MERCEDES-BENZ S-Class 2008 W221 Comand Manual

380 Controls in detailSeatsHead restraint adjusting
1Adjusting head restraint
Push or pull on the upper edge of the
head restraint cushion to the desired
position.Luxury head restraint* adjusting
1Head restraint side cushions
2Adjusting head restraint forward and
backward
You can individually adjust side
cushions1 of the luxury head restraints.

Adjusting side cushions: Pul l or pu sh
side cushions1 into desired position.

Adjusting forward or backward: Pull
or push head restraint in direction of
arrow2.
Rear head restraints
i
Depending on the seat’s set fore and aft po-
sition, the head restraint height is automatically
pre-set.
Warning!
G
When folding back the side cushions, never
reach between the side cushion and the
mounting post. You could otherwise be
trapped.
Warning!
G
For safety reasons, always drive with the
rear head restraints in the upright position
when the rear seats are occupied.
Otherwise, the back of the head will not be
supported in the event of a collision. As a re-
sult, rear seat occupants could be injured.Warning!
G
Keep the area around head restraints clear
of articles (e.g. clothing) to not obstruct the
folding operation of the head restraints.


381 Controls in detailSeats
Folding head restraints back
The rear seat head restraints and the rear
seat power head restraints* can be folded
backward for increased visibility.
1Switch in the front center console
Switch on the ignition (
page 370).

Press switch1 in the front center con-
sole briefly.
The rear head restraints will fold back-
ward.Placing head restraints upright

Pull the rear head restraint upright until
it locks into position.Placing power head restraints* upright
(rear outer seats)

Switch on the ignition (
page 370).

Press and hold switch1 in the front
center console (
page 381).
The rear outer seats head restraints
will place upright.

Pull the rear center seat head restraint
upright manually until it locks into posi-
tion.
!
M ake s ure t he h ead re str ain ts e ng ag e w he n
placing them upright manually. Otherwise their
protective function cannot be ensured.
i
When you fasten your seat belt in the rear,
the respective rear outer seat head restraint
places upright automatically.

382 Controls in detailSeatsRear power head restraints*
(rear outer seats)
1Placing upright head restraint
2Head restraint tilt
3Folding down head restraint
4Head restraint tilt
Press switch up in the direction of
arrow1.
The rear outer seats power head re-
straint will place upright.

Press switch down in the direction of
arrow3.
The rear power head restraint will fold
down.

Press the switch forward or backward
in the direction of arrow2 or4.
The power head restraint will be tilted.
Luxury head restraints*
(rear outer seats)1Head restraint side cushions
2Head restraint height
You can individually adjust side
cushions1 of the luxury head restraints:

Adjusting side cushions: Pul l or pu sh
side cushions1 into desired position.

Adjusting head restraint angle: Push
or pull on the lower edge of the head re-
straint cushion in the direction of
arrow2.
i
Depending on vehicle production date you
have to switch on the ignition or open the re-
spective door before adjusting the rear power
head restraints.
Warning!
G
When folding back the side cushions, never
reach between the side cushion and the
mounting post. You could otherwise be
trapped.
i
Depending on vehicle production date you
have to switch on the ignition or open the re-
spective door before adjusting the rear luxury
head restraints.

383 Controls in detailSeats
Multicontour seats*, rear
You can adjust the rear outer multicontour
seats using the buttons on the center con-
sole.
1To select right rear passenger seat
2Massage setting, gentle
3Massage setting, vigorous
4To adjust position of backrest curva-
ture (lordosis)
5Lumbar region support
6Side bolster adjustment
7To select left rear passenger seat

Switch on the ignition.

Selecting a seat: Press rocker
switch1 or7 forward or backward.
The indicator lamp on the selected but-
ton lights up for a short while.
Gentle massage

Switching on: Press rocker switch2
forward.

Switching off: Pull rocker switch2
backward.
Vigorous massage

Switching on: Press rocker switch3
forward.

Switching off: Pull rocker switch3
backward.Position of backrest curvature

Moving upward: Press rocker
switch4 forward.

Moving downward: Pull rocker
switch4 backward.
Lumbar region support

Selecting greater curvature: Press
rocker switch5 forward.

Selecting less curvature: Pull rocker
switch5 backward.
Side bolster adjustment

Reducing width: Press rocker
switch6 forward.

Increasing width: Pull rocker
switch6 backward.

384 Controls in detailSeatsEasy-entry/exit feature
This feature allows for easier entry into and
exit from the vehicle. When entering and
exiting the vehicle, the driver’s seat is in its
maximum rearward position and the steer-
ing wheel is in its uppermost position.
The easy-entry/exit feature can be activat-
ed or deactivated in the “Vehicle” menu of
the COMAND system (
page 268).With the easy-entry/exit feature activated,
the steering wheel and driver’s seat will re-
turn to their last set memory position or a
factory-set maximum forward position
when you:


close the driver’s door with the ignition
switched on


insert the SmartKey into the starter
switch or press the KEYLESS-GO*
start/stop button (
page 372) once
with the driver’s door closed
Warning!
G
You must make sure no one can become
trapped or injured by the moving steering
wheel and driver’s seat when the easy-en-
try/exit feature is activated.
To stop seat/steering wheel movement, do
one of the following:

Press seat adjustment switch
(page 374).


Move steering wheel adjustment stalk
(page 386).


Press one of the memory position but-
tons or the memory buttonM
(page 393).
Do not leave children unattended in the ve-
hicle, or with access to an unlocked vehicle.
Children could open the driver’s door and
unintentionally activate the easy-entry/exit
feature, which could result in an accident
and/or serious personal injury.
!
Do not activate the easy-entry/exit feature
if the seat backrest is in an excessively reclined
position. Doing so could cause damage to front
or rear seats.
First move the seat backrest to an upright posi-
tion.
i
For safety reasons, the driver’s seat will not
return to its last set position with the easy-en-
try/exit feature activated if the system recogniz-
es the last set position as an extreme forward
position. Instead, the driver’s seat will remain at
or move to a factory-set maximum forward posi-
tion. To again fully return the driver’s seat to

385 Controls in detailSeats
With the easy-entry/exit feature activated
the steering wheel tilts upwards and the
driver’s seat moves a few inches to the
rear when you:

remove the SmartKey from the starter
switch,
or


open the driver’s door with the
SmartKey in starter switch position0
or1 or the KEYLESS-GO* start/stop
button (
page 372) in position1
your last set position or to memory position, ad-
just the seat to the desired position or press and
hold the respective memory position button
(page 393).
i
The last set driver’s seat and steering wheel
positions are stored when


the ignition is switched off (
page 370)


the position is stored in memory
(page 392)
i
If the current position for the steering wheel
is in the uppermost tilt position, the steering
wheel will no longer be able to move upward
when the easy-entry/exit feature is activated.
If the current seat position falls into a factory-set
position range and the system recognizes the
current seat position to be rearward enough for
easy entry and exit, the driver’s seat will not
move to the rear when the easy-entry/ exit fea-
ture is activated.
The adjustment procedure is briefly interrupted
when the engine is started.Warning!
G
Let the system complete the adjustment
procedure before setting the vehicle in mo-
tion. All driver’s seat and steering wheel ad-
justments must be completed before setting
the vehicle in motion. Driving off with the
driver’s seat/steering wheel still adjusting
could cause the driver to lose control of the
vehicle.

386 Controls in detailSteering wheel
Make sure that

you can reach the steering wheel with
your arms slightly bent at the elbows


you can move your legs freely


all displays (including malfunction and
indicator lamps) on the instrument
cluster are clearly visible
Steering wheel adjustment
1Adjusting steering wheel, in or out
2Adjusting steering column, up or down
Adjusting steering wheel in or out:
Move stalk forward or back in the direc-
tion of arrow1 until a comfortable
steering wheel position is reached with
your arms slightly bent at the elbow.

Adjusting steering wheel up or
down: Move stalk up or down in the di-
rection of arrow2.
Warning!
G
Do not adjust the steering wheel while driv-
ing. Adjusting the steering wheel while driv-
ing could cause the driver to lose control of
the vehicle.
When leaving the vehicle, always remove the
SmartKey or SmartKey with KEYLESS-GO*
from the starter switch, take it with you, and
lock the vehicle.
Even with the SmartKey or SmartKey with
KEYLESS-GO* removed from the starter
switch or the SmartKey with KEYLESS-GO*
removed from the vehicle, the steering
wheel adjustment feature can be operated.
Therefore, do not leave children unattended
in the vehicle, or with access to an unlocked
vehicle. A child’s unsupervised access to a
vehicle could result in an accident and/or
serious personal injury.
i
The memory function (
page 392) lets you
store settings for the steering wheel together
with the settings for the seat position and the ex-
terior rear view mirrors.

387 Controls in detail
Steering wheel
Heated steering wheel*
The steering wheel heating warms up the
leather area of the steering wheel.
1Switching on
2Switching off
3Indicator lamp
Switch on the ignition (
page 370).

Switching on: Turn switch at the tip of
stalk in the direction of arrow1.
The steering wheel is heated. Indicator
lamp3 comes on.

Switching off: T u r n s w i t c h a t t h e t i p o f
stalk in the direction of arrow2.
The steering wheel heating is turned
off. Indicator lamp3 goes out.
i
The steering wheel heating will not switch
on, when the temperature of the vehicle interior
is above 86°F (30°C).
i
Indicator lamp3 flashes or goes out


in case of power surge or undervoltage


in case of a steering wheel heating malfunc-
tion
i
The steering wheel heating switches off au-
tomatically:


when you remove the SmartKey from the
starter switch


on vehicles with KEYLESS-GO*, when you
switch off the ignition (
page 370) and
open the driver’s door


when the temperature of the vehicle interior
is above 86°F (30°C)


after approximately 24 minutes

388 Controls in detailMirrorsAdjust the interior and exterior rear view
mirrors before driving so that you have a
good view of the road and traffic condi-
tions.Interior rear view mirror
Manually adjust the interior rear view
mirror.
For more information, see “Auto-dimming
rear view mirrors” (
page 390).
Exterior rear view mirrors1 Selector switch for right or left exterior
mirror
2Adjustment button

Switch on the ignition (
page 370).

Press button1 repeatedly until de-
sired exterior mirror is selected.
The left or right indicator lamp in
button1 comes on.

Push adjustment button2 up, down,
left, or right according to the desired
setting.
Warning!
G
Exercise care when using the passenger
side exterior rear view mirror. The mirror
surface is convex (outwardly curved surface
for a wider field of view). Objects in mirror
are closer than they appear. Check your in-
terior rear view mirror or glance over your
shoulder before changing lanes.
i
When you press button1 for the first time,
the exterior mirror on the driver’s side is always
selected.
If you do not make adjustments to the selected
exterior rear view mirror within 15 seconds, the
indicator lamp goes out. You will then have to se-
lect the desired exterior rear view mirror again
before any adjustments can be made. Adjust-
ments can only be made with the indicator lamp
for the respective exterior rear view mirror but-
ton illuminated.
i
At low ambient temperatures, the exterior
rear view mirrors will be heated automatically.
i
The memory function (
page 392) lets you
store the setting for the exterior rear view mir-
rors together with the setting for the steering
wheel and the seat positions.

389 Controls in detail
Mirrors
Power folding exterior rear view mirrors
Folding exterior rear view mirrors in
and out automatically
When the corresponding function in the
COMAND system is activated
(page 266):


The exterior rear view mirrors automat-
ically fold in as soon as the vehicle is
locked from the outside.


The exterior rear view mirrors automat-
ically fold out as soon as the vehicle is
unlocked and the driver’s or front pas-
senger door are subsequently opened.Folding exterior rear view mirrors in
and out manually
The exterior rear view mirrors can vibrate if
they are not folded out completely.
1Folds the exterior mirrors in and out

Switch on the ignition (
page 370).

Folding in: Press button1.

Folding out: Press button1 again.
!
Before driving the vehicle through an auto-
matic car wash, fold the exterior mirrors in. Oth-
erwise they may get damaged.
i
If you are driving at more than approximately
9 mph (15 km/h), you will not be able to fold the
exterior mirrors in.
i
The mirrors do not fold out if they were pre-
viously folded in manually. Please make sure
both mirrors are folded out before driving off.
!
If an exterior rear view mirror housing has
been forcibly pushed forward (hit from the rear),
reposition it manually by applying firm pressure
until it snaps back into place.
If an exterior rear view mirror housing has been
forcibly pushed rearward (hit from the front),
press button1 to fold mirrors in, then press
button1 again to fold mirrors out. Do not force
mirrors by hand as this may damage the adjust-
ment mechanism.
The mirror housing is then properly positioned
and you can adjust the mirror in the usual
manner.
