Servicing Your Villager
317
[SV19600(ALL)05/96]
Recycled engine coolant
[SV19700(ALL)05/96]
Ford Motor Company recommends that Ford and
Lincoln-Mercury dealers use recycled engine coolant produced
by Ford-approved processes. Not all coolant recycling processes
produce coolant which meets Ford specification ESE-M97B44-A,
and use of such coolant may harm engine and cooling system
components.
[SV19800(ALL)05/96]
Always dispose of used automotive fluids in a responsible
manner. Follow your community's regulations and standards for
recycling and disposing of automotive fluids.
[SV19900(ALL)05/96]
Coolant refill capacity
[SV19950(ALL)05/96]
To find out how much fluid your vehicle's cooling system can
hold, seeRefill capacities for fluidsin the Index.
[SV20000(ALL)05/96]
Have your dealer check the engine cooling system for leaks if
you have to add more than a quart (liter) of engine coolant per
month.
[SV20100(ALL)05/96]
Severe winter climate
[SV20200(ALL)05/96]
If you drive in extremely cold climates (less than-34ÊF [-36ÊC]),
it may be necessary to increase the coolant concentration above
50%. Refer to the chart on the coolant container to ensure the
coolant concentration in your vehicle is such that the coolant
will not freeze at the temperature level in which you drive
during winter months. Never increase the engine coolant
concentration above 60%. Leave a 50/50 mixture of engine
coolant and water in your vehicle year-round in non-extreme
climates.
[SV20300(ALL)05/96]
Checking hoses
[SV20400(ALL)05/96]
Inspect all engine and heater system hoses for deterioration,
leaks and loose clamps before adding or replacing engine
coolant. Make whatever repairs or replacements are necessary
using Motorcraft parts or their equivalents.
File:15vxsvn.ex
Update:Wed Jun 5 12:25:18 1996

318
[SV21460(ALL)09/93] Theairfilte rshoul dno tbe cleane dan dreused .Replac eit
WARNING
Neve rpou rfue lin thethrottl ebod yor attemp tto start

ServicingYou rVillager
319
WARNING
D o no tpu twindshiel dwashe rflui din thecontaine rfor
File:15vxsvn.ex

320
%*
[SV22100(ALL)01/95]
Use specially formulated windshield washer fluid rather than
plain water, because specially formulated washer fluids contain
additives that dissolve road grime. For safety reasons, washer
fluids containing an appropriate antifreeze such as methanol
should be used in freezing weather (temperatures below32ÊF
[0ÊC]). State or local regulations on Volatile Organic Compounds
(VOC's) may restrict use of the most common antifreeze,
methanol. Washer fluids containing non-methanol antifreeze
agents should be used only if they provide cold weather
protection without damaging the vehicle's paint finish, wiper
blades, and windshield washer system.
%*
[SV22300(ALL)03/95]
Wiper Blades
*
[SV22400(ALL)03/95]
Check the windshield wiper blades at least twice a year. Also
check them whenever they seem less effective than usual.
Substances such as tree sap and some hot wax treatments used
by commercial car washes reduce the effectiveness of wiper
blades.
*
[SV22500(ALL)09/95]
If the blades do not wipe properly, clean both the windshield
and the wiper blades. Use undiluted windshield washer solution
or a mild detergent. Rinse thoroughly with clear water. Do not
use fuel, kerosene, paint thinner, or other solvents to clean your
wiper blades. These will damage your blades.
*
[SV22600(ALL)04/95]
To reach the wiper blades easily, turn the ignition switch to
ACCESSORY and turn your wipers on. Wait for them to reach a
vertical position and turn the ignition to OFF. Moving the
wipers manually may damage them.
File:15vxsvn.ex
Update:Wed Jun 5 12:25:18 1996

Servicing Your Villager
321
*
[SV22700(ALL)03/01]
Wiper blade replacement
*
[SV22800(ALL)01/95]
If the wipers still do not work properly after you clean them,
you may need to replace the wiper blade assembly. When
replacing the wiper blade assembly always use a Motorcraft part
or equivalent.
*
[SV22900(ALL)10/93]
To replace the wiper blades:
*
[SV23000(ALL)06/95]1.
Pull the wiper arm away from the windshield and into the
lock position.
[SV23100(ALL)04/95]2.
Turn the blade at an angle from the wiper arm. Push the
lock pin to release the blade and pull the wiper blade down
toward the windshield to remove it from the arm.
*
[SV23200(ALL)03/94]3.
Attach a new wiper blade to the wiper arm and press it into
place until you hear it click.
[SV23300(ALL)06/95]
13-1/2 pica
art:0040235-B
Replacing the wiper blades
File:15vxsvn.ex
Update:Wed Jun 5 12:25:18 1996

322
WARNING
Alwaysobe yposte dspee dlimits .If yo udriv etoo fast
WARNING
Improperl yinflate dtire sca n affec tvehicl ehandlin gand

Servicing Your Villager
323
%*[SV24500(ALL)08/95]Tire Inspection and Maintenance
*[SV24600(ALL)02/95]Inspect the tire treads, and remove stones, nails, glass or other
objects that may be wedged in the tread grooves. Check for
holes or cuts that may permit air to leak from the tire, and
make the necessary repairs.
*[SV24700(ALL)05/95]Inspect the tire sidewalls for cuts, bruises and other damage. If
you suspect internal damage to the tire, have it removed and
checked. You may need to repair or replace it.
%*[SV24800(ALL)02/95]Tire Rotation
*[SV24900(ALL)03/95]Because your vehicle's front and rear tires perform different
jobs, they often wear differently. To make sure your tires wear
evenly and last longer, rotate them at the mileage shown in the
Maintenance Schedule and Recordbooklet which came with your
vehicle.
*[SV25000(ALL)03/90]In situations where the tires differ from front to rear
(snow/traction), simply rotate using a side to side pattern.
[SV25100(ALL)09/93]
10-1/2 pica
art:0040199-B
Rotating the tires
File:15vxsvn.ex
Update:Wed Jun 5 12:25:18 1996

324
WARNING
If yo uus eth etemporar yspar etir econtinuousl yor do
*

ServicingYou rVillager
325
WARNING
Whe nreplacin gful lsiz etires ,neve rmi xradial,
WARNING
Mak esur etha tal lreplacemen ttire sar e of th esam esize,
WARNING
Failur eto follo wthes eprecaution sma yadversel yaffect

326
%*
[SV27400(ALL)02/95]
Information About Tire Quality Grades
*
[SV27500(ALL)01/95]
New vehicles are fitted with tires that have their Tire Quality
Grade (described below) molded into the tire's sidewall. These
Tire Quality Grades are determined by standards that the
United States Department of Transportation has set.
*
[SV27600(ALL)12/93]
Tire Quality Grades apply to new pneumatic tires for use on
this vehicle. They do not apply to deep tread, winter-type snow
tires, space-saver or temporary use spare tires, tires with
nominal rim diameters of 10 to 12 inches (254-305 mm) or
limited production tires as defined in Title 49 Code of Federal
Regulations Part 575.104(c)(2).
*
[SV27700(ALL)01/95]
U.S. Department of Transportation Ð Tire quality grades:The
U.S. Department of Transportation requires Ford to give you
the following information about tire grades exactly as the
government has written it.
%*
[SV27800(ALL)01/95]
Treadwear
*
[SV27900(ALL)01/95]
The treadwear grade is a comparative rating based on the wear
rate of the tire when tested under controlled conditions on a
specified government test course. For example, a tire graded 150
would wear one and one-half (1 1/2) times as well on the
government course as a tire graded 100. The relative
performance of tires depends upon the actual conditions of their
use, however, and may depart significantly from the norm due
to variations in driving habits, service practices and differences
in road characteristics and climate.
*
[SV28000(ALL)01/95]
Traction A B C
[SV28100(ALL)01/93]
The traction grades, from highest to lowest, are A, B, and C,
and they represent the tire's ability to stop on wet pavement as
measured under controlled conditions on specified government
test surfaces of asphalt and concrete. A tire marked C may have
poor traction performance.
