ENGINE – Alternator and Ignition System11-14
ALTERNATOR AND IGNITION SYSTEM
REMOVAL AND INSTALLATION
44 Nm 10 Nm
25 Nm
21 Nm
9 Nm 13 Nm
23 Nm
25 Nm 3 Nm
2
1
34
5 67
89
10
11
12
13 1415
16
Removal steps
1. Oil level gauge
2. O-ring
3. Oil level gauge guide
4. O-ring
5. Water pump pulley
6. Alternator brace
7. Alternator
8. Crankshaft pulley9. Center cover
10. Spark plug cable
11. Ignition coil
12. Spark plug
13. Breather hose
14. PCV hose
15. PCV valve
16. PCV valve gasket

ENGINE – Timing Belt11-15
TIMING BELT
REMOVAL AND INSTALLATION
1
2
3
4
5 67
8
9
1011
12 1314
1516
17 1819
20212223
24
2526
27
28 2930
31
32
9 Nm
9 Nm 49 Nm 11 N m
11 N m
19 Nm 3.5 Nm
30 Nm
45 Nm 49 Nm 11 8 N m
88 Nm
48 Nm 49 Nm 11 N m
24 Nm
24 Nm
54 Nm
Removal steps
1. Timing belt front upper cover
2. Timing belt front center cover
3. Rubber plug
4. Timing belt front lower cover
5. Power steering pump bracket
AL6. Timing belt
K7. Tensioner pulley
8. Tensioner arm
J9. Auto tensioner
10. Idler pulley
11. Crank angle sensor
BI12. Oil pump sprocket
CH13. Crankshaft sprocket bolt
D14. Crankshaft sprocket
15. Crankshaft sensing blade
16. Tensioner BEG17. Timing belt B
FF18. Counterbalance shaft sprocket
E19. Crankshaft spacer
G20. Crankshaft sprocket B
21. Crankshaft key
22. Oil filler cap
D23. Rocker cover
24. Rocker cover gasket A
25. Rocker cover gasket B
C26. Semi-circular packing
B27. Engine support bracket
HA28. Camshaft sprocket bolt
29. Camshaft sprocket
30. Timing belt rear right cover
31. Timing belt rear left upper cover
32. Timing belt rear left lower cover

ENGINE – Timing Belt11-16
REMOVAL SERVICE POINTS
ATIMING BELT REMOVAL
(1) If the timing belt is to be reused, chalk an arrow mark
on the back surface of the belt so that the belt can be
reinstalled in the same direction.
(2) Place the exhaust camshaft sprocket in a position where
the timing mark for No. 1 cylinder is positioned about
one tooth before the top dead center of the compression
stroke.
Caution
The camshaft sprocket on the exhaust side can turn
very easily because of the valve spring tension. Use
care not to allow your fingers to get caught by the
sprocket.
(3) Loosen the lock nut of the tensioner pulley, then remove
the timing belt.
BOIL PUMP SPROCKET REMOVAL
(1) Remove the plug on the left side of cylinder block.
(2) Insert a screwdriver (shank diameter 8 mm) to block the
counterbalance shaft.
(3) Remove the nut.
(4) Remove the oil pump sprocket.
CCRANKSHAFT BOLT LOOSENING
(1) Hold the drive plate with the special tool as shown.
(2) Remove the crankshaft bolt.
DCRANKSHAFT SPROCKET REMOVAL
If it is difficult to remove the sprocket, use the special tool.
Timing mark

ENGINE – Timing BeltENGINE – Timing Belt11-17
ETIMING BELT “B” REMOVAL
Make a mark on the back of the timing belt indicating the
direction of rotation so it may be reassembled in the same
direction if it is to be reused.
NOTE
(1) Water or oil on the belt shortens its life drastically, so
the removed timing belt, sprocket, and tensioner must
be free from oil and water. These parts should not be
washed. Replace parts if seriously contaminated.
(2) If there is oil or water on each part check front case
oil seals, camshaft oil seal and water pump for leaks.
FCOUNTERBALANCE SHAFT SPROCKET
REMOVAL
(1) Set the special tool as shown to prevent the
counterbalance shaft sprocket from turning together.
(2) Loosen the bolt and remove the sprocket.
GCRANKSHAFT SPROCKET “B” REMOVAL
If it is difficult to remove the sprocket, use the special tool.
HCAMSHAFT SPROCKET BOLT LOOSENING
Use a wrench to hold the hexagonal part of the camshaft,
and then remove the camshaft sprocket mounting bolt.
INSTALLATION SERVICE POINTS
ACAMSHAFT SPROCKET BOLT TIGHTENING
Using a wrench, hold the camshaft at its hexagon and tighten
the bolt to the specification.
6EN1322
MD998785

ENGINE – Timing Belt11-18
BENGINE SUPPORT BRACKET INSTALLATION
Coat the bolts illustrated with sealant before tightening.
Specified sealant: 3M
TM AAD Part No. 8672 or equivalent
CSEALANT APPLICATION TO SEMI-CIRCULAR
PACKING
Specified sealant: 3M
TM AAD Part No. 8672 or equivalent
10 mm
10 mm
Semi-
circular
packing
Cylinder head

ENGINE – Timing Belt11-19
DSEALANT APPLICATION TO ROCKER COVER
Apply sealant to the areas indicated in the illustration.
Specified sealant: 3M
TM AAD Part No. 8672 or equivalent
Apply sealantApply sealant
Apply sealant 10 mm
10 mm
10 mm
10 mm
Apply sealant
ESPACER INSTALLATION
Install the spacer with the chamfered end toward the oil seal.
FCOUNTERBALANCE SHAFT SPROCKET
INSTALLATION
(1) Install the counterbalance shaft sprocket and screw the
bolt.
(2) Install special tool MD998785 as shown in the illustration
to lock the counterbalance shaft.
(3) Tighten the bolt, and then remove the special tool.
Counter-
balance
shaft
Sharp
edge
MD998785

ENGINE – Timing Belt11-20
GTIMING BELT “B” INSTALLATION
(1) Align timing marks on the crankshaft sprocket “B” and
counterbalance shaft sprocket with the marks on the front
case respectively.
(2) Install the timing belt “B” on the crankshaft sprocket “B”
and counterbalance shaft sprocket. There should be no
slack on the tension side.
(3) Make sure that the relationship between the tensioner
pulley center and the bolt center is as shown in the
illustration.
(4) Move the tensioner “B” in the direction of arrow while
lifting with a finger to give a sufficient tension to the tension
side of timing belt. In this condition, tighten bolt to secure
tensioner “B”. When the bolt is tightened, use care to
prevent shaft from turning together. If shaft is turned
together, belt will be overtensioned.
(5) Check to ensure that timing marks on sprockets and front
case are in alignment.
(6) Press with index finger the center of span on the tension
side of timing belt “B”. The bolt must deflect 5 – 7 mm.
HCRANKSHAFT BOLT TIGHTENING
(1) Using the special tool, hold the flywheel or drive plate.
(2) Install the crankshaft pulley in position.
Timing
marks
Timing
marks
(on front
case)

ENGINE – Timing Belt11-21
IOIL PUMP SPROCKET INSTALLATION
(1) Insert a Phillips screwdriver (shank diameter 8 mm shaft)
through the plug hole on the left side of the cylinder
block to block the left counterbalance shaft.
(2) Install the oil pump sprocket.
(3) Apply a proper amount of engine oil to the bearing surfaces
of the nuts.
(4) Tighten the nuts to the specified torque.
JAUTO TENSIONER INSTALLATION
(1) If the auto tensioner rod is in its fully extended position,
reset it as follows.
(2) Clamp the auto-tensioner in the vise with soft jaws.
(3) Push in the rod little by little with the vise until the set
hole A in the rod is aligned with the hole B in the cylinder.
(4) Insert a wire (1.4 mm in diameter) into the set holes.
(5) Unclamp the auto tensioner from the vise.
(6) Install the auto tensioner to front case and tighten to
the specified torque.
Caution
Leave the wire installed in the auto tensioner.
KTENSIONER PULLEY INSTALLATION
Install the tensioner pulley in such direction that its two small
holes are arranged vertically.
6EN0564
A
B
6EN1323
Small holes

ENGINE – Timing Belt11-22
LTIMING BELT INSTALLATION
(1) Place the exhaust side camshaft sprocket in a position
where its timing mark is one tooth offset from the timing
mark on the rocker cover in the counterclockwise direction.
NOTE
Even if the timing marks on the sprocket and the rocker
cover are brought into alignment, the exhaust camshaft
is forced back by the valve spring tension. It is stabilized
at a position one tooth before the timing mark.
(2) Align the timing mark on the intake side camshaft sprocket
with that on the rocker cover.
NOTE
Even if the timing marks on the sprocket and the cover
are brought into alignment, the intake camshaft is forced
to turn one tooth in the clockwise direction by the valve
spring tension and stabilized there.
(3) Place the timing mark on the crankshaft sprocket one
tooth this side from the mated timing mark as in the case
of the camshaft sprocket.
(4) Align the timing mark on oil pump sprocket with its mating
mark.
(5) Remove the plug on cylinder block and insert a Phillips
screwdriver (shank diameter 8 mm) through the hole
(Engine with counterbalance shafts).
If it can be inserted as deep as 60 mm or more, the
timing marks are correctly aligned. If the inserted depth
is only 20 – 25 mm, turn the oil pump sprocket one turn
and realign timing marks. Then check to ensure that the
screwdriver can be inserted 60 mm or more. Keep the
screwdriver inserted until installation of timing belt is
finished.
Timing mark
Timing mark
6EN1327
Oil pump
sprocket
timing marks
Screwdriver
6EN1026
Plug

ENGINE – Timing Belt11-23
(6) Remove the Phillips screwdriver. Place the oil pump
sprocket in a position where its timing mark is one tooth
offset from the mated timing mark in the counterclockwise
direction.
(7) Fit the timing belt over the exhaust side camshaft sprocket,
and secure it at the illustrated position using a paper
clip.
(8) Turn the intake side camshaft sprocket as shown to a
position where its timing mark is one tooth offset from
the mated timing mark in the counterclockwise direction.
Then, fit the timing belt over the sprocket and secure
it with a paper clip.
NOTE
The intake camshaft will be turned a little clockwise by
the valve spring tension and stabilized in position even
if the belt is clipped at one tooth offset position.
(9) Check to ensure that the timing marks on the intake
camshaft sprocket side are in alignment when the exhaust
camshaft sprocket is turned clockwise to align the timing
marks.
NOTE
The timing belt span between the intake and exhaust
sprockets will have 17 cogs.
(10)Fit the timing belt over the idler pulley, oil pump sprocket
and crankshaft sprocket in this order.
NOTE
Be careful that the belt does not become slack.
Timing mark
6EN1327
Timing mark
Crankshaft
sprocketOil pump
sprocket
