400 Technical dataConsumer informationTemperature
The temperature grades are A (the high-
est), B, and C, representing the tire’s resis-
tance to the generation of heat and its
ability to dissipate heat when tested under
controlled conditions on a specified indoor
laboratory test wheel. Sustained high tem-
perature can cause the material of the tire
to degenerate and reduce tire life, and ex-
cessive temperature can lead to sudden
tire failure. Grade C corresponds to a level
of performance which all passenger car
tires must meet under the Federal Motor
Vehicle Safety Standard No. 109. Grades B
and A represent higher levels of perfor-
mance on the laboratory test wheel than
the minimum required by law.
Warning
G
The temperature grade for this tire is estab-
lished for a tire that is properly inflated and
not overloaded. Excessive speed, underin-
flation, or excessive loading, either sepa-
rately or in combination, can cause
excessive heat build-up and possible tire
failure.

401 Technical terms
ABC
(A
ctive B
ody C
ontrol)
Active, computer-controlled system
that hydraulically adjusts the suspen-
sion at all four wheels in response to
various driving situations.
ABS
(A
ntilock B
rake S
ystem)
Prevents the wheels from locking up
during braking so that the vehicle can
continue to be steered.
Alignment bolt
Metal pin with thread. The centering
pin is an aid used when changing a tire
to align the wheel with the wheel hub.BabySmart
TM airbag deactivation
system
This system detects if a special system
compatible child restraint seat is in-
stalled on the front passenger seat. The
system will automatically deactivate
the passenger front airbag when such
a seat is properly installed (indicator
lamp PASSENGER AIRBAG OFF in the
center console comes on). See an au-
thorized Mercedes-Benz Center for
availability.
BabySmartTM compatible child seats
Special restraint system for children.
The sensor system for the passenger
seat prevents deployment of the pas-
senger front airbag if a BabySmart
TM
compatible child seat is installed.BAS
(B
rake A
ssist S
ystem)
System for potentially reducing braking
distances in emergency braking situa-
tions. The system is activated when it
senses an emergency based on how
fast the brake is applied.
Bi-xenon headlamps
Headlamps which use an electric arc as
the light source and produce a more in-
tense light than filament headlamps.
Bi-xenon headlamps produce low beam
and high beam.

402 Technical termsCAC
(C
ustomer A
ssistance C
enter)
Mercedes-Benz customer service cen-
ter, which can help you with any ques-
tions about your vehicle and provide
assistance in the event of a break-
down.
CAN system
(C
ontroller A
rea N
etwork)
Data bus network serving to control ve-
hicle functions such as door locking or
windshield wiping.
Cockpit
All instruments, switches, buttons and
indicator/warning lamps in the passen-
ger compartment needed for vehicle
operation and monitoring.COMAND
(C
ockpit M
anagement and D
ata Sys-
tem)
Information and operating center for
vehicle sound and communications
systems, including the radio and navi-
gation system, as well as other optional
equipment (CD changer, telephone,
etc.).
Control system
The control system is used to call up
vehicle information and to change
component settings. Information and
messages appear in the multifunction
display. The driver uses the buttons on
the multifunction steering wheel to
navigate through the system and to ad-
just settings.
Cruise control
Driving convenience system for auto-
matically maintaining the vehicle speed
set by the driver.Distronic*
A driving convenience cruise control
system which helps the driver maintain
a pre-selected speed:


If there is no vehicle directly ahead,
the system operates in the same
way as conventional ->cruise con-
trol.


If a slower moving vehicle is ahead,
Distronic will reduce your vehicle
speed to the extent permitted by re-
duced throttle and up to 20% brak-
ing power to maintain the preset
minimum following distance.
Engine number
The number set by the manufacturer
and stamped on the cylinder block to
uniquely identify each engine pro-
duced.

403 Technical terms
Engine oil viscosity
Measurement for the inner friction (vis-
cosity) of the oil at different tempera-
tures. The higher the temperature an
oil can tolerate without becoming thin,
or the lower the temperature it can tol-
erate without becoming viscous, the
better the viscosity.
ESP
(E
lectronic S
tability P
rogram)
Improves vehicle handling and direc-
tional stability.
ETD
(E
mergency T
ensioning D
evice)
Device which deploys in certain frontal
and rear collisions exceeding the sys-
tem's threshold to tighten the seat
belts.
->SRSFSS
(F
lexible S
ervice S
ystem)
Service indicator in the multifunction
display that informs the driver when
the next vehicle maintenance service is
due.
Gear range
Number of gears which are available to
the automatic transmission for shifting.
The automatic gear shifting process
can be adapted to specific operating
conditions using the selector lever.
GPS
(G
lobal P
ositioning S
ystem)
Satellite-based system for relaying
geographic location information to and
from vehicles equipped with special re-
ceivers. Employs DVD digital maps for
navigation.
Instrument cluster
The displays and indicator/warning
lamps in the driver’s field of vision, in-
cluding the tachometer, speedometer,
engine temperature and fuel gauge.KEYLESS-GO*
System for entering and operating the
vehicle without the use of a SmartKey.
Kickdown
Depressing the accelerator past the
point of resistance shifts the transmis-
sion down to the lowest possible gear.
This very quickly accelerates the vehi-
cle and should not be used for normal
acceleration needs.
Lock button
Button on the door which indicates
whether the door is locked or un-
locked. Pushing the lock button down
on an individual door from inside will
lock that door.
Memory function*
Used to store three individual seat,
steering wheel and exterior mirror posi-
tions for each SmartKey or SmartKey
with KEYLESS-GO*.

404 Technical termsMON
(M
otor O
ctane N
umber)
The Motor Octane Number for gasoline
as determined by a standardized meth-
od. It is an indication of a gasoline's
ability to resist undesired detonation
(knocking). The average of both the
MON (Motor Octane Number) and
->RON (Research Octane Number) is
posted at the pump, also known as AN-
TI-KNOCK INDEX.
Multifunction display
Display field in the speedometer used
to present information provided by the
control system.
Multifunction steering wheel
Steering wheel with buttons for operat-
ing the control system.Overspeed range
Engine speeds within the red marking
of the tachometer dial. Avoid this en-
gine speed range, as it may result in se-
rious engine damage that is not
covered by the Mercedes-Benz Limited
Warranty.
Parktronic*
System which uses visual and acoustic
signals to assist the driver during park-
ing maneuvers.
Poly-V-belt drive
Drives engine components (alternator,
AC compressor, etc.) from the engine.Power train
Collective term designating all compo-
nents used to generate and transmit
motive power to the drive axles, includ-
ing:


Engine


Clutch/torque converter


Transmission


Transfer case


Drive shaft


Differential


Axle shafts/axles
Program mode selector switch
Used to switch the automatic transmis-
sion between standard operationS and
comfort operationC.
S 55 AMG with steering wheel gearshift
control and manual shift program: in
addition toS andC (see above), you
can useM for manual operation

405 Technical terms
Remote Vehicle Diagnostics
Transmission of vehicle data and cur-
rent location to the Mercedes-Benz
Customer Assistance Center for sub-
scribers to the Tele Aid service.
REST
(Residual engine heat utilization)
Feature that uses the engine heat
stored in the coolant to heat the vehi-
cle interior for a short time after the en-
gine has been turned off.
Restraint systems
Seat belts, belt tensioners, airbags and
child restraint systems. As indepen-
dent systems, their protective func-
tions complement one another.RON
(R
esearch O
ctane N
umber)
The Research Octane Number for gaso-
line as determined by a standardized
method. It is an indication of a gaso-
line's ability to resist undesired detona-
tion (knocking). The average of both
the ->MON (Motor Octane Number)
and RON (Research Octane Number) is
posted at the pump, also known as AN-
TI-KNOCK INDEX.
Shift lock
When the vehicle is parked, this lock
prevents the transmission selector le-
ver from being inadvertently moved out
of positionP without the SmartKey
turned and the brake pedal depressed.
SRS
(S
upplemental R
estraint S
ystem)
Seat belts, emergency tensioning de-
vice and airbags. Though independent
systems, they are closely interfaced to
provide effective occupant protection.Tele Aid System
(T
elematic A
larm I
dentification on
D
emand)
The Tele Aid system consists of three
types of response: automatic and man-
ual emergency, Roadside Assistance
and information. Tele Aid is initially ac-
tivated by completing a subscriber
agreement and placing an acquain-
tance call.
The Tele Aid system is operational pro-
vided that the vehicle’s battery is
charged, properly connected, not dam-
aged and cellular and GPS coverage is
available.
Telematics*
A combination of the terms “telecom-
munications” and “informatics.”
Tightening torque
Force times lever arm (e.g. a lug
wrench) with which threaded fasteners
such as wheel bolts are tightened.

406 Technical termsTire speed rating
Part of a tire designation; indicates the
speed range for which a tire is ap-
proved.
Traction
Force exerted by the vehicle on the
road via the tires.
VIN
(V
ehicle I
dentification N
umber)
The number set by the manufacturer
and stamped on the body to uniquely
identify each vehicle produced.
Voice control system*
Voice control system for car phones,
portable cell phones and audio sys-
tems (radio, CD, etc.).

407 Index
A
ABC 220, 401
Messages in display 313, 318
Setting vehicle level 219, 221
ABS 77, 401
Malfunction indicator lamp 304
Messages in display 314
Warning lamp 304
Accelerator position, automatic
transmission 170
Accident
In case of 50
Activating
Air conditioner (cooling) 191
Air conditioning 190
Air recirculation mode 187
Anti-theft alarm system 84
Central locking (control system) 159
Charcoal filter 188
Distance warning function* 215
Distronic* 211
Easy-entry/exit feature 160
ESP 81
Exterior lamps 125Exterior rear view mirror parking
position 175
Front and rear fog lamp 126, 127
Hazard warning flasher 129
Headlamps 47
High beams 128
Ignition 31
Ignition with KEYLESS-GO*
start/stop button 33
Immobilizer 53, 83
Limiting opening height of
trunk lid* 159
Rear window defroster 189
Residual heat 191
Seat heater 114, 116
Seat ventilation* 117
Tow-away alarm 85
Windshield wipers 48
Activating steering wheel gearshift control
Downshifting 169, 172
Upshifting 169, 172
Adding
Coolant 279
Engine oil 277
Additional turn signals 353Adjustable air vents, rear passenger
compartment 192
Adjusting 34
Air distribution 184
Air volume 186
Backrest tilt 35
Drive-dynamic seat 163
Exterior rear view mirror 38
Head restraint height 36
Head restraint tilt 36
Instrument cluster illumination 131
Interior rear view mirror 38
Lumbar support 112
Mirrors 38
Multicontour backrest* 112
Power seat bench* 118
Seat cushion depth 35, 112
Seat cushion tilt 35
Seat fore and aft adjustment 35
Seat height 35
Seat in the lumbar region 113
Seat in the shoulder region 112
Seats 34
Steering column height 37
Steering column in or out 37

408 Index
Steering column up or down 37
Steering wheel 37
Air conditioning
Turning off 190
Turning on 190
Air pressure see Tire inflation
pressure 283
Air recirculation mode 187
Activating 187
Deactivating 188
Air vents, rear passenger compartment
Adjustable 192
Air volume
Adjusting 186
AIRBAG OFF indicator lamp 311
Airbags 59
BabySmart
TM airbag deactivation
system 71, 401
Children 60
Front 63
Passenger 63
Safety guidelines 62
Side impact 63
Window curtain 63AIRMATIC 218
Alarm
Audible 76, 84
Canceling 84
Visual 83
Alarm system
Anti-theft 83
Alignment bolt 364
Alignment bolt (vehicle tool kit) 345, 401
Antiglare
Automatic 174
Antilock brake system (ABS) 401
Anti-theft alarm system
Arming 84
Canceling alarm 84
Disarming 84
Anti-theft systems 83
Anti-theft alarm system 83
Immobilizer 83
Tow-away alarm 85
Aquaplaning see Hydroplaning 263
Armrest
Storage compartment in front of 232,
233, 234Ashtray 238
At the gas station 269
ATF (Automatic Transmission Fluid) 278
AUDIO menu 139
Operating
Cassette player 141
Selecting radio station 140
Selecting satellite radio* station
(USA only) 140
Audio system
CD mode 142
Automatic antiglare for rear view
mirror 174
Automatic central locking
Activating/deactivating
(control system) 159
Automatic climate control 180
Air recirculation mode 187
Defrosting 187
Rear window defroster 189
Setting the temperature 183
Automatic headlamp mode 125

409 Index
Automatic lighting control
Activating 129
Deactivating 130
Automatic locking when driving 106
Automatic transmission 164
Accelerator position 170
Comfortable program mode 170
Deactivating steering wheel gearshift
control 173
Emergency operation
(Limp Home Mode) 173
Fluid level 278
Gear ranges 166
Gear selector lever position 167
Gear shifting malfunctions 173
Kickdown 170
One-touch gearshifting 165
Program mode selector switch 170
Selector lever position 164
Starting the engine 43
Steering wheel gearshift control
(Speedshift) S 55 AMG 168
Transmission fluid 278
Winter program mode 171
Auxiliary fuse box 374B
BabySmart
TM
Airbag deactivation system 71
Compatible child seats 71, 401
Self-test 71
BabySmart
TM airbag deactivation
system 401
Backrest supports
Lumbar region 113
Shoulder region 112
Backup lamps 354, 358
Bulbs 354
BAS 78, 401
Messages in display 315
Batteries, SmartKey
Changing 350
Check lamp 90, 91
Replacing 349
Battery discharged
Jump starting 369
Battery, SmartKey with KEYLESS-GO*
Changing 351
Check lamp 95Battery, vehicle 280, 366
Charging 367
Disconnecting 367
Reconnecting 368
Reinstalling 367
Removing 367
Bi-Xenon headlamps 401
Block heater (Canada only) 293
Blocking
Rear window operation 74
Brake assist system (BAS) 401
Brake fluid 270, 394
Brake lamp bulbs 354
Brake lamp, high mounted 354
Brake pads
Message in display 321
Brakes 260
Warning lamp 305
Break-in period 258
Bulbs, replacing 353
Additional turn signals 353
Backup lamps 354
Brake lamps 354
