MITSUBISHI 380 2005 Workshop Manual FRONT SEAT ASSEMBLY
INTERIOR52A-21
FRONT SEAT ASSEMBLY
REMOVAL AND INSTALLATIONM1522001300560
Before removing the front seat assembly, refer to GROUP 52B, Service Precautions
P.52B-16 and Air Bag Mod

Page 525 of 1500

MITSUBISHI 380 2005 Workshop Manual FRONT SEAT ASSEMBLY
INTERIOR52A-36
DISASSEMBLY STEPS
<<A>>HEADREST
1. HINGE COVER
2. INNER SEAT BELT
3. MANUAL RECLINER ADJUSTER
(VEHICLES WITH MANUAL
RECLINER)
4. SIDE SHIELD COVER
5. POWER RECLINE

Page 530 of 1500
FRONT SEAT ASSEMBLY
INTERIOR52A-41
REMOVAL STEPS
<>HEADREST
1. HINGE COVER
2. INNER SEAT BELT
3. MANUAL RECLINER ADJUSTER
HANDLE (VEHICLES WITH
MANUAL RECLINER)
4. SIDE SHIELD COVER
5. FORE AFT ADJUSTER KNOB
6. MAIN POWER SWITCH
7. SIDE SHIELD MOUNT BRACKET
8. FRONT SEAT BACK ASSEMBLY
9. CUSHION ASSEMBLY
10. SEAT CUSHION COVER
11. SEAT CUSHION PAD
12. SEAT CUSHION FRAME13. SEATBACK PANEL
14. SIDE AIRBAG MODULE
<>
15. HEADREST GUIDE
16 MANUAL LUMBAR ADJUSTER
HANDLE
<>
17. SEATBACK COVER
18. SEATBACK PAD
19. LUMBAR ASSEMBLY
20. RECLINER LEVER RETURN
SPRING
21. RECLINER LEVER SHAFT
22. SEAT BACK FRAME
23. SEAT POWER HARNESS
24. SEAT SLIDE ADJUSTERREMOVAL STEPS (Continued)

Page 531 of 1500
FRONT SEAT ASSEMBLY
INTERIOR52A-42
REMOVAL SERVICE POINT
.
<> HEADREST REMOVAL
1. Raise the head restraint fully.
2. Insert a probe that is suited to fit into the hole (1) in the right
hand head restraint sleeve (2) as illustrated in the figure
below.
3. Whilst the probe is inserted slightly, apply slight pressure on
the head restraint. Apply and hold pressure upwards.
4. To remove the head restraint, you must depress the sleeve
height adjuster lock (3) on the left-hand head restraint
sleeve as illustrated below.
<> HEADREST SLEEVE REMOVAL
1. To reveal upper portion of the seat back frame or
active head restraint frame (1) as shown in figure
below, push down on the surrounding seat cover.
2. By using a small flat blade screwdriver, depress
the sleeve locking tab (2), and remove the head
restaint sleeve (3) in upwards movement from the
frame as illustrated below.
3. If required, repeat process for the remaining
sleeve.
<> SEAT BACK PANEL REMOVAL
AND FITMENT
1. Move front seat to the most forward position.
2. Pull the lower edge of seat panel towards you, as
shown below (1).
3. Slide the panel downwards (2) as the top section
is held in by 2 locating hooks (lugs).
4. Upon fitment, be sure to firstly locate the top 2
lugs into position (2), as shown above.
5. Approximately square up panel to the seat, so by
doing this you will be able to locate the bottom 2
clips to press in the panel (1), as shown above.
