MERCEDES-BENZ SPRINTER 2006 Service Manual

8W-45 CENTRAL TIMER MODULE
Component Page
Airbag Control Module................ 8W-45-3
Central Timer Module....... 8W-45-2, 3, 4, 5, 6, 7
Data Link Connector................. 8W-45-3
Door Lock Motor/Ajar Switch Assembly-
Driver........................... 8W-45-2
Door Lock Motor/Ajar Switch Assembly-Left
Sliding........................ 8W-45-5, 6
Door Lock Motor/Ajar Switch Assembly-
Passenger........................ 8W-45-7
Door Lock Motor/Ajar Switch Assembly-
Rear.......................... 8W-45-4, 6
Door Lock Motor/Ajar Switch Assembly-Right
Sliding........................ 8W-45-5, 6Component Page
Fuse 5............................ 8W-45-3
Fuse 15............................ 8W-45-3
Fuse Block No. 1.................... 8W-45-3
Fuse Block No. 2.................... 8W-45-3
G202.............................. 8W-45-3
Master Door Lock Switch.............. 8W-45-4
Security System Module............... 8W-45-2
Sentry Key Remote Entry Module....... 8W-45-2
Window Defogger Module-Rear......... 8W-45-3
VA8W-45 CENTRAL TIMER MODULE 8W - 45 - 1

8W-47 AUDIO SYSTEM
Component Page
CTEL Connector..................... 8W-47-4
Data Link Connector................. 8W-47-3
Daytime Running Lamps Relay......... 8W-47-2
Fuse 8............................ 8W-47-2
Fuse 15............................ 8W-47-2
Fuse Block No. 1.................... 8W-47-2
G203.............................. 8W-47-3
Instrument Cluster................... 8W-47-2Component Page
Radio....................... 8W-47-2, 3, 4, 5
Radio Antenna...................... 8W-47-3
Radio/Cellular Antenna............... 8W-47-3
Speaker-Left Front Door Assembly....... 8W-47-4
Speaker-Left Rear................... 8W-47-5
Speaker-Right Front Door............. 8W-47-5
Speaker-Right Rear.................. 8W-47-5
VA8W-47 AUDIO SYSTEM 8W - 47 - 1
