ServicingYou rVillager
307
WARNING
Automotiv efuel sca n caus eseriou sinjur yor deat hif
WARNING
Gasolin eor gasolin eblende dwit hmethano lca n cause

308
%*
[SV12100(ALL)05/95]
Running Out of Fuel
*
[SV12150(ALL)06/95]
NOTE: Avoid running out of fuel because this situation may
have an adverse effect on modern powertrain
components.
*
[SV12300(ALL)07/95]
You may need to crank the engine several times before the fuel
system starts to pump fuel from the tank to the engine.
%*
[SV12400(ALL)05/95]
Fuel Economy
*
[SV12450(ALL)05/95]
Fuel economy is an estimate of the efficiency of your vehicle,
and can be calculated as Miles Per Gallon (MPG) or Liters Per
100 Kilometers (L/100K).
*
[SV12460(ALL)05/95]
Do not calculate fuel economy during your vehicle's break-in
period. This would not be an accurate estimate of how much
fuel your vehicle will normally use.
*
[SV12475(ALL)05/95]
To calculate fuel economy:
*
[SV12505(ALL)05/95]1.
Fill the fuel tank completely and record the initial odometer
reading.
*
[SV12550(ALL)05/95]2.
Every time you buy fuel, record the amount (in gallons or
liters) purchased.
*
[SV12605(ALL)05/95]3.
After at least 3-5 tankfuls, fill the fuel tank and record the
final odometer reading.
*
[SV12650(ALL)10/95]4.
Use these equations to calculate your fuel economy:
*
[SV12705(ALL)10/95]
n
English: MPGU(total miles driven)V(gallons used)
[SV12750(ALL)06/95]
n
Metric: L/100kUMultiply the number of liters used by 100
and divide the answer by the number of kilometers
travelled.
File:15vxsvn.ex
Update:Wed Jun 5 12:25:18 1996

Servicing Your Villager
309
*
[SV13200(ALL)01/93]
Comparisons With Environmental Protection Agency
(EPA) Fuel Economy Estimates
*
[SV13300(ALL)05/95]
EPA fuel economy figures are obtained from laboratory tests
under simulated road conditions and may not reflect the actual
conditions you experience or your style of driving. The EPA
fuel economy estimate is not a guarantee that you will achieve
the fuel economy shown.
*
[SV13550(ALL)05/95]
The following decrease fuel economy:
*
[SV13650(ALL)05/95]
n
Lack of regular, scheduled maintenance
*
[SV13750(ALL)05/95]
n
Rapid acceleration and excessive speed
*
[SV13950(ALL)05/95]
n
Driving with your foot on the brake
*
[SV14050(ALL)05/95]
n
Sudden stops
*
[SV14150(ALL)05/95]
n
Extended engine idling
*
[SV14250(ALL)05/95]
n
Using speed control in hilly terrain
[SV14350(ALL)02/95]
n
Extended use of the A/C, defroster, rear window defroster
and other accessories
*
[SV14450(ALL)05/95]
n
Underinflated tires
[SV14460(ALL)02/95]
n
Heavy loads
[SV14470(ALL)02/95]
n
Aftermarket add-ons such as bike, ski or luggage racks, bug
deflectors, etc.
File:15vxsvn.ex
Update:Wed Jun 5 12:25:18 1996

310
%*
[SV14600(ALL)02/95]
Engine Oil Recommendations
*
[SV14750(ALL)02/96]
We recommend using Motorcraft oil or an equivalent oil
meeting Ford Specification WSS-M2C153-F and displaying the
American Petroleum Institute CERTIFICATION MARK on the
front of the container.
*
[SV14850(ALL)03/95]
one third page
art:0060021-E
The API Certification Mark
*
[SV15000(ALL)01/95]
Neveruse:
*
[SV15100(ALL)01/95]
n
ªNon-Detergentº oils
*
[SV15200(ALL)04/95]
n
Oils labeled API SA, SB, SC, SD, SE, SF or SG
%*
[SV15300(ALL)01/95]
n
Additional engine oil additives, oil treatments or engine
treatments
%*
[SV15400(ALL)03/95]
Engine oils with an SAE 5W-30viscosity arePREFERREDfor
your vehicle. They provide the best engine performance, fuel
economy and engine protection for all climates down to-15ÊF
(-25ÊC).
File:15vxsvn.ex
Update:Wed Jun 5 12:25:18 1996

Servicing Your Villager
311
[SV15500(ALL)02/94]
10-1/2 pica
art:0040196-B
Selecting the right viscosity for your climate
%*
[SV15575(ALL)03/95]
Synthetic engine oils which are CERTIFIED and of the preferred
viscosity may be used in your engine. The engine oil and oil
filter must still be changed according to the maintenance
schedule.
%*
[SV15600(ALL)01/95]
Checking and Adding Engine Oil
*
[SV15700(ALL)03/95]
Since the proper amount of engine oil is important for safe
engine operation, check the oil using the dipstick each time you
put fuel in your vehicle. Remember the engine must be off, the
oil must be warm and the vehicle must be parked on level
ground.
%*
[SV15800(ALL)03/95]
Checking the engine oil level:
*
[SV15900(ALL)02/95]1.
Turn the engine off after it has warmed up and allow a few
minutes for the engine oil to drain back into the oil pan.
[SV16000(ALL)07/95]2.
Set the parking brake fully and make sure that the gearshift
is securely latched in P (Park).
*
[SV16100(ALL)02/95]3.
Open the hood. Protect yourself from engine heat.
*
[SV16200(ALL)03/95]4.
Locate the engine oil dipstick (highlighted in yellow) and
carefully pull it out of the engine.
File:15vxsvn.ex
Update:Wed Jun 5 12:25:18 1996

312
*
[SV16300(ALL)01/95]5.
Wipe the dipstick clean and put it back into position, making
sure it is fully seated.
[SV16400(ALL)05/93]
7-1/2 pica art:0040218-A
Engine oil dipstick
[SV16500(ALL)05/94]6.
Carefully pull the dipstick out again. If the oil level is below
the ªLº line, add engine oil as necessary. If the oil level is
beyond the letter ªH,º engine damage or high oil
consumption may occur and some oil must be removed from
the engine.
*
[SV16600(ALL)01/95]7.
Put the dipstick back in and make sure it is fully seated.
%*
[SV16650(ALL)03/95]
Adding engine oil
*
[SV16700(ALL)01/95]
It may be necessary to add some oil between oil changes. Make
sure you use a CERTIFIED engine oil of the preferred viscosity.
Your vehicle's warranty coverage may not apply if engine
damage is caused by the use of improper engine oil.
*
[SV16800(ALL)03/95]
Add engine oil through the oil filler cap highlighted in yellow.
To add oil, remove the filler cap and use a funnel to pour oil
into the opening. Be careful not to overfill the engine. Recheck
the oil level after you finish adding oil.
File:15vxsvn.ex
Update:Wed Jun 5 12:25:18 1996

ServicingYou rVillager
313
WARNING
Continuou scontac twit hUSE Dmoto roi lha scaused

314
%*
[SV18400(ALL)03/95]
Engine Coolant
%*
[SV18500(ALL)09/95]
Checking the Engine Coolant
*
[SV18550(ALL)08/95]
NOTE: Be sure to read and understandPrecautions When
Servicing Your Vehicleat the beginning of this chapter.
[SV18600(ALL)01/93]
Your vehicle's engine coolant protects the engine from
overheating in the summer and from freezing in the winter.
Check the level of the engine coolant at least once a month, but
preferably each time you stop for fuel. Simply check the coolant
reservoir, located in the engine compartment. The coolant
should stay between the MIN and MAX marks. It will be closer
to MAX when the engine is warm and closer to MIN when the
engine is cold. To locate the coolant reservoir, see the diagram
of your vehicle's engine underEngine Compartmentin this
chapter.
File:15vxsvn.ex
Update:Wed Jun 5 12:25:18 1996

ServicingYou rVillager
315
*WARNING
D o no tpu tengin ecoolan tin thecontaine rfo rthe

316
WARNING
Neverremov eth ecoolan trecover ycap whil eth eengine
