AC temperature sensor MITSUBISHI 380 2005 Workshop Manual

INSTRUMENT PANEL ASSEMBLY
INTERIOR52A-6
6. RADIO AND CD PLAYER,
ASSEMBLY
7. RADIO, CD PLAYER AND CD
CHANGER ASSEMBLY
8. CONSOLE METER HOOD
11. MULTI-CENTER DISPLAY
ASSEMBLY
12. INSTRUMENT DIGITAL CLOCK
ASSEMBLY
13. CENTER CONSOLE ASSEMBLY
14. INSTURMENT PANEL GARNISH
15. COMBINATION METER
ASSEMBLY
FRONT PILLAR TRIM (REFER TO
P.52A-11.)
16. FRONT SPEAKER GARNISH
17. TWEETER
18. INSTRUMENT PANEL SIDE
COVER
19. INSTRUMETN PANEL SIDE AIR
OUTLET
AIR BAG MODULE ASSEMBLY
(DRIVER’S SIDE) (REFER TO
GROUP 52B, AIR BAG MODULE
AND CLOCK SPRING P.52B-237.)
STEERING WHEEL ASSEMBLY
(REFER TO GROUP 37,
STEERING WHEEL P.37-23.)
20. STEERING COLUMN COVERREMOVAL STEPS (Continued)
<>CLOCK SPRING CONNECTOR
<>COLUMN SWITHC CONNECTOR
CLOCK SPRING AND COLUMN
SWITCH ASSEMBLY (REFER TO
GROUP 37, STEERING SHAFT
P.37-25.)
21. INTERIOR TEMPERATURE
SENSOR (GROUP 55B,
SENSORS 55-160.)
22. INSTRUMENT PANEL FRONT
END GARNISH
23. PHOTO SENSOR (GROUP 55B,
SENSORS 55-160.) AND
SECURITY LED.
FLOOR CONSOLE ASSEMBLY
(REFER TO P.52A-10.)
COWL SIDE TRIM (REFER TO
P.52A-11.)
<>AIR BAG MODULE CONNECTOR
(PASSENGER’S SIDE) (REFER
TO GROUP 52B, AIR BAG
MODULE AND CLOCK SPRING
P.52B-237.)
25. INSTRUMENT PANEL ASSEMBLYREMOVAL STEPS (Continued)

ENGINE COMPARTMENT
CONFIGURATION DIAGRAMS80-5
A-22 (2-B) FOG LAMP (LH)
A-23 (2-Y) FRONT IMPACT SENSOR (LH)
A-24 (3-B) RADIATOR AND CONDENSER FAN
CONTROLLER MODULE
A-25 (2-BR) AMBIENT TEMPERATURE SENSOR
A-26 (2-B) HOOD SECURITY SWITCH
A-27 (2-Y) FRONT IMPACT SENSOR (RH)
A-28 (2-B) FOG LAMP (RH)
A-29 (2) WINDSHIELD WASHER MOTORA-30 (3-B) A/C PRESSURE SENSOR
A-32 (6) HEADLAMP COMBINATION (RH)
A-34 (2) FRONT TURN SIGNAL LAMP (RH)
A-35 (2) SIDE TURN SIGNAL LAMP (RH)
A-36 (1-B) HORN (LOW)
A-37 (1-B) HORN (HIGH)
A-38 (2) CONDENSOR FAN CONNECTION
TO CONTROLLER MODULE

ENGINE AND TRANSMISSION
CONFIGURATION DIAGRAMS80-8
B-101 (3-GR) IGNITION COIL 1
B-102 (3-GR) IGNITION COIL 3
B-103 (3-GR) IGNITION COIL 5
B-104 (2-B) ENGINE COOLANT TEMPERATURE
SENSOR
B-106 (3-B) CAMSHAFT POSITION SENSORB-107 (3-GR) OUTPUT SHAFT SPEED SENSOR
B-108 (10-GR) A/T CONTROL SOLENOID VALVE
ASSEMBLY
B-109 (3-B) INPUT SHAFT SPEED SENSOR
B-110 (10-B) TRANSMISSION INHIBITOR
(RANGE) SWITCH

DASH PANEL
CONFIGURATION DIAGRAMS80-13
C-115 (2) BLOWER MOTOR
C-121 (28-Y) SRS-ECU (INSTRUMENT PANEL
HARNESS)
C-123 (2) INTERIOR TEMPERATURE SENSOR
C-125 (16-B) DATA LINK CONNECTORC-126 (2) AIR THERMO SENSOR
C-128 (6) FOG LAMP SWITCH
C-129 (2-B) TWEETER SPEAKER (LH)
C-131 (6-GR) TCL SWITCH

HEATER, AIR CONDITIONING AND VENTILATION55-2
AMBIENT TEMPERATURE
SENSOR. . . . . . . . . . . . . . . . . . . . . . .55-162
REMOVAL AND INSTALLATION . . . . . . . . 55-162
INSPECTION . . . . . . . . . . . . . . . . . . . . . . . 55-163
COMPRESSOR ASSEMBLY AND
DRIVE BELT . . . . . . . . . . . . . . . . . . .55-164
REMOVAL AND INSTALLATION . . . . . . . . 55-164
INSPECTION . . . . . . . . . . . . . . . . . . . . . . . 55-166
AIR GAP CHECK . . . . . . . . . . . . . . . . . . . . 55-166
CONDENSER AND CONDENSER
FAN . . . . . . . . . . . . . . . . . . . . . . . . . .55-167
REMOVAL AND INSTALLATION . . . . . . . . 55-167
INSPECTION . . . . . . . . . . . . . . . . . . . . . . . 55-168
DRYER REPLACEMENT . . . . . . . . . . . . . . 55-168
REFRIGERANT LINE . . . . . . . . . . . . .55-170
REMOVAL AND INSTALLATION . . . . . . . . 55-170
O-RING AND PIPE INSTALLATION . . . . . . 55-172
DUCTS . . . . . . . . . . . . . . . . . . . . . . . .55-175
REMOVAL AND INSTALLATION . . . . . . . . 55-175
VENTILATORS . . . . . . . . . . . . . . . . . .55-177
REMOVAL AND INSTALLATION . . . . . . . . 55-177
SPECIFICATIONS . . . . . . . . . . . . . . .55-178
FASTENER TIGHTENING
SPECIFICATIONS. . . . . . . . . . . . . . . . . . . . 55-178
GENERAL SPECIFICATIONS . . . . . . . . . . 55-178
SERVICE SPECIFICATIONS . . . . . . . . . . . 55-178
LUBRICANTS . . . . . . . . . . . . . . . . . . . . . . . 55-178

GENERAL DESCRIPTION
HEATER, AIR CONDITIONING AND VENTILATION55-4
OPERATION
.
CONDENSER FAN AND RADIATOR FAN
CONTROL
The ECU judges the required revolution speed of
radiator fan motor and condenser fan motor using
the input signals transmitted from A/C switch, output
shaft speed sensor and engine coolant temperature
sensor. The ECU activates the fan control relays to
drive the radiator fan motor and condenser fan
motor.
.
COMPRESSOR CONTROL
When operating the air conditioning switch
The air thermo sensor, which senses the temper-
ature of the air flowing out of the evaporator,
deactivates the compressor at 3
C (37.4F) or
below.
The dual pressure switch turns OFF when the
refrigerant pressure becomes excessively high or
low, thus protecting the compressor circuit (See
Table below).
When the air thermo sensor is activated, and the
ignition switch, blower switch, and air condition-
ing switch are ON, the A/C compressor clutch
relay is energized.
When operating the mode selection dial
The air conditioning will work when the mode
selection dial is set to the "Defroster" or
"Defroster/foot" position, or the temperature con-
trol dial is set to the "MAX A/C" position. In other
dial positions, when the air conditioning switch is
turned on, the air conditioning will work.
A/C Compressor Clutch Relay ON Conditions
Ignition switch (IG2) ONNOTE: A/C compressor clutch relay is
de-energized when any one switch, sensor
or control unit shown on the left turns off.
NOTE: The components marked by
*
communicate with the ECU. If the air thermo
sensor detects a temperature of 3
C
(37.4
F), the A/C-ECU will turn off the A/C
compressor clutch relay. Blower switch ON
Air conditioning switch, mode selection dial
defroster, defroster/foot position or temperature
control MAX A/CON
Air thermo sensor*
Pressure detected
by A/C pressure
sensor2940 kPa or less (If the
refrigerant pressure exceeds
2940 kPa, A/C compressor
clutch relay is not ON
condition until the refrigerant
pressure has been measured
up to 2350 kPa or less.)ON
190 kPa or more (If the
refrigerant pressure falls short
of 190 kPa, A/C compressor
clutch relay is not ON
condition until the refrigerant
pressure has been measured
up to 220 kPa or more.)
A/C compressor clutch relay driving transistor (within
ecu)ON

AUTO A/C DIAGNOSIS
HEATER, AIR CONDITIONING AND VENTILATION55-9
DIAGNOSTIC TROUBLE CODE CHART M1554004900214
During diagnosis, a DTC code associated with
other system may be set when the ignition switch
is turned on with connector(s) disconnected. On
completion of repairs, confirm all systems for
DTC code(s). If DTC code(s) are set, erase them
all.
DIAGNOSTIC
TROUBLE CODE
NO.DIAGNOSTIC ITEM REFERENCE
PA G E
B1001 Interior temperature sensor system (short circuit)
P.55-10
B1002 Interior temperature sensor system (open circuit)
P.55-10
B1011 Ambient air temperature sensor system (short circuit)
P.55-16
B1012 Ambient air temperature sensor system (open circuit)
P.55-16
B1021 Air thermo sensor system (short circuit)
P.55-22
B1022 Air thermo sensor system (open circuit)
P.55-22
B1041 Air mixing damper control motor and potentiometer (potentiometer
system shorted to its power supply)P.55-28
B1042 Air mixing damper control motor and potentiometer (potentiometer
system shorted to its ground)P.55-28
B1045 Air mixing damper control motor and potentiometer (activating
system failure)P.55-35
B1061 Mode selection damper control motor and potentiometer
(potentiometer system shorted to its power supply)P.55-41
B1062 Mode selection damper control motor and potentiometer
(potentiometer system shorted to its ground)P.55-41
B1065 Mode selection damper control motor and potentiometer (activating
system failure)P.55-48
U1073 Bus off
P.55-54
U1100
Electronic control unit time-out (related to engine)P.55-56
U 1111 M u l t i - c e n t e r d i s p l a y u n i t ( m i d d l e g r a d e t y p e ) t i m e - o u t
P.55-60
U1120 Failure information on Electronic control unit (related to engine)
P.55-64

AUTO A/C DIAGNOSIS
HEATER, AIR CONDITIONING AND VENTILATION55-10
DIAGNOSTIC TROUBLE CODE PROCEDURES
DTC B1001, B1002: Interior Temperature Sensor System.
DTC SET CONDITION
DTC B1001 is set if there is a short circuit in the
interior temperature sensor input circuit.
DTC B1002 is set if there is a defective connector
connection, or if there is an open circuit in the
harness.
.
TECHNICAL DESCRIPTION (COMMENT)
Current trouble
The A/C-ECU, the interior air temperature sensor,
or connector(s) or wiring between the two may be
defective.Past trouble
If DTC B1001 or B1002 is stored as a past trou-
ble, carry out diagnosis with particular emphasis
on wiring and connector(s) between the A/C-ECU
and the interior air temperature sensor. If the con-
nectors and wiring are normal, and obviously the
ECU is the cause of the trouble, replace the ECU.
If in doubt, do not replace the ECU.
.
TROUBLESHOOTING HINT
Malfunction of connector.
Malfunction of the harness.
Malfunction of the interior temperature sensor.
Malfunction of the A/C-ECU.
Refer to component locations GROUP-70
Refer to configuration diagrams GROUP-80
Refer to circuit diagrams GROUP-90
DIAGNOSIS
Required Special Tool:
: Diagnostic Tool (MUT-III Sub Assembly)
MB991824: Vehicle Communication Interface (V.C.I.)
MB991827: MUT-III USB Cable
MB991910: MUT-III Main Harness A (Vehicles with CAN
communication system)

AUTO A/C DIAGNOSIS
HEATER, AIR CONDITIONING AND VENTILATION55-12
STEP 3. Using diagnostic tool , check data list item 59:
Inside temperature sensor.
To prevent damage to diagnostic tool , always turn the
ignition switch to the "LOCK" (OFF) position before con-
necting or disconnecting diagnostic tool .
(1) Connect diagnostic tool to the data link connector.
(2) Start the engine.
(3) Set diagnostic tool to the data reading mode for item 59:
Inside temperature sensor.
Check that the interior temperature matches the dis-
played value on the diagnostic tool.
NOTE: When this DTC is set and the system is in fail-safe
status, the value of service data displays 25
C.
(4) Turn the ignition switch to the "LOCK" (OFF) position.
Q: Does the interior temperature match the displayed value
on the diagnostic tool?
YES : Replace the A/C-ECU. Then go to Step 7.
NO : Go to Step 4.

AUTO A/C DIAGNOSIS
HEATER, AIR CONDITIONING AND VENTILATION55-13
STEP 4. Check A/C-ECU connector C-15, C-16 and interior
temperature sensor connector C-123 for loose, corroded
or damaged terminals, or terminals pushed back in the
connector.
Q: Are A/C-ECU connectors C-15, C-16 and interior
temperature sensor connector C-123 in good condition?
YES : Go to Step 5.
NO : Repair or replace the connector. Refer to GROUP
00E, Harness Connector Inspection P.00E-2. Then go
to Step 7.
