Mercury Mystique 1998 s Owner's Guide

Controls and features
21
Using MAXA/C mode
(if equipped)
The MAXA/C mode recirculates
the air and directs it to flow
through the instrument panel
vents.
This mode is noisier, but provides
quicker cooling than the A/C mode.
The A/C compressor only functions
if the outside temperature is above
10°C (50°F).
LO
HIOFFPNL/FLR
PANEL
A/CFLOOR
DEFFLR
DEF

MAX
A/C
Using A/C mode (if equipped)
The A/C mode directs outside
conditioned air to flow through the
instrument panel vents. The A/C
mode can be used for heating,
ventilating and air conditioning.
The A/C compressor only functions
in the A/C mode if the outside
temperature is above 10°C (50°F).
LO
HIOFFPNL/FLR
PANEL
A/CFLOOR
DEFFLR
DEF

MAX
A/C
CDW IIIC3Cont en MM 5/15/97 7:45 PM Page 21

Controls and features
22
Using the PANELmode
The panel mode directs outside air
to the panel vents.
LO
HIOFFPNL/FLR
PANEL
A/CFLOOR
DEFFLR
DEF

MAX
A/C
OFF mode
Select the off position for all
climate control functions to cease.
The outside inlet door will close
and the fan will shut off.
Drive with the climate control
system on (either in heating or A/C
mode) to reduce humidity in your
vehicle.
Using the PNL/FLR mode
The panel/floor mode directs
outside air to flow through both the
panel and floor vents.
LO
HIOFFPNL/FLR
PANEL
A/CFLOOR
DEFFLR
DEF

MAX
A/C
LO
HIOFFPNL/FLR
PANEL
A/CFLOOR
DEFFLR
DEF

MAX
A/C
Using the FLOOR mode
The floor mode directs outside air
to the floor vents.
LO
HIOFFPNL/FLR
PANEL
A/CFLOOR
DEFFLR
DEF

MAX
A/C
CDW IIIC3Cont en MM 5/15/97 7:45 PM Page 22

Controls and features
23
Using the FLR/DEF mode
The floor/defrost mode directs
outside air to flow through the floor
vents and windshield defroster
vents. The A/C compressor (if
equipped) will function to
dehumidify the windows provided
the outside temperature is above
10°C (50°F).
LO
HIOFFPNL/FLR
PANEL
A/CFLOOR
DEFFLR
DEF

MAX
A/C
Using the DEF mode
In addition to defogging and
demisting the front windshield, the
defrost mode of your vehicle also
has the capability to demist the
front side windows. The A/C
compressor (if equipped) will
function to dehumidify the
windows provided the outside
temperature is above 10°C (50°F).
LO
HIOFFPNL/FLR
PANEL
A/CFLOOR
DEFFLR
DEF

MAX
A/C
Passenger compartment air
filter
Your vehicle is equipped with an air
filter that removes pollen and road
dust from outside air before it is
directed to the interior of the
vehicle. Refer to the
Maintenance
and carechapter for maintenance
of this filter.
CDW IIIC3Cont en MM 5/15/97 7:45 PM Page 23

Controls and features
24STEERING COLUMN
CONTROLS
Ignition
1. Ignition off, steering wheel
locked.
On vehicles with automatic
transaxles, the ignition key can
return to this position only if the
gearshift lever is in P (Park).
2. The accessory position. Steering
unlocked, radio operational.
Ignition and all main electrical
circuits are disabled.
The ignition key should not be left
in this position for too long to avoid
discharging the battery
unnecessarily.
3. Ignition switched on, all
electrical circuits operational.
Warning and indicator lights
illuminate. This key position is for
normal driving.
4. Starter motor activated. Release
the key as soon as the engine
starts.
3
4
21
MIRRORS
000123
000010 20 3040506070
80
90
100
110
120
130MPH20 406055
80120 100
140
160
180
200EF 1
/
2UNLEADED FUEL ONLY
12
03x 1000
4
5
6
7
8
NORMALBRAKE
CHECK
ENGINE TRACTION
CONTROLO/D
OFF
Off
Res
Set
AccCoast
On
CDW IIIC3Cont en MM 5/15/97 7:45 PM Page 24

Controls and features
25
POWERAUDIOAM/FM
SCAN
SEEK 312645ANSSIDE1-2EJECTVOLUME
MIRRORSDEF
LO
HIOFFPNL/FLR
PANEL
A/CFLOOR
FLR
DEF

MAX
A/C
000123
000010 20 3040506070
80
90
100
110
120
130MPH20 406055
80120 100
140
160
180
200EF 1
/
2UNLEADED FUEL ONLY
12
03x 1000
4
5
6
7
8
NORMALBRAKE
CHECK
ENGINE TRACTION
CONTROLO/D
OFF
:
I0 20
Off
Res
Set
AccCoast
On
Tilt steering
Pull the locking lever on the
steering column cover up to adjust
the steering column position.
Secure the wheel by pushing the
locking lever down.
Never adjust the steering
wheel while the vehicle is
moving.
CDW IIIC3Cont en MM 5/15/97 7:45 PM Page 25

Controls and features
26Hazard flasher control
Use only in an emergency to warn
traffic of vehicle breakdown or
approaching danger. Depress to
activate. Depress again to switch
off. The hazard lights can be
operated when the ignition is off.
Off
ResSet
AccCoast
On
Off
ResSet
AccCoast
On
Horn
Press the pad. The horn can be
operated when the ignition is off.
CDW IIIC3Cont en MM 5/15/97 7:45 PM Page 26

Controls and features
27
POWERAUDIOAM/FM
SCAN
SEEK 312645ANSSIDE1-2EJECTVOLUME
MIRRORSDEF
LO
HIOFFPNL/FLR
PANEL
A/CFLOOR
FLR
DEF

MAX
A/C
000123
000010 20 3040506070
80
90
100
110
120
130MPH20 406055
80120 100
140
160
180
200EF 1
/
2UNLEADED FUEL ONLY
12
03x 1000
4
5
6
7
8
NORMALBRAKE
CHECK
ENGINE TRACTION
CONTROLO/D
OFF
:
I0 20
Off
Res
Set
AccCoast
On
Multi-function switch
The turn signal functions are
available only with the ignition
switch on.
Right turn signal
Move the lever up.
Left turn signal
Move the lever down.
Flash-to-pass
Pull the lever toward you and
release quickly for “flash-to-pass”
operation.
High beam Headlamps
Push the lever toward the
instrument panel.
CDW IIIC3Cont en MM 5/15/97 7:45 PM Page 27

Controls and features
28
Wipers
Lift the windshield wiper lever to
the desired speed interval.
•Intermittent: push lever up to the
first position.
•Low: push lever up to the second
position.
•High: push lever up to the third
position.
For a single wipe, push the lever
downward.
Windshield wipers and washer
Intermittent wiper control
(if equipped)
Rotate the variable intermittent
wiper control to the desired speed.
1 = Short time interval
6 = Extended time interval
Washer
Pull the lever toward the steering
wheel. The washer operates in
conjunction with the windshield
wipers.
CDW IIIC3Cont en MM 5/15/97 7:45 PM Page 28

Controls and features
29
Do not use the speed control
in heavy traffic or on roads
that are winding, slippery, or
unpaved.
Off
On
Speed control (if equipped)
To turn speed control off
•Press Off or
•turn off the vehicle ignition.
Once speed control is switched off,
the previously programmed set
speed will be erased.
To turn speed control on
•Press On.
POWERAUDIOAM/FM
SCAN
SEEK 312645ANSSIDE1-2EJECTVOLUME
MIRRORSDEF
LO
HIOFFPNL/FLR
PANEL
A/CFLOOR
FLR
DEF

MAX
A/C
000123
000010 20 3040506070
80
90
100
110
120
130MPH20 406055
80120 100
140
160
180
200EF 1
/
2UNLEADED FUEL ONLY
12
03x 1000
4
5
6
7
8
NORMALBRAKE
CHECK
ENGINE TRACTION
CONTROLO/D
OFF
:
I0 20
Off
Res
Set
AccCoast
On
CDW IIIC3Cont en MM 5/15/97 7:45 PM Page 29

Controls and features
30
To set a speed
Press SetAcc. For speed control to
operate, the speed control must be
on and the vehicle speed must be
greater than 48 km/h (30 mph).
If you drive up or down a steep hill,
your vehicle speed may vary
momentarily slower or faster than
the set speed. This is normal.
Speed control cannot reduce the
vehicle speed if it increases above
the set speed on a downhill. If your
vehicle speed is faster than the set
speed while driving on a downhill
in overdrive, you may want to shift
to the next lower gear to reduce
your vehicle speed.Res
Set
Acc
Coast
Res
Set
Acc
Coast
If your vehicle slows down more
than 16 km/h (10 mph) below your
set speed on an uphill, your speed
control will disengage. This is
normal. Press Res to re-engage it.
CDW IIIC3Cont en MM 5/15/97 7:45 PM Page 30
