MITSUBISHI LANCER 2015 8.G Owners Manual

Multi-information display 5-122 Features and controls
5
1. Shows the time until the next periodic inspection.
2. This informs you that a periodic inspec- tion is due. Contact an authorized Mit- subishi Motors dealer or a repair facility of your choice to have the systemchecked. At that time, when the ignition switch is switched from the “OFF” position to the “ON” position, the warning display is dis- played for a few seconds on the informa-tion screen.Type 1 Type 2 3. After your vehicle is inspected at an authorized Mitsubishi Motors dealer, itdisplays the time until the next periodicinspection.
The “---” display can be reset while the igni- tion switch is in the “OFF” position. Whenthe display is reset, the time until the next periodic inspection is displayed and the warn- ing display is no longer displayed when theignition switch is switched from the “OFF” position to the “ON” position. 1. When you lightly press the multi-informa- tion meter switch, the information screen changes to the service reminder displayscreen.
 For vehicles with Twin Clutch SST, the ser- vice reminder time can be modified by an authorized Mitsubishi Motors dealer, to adjust for severe usage, etc. Refer to “Severe maintenance schedule” in your vehicle’sWarranty and Maintenance Manual. For fur- ther information, please contact your autho- rized Mitsubishi Motors dealer.NOTE
 Shows the distance in uni
ts of 100 miles (100
km) and the time in units of 1 month.NOTE
Type 1 Type 2
To r e s e t Type 1 Ty p e 2
BK0210300US.book
122 ページ ２０１４年４月８日　火曜日　午前１０時４６分

Multi-information display
Features and controls 5-123
5
2. Press and hold the multi-information meter switch (for about 2 seconds or more) to display “ ” and make it flash. (If there is no operation for about 10 sec- onds with this indicator flashing, the dis-play returns to the previous screen.) 3. With this indicator flashing, if you lightly press the multi-information meter switch,the screen switches from “---” to “CLEAR”. After that, the time until the next periodic inspection is shown.
N00555700145
If any of the doors or the trunk lid is not com- pletely closed, this displays the open door or trunk lid.If the speed increases to about 5 mph (8 km/h) or higher with a door ajar, a buzzer will
sound 4 times to inform you that a door is ajar. The buzzer will not sound if only the trunk lid is open. Type 1 Type 2
N00556801153
1. Park your vehicle in a safe place.
Type 1 Ty p e 2
CAUTION The customer is responsible for making sure that regular inspections and maintenance and periodic inspections and maintenance are performed. Inspections and maintenance must be per-formed to prevent accidents and malfunc- tions.NOTE
 The “---” display cannot be reset while the ignition switch is in the “ON” position.  When “---” is displayed, after a certain dis- tance and a certain period of time, the dis- play is reset and the time until the next periodic inspection is displayed.  If you accidentally reset the display, consult an authorized Mitsubishi Motors dealer forassistance.
Door ajar warning display (With ignition switch in the “ON” position)
CAUTION Always make sure that the warning display goes out before beginning to drive.
Changing the function settings (With ignition switch in the “ON” position)
BK0210300US.book
123 ページ ２０１４年４月８日　火曜日　午前１０時４６分

Multi-information display 5-124 Features and controls
5
Fully apply the parking brake and move the shift lever into the “N” position (man- ual transaxle), the selector lever {continu- ously variable transmission (CVT)} or thegearshift lever (Twin Clutch SST) into the “P” position. 2. When you lightly press the multi-informa-tion meter switch, the information screen changes to the function setting screen. Refer to “Information screen (With igni-tion switch in the “ON” position)” onpage 5-116.
3. Press and hold the multi-information meter switch (for about 2 seconds or more) to switch from the setting mode screen to the menu screen.
4. Select the item to change on the menu screen and change to the desired setting. For further details on the operation meth- ods, refer to the following sections. Refer to “Changing the reset mode for average fuel consumption and averagespeed” on page 5-125. Refer to “Changing the fuel consumption display unit” on page 5-125.Refer to “Changing the temperature unit”on page 5-126. Refer to “Changing the display language” on page 5-127.Refer to “Operation sound setting” on page 5-127. Refer to “Changing the amount of timeuntil “REST REMINDER” is displayed” on page 5-128. Refer to “Changing the turn signal sound”on page 5-129. Refer to “Changing the momentary fuel consumption display (Type 2)” on page5-129. Refer to “Returning to the factory set- tings” on page 5-129.
CAUTION For safety, stop the vehicle before operating. While driving, even if you operate the multi- information meter switch, the function set-ting screen is not displayed.
Type 1 Type 2
NOTE
 To return the menu screen to the function set- ting screen, press and hold the multi-infor- mation meter switch (for about 2 seconds or more).  If no operations are made within about 15 seconds of the menu screen being displayed,the display returns to the function setting screen.Type 1 Type 2
BK0210300US.book
124 ページ ２０１４年４月８日　火曜日　午前１０時４６分

Multi-information display
Features and controls 5-125
5
N00557000184
You can change the mode condition for the average fuel consumption and average speed display to “Auto reset” or “Manual reset”. 1. Press and hold the multi-information meter switch (for about 2 seconds ormore) to switch from the setting modescreen to the menu screen. Refer to “Changing the function settings (With ignition switch in the “ON” posi-tion)” on page 5-123. 2. Lightly press the multi-information meter switch to select “AVG” (average fuel con-sumption and average speed setting).
3. Press and hold the multi-information meter switch (for about 2 seconds or more) to switch in sequence from A or 1 (Auto reset mode)
M, 2 or P (Manual
reset mode)
A or 1 (Auto reset mode).
The setting will change to the selected mode condition. • If you press and hold the multi-informa- tion meter switch when the average fuel consumption and average speed are dis- played, these calculations will be reset tozero. • When the ignition switch is turned to the “ON” position from the “ACC” or“LOCK” position, the mode setting changes automatically from manual to auto.Switching to auto occurs automatically. If switching to manual mode is done, however, the data from the last reset isdisplayed. • When the average fuel consumption and average speed are being displayed, if youhold down the multi-information meter switch, these calculations will be reset to zero.
• When the ignition switch has been set to the “ACC” or “LOCK” position for about 4 hours or more, the average fuel consumption display and the averagespeed display will automatically reset.
N00557100130
The fuel consumption display unit can bechanged. The distance, speed, and amountunits are also changed to match the selected fuel consumption unit. 1. Press and hold the multi-information meter switch (for about 2 seconds ormore) to change from the setting mode screen to the menu screen.
Changing the reset mode for aver- age fuel consumption and average speed Type 1 Type 2
Manual reset mode Auto reset mode
NOTE
 The average speed display and average fuel consumption display can be reset separately in both auto reset mode and manual resetmode.  The average speed display memories and average fuel consumption memories for auto reset mode and manual reset mode are erased if the battery is disconnected.  The initial (default) setting is “Auto reset mode”.
Changing the fuel consumption display unit
BK0210300US.book
125 ページ ２０１４年４月８日　火曜日　午前１０時４６分

Multi-information display 5-126 Features and controls
5
Refer to “Changing the function settings (With ignition switch in the “ON” posi- tion)” on page 5-123. 2. Lightly press the multi-information meterswitch to select “AVG UNIT” (fuel con- sumption display unit setting). 3. Press and hold the multi-information meter switch (for about 2 seconds or more) to display “AVG UNIT” (fuel con-sumption display unit setting). 4. Lightly press the multi-information meter switch to switch in sequence from km/L L/100 km
 mpg (US)
 mpg (UK)
 RETURN
 km/L.
5. Press and hold the multi-information meter switch (for about 2 seconds or more) to change the setting to the selectedunit.
The distance and speed units are also changed in the following combinations to match the selected fuel consumption unit.
N00557200102
The temperature display unit can be changed. 1. Press and hold the multi-information meter switch (for about 2 seconds ormore) to change from the setting modescreen to the menu screen. Refer to “Changing the function settings (With ignition switch in the “ON” posi-tion)” on page 5-123. 2. Lightly press the multi-information meter switch to select “ ” (temperature unit setting).
Ty p e 1 Type 2
NOTE
 The display units for the driving range, the average fuel consumption, the average speed and the momentary fuel consumption arechanged, but the units for the indicating nee- dle (speedometer), the odometer and the trip odometer will remain unchanged.  If the battery is disconnected, the memory of the unit setting is erased and is automaticallyset to {mpg (US) or L/100 km}.
Type 2
Type 1
Fuel econ-
omy
Distance(driving range)
Speed (average speed)
mpg (US) mile (s) mphmpg (UK) mile (s) mphkm /L km km /hL /100 km km km /hChanging the temperature unit
BK0210300US.book
126 ページ ２０１４年４月８日　火曜日　午前１０時４６分

Multi-information display
Features and controls 5-127
5
3. Press and hold the multi-information meter switch (for about 2 seconds or more) to change in sequence from °F

°C
 °F.
The setting is changed to the selected tem- perature unit.
N00557300145
The language of the multi-information dis- play can be changed.
1. Press and hold the multi-information meter switch (for about 2 seconds or more) to change from the setting mode screen to the menu screen.Refer to “Changing the function settings (With ignition switch in the “ON” posi- tion)” on page 5-123.2. Lightly press the multi-information meter switch to select “LANGUAGE” (lan- guage setting). 3. Press and hold the multi-information meter switch (for about 2 seconds ormore) to display “LANGUAGE” (lan- guage setting). 4. Lightly press the multi-information meterswitch to select the desired language.
5. Press and hold the multi-information meter switch (for about 2 seconds or more) to change the setting to the selected language.
N00557400104
You can turn off the operation sounds of themulti-information meter switch and rheostat meter illumination button. 1. Press and hold the multi-information meter switch (for about 2 seconds ormore) to switch from the setting mode screen to the menu screen. Refer to “Changing the function settings(With ignition switch in the “ON” posi- tion)” on page 5-123. 2. Lightly press the multi-information meter switch to select “ ” (operation sound setting).
NOTE
 If the battery is disconnected, the memory of the unit setting is erased and is automatically set to °F (°C).
Changing the display language Type 1 Type 2
Type 1 Type 2
NOTE
 If the battery is disconnected, the memory of the language setting is erased and is automat- ically set to ENGLISH.  If “---” is selected in the language setting, a warning message is not displayed when there is a warning display or interrupt display.
Operation sound setting
BK0210300US.book
127 ページ ２０１４年４月８日　火曜日　午前１０時４６分

Multi-information display 5-128 Features and controls
5
3. Press and hold the multi-information meter switch (for about 2 seconds or more) to switch in sequence from ON(operation sound on)
 OFF (operation
sound off)
 ON (operation sound on).
The setting is changed to the selected con-dition.
N00557500121
The amount of time until the display appears can be changed. 1. Press and hold the multi-information meter switch (for about 2 seconds ormore) to switch from the setting mode screen to the menu screen. Refer to “Changing the function settings(With ignition switch in the “ON” posi-tion)” on page 5-123. 2. Lightly press the multi-information meter switch to select “ALARM” (rest time set-ting).
3. Press and hold the multi-information meter switch (for about 2 seconds or more) to display “ALARM” (rest time setting). 4. Lightly press the multi-information meter switch to select the amount of time untilthe display appears.5. Press and hold the multi-information meter switch (for about 2 seconds or more) to change the setting to the selectedtime.
NOTE
 If the battery is disconnected, the memory of the operation sound setting is erased and isautomatically set to “ON” (operation sound on).  The operation sound setting only deactivates the operation sound of the multi-information meter switch and rheostat meter illuminationbutton. The warning display and other sounds cannot be deactivated.Type 1 Type 2
Changing the amount of time until “REST REMINDER” is displayed Ty p e 1 Type 2
NOTE
 If the battery is disconnected, the memory of the unit setting is erased and is automatically set to the “OFF”.  The drive time is reset when the ignition switch is in the “OFF” position.
Type 1
Ty p e 2
BK0210300US.book
128 ページ ２０１４年４月８日　火曜日　午前１０時４６分

Multi-information display
Features and controls 5-129
5
N00563500038
It is possible to change the turn signal sound. 1. Press and hold the multi-information meter switch for about 2 seconds or moreto switch from the setting mode screen to the menu screen. Refer to “Changing the function settings(With ignition switch in the “ON” posi- tion)” on page 5-123. 2. Lightly press the multi-information meter switch to select . (changing the turn signal sound)
3. Press and hold the multi-information meter switch for about 2 seconds or more to switch in sequence from 1 (turn signal sound 1)
 2 (turn signal sound 2)
 1
(turn signal sound 1). The setting changes to the selected turn signal sound.
N00563600013
It is possible to change the bar graph settingof the momentary fuel consumption display. 1. Press and hold the multi-information meter switch for about 2 seconds or more to switch from the setting mode screen tothe menu screen. Refer to “Changing the function settings (With ignition switch in the “ON” posi-tion)” on page 5-123. 2. Lightly press the multi-information meter switch to select . (changing the momentary fuel consumption display)
3. Press and hold the multi-information meter switch for about 2 seconds or more to switch in sequence from ON (with thegreen bar graph)
 OFF (without the
green bar graph)
 ON (with the green
bar graph).The setting changes to the selected bar graph setting.
N00557600148
All of the function settings can be returned to their factory settings. 1. Press and hold the multi-information meter switch (for about 2 seconds or more) to change from the setting modescreen to the menu screen. Refer to “Changing the function settings (With ignition switch in the “ON” posi-tion)” on page 5-123.
Changing the turn signal sound Type 1 Type 2
Changing the momentary fuel con- sumption display (Type 2)
Returning to the factory settings
BK0210300US.book
129 ページ ２０１４年４月８日　火曜日　午前１０時４６分

Multi-information display 5-130 Features and controls
5
2. Lightly press the multi-information meter switch to select “RESET” (return to the factory settings). 3. Press and hold the multi-information meter switch (for about 5 seconds or more), the buzzer sounds and all of thefunction settings are returned to the fac- tory settings.NOTE
 The factory settings are as follows. • Average fuel consumption and average speed reset mode: A (Auto reset) • Fuel consumption display unit: mpg (US) or (L/100 km) • Temperature unit: °F (Fahrenheit) or {°C (Centigrade)} • Display language: ENGLISHType 1 Type 2
• Cooperative language setting: A• Operation sounds: ON (Operation sound on) • “REST REMINDER” display: OFF • Turn signal sound: Turn signal sound 1• Momentary fuel consumption with the green bar graph (Type 2): ONNOTE
BK0210300US.book
130 ページ ２０１４年４月８日　火曜日　午前１０時４６分

Indicator light, warning light, an
d information screen display list Features and controls 5-131
5
N00557700035 N00557800238
Indicator light, warning light, and information screen display list Indicator and warning light list Type A Type B1- Position indicator
P.5-143
2- High beam indicator
P.5-143
3- Charging system warning light
 P.5-145
4- Turn signal indicator/hazard warning
light
P.5-143
5- Front fog light indicator (if so
equipped)
P.5-143
6- Anti-lock braking system warning light
 P.5-92
7- Tire pressure monitoring system warn-
ing light
P.5-103
8- Brake warning light
P.5-144
9- Cruise control indicator (if so
equipped)
P. 5 - 9 8
10- Seat belt reminder/warning light
 P. 4 - 1 1
11- Supplemental Restraint System (SRS)
warning light  P.4-27
12- ECO mode indicator (if so equipped)
 P.5-121
13- Engine malfunction indicator (“SER-
VICE ENGINE SOON” or “Check engine light”)
P.5-144
14- Active stability
control (ASC) OFF
indicator (if so equipped)
P.5-95
15- Active stability control (ASC) indicator
(if so equipped)
P. 5 - 9 5
16- Information screen display list
 P.5-132
