ly switched on if

an air bag has been triggered


S 600 and S 65 AMG, USA only: you
brake the vehicle strongly at a speed of
more than 50 mph (70 km/h) and
bring it to a complete stop
1Hazard warning flasher switch

Switching on: Press hazard warning
flasher switch.
All turn signals will flash.

Switching off: Press hazard warning
flasher switch again.
i
If you are driving faster than 25 mph
(40 km/h) when activating the turn signal indica-
tor, the corner-illuminating lamp function is
switched off.
i
The corner-illuminating lamp may remain lit
for a short time. The corner-illuminating lamp
lights up for no more than 20 seconds with the
vehicle standing still. It is then switched off even
if the turn signal is still switched on or you have
turned the steering wheel to full lock.
i
With the hazard warning flasher activated
and the combination switch set for either left or
right turn, only the respective left or right turn
signals will operate when the SmartKey in the
starter switch is in position1 or2 or the
KEYLESS-GO* start/stop button (
page 372) is
pressed once or twice.
i
If the hazard warning flasher was activated
automatically, also press hazard warning flasher
switch 1 to switch off the hazard warning flash-
er.

406 Controls in detailLightingInterior lighting Interior lighting in the front
The controls are located in the overhead
control panel.
1Left reading lamp on/off
2Rear interior lamps on/off
3Front interior lighting on/off
4Interior lighting control
5Right reading lamp on/offAutomatic control

Deactivating: Press button4.
The OFF indicator lamp next to the but-
ton comes on.
The interior lighting remains switched
off in darkness, even when you:

unlock the vehicle


remove the SmartKey from the
starter switch


open a door

Activating: Press button4.
The interior lighting switches on in
darkness, when you:

unlock the vehicle


remove the SmartKey from the
starter switch


open a door
i
Even with the SmartKey being removed from
the starter switch you can still use the lighting for
the storage compartment, glove box and vanity
mirrors, when you open a door or press one of
the interior lighting buttons. If a lamp is switched
on and you do not lock the vehicle, it will be
switched off automatically after 30 minutes.
When you lock the vehicle from the outside, the
interior lighting is switched off.
i
The interior lighting is factory-set to auto-
matic mode.

407 Controls in detail
Lighting
The interior lighting switches off auto-
matically following an adjustable time
delay (
page 270).
Manual control

Switching on/off front interior light-
ing: Press button 3.

Switching on/off rear interior light-
ing: Press button 2.
The front reading lamps reading lamps are
located in the lower edge of the interior
rear view mirror.

Switching on/off front reading
lamps: Press button 1 or 5.

Ambient lighting: The brightness of
the ambient lighting is adjusted via
COMAND (
page 269).Interior lighting in the rear
1Rear interior lamp
2Button
3Reading lamp

Press button2.
You can switch the lamps on/off in
succession as follows:

reading lamp3 and rear interior
lamp1 on


only reading lamp3 on


reading lamp3 off
Door entry lamps
For better orientation in the dark, the cor-
responding door entry lamps will switch on
in darkness when you open a door and the
automatic control is activated.
The door entry lamps switch off when the
corresponding door is closed.Trunk lamp
The trunk lamp switches on if the trunk is
opened.
If the trunk remains open, the trunk light-
ing switches off automatically after ap-
proximately 10 minutes.
i
If the door remains open, the interior lighting
switches off automatically after approximately
5minutes.
i
If you turn the SmartKey in the starter
switch to position0 and switch off the exterior
headlamps, the door entry lamps will remain lit
for approximately 5 minutes.

408 Controls in detailWindshield wipersCombination switch1Switching on windshield wipers
2Single wipe
Wiping with windshield washer fluid

Switch on the ignition (
page 370).
Switching on/off windshield wipers
Turn the combination switch to the
desired position depending on the
intensity of the rain.
MWindshield wipers off
USlow intermittent wiping
(rain sensor operation with low
sensitivity)
VFast intermittent wiping
(rain sensor operation with high
sensitivity)
uSlow continuous wiping
tFast continuous wiping
!
If the windshield wipers leave smears on the
windshield after the car has been driven through
an automatic car wash, then wax or other resi-
due is on the windshield. Shortly after washing
the car in an automatic car wash, clean the wind-
shield with windshield washer fluid
(
page 409).
!
Do not operate the windshield wipers when
the windshield is dry. Dust that accumulates on
a windshield might scratch the glass and/or
damage the wiper blades when wiping occurs on
a dry windshield. If it is necessary to operate the
windshield wipers in dry weather conditions, al-
ways operate the windshield wipers with wind-
shield washer fluid (
page 409).
!
If anything blocks the windshield wipers
(leaves, snow, etc.), switch them off immediate-
ly.


For safety reasons, stop the vehicle in a safe
location and,

remove SmartKey from starter switch
or


turn off the engine by pressing the
KEYLESS-GO* start/stop button
(page 372) and open the driver’s door
(with the driver’s door open, starter
switch is in position0, same as with
SmartKey removed from starter switch)
before attempting to remove any blockage.


Remove blockage.


Turn the windshield wipers on again.If the windshield wipers fail to function at all in
the combination switch position U or V,


set the combination switch to the next
higher wiper speed


have the windshield wipers checked at the
nearest authorized Mercedes-Benz Center

409 Controls in detail
Windshield wipers
Intermittent wiping
Only switch on intermittent wiping under
wet weather conditions or in the presence
of precipitation.

Turn the combination switch to posi-
tion U or V.
The wipers move across the wind-
shield. Afterward, the wiping intervals
are determined by the wetness of the
windshield.
After the initial wipe, pauses between
wipes are automatically controlled by the
rain sensor.
Single wipe
Press the combination switch briefly in
the direction of arrow2 (
page 408)
to the resistance point.
The windshield wipers wipe one time
without washer fluid.
Wiping with windshield washer fluid
Press the combination switch in the di-
rection of arrow2 (
page 408) past
the resistance point.
The windshield wiper operates with
washer fluid.
For information on filling up the washer
reservoir, see “Windshield washer system
and headlamp cleaning system”
(
page 580).
i
When the windshield wipers are switched on
and you brake the vehicle to a stop, the wipers
operate more slowly.
!
Do not leave windshield wipers on an inter-
mittent setting when the vehicle is taken to an
automatic car wash or during windshield clean-
ing. Wipers will operate in the presence of water
sprayed on the windshield, and windshield wip-
ers may be damaged as a result.
!
If you have set intermittent wiping, dirt on
the surface of the rain sensor or optical effects
may cause the windshield wipers to wipe in an
undesired fashion. This could then damage the
windshield wiper blades or scratch the windows.
You should therefore switch off the windshield
wipers when weather conditions are dry.
i
Intermittent wiping is interrupted when the
vehicle is at a standstill and a front door is
opened. This protects persons getting into or out
of the vehicle from being sprayed.
Intermittent wiping will be continued when


all doors are closed
and


the automatic transmission is set to drive
positionD or reverse gearR
or


the wiper setting is changed using the com-
bination switch
i
To prevent smears on the windshield or
noisy/chattering wiper blades, wipe with wind-
shield washer fluid every now and then even
when it is raining.
