MERCEDES-BENZ S550 2007 W221 Owner's Manual

220 Control systemsCOMAND vehicle menuIn this menu, you can program the follow-
ing vehicle functions:
Setting night security illumination
(Exterior Lighting Delayed Switch-off)
Use this function to set whether and how
long you would like the exterior lighting to
illuminate during darkness after exiting the
vehicle and all doors closed.
The exterior lighting automatically goes
out after the delayed switch-off time has
expired.
You can select:

“0 sec.”, the delayed switch-off feature
is deactivated


“15 sec.”, “30 sec.”, “45 sec.”, or
“60 sec.”, the delayed switch-off fea-
ture is activated

Select “Vehicle”.
The main area is active.

Selecting “Exterior Lighting Delayed
Switch-off” menu: Slide omp or
rotateymz.

Confirming selection: Press n.

Selecting length of time: Slide qmr
or rotate ymz.

Confirming selection: Press n.
or

Select “Vehicle”
“Vehicle”
“Exte-
rior Lighting Delayed Switch-off”.
A selection list appears.
The current setting is indicated by a
dotR.
Function
Page
Exterior Lighting Delayed
Switch-off
220
Locator Lighting
221
Exterior Mirror Convenience Set-
tings
222
Automatic Locking
223
Easy Entry/Exit Feature
224
Interior Ambient Light
225
Interior Lighting Delayed
Switch-off
226
Rear Window Sunshade
227
Trunk Opening-height Restriction
227
Tow-away Alarm
228
i
The components and operating principles of
COMAND can be found on (
page 79).
i
You can reactivate this function within
10 minutes by opening a door.

221 Control systems
COMAND vehicle menu

Selecting length of time: Slide qmr
or rotate ymz.

Confirming selection: Press n.
To activate night security illumination:

Select delayed switch-off period (see
above).

Turn the exterior lamp switch to
position* before turning off the en-
gine.
Locator lighting on/off
With the locator lighting feature activated
and the exterior lamp switch in position
*(
page 346), the following lamps will
switch on during darkness when the vehi-
cle is unlocked from the outside:


Parking lamps


Tail lamps


License plate lamps


Front fog lamps


Door entry lamps in the mirror


Side marker lamps
The locator lighting switches off when the
driver’s door is opened.If you do not open a door after unlocking
the vehicle with the SmartKey, the lamps
will switch off automatically after approxi-
mately 40 seconds.

Select “Vehicle”.
The main area is active.

Selecting “Locator Lighting” func-
tion: Slide omp or rotate ymz.

Confirming selection: Press n.

Switching locator lighting on or off:
Press n.
or
i
The components and operating principles of
COMAND can be found on (
page 79).


222 Control systemsCOMAND vehicle menu
Select “Vehicle”
“Vehicle”
“Loca-
tor Lighting”.
A checkmark appears when the locator
lighting is switched on.

Confirming selection: Press n.
To activate locator lighting:

Make sure the function “Locator Light-
ing” is set.

Turn the exterior lamp switch to
position* when exiting the vehicle.
Exterior mirror convenience settings
In the “Exterior Mirror Convenience Set-
tings” menu, you can switch the following
exterior mirror functions on or off:

Exterior mirrors automatically fold in
when the vehicle is locked


Exterior mirror on front passenger’s
side automatically tilts downward
when the vehicle is reversing

Select “Vehicle”.
The main area is active.

Selecting “Exterior Mirror Conve-
nience Settings” menu: Slide omp or
rotate ymz.

Confirming selection: Press n.

Selecting “Fold in automatically
when locking” or “Lower mirror
when reversing”: Rotateymz.

Confirming selection: Press n.

Slide omp to exit.
or
i
The components and operating principles of
COMAND can be found on (
page 79).


223 Control systems
COMAND vehicle menu

Select “Vehicle”
“Vehicle”
“Exte-
rior mirror Convenience Settings”.
A selection list appears.

Selecting a function: Slide qmr or
rotateymz.
A checkmark appears in the corre-
sponding box when the option has
been selected.

Confirming selection: Press n.

Slide omp to exit.
Automatic locking on/off
Use this function to activate or deactivate
the automatic central locking
(page 313). With the automatic central
locking system activated, the vehicle is
centrally locked at vehicle speeds of ap-
proximately 9 mph (15 km/h).

Select “Vehicle”.
The main area is active.

Selecting “Automatic Locking” func-
tion: Slide omp or rotate ymz.

Switching automatic locking on or
off: Press n.
or

Select “Vehicle”
“Vehicle”
“Auto-
matic Locking”.
A checkmark appears when automatic
locking is switched on.

Confirming selection: Press n.

Slide omp to exit.
i
The components and operating principles of
COMAND can be found on (
page 79).

224 Control systemsCOMAND vehicle menuActivating easy-entry/exit feature
Use this function to activate and deacti-
vate the easy-entry/exit feature
(page 328).
The following settings are available for the
easy-entry/exit feature:

Select “Vehicle”.
The main area is active.

Selecting “Easy Entry/Exit Feature”
menu: Slide omp or rotate ymz.

Confirming selection: Press n.
or

Select “Vehicle”
“Vehicle”
“Easy
Entry/Exit Feature”.

Confirming selection: Press n.
A selection list appears.
The current setting is indicated by a
dotR.
i
The components and operating principles of
COMAND can be found on (
page 79).
OFF
The easy-entry/exit
feature is deactivated.
Steering Column
& Seat
Both the steering col-
umn and the driver’s
seat are moved.
Warning!
G
You must make sure no one can become
trapped or injured by the moving steering
wheel and driver’s seat when the easy-en-
try/exit feature is activated.
To cancel seat/steering wheel movement,
do one of the following:

Press seat adjustment switch
(page 319).


Move steering column stalk
(page 330).


Press one of the memory position but-
tons or the memory button M
(page 337).
Do not leave children unattended in the ve-
hicle, or with access to an unlocked vehicle.
Children could open the driver’s door and
unintentionally activate the easy-entry/exit
feature, which could result in an accident
and/or serious personal injury.

225 Control systems
COMAND vehicle menu

Selecting a setting: Slide qmr or
rotateymz.

Confirming selection: Press n.
Setting interior ambient lighting
You can adjust the brightness of the interi-
or lighting on a scale of “0” (off) to “5”
(bright).
Select “Vehicle”.
The main area is active.

Selecting “Interior Ambient Light”
menu: Slide omp or rotate ymz.

Confirming selection: Press n.

Adjusting brightness: Slide omp or
rotate ymz.

Confirming selection: Press n.
or

Select “Vehicle”
“Vehicle”
“Interi-
or Ambient Light”.

Adjusting brightness: Slide qmr or
rotate ymz.

Confirming selection: Press n.
i
The components and operating principles of
COMAND can be found on (
page 79).

226 Control systemsCOMAND vehicle menuSetting interior lighting delayed switch-off
Use this function to set whether and how
long you would like the interior lighting to
remain lit during darkness after you have
removed the SmartKey from the starter
switch.
You can select:

“0 sec.”, the delayed switch-off feature
is deactivated


“15 sec.”, “30 sec.”, “45 sec.”, or
“60 sec.”, the delayed switch-off fea-
ture is activated

Select “Vehicle”.
The main area is active.

Selecting “Interior Lighting Delayed
Switch-off” menu: Slide omp or
rotateymz.

Confirming selection: Press n.
A selection list appears.
The current setting is indicated by a
dotR.

Selecting length of time: Slide qmr
or rotate ymz.

Confirming selection: Press n.
or

Select “Vehicle”
“Vehicle”
“Interi-
or Lighting Delayed Switch-off”.
A selection list appears.
The current setting is indicated by a
dotR.

Selecting length of time: Slide qmr
or rotate ymz.

Confirming selection: Press n.
i
The components and operating principles of
COMAND can be found on (
page 79).

227 Control systems
COMAND vehicle menu
Extending or retracting rear window sunshade
This function is used to extend or retract
the rear sunshade.
Select “Vehicle”.
The main area is active.

Selecting “Rear-window Sunshade”
function: Slide omp or rotate ymz.

Extending or retracting rear window
sunshade: Press n.
or

Select “Vehicle”
“Vehicle”

“Rear-window Sunshade”.

Confirming selection: Press n.
Trunk opening-height restriction on/off
You can select whether the trunk lid should
open fully or only to the height of the roof.
Select “Vehicle”.
The main area is active.

Selecting “Trunk Opening-height Re-
striction” function: Slide omp or
rotateymz.

Confirming selection: Press n.
or
i
The components and operating principles of
COMAND can be found on (
page 79).
i
If you operate the rear-window sunshade via
COMAND or by using the favorite button
(
page 216), this takes precedence over the
buttons for the rear window sunshade in the rear
doors (
page 456).
i
You can program this function using the fa-
vorite button (
page 216).
i
At temperatures below -4°F (-20°C), the
rear window sunshade is switched off.
i
The components and operating principles of
COMAND can be found on (
page 79).


228 Control systemsCOMAND vehicle menu
Select “Vehicle”
“Vehicle”
“Trunk
Opening-height Restriction”.
A checkmark appears when the trunk
opening-height restriction is switched
on.

Confirming selection: Press n.
Switching on/of the tow-away alarm
To prevent triggering the tow-away alarm
feature (
page 76), switch off the
tow-away alarm before towing the vehicle,
or when parking on a surface subject to
movement, such as a ferry or auto train.

Select “Vehicle”.
The main area is active.

Selecting “Tow-away Alarm” func-
tion: Slide omp or rotate ymz.

Confirming selection: Press n.or

Select “Vehicle”
“Vehicle”

“Tow-away Alarm”.
A checkmark appears when the
tow-away alarm is switched on.

Confirming selection: Press n.
i
The components and operating principles of
COMAND can be found on (
page 79).
i
You can program the tow-away alarm func-
tion (page 216) using the favorite button in the
center console.
When you press the favorite button, you can
switch the functions on or off.


229 Control systems
COMAND automatic climate control
COMAND automatic climate control
You can operate the automatic climate
control via COMAND or via the buttons on
the front and rear* automatic climate con-
trol panel (
page 424).
The following automatic climate control
functions can be operated via COMAND:The automatic climate control menu is
called up via the climate control settings.
Climate control settings with functions
(submenus)1Temperature, left
2Air distribution, left
3Air volume, left
4Central menu, climate control
5Air volume, right
6Air distribution, right
7Temperature, right
i
The components and operating principles of
COMAND can be found on (
page 79).
Warning!
G
When operating the automatic climate con-
trol, the air that enters the passenger com-
partment through the air vents can be very
hot or very cold (depending on the set tem-
perature). This may cause burns or frostbite
to unprotected skin in the immediate area of
the air vents.
Always keep sufficient distance between un-
protected parts of the body and the air
vents. If necessary, use the air distribution
adjustment (
page 230) to direct the air to
air vents in the vehicle interior that are not
in the immediate area of unprotected skin.
Warning!
G
Follow the recommended settings for heat-
ing and cooling given on the following pages
and pages in the “Controls in detail” part
(page 424) Otherwise the windows could
fog up, impairing visibility and endangering
you and others.
Function
Page
Temperature
230
Air distribution
230
Air volume
230
Switching off cooling (“AC
OFF”)
231
Central climate control (“Mono”)
232
Footwell temperature
232
Air flow from air vents
233
Rear climate control*
234
