MITSUBISHI LANCER 2015 8.G Owners Manual

Indicator light, warning light, an
d information screen display list
5-132 Features and controls
5
N00557900024
When there is information to be
announced, such as light reminders
, the tone sounds and the screen
switches to the displays sho
wn below. Refer
to the appropriate page and take the necessary measures.When the cause of the warning display is eliminated, the warning display goes out automatically. Refer to “Warning display list (With ignition switch in the “OFF” position)” on page 5-132. Refer to “Warning display list (With ignition
switch in the “ON” position)” on page 5-135.
Refer to “Other interrupt displays (With ignition switch in the “ON” position)” on page 5-141.
N00558000165
Information screen display list
NOTE
 In the following cases, a warning may be displayed on the inform
ation screen and the buzzer may
sound for a few seconds, at tim
es.
This is caused by the system picking up interference such as stro
ng electromagnetic waves or nois
e, and is not a functional pro
blem.
• An extremely strong electromagnetic wave is received from a source
such as an illegal radio set,
a spark from a wire, or a rad
ar station.
• Abnormal voltage or a static electricity discharge is generate
d by the operation of installed electronics (including after-mar
ket parts).
If the warning display has occurred a number of times, take your vehicle to an authorized Mitsubishi Motors dealer or a repair
facility of your choice and
have the system checked.
Warning display list (With ignition switch in the “OFF” position)
Screen type 1
Screen type 2
Cause
Do this (Reference)
 You have forgotten to remove the key from the ignition switch.
 Remove the key. Refer to “Key reminder system” on page 5-36.
BK0210300US.book
132 ページ ２０１４年４月８日　火曜日　午前１０時４６分

Indicator light, warning light, an
d information screen display list Features and controls 5-133
5
 You have forgotten to turn off the lights.
Refer to “Light auto-cutout function (headlights and other lights)” on page 5-149.
 The theft-alarm system is operating.
Refer to “Theft-alarm system” on page 5-42.
 After turning off the engine, an attempt was made to open the driver’s door with the ignition switch in any position other than “LOCK” (PUSH OFF).
 Turn the ignition switch to the “LOCK” (PUSH OFF) position. Refer to “Ignition switch return reminder system” on page 5-37.
 An attempt was made to lock all the doors and the trunk lid with the ignition switch in any position other than “LOCK” (PUSH OFF).
 Turn the ignition switch to the “LOCK” (PUSH OFF) position.Refer to “Ignition switch turn-off reminder system” on page 5-20.
Screen type 1
Screen type 2
Cause
Do this (Reference)
BK0210300US.book
133 ページ ２０１４年４月８日　火曜日　午前１０時４６分

Indicator light, warning light, an
d information screen display list
5-134 Features and controls
5
 There is a fault in the F.A.S.T.-key.
Refer to “F.A.S.T.-key” on page 5-12.
Screen type 1
Screen type 2
Cause
Do this (Reference)
BK0210300US.book
134 ページ ２０１４年４月８日　火曜日　午前１０時４６分

Indicator light, warning light, an
d information screen display list Features and controls 5-135
5
N00558101323
Warning display list (With ignition switch in the “ON” position)
Screen type1
Screen type 2
Cause
Do this (Reference)
 There is a fault in the electric power steering system (EPS).
 Have the vehicle inspected by an autho- rized Mitsubishi Motors dealer or a repair facility of your choice as soon as possible. Refer to “Electric power steering sys- tem (EPS)” on page 5-97.
BK0210300US.book
135 ページ ２０１４年４月８日　火曜日　午前１０時４６分

Indicator light, warning light, an
d information screen display list
5-136 Features and controls
5
 There is a fault in the F.A.S.T.-key.
Refer to “F.A.S.T.-key” on page 5-12.
 Immobilizer is registered.
Refer to “Electronic immobilizer (Anti- theft starting system)” on page 5-4, 5-28.
Screen type1
Screen type 2
Cause
Do this (Reference)
BK0210300US.book
136 ページ ２０１４年４月８日　火曜日　午前１０時４６分

Indicator light, warning light, an
d information screen display list Features and controls 5-137
5
 The brake fluid level is low.  There is a fault in the brake system.
 Park the vehicle in a safe place and con- tact an authorized Mitsubishi Motors dealer or a repair facility of your choice for assistance. Refer to “Brake warning display” on page 5-145.
 There is a fault in the Anti-lock braking system.
 Avoid sudden braking and high-speed driving, park the vehicle in a safe place, and take corrective measures. Refer to “Anti-lock braking system warning light/display” on page 5-92.
 The tire pressure in one of the tires (except spare tire) is low.
 Refer to “Tire Pressure Monitoring Sys- tem” on page 5-102.
 There is a fault in the Tire Pressure Monitoring System.
 Refer to “Tire Pressure Monitoring Sys- tem” on page 5-102.
 One of the doors or the trunk lid is not completely closed. The open door or open trunk lid is dis- played.
 Close the door or trunk lid. Refer to “Door ajar warning display (With ignition switch in the “OFF” position)” on page 5-114.
Screen type1
Screen type 2
Cause
Do this (Reference)
BK0210300US.book
137 ページ ２０１４年４月８日　火曜日　午前１０時４６分

Indicator light, warning light, an
d information screen display list
5-138 Features and controls
5
 The engine hood is open.
Close the engine hood. Refer to “Engine hood” on page 9-3.
 The engine is overheated.
Park the vehicle in a safe place and take corrective measures.Refer to “Engine overheating” on page 8-4.
 The continuously variable transmission (CVT) fluid or the Twin Clutch SST fluid temperature is increased.
 Park the vehicle in a safe place and take corrective measures.Refer to “Continuously variable trans- mission (CVT)” on page 5-61. Refer to “Twin Clutch SST” on page 5-70.
 The seat belt is not fastened when the ignition switch is in the “ON” position.
 Fasten your seat belt properly. Refer to “Driver’s seat belt reminder/warning light and display” on page 4-11.
 There is a fault in the fuel system.
Contact an authorized Mitsubishi Motors dealer or a repair facility of your choice to have the system checked.
Screen type1
Screen type 2
Cause
Do this (Reference)
BK0210300US.book
138 ページ ２０１４年４月８日　火曜日　午前１０時４６分

Indicator light, warning light, an
d information screen display list Features and controls 5-139
5
 The vehicle is being driven with the parking brake still applied.
 Release the parking brake. Refer to “Brake warning display” on page 5-145.
 There is a fault in the engine oil circula- tion system.
 Park your vehicle in a safe place as soon as possible and contact an autho-rized Mitsubishi Motors dealer or a repair facility of your choice to have the system checked.Refer to “Oil pressure warning display” on page 5-146.
 There is a fault in the charging system.
Park your vehicle in a safe place as soon as possible and contact an autho-rized Mitsubishi Motors dealer or a repair facility of your choice for assis- tance.Refer to “Charging system warning dis-play” on page 5-146.
 There is a fault in the SRS airbag or the seat belt pre-tensioner system.
 Contact an authorized Mitsubishi Motors dealer or a repair facility of your choice to have the system checked, immediately. Refer to “SRS warning light/display” on page 4-27.
Screen type1
Screen type 2
Cause
Do this (Reference)
BK0210300US.book
139 ページ ２０１４年４月８日　火曜日　午前１０時４６分

Indicator light, warning light, an
d information screen display list
5-140 Features and controls
5
 There is a fault in the Active Stability Control (ASC).
 Contact an authorized Mitsubishi Motors dealer or a repair facility of your choice to have the system checked.Refer to “Active Stability Control (ASC)” on page 5-94.
 There is a fault in the ACD (Active Center Differential system). There is a fault in the electronically controlled 4WD system.
 Contact an authorized Mitsubishi Motors dealer or a repair facility of your choice to have the system checked. Refer to “ACD (Active Center Differ- ential system)” on page 5-82. Contact an authorized Mitsubishi Motors dealer or a repair facility of your choice to have the system checked.Refer to “Electronically controlled 4WD system” on page 5-84.
 There is a fault in the CVT.  A safety device in the Twin Clutch SST has been activated due to a possible malfunction in the Twin Clutch SST or in the engine electronic control module.
 Contact an authorized Mitsubishi Motors dealer or a repair facility of your choice to have the system checked. Refer to “Continuously variable trans- mission (CVT)” on page 5-61.Refer to “Twin Clutch SST” on page 5-70.
 The electronically controlled 4WD sys- tem is hot.
 Refer to “Electronically controlled 4WD system” on page 5-84.
Screen type1
Screen type 2
Cause
Do this (Reference)
BK0210300US.book
140 ページ ２０１４年４月８日　火曜日　午前１０時４６分

Indicator light, warning light, an
d information screen display list Features and controls 5-141
5
N00558200239
The operation status of each system is displayed on the information screen. For further details, refer to the appropriate page
for each system.
 The fuel is running low.
Refuel as soon as possible. Refer to “Fuel remaining display screen” on page 5-121.
 The outside temperature is 37 °F (3 °C)
 Be careful driving on frozen ground.  The ground may be frozen even when this warning is not displayed, so drive carefully.
 The timing chain may be worn.
Contact an authorized Mitsubishi Motors dealer or a repair facility of your choice to have the system checked.
Other interrupt displays (With igniti
on switch in the “ON” position)
Screen type1
Screen type 2
Cause
Do this (Reference)
