200 Control systemsCOMAND navigation system (destination memory)Displaying your own address
Select “Navi”
“Destination”

“From Memory”.
The destination memory list appears ei-
ther with or without the input charac-
ters. Whether the input characters
appear depends on the number of en-
tries in the destination memory.

Press n.
Destination memory list without input
characters
In the destination memory list without in-
put characters, the “My Address” entry is
automatically highlighted.

Press n.
If your own address has already been
assigned, you will see the menu for
starting route guidance with your own
address data.

Exiting menu: Select “Back”.
Destination memory list with input char-
acters
1Input characters
In the destination memory list with input
characters 1, the input characters are au-
tomatically activated.

Slide qm repeatedly until the input
characters disappear.
The list entry “My Address” is automat-
ically highlighted as long as you have
not entered any characters using the
input characters.
If you have entered characters
from the list of input characters:
Rotate ymz or slide qm repeatedly
until the list entry “My Address” is
highlighted.

Press n.
If your own address has already been
assigned, you will see the menu for
starting route guidance with your own
address data.

Exiting menu: Select “Back”.

201 Control systems
COMAND navigation system (last destinations)
COMAND navigation system (last destinations)
Saving a destination permanently in the destination memory
Proceed as described in the “Saving a
destination from the list of last destina-
tions” section (
page 195).Saving the vehicle position in the list of
last destinations
Centering map on the vehicle’s posi-
tion: Select “Navi”
“Position”

“Vehicle Position Map”.

Saving: Select “Navi”
“Position”

“Save Position”.
COMAND saves the current vehicle po-
sition as a destination in the list of last
destinations.
Saving the crosshair position in the list
of last destinations

Showing menu system, if neces-
sary: Press n.

Select “Position”
“Save Position”.
COMAND saves the crosshair position
as a destination in the list of last desti-
nations.
Deleting one of the last destinations
Select “Navi”
“Destination”

“From Last Destinations”.
The list of last destinations appears.

Select desired destination.
The address of the destination ap-
pears.

Select “Delete”.

Select “Yes” or “No”.
i
COMAND automatically saves the last desti-
nations for which the route calculation was
launched. It is stored in the “last destinations”
memory. If this memory is full, COMAND deletes
the oldest destination. You can also save one
destination from the list of last destinations in
the destination memory. It will be saved there
permanently.
i
If you have manually moved the map, you
will see a crosshair on the map (
Seite 149).
You can save the crosshair position as a destina-
tion in the list of last destinations.

202 Control systemsCOMAND address bookGeneral notes
The address book contains the entries that
are saved in the COMAND address book
memory. The entries are permanently
available even if the phone is not inserted
in the cradle*. When you insert the mobile
phone into the cradle*, COMAND reads-in
the phone book entries saved in the mobile
phone and stores the entries as a separate
list from the COMAND address book. This
list is a copy of the phone’s phone book.
This can take several minutes, depending
on how many entries the phone book and
the address book contain. After the read-in
process, the COMAND compares the
phone book entries with the address book
entries. If all of the telephone numbers of a
phone book entry in the mobile phone are
present in an address book entry, the ad-
dress book shows only the address book
entry. If not, the address book also shows
the phone book entry in the mobile phone.
Address book menu overviewCalling up the address book
Select “Telephone”
“Telephone”

“Address Book”.
The main address book display ap-
pears. If the address book already con-
tains entries, you will see the data of an
entry.
Illustration: address book entrySelecting an entry in the main address book display
Slide omp or rotate ymz until the
main area is selected.
i
The components and operating principles of
COMAND can be found on (
page 79).
Search
New Entry
Search for an ad-
dress book entry
Create new address
book entry
i
For phone book entries in the mobile phone
that contain a name and a telephone number,
you will see the name and the number. If a phone
book entry in the mobile phone contains several
telephone numbers, you will see the message
“Multiple Numbers” instead of a telephone num-
ber.

203 Control systems
COMAND address book
Creating a new address book entry
Select “Telephone”
“Telephone”

“Address Book”
“New Entry”.
The input menu appears with the data
fields and the input characters.
Illustration: input menu for private data1To switch between work and home
data ( or symbol)
2Selected data field with input mark
(cursor)
3Display of set data type – in example
display, home data is set ( symbol
and “Home” display)
4Input characters
Switching between private and
business data: Select symbol 1.
The display switches to private or busi-
ness data, depending on the previous
status.

Changing data field: Slide rmq re-
peatedly until desired entry is highlight-
ed.
or

Select [ or ] repeatedly until de-
sired entry is highlighted.

Entering data into a field:
Select desired characters one by one
from the input characters.

Toggling upper and lower case for
the input characters: Select& or
(.

Changing language for the input
characters: Select!.

Select desired language.

Changing character set for the input
characters: Select#.
Depending on the previous setting, you
will change to letters with special char-
acters or to numbers with special char-
acters.
i
Please observe the following when creating
a new address book entry:
You can define your own address in the destina-
tion memory in navigation mode. When defining
the address, you can transfer data already en-
tered as an address book entry.
In the address book entry, the town/city and
street must be spelled in the same way as the
destination entry so that the data matches the
digital map data.
In order for the state (province) to match the
map data, its complete name or abbreviation
may be entered.
Examples:


Florida or FL


Colorado or CO


Alberta or AB


Ontario or ON


204 Control systemsCOMAND address book
Moving cursor in the data field:
SelectY or Z.

Deleting individual characters:
Select) and briefly press n.
The character to the left of the cursor is
deleted.

Deleting an entire entry: Select)
and press and hold n until the entry is
deleted.

Saving an entry: Select?.

Canceling an entry: Select “Back”.
If one of the data fields contains new
data, a prompt will appear asking
whether you want to save the entry.
Select “Yes” or “No”.
The entry will either be saved or
not, depending on your selection.
Deleting an entry
Search for desired entry (
page 204).

Select “Options”
“Delete”.
A deletion prompt appears.

Select “Yes” or “No”.
The entry will either be deleted or not,
depending on your selection.
Searching for an address book entry
Select “Telephone”
“Telephone”

“Address Book”
“Search”.
The search menu appears with the
smart speller.
1Symbol for complete address data
from the navigation system
2Symbol for summarized entries
from the mobile phone with the same
name but different telephone numbers
3Category symbol
4Smart speller
5Symbol for voice entry
6Back to the main address book display
i
You cannot delete phone book entries from
the mobile phone.


205 Control systems
COMAND address book
Entries with category symbol 3 come
from the mobile phone. The following cate-
gory symbols are possible:

= symbol for “Mobile” category


= symbol for “Home” category


= symbol for “Work” category


= symbol for “Fax” category


= symbol for “Pager” category


= symbol for “Main” category or for
unknown category or for phone entries
that are saved on the SIM card of a
GSM mobile phone
Entries without a category symbol or with
the or symbols come from the
COMAND address book. All other entries
come from the mobile phone and are only
visible when the mobile phone is in the cra-
dle*.
Entries with the symbol contain a voice
entry (page 210). It is possible to add
voice entries in vehicles with Voice Con-
trol*.Entries with the symbol contain com-
plete, navigable address data from the nav-
igation system that correspond to digital
map data. It is possible to quickly start
route guidance to these types of entry
(
page 209).
Switching from the smart speller to the
list

Slide mq repeatedly or press n until
the smart speller is hidden.
or

Select ?.
Switching from the list to the smart
speller

Select “Back” from the list.
Searching
Searching via the smart speller

Switch from the list to the smart speller
if necessary.

Changing smart speller language:
Select!.

Select desired language.

Changing smart speller character
set: Select#.
Depending on the previous setting, you
will change to letters with special char-
acters or to numbers with special char-
acters.

Entering characters: Select the char-
acters one by one of the entry you are
searching for.

Deleting individual characters:
Select) and briefly press n.
Each time you enter or delete a charac-
ter, the closest match will be displayed
at the top of the list.

Deleting an entire entry: Select)
and press and hold n until the entry is
deleted.


206 Control systemsCOMAND address book
Canceling search: Switch from the
smart speller to the list (
page 205).
The entry at the top of the list is auto-
matically highlighted.

Going back to main address book
display: If necessary, switch from the
list to the smart speller (
page 205)
and select “Back” in the smart speller.
Searching via the list

If necessary, switch from the smart
speller to the list (
page 205).

Rotate ymz or slide qmr until desired
entry is highlighted on the list.
Displaying a complete address book en-
try
Searching for the desired entry
Search for an address book entry
(page 204).
or

Select an address book entry in the
main address book menu
(page 202).

Press n.
The detailed view appears.
Illustration: detailed view for private data1To go back to the previous menu
2To switch between work and home
data ( symbol or )
3Selected data field
4Display of set data type – in example
display, home data is set ( symbol
and “Home” display)
5To call up optionsSwitching between private or business
data

Select symbol 2.
The display switches to private or busi-
ness data, depending on the previous
status.
i
The options available under “Options” menu
item 4 depend on which data field 3 is select-
ed. The following options may be available:


Displaying abbreviated content in full
(page 207)


Changing an address book entry
((page 207)


Changing the description of a telephone
number data field (
page 208)


Adding a telephone number data field
(page 208)


Calling a number saved in an entry
(page 209)


Starting route guidance to an entry
(page 209)


Options for voice entries (
page 210)


207 Control systems
COMAND address book
Selecting a different data field
Rotate ymz or slide qmr.
Displaying abbreviated content in full

Select “Options”
“Details”.
The display is shown in full.

Closing entire display: Slide qmr or
omp or pressn.
Closing the detailed view

Select “Back”.
Displaying of a complete phone book
entry in the mobile phone
Searching for the desired entry
Search for phone book entry in mobile
phone (
page 204).
or

Select a phone book entry from the
mobile phone using the COMAND
address book menu (
page 202).

Press n.
The detailed view appears.
1To go back to the previous menu
2Category symbol
3Display for phone book entry in mobile
phone
4To call up optionsClosing the detailed view

Select “Back”.
Changing an entry
Changing an address book entry
Search for an address book entry
(page 204) then, select “Options”

“Change”.
or
i
The mobile phone must be inserted in the
cradle*.
i
If a phone book entry in the mobile phone
has more than one telephone number, you will
see all telephone numbers with the respective
category symbol 2 in the detailed view.
i
The options available under “Options” menu
item 4 depend on which data field 3 is select-
ed. The following options may be available:


Changing a a phone book entry in the mobile
phone (
page 207)


Calling a number saved in an entry
((page 209)


Saving a phone book entry from mobile
phone in the address book (
page 212)
i
You cannot change address book entries
that come from the phone book in the mobile
phone.


208 Control systemsCOMAND address book
Display the details of an address book
entry (
page 206) then, select “Op-
tions”
“Change Content”.
The input menu appears with the data
fields.

Proceed as described in the “Switching
between private and business data”
paragraph in the Creating a new ad-
dress book entry section (
Seite 203).
Changing the description of a tele-
phone number data field

Display the details of an entry and high-
light the telephone number data field
(page 206).

Select “Options”
“Change Entry
Name”.

Select a number category, e.g. “Home”.

Select a telephone category, e.g. “Land
Line”.

Select “Save”.COMAND saves the data if there are
fewer than four numbers assigned to
the entry you are searching for in the
selected number category.
Otherwise, you will see a prompt ask-
ing whether one of the existing num-
bers should be overwritten.

Select “Yes” or “No”.
If you select “Yes”, a selection list will
appear containing the four existing
numbers.

Select number to be overwritten.
COMAND overwrites the selected num-
ber with the new data.
Adding to a telephone number data
field

Display the details of an entry and high-
light the telephone number data field
(page 206).

Select “Options”
“Add Number”.

Select a number category, e.g. “Home”.

Select a telephone category, e.g. “Land
Line”.

Select “Save”.
COMAND adds the data field to the entry if
there are fewer than four numbers as-
signed to the entry in the selected number
category. You can now enter a number into
the data field.

Proceed as described from the “Enter-
ing data into a field” operating step in
the Creating a new address book entry
section (
Seite 203).
If four numbers are already saved for the
entry in the selected number category, a
prompt will appear asking whether one of
the data fields should be overwritten.
i
This function is not possible for phone book
entries in the mobile phone.
i
One address book entry may contain up to
four data fields for private telephone numbers
and four data fields for business telephone num-
bers.
This function is not possible for phone book en-
tries in the mobile phone.


209 Control systems
COMAND address book

Select “Yes” or “No”.
If you select “Yes”, a selection list will
appear containing the four data fields.

Select field to be overwritten.
COMAND deletes the number of the se-
lected field. You can now enter a new
number into the data field.

Proceed as described from the “Enter-
ing data into a field” operating step in
the Creating a new address book entry
section (
Seite 203).
Calling a number saved in an entry
Display the details of an entry and high-
light the telephone number data field
(page 206).

Press n.
or

Select “Options”
“Call”.
In both cases, the telephone* connects
the call.
Starting route guidance to an entry
Search for an address book entry
(page 204).

Display the details of an entry and high-
light the address data field
(page 206).

Select “Options”
“Navigate”.
or

Press n.
Further operation depends on whether the
address data is complete and matches the
digital map data of the navigation system.
It does not match, for example, if it is not
spelled in the same way as the destination
entry.Address data is complete and matches
digital map
If “Navigate” is selected, the navigation
system starts the route calculation.
Address data is incomplete or does not
match digital map
If “Navigate” is selected, a message ap-
pears indicating that the address is incom-
plete.

Closing message: Select “OK”.
i
To do this, COMAND must be equipped with
a telephone*. The mobile phone must be insert-
ed in the cradle*.
i
Pressing n only functions if one of the ad-
dress data fields contains data.
i
For the route calculation, the navigation sys-
tem requires the correct spellings of the state
(province), the town/city or zip code, the street
and under some circumstances, the house num-
ber. The town/city and street must be spelled in
the same manner as the destination entry.
The state (province) can be spelled as an entire
name or as an abbreviation.
Examples:


Florida or FL


Colorado or CO


Alberta or AB


Ontario or ON
