SYMPTOM PROCEDURES
SIMPLIFIED WIRING SYSTEM (SWS)54B-106
INSPECTION PROCEDURE B-4: Tone Alarm: Door ajar Warning Buzzer Function does not Work
Normally.
NOTE: This troubleshooting procedure requires the
use of diagnostic tool MB991958 and SWS monitor
kit MB991813. For details on how to use the SWS
monitor, refer to "How to connect SWS monitor
P.54B-13."
.
CIRCUIT OPERATION
The ETACS-ECU controls the door-ajar warning tone
alarm, based on the signals from the switches and
sensors below.
Ignition switch (IG1): ON
One of the door switches: ON
Vehicle speed signal: 8 km/h (5 mph) or more
.
TECHNICAL DESCRIPTION (COMMENT)
If the door-ajar warning tone alarm does not work,
connector(s), wiring harness in the CAN bus lines,
the combination meter, the ETACS-ECU or the input
signal circuit may be defective.
.
TROUBLESHOOTING HINTS
Refer to circuit diagrams GROUP-90
Refer to configuration diagrams GROUP-80
Trouble in input signal system
The wiring harness or connectors may have
loose, corroded, or damaged terminals, or termi-
nals pushed back in the connector
The combination meter may be defective
The ETACS-ECU may be defective

SYMPTOM PROCEDURES
SIMPLIFIED WIRING SYSTEM (SWS)54B-142
INSPECTION PROCEDURE C-3: Central Door Locking System: All the Doors do not Lock or Unlock
with just the Door Lock Switch Operation.
.
TECHNICAL DESCRIPTION (COMMENT)
The door lock switch (incorporated in the power win-
dow main switch and front power window sub switch)
or the ETACS-ECU may be defective.
.
TROUBLESHOOTING HINTS
Refer to circuit diagrams GROUP-90
Refer to configuration diagrams GROUP-80
Trouble in input signal system
The wiring harness or connectors may have
loose, corroded, or damaged terminals, or termi-
nals pushed back in the connector
The ETACS-ECU may be defective
DIAGNOSIS
Required Special Tools:
MB991223: Harness Set
MB991958: diagnostic tool (MUT-III Sub Assembly)
MB991824: Vehicle Communication Interface (V.C.I.)
MB991827: MUT-III USB Cable
MB991910: MUT-III Main Harness A
Check the input signal (by using the pulse check mode of
the monitor).
Check the input signals from the door lock switch (incorporated
in the power window main switch and front power window sub
switch):
To prevent damage to diagnostic tool MB991958, always
turn the ignition switch to the "LOCK" (OFF) position
before connecting or disconnecting diagnostic tool
MB991958.
(1) Connect the special tool. Refer to "How to connect SWS
monitor P.54B-13."
(2) When the driver's or the front passenger's door lock switch
is moved from "LOCK" to "UNLOCK" and vice versa, check
if diagnostic tool MB991958 sounds or not.
(3) Operate diagnostic tool MB991958 according to the
procedure below to display "Pulse check."
a. Select "Interactive Diagnosis."
b. Select "System Select."
c. Select "SWS."
d. Select "Pulse Checking."
Q: Does diagnostic tool MB991958 sound when the driver's
or the front passenger's door lock switch is moved from
"LOCK" to "UNLOCK" and vice versa?
YES : Replace the ETACS-ECU. Check that all the doors
should be locked and unlocked by the door lock
switch.
NO : Refer to Inspection Procedure N-6 "ETACS-ECU
does not receive any signal from the door lock switch
(incorporated in the power window main switch and
front power window sub switch) P.54B-460."

SYMPTOM PROCEDURES
SIMPLIFIED WIRING SYSTEM (SWS)54B-143
INSPECTION PROCEDURE C-4: Central Door Locking System: All the Doors do not Lock or Unlock
with just the Door Lock Key Cylinder Key Operation.
.
TECHNICAL DESCRIPTION (COMMENT)
The door lock key cylinder switch or the ETACS-ECU
may be defective.
.
TROUBLESHOOTING HINTS
Refer to circuit diagrams GROUP-90
Refer to configuration diagrams GROUP-80
Trouble in input signal system
The wiring harness or connectors may have
loose, corroded, or damaged terminals, or termi-
nals pushed back in the connector
The ETACS-ECU may be defective
DIAGNOSIS
Required Special Tools:
MB991223: Harness Set
MB991958: diagnostic tool (MUT-III Sub Assembly)
MB991824: Vehicle Communication Interface (V.C.I.)
MB991827: MUT-III USB Cable
MB991910: MUT-III Main Harness A
Check the input signal (by using the pulse check mode of
the monitor).
Check the input signals from the door lock key cylinder switch.
To prevent damage to diagnostic tool MB991958, always
turn the ignition switch to the "LOCK" (OFF) position
before connecting or disconnecting diagnostic tool
MB991958.
(1) Connect the special tool. Refer to "How to connect SWS
monitor P.54B-13."
(2) When the doors are locked and unlocked by using the
driver's door lock key cylinder, check that diagnostic tool
MB991958 sounds.
(3) Operate diagnostic tool MB991958 according to the
procedure below to display "Pulse check."
a. Select "Interactive Diagnosis."
b. Select "System Select."
c. Select "SWS."
d. Select "Pulse Checking."
Q: When the doors are locked and unlocked by using the
driver's door lock key cylinder, does diagnostic tool
MB991958 sound?
YES : Replace the ETACS-ECU. Check that all the doors
should be locked and unlocked by using driver door
lock key cylinder switch.
NO : Refer to Inspection Procedure N-4 "ETACS-ECU
does not receive any signal from the door lock key
cylinder switch P.54B-446."

SYMPTOM PROCEDURES
SIMPLIFIED WIRING SYSTEM (SWS)54B-144
INSPECTION PROCEDURE C-5: Central Door Locking System: Forgotten Key Prevention Function
does not Work Normally.
NOTE: This troubleshooting procedure requires use
of diagnostic tool MB991958 and SWS monitor kit
MB991813. For details on how to use the SWS mon-
itor, refer to "How to connect SWS monitor
P.54B-13."
.
CIRCUIT OPERATION
The ETACS-ECU operates the forgotten key preven-
tion function according to the following switches:
Key reminder switch: OFF
Front door switch: ON
Front door lock actuator switch: being turned on
The ETACS-ECU operates the forgotten key preven-
tion function under the following conditions:
Ignition key: inserted into the ignition key cylinder
Front door: open
Front door lock: being locked
.
TECHNICAL DESCRIPTION (COMMENT)
If the function does not work normally, the input cir-
cuit system from the switches or the ETACS-ECU
may be defective (refer to "CIRCUIT OPERATION").
.
TROUBLESHOOTING HINTS
Refer to circuit diagrams GROUP-90
Refer to configuration diagrams GROUP-80
Trouble in input signal system
The wiring harness or connectors may have
loose, corroded, or damaged terminals, or termi-
nals pushed back in the connector
The ETACS-ECU may be defective

SYMPTOM PROCEDURES
SIMPLIFIED WIRING SYSTEM (SWS)54B-151
INSPECTION PROCEDURE D-1: Power Windows: Power windows do not work at all.
NOTE: This troubleshooting procedure requires use
of diagnostic tool MB991958 and SWS monitor kit
MB991813. For details on how to use the SWS mon-
itor, refer to "How to connect SWS monitor
P.54B-13."
.
CIRCUIT OPERATION
The ETACS-ECU turns on the power window relay
(installed on the junction block) to activate the power
windows when the ignition switch (IG1) is turned to
the "ON" position.
.
TROUBLESHOOTING HINTS
Refer to circuit diagrams GROUP-90
Refer to configuration diagrams GROUP-80
The wiring harness or connectors may have
loose, corroded, or damaged terminals, or termi-
nals pushed back in the connector
The power window relay may be defective
The power window main switch may be defective
The ETACS-ECU may be defective

SYMPTOM PROCEDURES
SIMPLIFIED WIRING SYSTEM (SWS)54B-159
Q: Is the wiring harness between power window main
switch connector E-04 (terminal 2) and ground in good
condition?
YES : No action is necessary and testing is complete.
NO : The wiring harness may be damaged or the
connector(s) may have loose, corroded or damaged
terminals, or terminals pushed back in the connector.
Repair the wiring harness as necessary. The power
windows function should now work normally.
STEP 12. Check the battery power supply circuit to the
power window main switch. Measure the voltage at power
window main switch connector E-04.
(1) Disconnect power window main switch connector E-04 and
measure the voltage available at the harness side of the
connector.
(2) Turn the ignition switch to "ON" position.
(3) Measure the voltage between terminal 10 and ground.
The voltage should measure approximately 12 volts
(battery positive voltage).
Q: Is the measured voltage approximately 12 volts (battery
positive voltage)?
YES : Replace the power window main switch. The power
windows function should now work normally.
NO : Go to Step 13.
STEP 13. Check ETACS-ECU connector C-219 for loose,
corroded or damaged terminals, or terminals pushed back
in the connector.
Q: Is ETACS-ECU connector C-219 in good condition?
YES : Go to Step 14.
NO : Repair or replace the damaged component(s). Refer
to GROUP 00E, Harness Connector Inspection
P.00E-2. The power windows function should now
work normally.

SYMPTOM PROCEDURES
SIMPLIFIED WIRING SYSTEM (SWS)54B-161
INSPECTION PROCEDURE D-2: Power Window: The power window timer function does not work
normally.
NOTE: This troubleshooting procedure requires use
of diagnostic tool MB991958 and SWS monitor kit
MB991813. For details on how to use the SWS mon-
itor, refer to "How to connect SWS monitor
P.54B-13."
.
CIRCUIT OPERATION
The ETACS-ECU operates the power window timer
function according to the following signals:
Ignition switch (IG1)
Front door switch
.
TECHNICAL DESCRIPTION (COMMENT)
If the power window timer function does not work
normally, its input circuit, the ETACS-ECU or the
front-ECU may be defective.
.
TROUBLESHOOTING HINTS
Refer to circuit diagrams GROUP-90
Refer to configuration diagrams GROUP-80
The wiring harness or connectors may have
loose, corroded, or damaged terminals, or termi-
nals pushed back in the connector
The ETACS-ECU may be defective

SYMPTOM PROCEDURES
SIMPLIFIED WIRING SYSTEM (SWS)54B-209
SUNROOF
GENERAL DESCRIPTION CONCERNING THE SUNROOFM1549021200223
Refer to circuit diagrams GROUP-90
Refer to configuration diagrams GROUP-80The following ECU affects the functions and control
of the sunroof.
Sunroof timer function
The ETACS-ECU enables opening and closing of the sunroof
for 30 seconds after the ignition is switched off.
During this timed operation, if the driver's door or passenger’s
door is opened, the sunroof timer function is deactivated from
that moment. FUNCTION CONTROL ECU
Sunroof timer function ETACS-ECU, sunroof motor assembly

SYMPTOM PROCEDURES
SIMPLIFIED WIRING SYSTEM (SWS)54B-210
INSPECTION PROCEDURE F-1: Sunroof: Sunroof does not operate.
.
CIRCUIT OPERATION
The sunroof motor assembly is energized
through fusible link (5) by the battery.
When the ignition switch (IG2) signal is on, the
sunroof motor assembly is ready to operate.
.
TROUBLESHOOTING HINTS
Refer to circuit diagrams GROUP-90
Refer to configuration diagrams GROUP-80
The sunroof switch may be defective
The sunroof motor assembly may be defective
The wiring harness or connectors may have
loose, corroded, or damaged terminals, or termi-
nals pushed back in the connector

SYMPTOM PROCEDURES
SIMPLIFIED WIRING SYSTEM (SWS)54B-213
STEP 4. Check the ignition switch (IG2) circuit to the
sunroof motor assembly. Measure the voltage at sunroof
motor assembly connector D-04.
(1) Disconnect sunroof motor assembly connector D-04 and
measure the voltage available at the wiring harness side of
the connector.
(2) Turn the ignition switch to the "ON" position.
(3) Measure the voltage between terminal 2 and ground.
The voltage should measure approximately 12 volts
(battery positive voltage).
Q: Is the measured voltage approximately 12 volts (battery
positive voltage)?
YES : Go to Step 6.
NO : Go to Step 5.
STEP 5. Check the wiring harness between sunroof motor
assembly connector D-04 (terminal 2) and ignition switch
(IG2).
