MERCEDES-BENZ S550 2007 W221 Owner's Manual

210 Control systemsCOMAND address bookDepending on which data is missing or
cannot be found on the digital map, you
must now either:

select a state (province)


select a county


or enter a town/city


or enter a street


or enter a house number

Selecting a state (province):
Select desired state (province) from
the list.

Selecting a county: Select desired
county from the list.

Entering a town: Proceed as de-
scribed for destination entry in the “En-
tering a town or city” section
(page 159).

Entering a street: Proceed as de-
scribed for destination entry in the “En-
tering a street” section (
page 161).

Entering a house number: Proceed
as described for destination entry in
the “Entering a house number” section
(page 166).
If all data is available and matches the dig-
ital map data, the navigation system starts
the route calculation.
Voice entries
Adding or changing a voice entry
Search for the address book entry with
or without a voice entry (
page 204).

Select “Options”
“Voice Name”

“Add” or “Change”.
Subsequent operation is controlled by
voice. Voice Control* guides you
through the dialogs.
i
If you have added data, COMAND saves your
additions. This means that you do not need to
re-enter this additional data later on.
The COMAND memory saves the additional data
in a special field, which cannot be displayed. The
data, which you have entered in the address
book initially in the display, remains unchanged.
i
For voice entries, your vehicle must be
equipped with Voice Control*. You can not add
voice entries for address book entry that come
from the phone book in the mobile phone.
i
You can add one voice entry per address
book entry.

211 Control systems
COMAND address book
Deleting a voice entry
Search for the address book entry with
a voice entry (
page 204).

Select “Options”
“Voice Name”

“Delete”.
A deletion prompt appears.

Select “Yes” or “No”.
COMAND deletes the voice entry de-
pending on your selection.
Listening to a voice entry

Search for the address book entry with
a voice entry (
page 204).

Select “Options”
“Voice Name”

“Read Aloud”.
You will hear the voice entry.Saving a phone book entry from mobile
phone in the COMAND address book
Saving a phone book entry from mobile
phone as new address book entry
Search for phone book entry in mobile
phone (
page 204).
or

Display details of a phone book entry in
the mobile phone (
page 206).

Select “Options”
“Save”
“New En-
try”.

Select a number category, e.g. “Work”.

Select a telephone category, e.g. “Mo-
bile”.

Select “Save”.
The input menu appears with the data
fields. The name and the telephone
number are entered automatically.
1Data field
2Input mark (cursor)
3Input characters

Proceed as described in the “Changing
a data field” paragraph in the “Creating
a new address book entry” section
(Seite 203).
i
The mobile phone must be inserted in the
cradle* and the COMAND have read out the mo-
bile phone book data. This can take several min-
utes, depending on how many entries each
phone book contains.

212 Control systemsCOMAND address bookSaving a phone book entry from the
mobile phone in an existing address
book entry
Search for a phone book entry in the
mobile phone (
page 204).
or

Display details of a phone book entry in
the mobile phone (
page 206).

Select “Options”
“Save”
“Add”.

Select a number category, e.g. “Home”.

Select a telephone category, e.g. “Land
Line”.

Select “Save”.
The search menu for address book en-
tries appears.

Search for desired entry.

After selecting an entry, press n.
COMAND saves the data if there are
fewer than four numbers assigned to
the selected entry in the selected num-
ber category. Otherwise, you will see a
prompt asking whether one of the ex-
isting numbers should be overwritten.

Select “Yes” or “No”.
If you select “Yes”, a selection list will
appear containing the four existing
numbers.

Select the number to be overwritten.
COMAND overwrites the selected num-
ber with the new data.
Importing data from external Bluetooth
devices
You can import vCards from external Blue-
tooth devices into the address book.
Please keep the following in mind:

Bluetooth is activated in COMAND
(page 217) and in the device con-
cerned.


The external device must be able to
send vCards by Bluetooth.


The external device is inside the vehi-
cle, switched on and authorized
(page 217).

Importing: Start data transfer on the
external device (see operating instruc-
tions of the device concerned).
If there is no address book entry with
the same first name and last name,
COMAND imports the data.
If there is already an address book en-
try with the same first name and last
name, a prompt will appear asking
whether the existing data should be
overwritten.

Select “Yes” or “No”.
The existing address book entry will be
overwritten or not, depending on your
selection.
i
The mobile phone must be inserted in the
cradle*.
i
There is a detailed description of how to
search for an address book entry in the “Search-
ing for an address book entry” section
(
page 204).

213 Control systems
COMAND system settings
COMAND system settings
Systems settings menu overviewDisplay settings
Switching the display on or off
Switching off: Select “Vehicle”

“Display OFF”.

Switching back on: Rotate ymz or
slideqmr.
Setting the display design

Select “Vehicle”
“System Settings”

“Display”.

Select “Day Mode” or “Night Mode” or
“Automatic”.
Time settings
Setting the time

Select “Vehicle”
“System Settings”

“Time”
“Time”.

Selecting hour or minute(s):
Slideomp.

Setting value: Rotate ymz or
slideqmr.

Saving setting: Press n.
i
The components and operating principles of
COMAND can be found on (
page 79).
Display
(page 213)
Time
(page 213)
Voice Control*
(page 215)
Language
(page 216)
Favorite
(page 216)
Services
(page 217)
Reset
(page 213)
Display settings
Time settings
Voice Control*
settings
Language
settings
Assign favorite
button
Bluetooth
settings
Reset COMAND to
factory settings
i
In the “Automatic” setting, COMAND ana-
lyzes the automatic vehicle light sensor and
switches between the display design automati-
cally.
i
The correct time must be set for the follow-
ing navigation system functions to operate cor-
rectly:


Route guidance on routes with time-depen-
dent traffic guidance


Calculation of estimated arrival time
i
The increment value for setting the minutes
depends on the situation. If GPS reception is
available, it is 30 minutes. If GPS reception is not
available, it is one minute.

214 Control systemsCOMAND system settingsSetting the time zone and switching be-
tween Daylight Saving Time and stan-
dard time
Setting time zone: Select “Vehicle”

“System Settings”
“Time”
“Time
Zone”.
The country list appears. The dot R in
front of a list entry indicates the current
setting.

Select the country in which you are cur-
rently driving.
A time zone list may also be displayed,
depending on the country selected.

Select desired time zone.Subsequent operation depends on:


whether your navigation system has
GPS reception


which country you have previously set.
You may either:


manually switch between “Daylight
Savings Time (Summer)” and “Standard
time (Winter)” in a list
or


switch automatic Daylight Saving Time
to standard time changeover (and vice
versa) on or off.

Switching manually: Select “Daylight
Savings Time (Summer)” or “Standard
time (Winter)”.
The dot R in front of a list entry indi-
cates the current setting.

Switching automatic changeover on
or off: Select “Automatic Daylight Sav-
ings Time”.
You have switched the function on or
off. A checkmark appears when the
function is switched on.

Saving setting and exit the menu:
Slide omp.
Setting the date

Select “Vehicle”
“System Settings”

“Time”
“Date”.

Selecting month, day or year:
Slideomp.

Setting value: Rotate ymz or
slideqmr.

Saving setting: Press n.
i
The correct time zone and Daylight Saving
Time/standard time must be set for the follow-
ing navigation system functions to operate cor-
rectly:


Route guidance on routes with time-depen-
dent traffic guidance


Calculation of estimated arrival time
i
If you have switched off the automatic
changeover function, you must change Daylight
Saving Time to standard time and vice versa
yourself.

215 Control systems
COMAND system settings
Setting the time/date format
Select “Vehicle”
“System Settings”

“Time”
“Format”.
The format list appears. The dots R in
front of the list entries indicate the cur-
rent setting.

Changing format setting:
Select desired format.

Saving setting and exit the menu:
Slide omp.
Voice Control* settings
Switching help window on or off
Select “Vehicle”
“System Settings”

“Voice Control”.

Select “Help Window”.
You can switch the help window on or
off. A checkmark appears when the
help window is switched on.Individualization
Using individualization, you can fine-tune
Voice Control* to your own voice and thus
improve voice recognition. The ability of
the system to recognize the commands of
other users does not deteriorate as a re-
sult.
Individualization consists of two parts. You
train the system to recognize digits in the
first part and specific commands in the
second part.
Starting new individualization

Select “Vehicle”
“System Settings”

“Voice Control”
“Start new indi-
vidualization”.
A prompt appears asking whether you
would like further information.

Select “Yes” or “No”.
If you select “No”, the first part of indi-
vidualization begins.
If you select “Yes”, an information dis-
play will be shown with audio instruc-
tion.
Closing display: Select “OK”.
The first part of individualization be-
gins.
At the end of the first part, you will see
a prompt asking whether you want to
begin the second part.

Select “Yes” or “No”.
If you select “No”, individualization will
be canceled. The data from the first
part is saved automatically.
If you select “Yes”, the second part be-
gins.
Individualization is completed at the end of
the second part. You will see a message to
this effect. The data from the second part
is saved automatically.
i
It is only possible to start individualization
with the vehicle stationary. After starting the
session, the system will guide you through the in-
dividualization by means of acoustic instruc-
tions.

216 Control systemsCOMAND system settingsCanceling during the first or second part
of individualization
Select “Cancel”.
A prompt appears asking whether you
really do want to cancel.

Select “Yes” or “No”.
If you select “Yes”, individualization will
be canceled. The data from the part at
which you exited is not saved.
If you select “No”, the part at which you
stopped begins again.
Deleting existing individualization data

Select “Vehicle”
“System Settings”

“Voice Control”
“Delete individu-
alization”.
A prompt appears asking whether you
really do want to delete.

Select “Yes” or “No”.
The individualization data will either be
deleted or not, depending on your se-
lection.
Setting the system language
Select “Vehicle”
“System Settings”

“Language”.
The language list appears. A dot R in-
dicates the current setting.

Changing setting: Select desired lan-
guage.
The language is set.
Assigning the favorite button
1Favorite buttonYou can assign the following predefined
functions to the favorite buttonP:


“Rear Window Sunshade”
You can use the favorite button to ex-
tend or retract the rear window sun-
shade. This is the default setting.


“Display OFF”
You can use the favorite button to
switch the COMAND display on or off.


“Tow-away Alarm”
You can use the favorite button to acti-
vate or deactivate the tow-away
alarm*.


“Repeat Navigation Command”
You can use the favorite button to re-
call the last command issued by the
navigation system.

Select “Vehicle”
“System Settings”

“Favorite”.
The list of predefined functions appears.
The dot R in front of the list entry indi-
cates the current setting.

217 Control systems
COMAND system settings

Changing setting: Rotate ymz and
select desired function.

Saving setting and exit the menu:
Press n.
Bluetooth settings
General information about Bluetooth
Bluetooth technology is the standard for
short-range wireless data transmission of
up to approximately 10 meters. Bluetooth
can be used to exchange vCards or make
calls using a headset.
Activate or deactivate Bluetooth
Select “Vehicle”
“System Settings”

“Services”
“Deactivate Blue-
tooth”.
You have activated or deactivated Blue-
tooth. A checkmark appears when
Bluetooth is deactivated.Connecting Bluetooth devices
It is possible to establish a Bluetooth con-
nection between COMAND and the follow-
ing types of device:


Mobile phone (only for transferring
business cards)


Headset


Laptop / PDA
You can connect up to twelve devices to
COMAND but only one device can be ac-
tive at a time.
The connection process includes search-
ing for the device and its subsequent au-
thorization.Calling up the Bluetooth device list and
searching for devices

Calling up the list: Select “Vehicle”

“System Settings”
“Services”

“Search for Bluetooth devices”.
When you call up the list for the first
time after switching on COMAND, the
search for devices in the reception
range starts automatically. You will see
a display to this effect.
The device list appears after a short
while.
Canceling search:
Select “Cancel”.
The second time you call up the list, and
each time thereafter, the device list ap-
pears immediately if COMAND has not
been switched off and on again in the
meantime.

Starting search manually:
select “Update”.
i
To connect a Bluetooth device, the Blue-
tooth function must be activated in COMAND
and in the device concerned. The Bluetooth de-
vice must also be set to “visible” or “findable” in
order for COMAND to find and display it. For the
setting procedures, please see the operating in-
structions for the Bluetooth device.

218 Control systemsCOMAND system settingsThe device list can contain the following
devices:

All detected devices, whether autho-
rized or not.


All authorized devices, whether detect-
ed or not.
1Authorized and detected device – de-
vice and padlock symbol are the same
color
2Device which was not detected, but
which has been authorized in the past
– device and padlock symbol are differ-
ent colors (the device may be switched
off or not in the vehicle, for example)
3Newly detected device - not yet autho-
rized (no symbol)Displaying details of a Bluetooth device

Call up Bluetooth device list
(page 217).

Select desired device.

Select “Details”.
The detailed display for this device ap-
pears.

Closing detailed display: Slide qmr
or press n.Authorizing a Bluetooth device

Call up Bluetooth device list
(page 217).

Select unauthorized device.

Select “Authorize”.
The input menu for the passkey ap-
pears.
i
If the device list already contains twelve au-
thorized devices, you must revoke authorization
for one of the authorized devices. Then you must
switch this device off and then restart the
search. Any new devices for which you would like
to search will otherwise not appear in the list.
i
The passkey is any one to sixteen-digit num-
ber which you can set yourself. You must enter
the same number in COMAND and also in the de-
vice to be authorized.
i
On devices which do not have an input key-
pad (e.g. headsets), the passkey is predeter-
mined. In this case, it is not necessary to enter
the number on the device itself. You will usually
find the passkey in the operating instructions for
the device.

219 Control systems
COMAND system settings

Entering passkey into COMAND:
Select the digits one by one.

Deleting digits: Select ) and briefly
press n.

Canceling entry into COMAND:
select “Back”.

Confirming entry into COMAND:
Select?.

If necessary, enter the same passkey
into the Bluetooth device (see the op-
erating instructions for the device).
The device is authorized.De-authorizing a Bluetooth device

Call up Bluetooth device list
(page 217).

Select authorized device.

Select “De-authorize”.
A prompt appears asking whether you
really want to de-authorize this device.

Select “Yes” or “No”.
If you select “Yes”, the device will be
de-authorized.
Reset
Select “Vehicle”
“System Settings”

“Reset”.
A prompt appears asking whether you
really want to reset.

Select “Yes” or “No”.
If you select “Yes” another prompt will
appear asking whether you really want
to reset.

Select “Yes” or “No”.
If you select “Yes”, COMAND will be re-
set and restarted.
i
If you de-authorize a device which has been
authorized in the past and which is not detected
in the search, this device will no longer be dis-
played in the device list.
Devices which have been authorized in the past
but which are not detected in the search are ei-
ther not switched on or not in the vehicle.
i
You can reset COMAND back to its factory
settings.
In this case, all personal data (e.g. address book
entries, entries in the destination memory and
the list of last destinations of the navigation sys-
tem), among other things, is deleted.
